Miniature Circuit Breaker - SU200M - 3P - 63 A - K - (400 V AC) 11.2 kA

Name: Miniature Circuit Breaker - SU200M - 3P - 63 A - K - (400 V AC) 11.2 kA
Brand: ABB
SKU: 2CDS273337R0607
Availability: InStock

Miniature Circuit Breaker - SU200M - 3P - 63 A - K - (400 V AC) 11.2 kA by ABB is listed by 1 electrical wholesaler on Voltimum UK, including Control Components Anglia. Trade price £316.68 excl. VAT. Voltimum+ members earn 139 points per unit.

SU203M-K63 Miniature Circuit Breaker K-Char., UL10kA, IEC15kA, 63A, 3P UL489

Product identifiers

SKU: 2CDS273337R0607

EAN: 4016779930475

GTIN: 4016779930475

MPN: SU203M-K63

Loyalty points: 139

Price: £ 316.68 Excl. VAT

Specifications

Frequency
Power loss	16.2
Voltage type	AC/DC
Rated current	63
Rated voltage	400
Built-in depth	69
Explosion-proof	no
Pollution degree	3
Over voltage category	3
Current limiting class	3
Release characteristic	K
Number of poles (total)	3
Degree of protection (IP)	IP20
Number of protected poles	3
Flush-mounted installation	no
Rated insulation voltage Ui	440
Additional equipment possible	yes
Width in number of modular spacings	3
Ambient temperature during operating
Rated impulse withstand voltage Uimp	4
Concurrently switching neutral conductor	no
Connectable conductor cross section solid-core
Connectable conductor cross section multi-wired
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	-
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	-
