"One entry cable gland plate, PanelSeT SFN, PanelSet SF, for electrical enclosure W1200 D500mm, fixed by clips"

Name: "One entry cable gland plate, PanelSeT SFN, PanelSet SF, for electrical enclosure W1200 D500mm, fixed by clips"
Brand: Schneider Electric
SKU: NSYEC1251
Price: 58.00 GBP
Availability: InStock

"One entry cable gland plate, PanelSeT SFN, PanelSet SF, for electrical enclosure W1200 D500mm, fixed by clips" by Schneider Electric is listed by 1 electrical wholesaler on Voltimum UK, including Control Components Anglia. Voltimum+ members earn 10 points per unit.

This is a multi-purpose 1-entry cable gland plate for PanelSeT SFN and PanelSeT SF electrical enclosures. The product is made of galvanised steel. It is suitable for enclosures with nominal width and depth of 1200 and 500 mm respectively. The set contains one plate with 1-entry, polyurethane adhesive gasket with cross-section of 15 x 25 mm and fixing elements. The cable gland plate is to be mounted on enclosure bottom.

Product identifiers

SKU: NSYEC1251

EAN: 3606485126371

GTIN: 3606485126371

MPN: NSYEC1251

Loyalty points: 10

Price: £ 58.00 Excl. VAT

Specifications

Type	Straight
Model	Other
Width	1200 mm
Height	30 mm
EFSE0006	-
Material	Steel
Thickness	1.5 mm
Thread type	None
Pre-stamping	yes
Surface protection	Galvanised
Number of connector holes	0
Degree of protection (NEMA)	Other
Suitable for cable diameter
Suitable for nominal thread metric/PG
