Current transformer

Name: Current transformer
Brand: ABB
SKU: 2CSG226045R1101
Availability: InStock

CT MAX 800 SELV is used to transform primary currents to../5A secondary currents for c.a. measurement instruments

Product identifiers

SKU: 2CSG226045R1101

EAN: 8012542260455

GTIN: 8012542260455

MPN: CT MAX 800 SELV

Price: £ 35.35 Excl. VAT

Specifications

Model	Through-feed current converter
Calibrated	yes
Snap mounting	no
Width opening
Accuracy class	0.5
Height opening
Opening diameter	-
With copper rail	no
Power consumption	-
Secondary connection	Screw connection
Rated primary current	800
Rated secondary current	5
With contact protection	yes
Number of primary inputs	1
Overcurrent limiting factor	FS 5
Rated secondary apparent power	100
