Red Ø30 mushroom pushbutton head Ø22 spring return

Link copied

SKU
EAN
GTIN
MPN

Red Ø30 mushroom pushbutton head Ø22 spring return by Schneider Electric is listed by 6 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, Control Components Anglia, Farnell and 3 more. It is currently in stock at 4 of them. Trade prices range from £10.67 to £17.12 excl. VAT. Voltimum+ members earn 2 points per unit.

This 30mm mushroom shaped red push button head is ideal when quick actions are required. It fits for a process or machine to function correctly or where operator movements require highest ergonomy. It is easily combined with Harmony range of contact blocks to perform a large variety of control functions. It is clearly distinguishable visually at a distance thanks to a prominent 30mm mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.

Loyalty points: 2

Price range: £ 10.67 - £ 17.12 Excl. VAT

ETIM group

Low-voltage industrial components

Specifications

Diameter cap	30 mm
Colour button	Red
Hole diameter	22.5 mm
Spring-return	yes
Width opening	-
With lighting	no
Height opening	-
Type of button	High
With front ring	yes
Unlocking method	None
Colour front ring	Black
Material front ring	Plastic
Supply voltage lamp	-
Suitable for lighting	no
Construction type lens	Round
Degree of protection (IP)	IP66
Degree of protection (NEMA)	Other
Suitable for emergency stop	no
Switching function latching	no
