Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X

Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X – Image 2 of 7

Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X – Image 3 of 7

Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X – Image 4 of 7

Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X – Image 5 of 7

Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X – Image 6 of 7

Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X – Image 7 of 7

1 / 7

Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X

Name: Surge protection device, Surgelogic, 40kA, 600Y/347 VAC, 3 phase, 4 wire, NEMA 4X
Brand: Schneider Electric
SKU: SDSA3650
Price: 287.00 GBP
Availability: OutOfStock

"Square D™ brand Surgelogic™ SDSA 3-Phase SPDs, SDSA3650, brings down initial surges to manageable levels and can offer additional value in a cascaded SPD system." "Equipped with LED status signal light for convenient use." "Suitable for applications in low voltage systems, building and industrial automation and control also for critical power, cooling and racks." "Complies with requirements of NEC® Article 285, CSA 233.1-87, and CSA C22.2 No. 8- M1986 as appropriate."

Product identifiers

SKU: SDSA3650

EAN: 785901210887

GTIN: 785901210887

MPN: SDSA3650

Loyalty points: 48

Price: £ 287.00 Excl. VAT

Specifications

Category type 2	-
Max. PV-voltage	-
Mounting method	Module
Construction size	-
Nominal voltage AC	600 V
Nominal voltage DC	-
Integrated backup fuse	no
System configuration DC	no
System configuration IT	no
System configuration TN	-
System configuration TT	-
Signalling at the device	None
Voltage protection level	-
Degree of protection (IP)	-
System configuration TN-C	-
System configuration TN-S	-
Max. continuous voltage AC	600 V
Max. continuous voltage DC	-
System configuration other	-
System configuration TN-C-S	-
Voltage protection level L-N	-
Voltage protection level N-PE	-
With remote signalling contact	no
Max. discharge surge current (8/20)	40 kA
Nominal discharge surge current (8/20)	40 kA
Number of conductors (without earthing)	0
Short-circuit breaking capacity (Isccr)	200 kA
Max. conductor cross section flexible (fine-strand)	-
Max. conductor cross section solid (solid, stranded)	-
