"PanelSet SFHD outdoor heavy duty - aluminium cable gland plate - W400 D230"

Name: "PanelSet SFHD outdoor heavy duty - aluminium cable gland plate - W400 D230"
Brand: Schneider Electric
SKU: NSYSFECA64HD
Price: 87.00 GBP
Availability: InStock

"PanelSet SFHD outdoor heavy duty - aluminium cable gland plate - W400 D230" by Schneider Electric is listed by 1 electrical wholesaler on Voltimum UK, including Control Components Anglia. Voltimum+ members earn 15 points per unit.

Multi-purpose plain aluminium outdoor heavy duty application cable gland plate for PanelSeT SFHD enclosures The enclosure nominal width is 1200mm, 600mm or 800mm The product is made of aluminium The plate is 2mm thick The nominal width is 400mm and real width is 610mm The height is 60mm The nominal depth is 230mm The set contains fixing elements, 1 plate and gasket The cable gland plate is to be mounted on enclosure bottom Anti-corrosion protection is ensured by an brushed finish coating

Product identifiers

SKU: NSYSFECA64HD

EAN: 3606480681288

GTIN: 3606480681288

MPN: NSYSFECA64HD

Loyalty points: 15

Price: £ 87.00 Excl. VAT

Specifications

Type	Straight
Model	Cable screw gland
Width	610 mm
Height	60 mm
EFSE0006	-
Material	Aluminium
Thickness	2 mm
Thread type	None
Pre-stamping	no
Surface protection	Untreated
Number of connector holes	0
Degree of protection (NEMA)	Other
Suitable for cable diameter
Suitable for nominal thread metric/PG
