Circuit breaker basic frame, ComPacT NSX100F, 36 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 3 poles

Link copied
SKU
EAN
GTIN
MPN

Circuit breaker basic frame, ComPacT NSX100F, 36 kA at 415 VAC 50/60 Hz, 100 A, without trip unit, 3 poles by Schneider Electric is listed by 5 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, RS Components, Rexel Group and 2 more. It is currently in stock at all of them. Trade prices range from £149.63 to £227.77 excl. VAT. Voltimum+ members earn 26 points per unit.

This is a 3 poles basic frame for ComPacT NSX100F. ComPacT NSX is designed to optimize space and breaking capacity for all standard and specific applications. This basic frame comes without trip unit, and is compatible with any type of trip unit ordered separately. The breaking capacity Icu is 36kA at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz (limited to 440VAC 50/60Hz if there is an earth-leakage protection). It can be equipped with a variety of optional functions and accessories. The dimensions are 105mm x 161mm x 86mm. It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX100F is part of Schneider Electric EcoStruxure Power architecture.

Voltimum+ Loyalty Programme Loyalty points: 26

Price range: £ 149.63 - £ 227.77 Excl. VAT

Specifications

Power loss 14.1 W
Rated voltage
Number of poles 3
Device construction Built-in device fixed built-in technique
Motor drive optional yes
Motor drive integrated no
Type of control element Toggle
Degree of protection (IP) IP40
With switched-off indicator yes
Integrated earth fault protection no
With integrated under voltage release no
Suitable for DIN rail (top hat rail) mounting no
Position of connection for main current circuit Front side
Number of auxiliary contacts as change-over contact 0
Number of auxiliary contacts as normally closed contact 0
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz 36 kA
