Schneider Electric

Complete potentiometer, metal, Ø22, 47K

Link copied
SKU
EAN
GTIN
MPN

Complete potentiometer, metal, Ø22, 47K by Schneider Electric is listed by 3 electrical wholesalers on Voltimum UK, including Control Components Anglia, Farnell and RS Components. It is currently in stock at 1 of them. Trade prices range from £86.81 to £87.68 excl. VAT. Voltimum+ members earn 11 points per unit.

This Harmony XB4 potentiometer has a resistance of 47kΩ. It has a metal bezel. This potentiometer provides an external interface for controlling key parameters of automation components like drives and inverters. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 IP69 IP69K, making it ideal for operation in harsh environments. It is ideal for analog control (like speed control of motor) via the voltage or resistor input of variable speed drives.

Voltimum+ Loyalty Programme Loyalty points: 11

Price range: £ 86.81 - £ 87.68 Excl. VAT

Categories

Electronic Components Resistors

ETIM group

Low-voltage industrial components

Specifications

Resistance 47000 Ohm
Hole diameter 22.5 mm
Power consumption 1 W
Number of revolutions
Degree of protection (IP) IP66
Degree of protection (NEMA) 4X
Type of electric connection Other

Documents

Declaration of Conformity (Sustainability)

XB4BD912R47K REACh Regulation

Open

Instruction sheet

XB4-XB5 - Mounting, Instruction Sheet

Open

Product data sheet

Open

Catalog

Discover the Harmony XB4 metal Control and signaling units catalog

Open

Declaration of Conformity (Sustainability)

XB4BD912R47K EU RoHS Directive

Open

Declaration of conformity

XB4B, XB5A/D/E/K, Control and signaling units, XD4P, XD5P Joystick Controllers

Open

Environmental Disclosure

Harmony Metal Potentiometer, Product Environmental Profile

Open

Circularity Profile

Harmony Metal Potentiometer, End of Life Instructions

Open
