Features
|
Screen
|
FALSE
|
|
Weight
|
-
|
|
AWG size
|
Other
|
|
Drain wire
|
FALSE
|
|
Cable geometry
|
Round
|
|
Number of cores
|
3
|
|
Strand diameter
|
-
|
|
Conductor surface
|
Other
|
|
Nominal voltage U
|
250 V
|
|
Stranding element
|
Triple
|
|
Torsion resistant
|
TRUE
|
|
Conductor category
|
Class 1 = solid
|
|
Conductor material
|
Copper
|
|
Material armouring
|
Copper
|
|
Nominal voltage U0
|
250 V
|
|
Protective barrier
|
Rubber - ethylene propylene rubber (EPR)
|
|
Shape of conductor
|
Round
|
|
Suspension element
|
Other
|
|
Cable width approx.
|
1500 mm
|
|
Colour outer sheath
|
Black
|
|
Core identification
|
Colour
|
|
Cable height approx.
|
-
|
|
Material outer sheath
|
Other
|
|
Screen over stranding
|
None
|
|
Outer diameter approx.
|
14 mm
|
|
Armouring/reinforcement
|
None
|
|
Material core insulation
|
Polyamide (PA)
|
|
With protective conductor
|
TRUE
|
|
Max. conductor temperature
|
65 °C
|
|
Number of stranding elements
|
-
|
|
Screen over stranding element
|
None
|
|
Specification core insulation
|
Polyethylene (PE)
|
|
Conductor resistance at 20 °C
|
-
|
|
Nominal cross section conductor
|
1.5 mm²
|
|
Number of strands per conductor
|
-
|
|
Number of pilot/reduced conductors
|
-
|
|
Specification material outer sheath
|
Polyethylene (PE)
|
|
Low smoke according to EN IEC 61034-2
|
TRUE
|
|
Nominal cross section conductor (AWG)
|
10 kcmil
|
|
Halogen free according to EN IEC 60754-1
|
TRUE
|
|
Halogen free according to EN IEC 60754-2
|
TRUE
|
|
Halogen free according to EN IEC 60754-3
|
TRUE
|
|
Max. tensile strength during installation
|
-
|
|
Core identification according to HD 308 S2
|
FALSE
|
|
Flame retardant according to IEC 60332-1-2
|
TRUE
|
|
Oil resistant according to EN IEC 60811-404
|
TRUE
|
|
Nominal cross section pilot/reduced conductors
|
-
|
|
Reaction-to-fire according to EN 13501-6: Class
|
Eca
|
|
Reaction-to-fire according to EN 13501-6: Acidity
|
a1
|
|
Flame retardant according to IEC 60332-3-22 (Cat A)
|
FALSE
|
|
Flame retardant according to IEC 60332-3-23 (Cat B)
|
TRUE
|
|
Flame retardant according to IEC 60332-3-24 (Cat C)
|
TRUE
|
|
Flame retardant according to IEC 60332-3-25 (Cat D)
|
TRUE
|
|
Nominal cross section pilot/reduced conductors (AWG)
|
-
|
|
Flame retardant according to IEC 60332-3-21 (Cat A F/R)
|
TRUE
|
|
Reaction-to-fire according to EN 13501-6: Smoke production
|
s2
|
|
Low temperature resistant according to EN 60811-504+505+506
|
TRUE
|
|
Permitted cable outer temperature during assembling/handling
|
|
|
Min. permitted bending radius, moving application/free movement
|
-
|
|
Permitted cable outer temperature after assembling without vibration
|
|
|
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles
|
d0
|
|
Min. permitted bending radius, moving application with forced guidance
|
-
|
|
Min. permitted bending radius, stationary application/permanent installation
|
-
|
