2-conductor disconnect terminal block for DIN-rail 35 x 15 and 35 x 7.5 4 mm² gray
Wago

2-conductor disconnect terminal block for DIN-rail 35 x 15 and 35 x 7.5 4 mm² gray

2-conductor disconnect terminal block; for DIN-rail 35 x 15 and 35 x 7.5; 4 mm²; CAGE CLAMP®; 4,00 mm²; gray

Product identifiers

SKU: 281-624
EAN: 4045454871604
GTIN: 4045454871604
MPN: 281-624

Voltimum+ Loyalty Programme Loyalty points: 6 (x50)

Price: £ 4.66 Excl. VAT

Categories

Terminals, Connectors & Interconnects Terminal Blocks

Specifications

Depth 60
Width 8
Colour Grey
Height 60
EFNA0008 V0
Rated voltage 800
Mounting method DIN rail (top hat rail) 35 mm
Number of levels 1
Type of slitting None
Closing plate required yes
Internally connected stages no
With integrated test socket no
Type of electrical connection 2 Spring clamp connection
Connectable conductor cross section solid-core 0.08 - 4
Connectable conductor cross section fine-strand with cable end sleeve 0.25 - 2.5

Documents
