4-conductor sensor terminal block LED (red) for PNP-(high-side) switching sensors gray
Wago

4-conductor sensor terminal block LED (red) for PNP-(high-side) switching sensors gray

4-conductor sensor terminal block; LED (red); for PNP-(high-side) switching sensors; 2.5 mm²; CAGE CLAMP®; 2,50 mm²; gray

Product identifiers

SKU: 270-570/281-434
EAN: 4050821283263
GTIN: 4050821283263
MPN: 270-570/281-434

Voltimum+ Loyalty Programme Loyalty points: 8 (x50)

Price: £ 414.50 Excl. VAT

Categories

Terminals, Connectors & Interconnects Terminal Blocks

Specifications

Depth 39
Width 5
Colour Grey
Height 83
Rated voltage 24
Mounting method DIN rail (top hat rail) 35 mm
Number of levels 4
Rated current In -
LED switching for PNP
Colour light source Red
Operating temperature 105 - 105
With shield connection no
With power supply function no
Explosion-tested version 'Ex e' no
Type of electrical connection 2 Spring clamp connection
Connectable conductor cross section solid-core 0.08 - 2.5
Inflammability class of insulation material according to UL94 -
Connectable conductor cross section fine-strand without cable end sleeve 0.08 - 2.5
