Solid-state relay module Nominal input voltage: 24 VDC Output voltage range: 3 … 30 VDC gray
Solid-state relay module; Nominal input voltage: 24 VDC; Output voltage range: 3 … 30 VDC; Limiting continuous current: 5 A; 2-wire connection; Red status indicator; Module width: 15 mm; gray
Product identifiers
SKU: 788-701
EAN: 4045454743871
GTIN: 4045454743871
MPN: 788-701
Loyalty points:
63
Price: £ 31.60 Excl. VAT
Categories
ETIM Group
Specifications
| Input voltage | 15 - 30 |
| Output voltage | |
| With LED indication | yes |
| Type of digital output | Electronic |
| Type of output voltage | DC |
| Rated operation current Ie | 5 |
| Type of voltage (input voltage) | DC |
