Linergy FT - Comb busbar - 63 A - 3 tap-offs - 45 mm pitch
Linergy FT - Comb busbar - 63 A - 3 tap-offs - 45 mm pitch by Schneider Electric is listed by 7 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, Control Components Anglia, Farnell and 4 more. It is currently in stock at 6 of them. Trade prices range from £8.03 to £16.48 excl. VAT. Voltimum+ members earn 2 points per unit.
TeSys GV busbar set, 3 phases, 63A/690V, for the upstream parallel wiring of groups of motor starters composed of GV2 motor circuit breakers or LS1D32 fuse carriers. For use with screw clamp terminal devices, it is composed of 3 tap-off outlets for the paralleling of 3 devices with a pitch of 45mm. The use of a terminal block GV1G09 or GV2G05 is recommended to supply the busbar sets (to be ordered separately). Green Premium compliant (RoHS/REACh).
Product identifiers
SKU: GV2G345
EAN: 3389110556438
GTIN: 3389110556438
MPN: GV2G345
Loyalty points:
2
Price range: £ 8.03 - £ 16.48 Excl. VAT
Categories
ETIM group
Specifications
| Colour | Black |
| Length | 135 mm |
| Insulated | yes |
| Module width | 45 mm |
| Cross section | - |
| Number of poles | 3 |
| Number of phases | 3 |
| Rated surge voltage | 6 kV |
