Network Option Switch
This product is part of the Modicon X80 range, a common platform of modules for Modicon M580 and M340 Programmable Automation Controllers (PAC). This network option switch has 3 ports. It is a network option switch with a rated supply voltage of 24V and a power consumption of 4.5W. This product is robust, high quality and based on the latest innovative technology. Integrated connections are EtherNet/IP for device network and service port. It is an IP20 rated product. It is suitable for medium to large process applications. This product is certified by CE, ABS, BV, GL, EAC, LR, DNV, RINA. It meets EN 61131-2, EN 61000-6-4, EN 61000-6-2 and EN 61010-2-201 standards. This switch module is compatible with BMEXBP backplane. Modicon X80 consists in a compatible modules common platform that reduce maintenance and training costs with same spare parts in stock, and unique training for different Programmable Automation Controllers (PAC).
Product identifiers
SKU: BMENOS0300
EAN: 3606480800061
GTIN: 3606480800061
MPN: BMENOS0300
Loyalty points:
229
Price range: £ 572.94 - £ 636.60 Excl. VAT
Categories
Features
|
Depth
|
101.5 mm
|
|
Width
|
32 mm
|
|
Height
|
100 mm
|
|
Layer 2
|
FALSE
|
|
Layer 3
|
FALSE
|
|
EFFR0001
|
FALSE
|
|
EFFR0002
|
FALSE
|
|
Ethernet
|
TRUE
|
|
Manageable
|
TRUE
|
|
Max. PoE power
|
-
|
|
Mounting method
|
Other
|
|
Number of ports PoE
|
0
|
|
Number of other ports
|
0
|
|
Number of module slots
|
0
|
|
Degree of protection (IP)
|
IP20
|
|
Power over Ethernet (PoE)
|
Other
|
|
Number of ports 100 Mbps SC
|
0
|
|
Number of ports 100 Mbps ST
|
0
|
|
Number of ports 10 Gbps RJ45
|
0
|
|
Number of ports 100 Mbps POF
|
0
|
|
Number of ports 1000 Mbps POF
|
0
|
|
Number of ports 1000 Mbps GBIC
|
0
|
|
Number of ports 1000 Mbps RJ45
|
0
|
|
Number of ports 10/100 Mbps M12
|
0
|
|
Number of ports 10/100 Mbps RJ45
|
3
|
|
Number of max. stackable switches
|
0
|
|
Number of ports 10 Gbps Mini GBIC
|
0
|
|
Number of ports 1000 Mbps SC (LX)
|
0
|
|
Number of ports 1000 Mbps SC (SX)
|
0
|
|
Number of ports 40 Gbps Mini GBIC
|
0
|
|
Number of ports 100 Gbps Mini GBIC
|
0
|
|
Number of ports 1000 Mbps Mini GBIC
|
0
|
|
Number of ports 10/100/1000 Mbps RJ45
|
0
|
|
Number of ports 100/1000 Mbps Mini GBIC
|
0
|
|
Number of combination-ports RJ45/Mini GBIC
|
0
|
