Thermal magnetic circuit breaker, TeSys GB2, 1P, 3 A, Icu 3 kA@240 V
Schneider Electric

Thermal magnetic circuit breaker, TeSys GB2, 1P, 3 A, Icu 3 kA@240 V

TeSys GB circuit breaker, 1 pole (1P), 3A/250V IEC/277V UL, for the protection of industrial equipment control circuits. It provides thermal-magnetic protection with a magnetic tripping level at 40A (13 In) and breaking capacity Icu 3kA@240V. It can also be used for protection of DC loads up to 3A/48V DC-13 with a breaking capacity Icu 1.5kA@24V. Compact device (15mm wide), mounting on 35mm DIN-rail, control by toggle lever (start-stop guaranteed for 8000 cycles). Sold in lots of 6 units. Multi standards certified (IEC, UL, CSA).

Product identifiers

SKU: GB2CB08
EAN: 3389110214628
GTIN: 3389110214628
MPN: GB2CB08

Voltimum+ Loyalty Programme Loyalty points: 3

Price range: £ 17.53 - £ 35.33 Excl. VAT

Categories

MCBs Circuit Breakers Switchgear & Circuit Protection

Specifications

Frequency
Power loss -
Voltage type AC
Rated current 3 A
Rated voltage 250 V
Built-in depth 74 mm
Explosion-proof no
Pollution degree 2
Current limiting class 3
Number of poles (total) 1
Number of protected poles 1
Rated insulation voltage Ui 250 V
Width in number of modular spacings 1
Rated impulse withstand voltage Uimp 4 kV
Connectable conductor cross section solid-core
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V -
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V 3 kA
