Wago

Potential Distribution 8-way 24 V light gray

Potential Distribution; 8-way 24 V

Product identifiers

SKU: 753-603
EAN: 4050821867616
GTIN: 4050821867616
MPN: 753-603

Voltimum+ Loyalty Programme Loyalty points: 1

Price: £ 20.86 Excl. VAT

Categories

Building Controls & Automation PLCs

ETIM group

Programmable logic controllers PLC

Specifications

Depth 69.8
Width 12
Height 100
Remote module no
System accessory yes
Supply voltage DC 24 - 24
Radio standard GSM no
Radio standard GPRS no
Bus diagnosis possible no
With optical interface no
Supply voltage AC 50 Hz
Radio standard Bluetooth no
Degree of protection (IP) IP20
Radio standard WLAN 802.11 no
Suitable as segment module yes
Number of HW-interfaces USB 0
Supporting protocol for CAN no
Supporting protocol for LON no
Number of HW-interfaces other 0
Suitable for safety functions no
Wall mounting/direct mounting no
Number of HW-interfaces RS-422 0
Supporting protocol for Modbus no
Supporting protocol for TCP/IP no
Number of HW-interfaces parallel 0
Supporting protocol for EtherCAT no
Supporting protocol for PROFIBUS no
Appendant operation agent (Ex ib) no
Supporting protocol for DeviceNet no
Explosion safety category for dust ATEX dust-ex-protection, Cat. 3D
Supporting protocol for EtherNet/IP no
Supporting protocol for SafetyBUS p no
Supporting protocol for PROFINET CBA no
Supporting protocol for DeviceNet Safety no
Certified for UL hazardous location class I yes
Supporting protocol for Foundation Fieldbus no
Certified for UL hazardous location class III no
Certified for UL hazardous location division 1 yes
Supporting protocol for AS-Interface Safety at Work no
Certified for UL hazardous location group B (hydrogen) yes
Fieldbus connection over separate bus coupler possible yes
Certified for UL hazardous location group E (metal dusts) no
Certified for UL hazardous location group G (non-conductive dusts) no
