| Depth |
158.5 mm |
| Width |
200 mm |
| Height |
312 mm |
| With fuse |
no |
| Release class |
- |
| With transformer |
no |
| Power consumption |
- |
| Type of motor starter |
Direct online starter (DOL) |
| External reset possible |
no |
| Degree of protection (IP) |
IP65 |
| Number of indicator lights |
0 |
| Rated operation current Ie |
40 A |
| Suitable for rail mounting |
no |
| Voltage type for actuating |
AC |
| With short-circuit release |
no |
| Degree of protection (NEMA) |
- |
| Number of command positions |
2 |
| Suitable for emergency stop |
no |
| Supporting protocol for ASI |
no |
| Supporting protocol for CAN |
no |
| Supporting protocol for LON |
no |
| Supporting protocol for Modbus |
no |
| Supporting protocol for SERCOS |
no |
| Supporting protocol for TCP/IP |
no |
| Rated control supply voltage DC |
|
| Supporting protocol for SUCONET |
no |
| Overload release current setting |
|
| Supporting protocol for INTERBUS |
no |
| Supporting protocol for PROFIBUS |
no |
| Supporting protocol for DeviceNet |
no |
| Supporting protocol for PROFIsafe |
no |
| Rated power, 460 V, 60 Hz, 3-phase |
22 kW |
| Rated power, 575 V, 60 Hz, 3-phase |
22 kW |
| Supporting protocol for EtherNet/IP |
no |
| Supporting protocol for PROFINET IO |
no |
| Supporting protocol for SafetyBUS p |
no |
| Rated operation power at AC-3, 400 V |
18.5 kW |
| Supporting protocol for Data-Highway |
no |
| Supporting protocol for PROFINET CBA |
no |
| Rated control supply voltage AC 50 Hz |
|
| Rated control supply voltage AC 60 Hz |
|
| Rated operation current at AC-3, 400 V |
40 A |
| Supporting protocol for INTERBUS-Safety |
no |
| Supporting protocol for DeviceNet Safety |
no |
| Supporting protocol for other bus systems |
no |
| Ambient temperature, upper operating limit |
40 °C |
| Supporting protocol for Foundation Fieldbus |
no |
| Temperature compensated overload protection |
- |
| Coordination class according to IEC 60947-4-3 |
- |
| Rated operation power at AC-3, 230 V, 3-phase |
11 kW |
| Type of electrical connection of main circuit |
Screw connection |
| Supporting protocol for AS-Interface Safety at Work |
no |
| Number of auxiliary contacts as normally open contact |
0 |
| Rated conditional short-circuit current, type 2, 230 V |
- |
| Rated conditional short-circuit current, type 2, 400 V |
- |
| Number of auxiliary contacts as normally closed contact |
0 |
| Rated conditional short-circuit current, type 1, 480 Y/277 V |
- |
| Rated conditional short-circuit current, type 1, 600 Y/347 V |
- |
| Type of electrical connection for auxiliary- and control current circuit |
Screw connection |
