| Depth |
260 mm |
| Width |
850 mm |
| Colour |
White |
| Height |
1493 mm |
| Lockable |
yes |
| Protection |
Miniature-/earth leakage circuit breaker |
| RAL-number |
9001 |
| With meter |
- |
| Cooker group |
- |
| Built-in depth |
|
| Built-in width |
- |
| Number of rows |
- |
| Built-in height |
- |
| Mounting method |
Other |
| Type of closure |
Cylinder |
| Housing material |
Steel |
| Number of phases |
3 |
| Type of covering |
Cover |
| Power consumption |
- |
| Suitable for data |
yes |
| Extension possible |
yes |
| With socket outlet |
yes |
| Protection dual RCD |
no |
| Protection split load |
no |
| With bell transformer |
no |
| Number of light groups |
- |
| Protection main switch |
yes |
| Release characteristic |
- |
| Total number of groups |
12 |
| With transparent cover |
no |
| Number of direct groups |
- |
| Number of outgoing ways |
12 |
| Over voltage protection |
no |
| Protection incoming RCD |
no |
| Degree of protection (IP) |
IP3X |
| Main switch rated current |
630 A |
| Protection high integrity |
no |
| Number of poles main switch |
4 |
| Width in number of modular spacings |
36 |
| Number of earth leakage switches 30 mA |
- |
| Type of over voltage protection device |
- |
| Number of earth leakage switches 300 mA |
- |
| Number of earth leakage circuit breakers |
- |
| Number of arc fault detection devices AFDD |
- |
| Cooker group suitable as power current group |
- |
| Number of groups behind earth leakage switch |
- |
| Number of three-phase miniature circuit breakers (MCB) |
12 |
| Number of single-phase miniature circuit breakers (MCB) |
36 |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V |
36 kA |
