| Width |
595 mm |
| Length |
1195 mm |
| EFNL0014 |
no |
| Lamp type |
LED not exchangeable |
| Beam angle |
Open beam/diffuse |
| Dimming RF |
no |
| Dimming DMX |
no |
| Dimming DSI |
no |
| Lamp holder |
Other |
| Dimming DALI |
no |
| Height/depth |
59 mm |
| Light outlet |
Direct |
| Power factor |
0.9 |
| Type of grid |
None |
| Voltage type |
AC |
| Built-in width |
595 mm |
| Dimming 0-10 V |
no |
| Dimming 1-10 V |
no |
| Dimming DALI-2 |
no |
| Dimming Zigbee |
no |
| Housing colour |
White |
| Material cover |
Plastic, opal |
| Outer diameter |
- |
| Type of wiring |
Ending |
| With air slots |
no |
| Built-in length |
1195 mm |
| Colour of light |
White |
| Connection type |
Other |
| Impact strength |
IK02 |
| No dim function |
yes |
| Nominal current |
260 - 260 mA |
| Nominal voltage |
220 - 240 V |
| Number of poles |
2 |
| Housing material |
Steel |
| Built-in diameter |
- |
| Light distributor |
Diffuser lens/optic/panel |
| Max. system power |
50 W |
| With control gear |
yes |
| With light sensor |
no |
| With light source |
yes |
| Colour temperature |
4000 - 4000 K |
| Dimming LineSwitch |
no |
| Light distribution |
Symmetric |
| Luminaire efficacy |
120 |
| Luminous intensity |
- |
| Dimming programmable |
no |
| Type of control gear |
LED operating device current-controlled |
| With movement sensor |
no |
| Beam angle adjustable |
No |
| Built-in height/depth |
120 mm |
| Dimming Touch and Dim |
no |
| Operation by Bluetooth |
no |
| Compatible with Casambi |
no |
| Conductor cross section |
0.75 mm² |
| Flickering value Pst LM |
1 |
| IFTTT support available |
no |
| Suitable for lamp power |
50 - 50 W |
| Dimming with push-button |
no |
| Luminous flux adjustable |
No |
| Degree of protection (IP) |
IP20 |
| Exchangeable control gear |
no |
| Total harmonic distortion |
20 |
| Unified Glare Ratio (UGR) |
23 |
| Colour of light adjustable |
No |
| Colour rendering index CRI |
80-89 |
| Suitable for wall mounting |
no |
| Surface protection housing |
Powder coating |
| Constant light output (CLO) |
no |
| Degree of protection (NEMA) |
- |
| Dimming Sine Wave Reduction |
no |
| Compatible with Amazon Alexa |
no |
| Stroboscope effect value SVM |
0.4 |
| Compatible with Apple HomeKit |
no |
| Suitable for ceiling mounting |
yes |
| Suitable for surface mounting |
yes |
| Suitable for built-in mounting |
yes |
| Suitable for emergency lighting |
no |
| Suitable for suspended mounting |
yes |
| Compatible with Google Assistant |
no |
| Dimming mains voltage modulation |
no |
| Emergency power supply integrated |
no |
| Rated life time L70/B50 at 25 °C |
30000 h |
| Dimming potentiometer (integrated) |
no |
| Colour consistency (McAdam ellipse) |
SDCM5 |
| Dimming phase cut-on (leading edge) |
no |
| Suitable for number of light sources |
- |
| Dimming phase cut-off (trailing edge) |
no |
| Suitable for light line configuration |
no |
| Protection class according to IEC 61140 |
II |
| Dimming manufacturer's proprietary system |
no |
| Filament test according to IEC 60695-2-11 |
650 °C - 30 s |
| Photobiological safety according to EN 62471 |
RG0 |
| Rated luminous flux according to IEC 62722-2-1 |
6000 |
| Suitable for workplace according to EN 12464-1 |
no |
| Rated ambient temperature according to IEC 62722-2-1 |
25 - 25 °C |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) |
12 |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) |
19 |
| Covering of the luminaire with thermally insulating material possible |
no |
| Failure rate at median useful life of 35,000 h at 25 °C ambient (tq) |
7.5 % |
| Failure rate at median useful life of 50,000 h at 25 °C ambient (tq) |
- |
| Failure rate at median useful life of 75,000 h at 25 °C ambient (tq) |
- |
| Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq) |
70 % |
| Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq) |
- |
| Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq) |
- |
| Energy efficiency class of the light source according to EU regulation 2019/2015 |
D |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 |
no |
