LS33P31B11 Limit Switch
LS33P31B11 is a 30 mm wide, standard Limit Switch made of fiber-glass reinforced UL-V0 material, with 2 mounting holes at the top, 1 ISO M20x1.5 cable entry on the bottom, plastic roller lever (Ø12,5 mm) on steel plunger actuator for horizontal movement and 1 N.O + 1 N.C snap action (Zb type) contacts
Product identifiers
SKU: 1SBV012231R1211
EAN: 3471522006950
GTIN: 3471522006950
MPN: LS33P31B11
Loyalty points:
15
Price: £ 29.65 Excl. VAT
Categories
Features
|
Width sensor
|
30
|
|
Forced opening
|
no
|
|
Coating housing
|
Other
|
|
Diameter sensor
|
0
|
|
Height of sensor
|
92
|
|
Housing material
|
Plastic
|
|
Length of sensor
|
30
|
|
Output electronic
|
no
|
|
Type of interface
|
None
|
|
Switching function
|
Quick-break switch
|
|
With status indication
|
no
|
|
Type of control element
|
Plunger
|
|
Construction type housing
|
Cuboid
|
|
Degree of protection (IP)
|
IP65
|
|
Degree of protection (NEMA)
|
-
|
|
Switching function latching
|
no
|
|
Type of electric connection
|
Cable entry metrical
|
|
Suitable for safety functions
|
no
|
|
Alignment of the control element
|
Other
|
|
Explosion safety category for gas
|
None
|
|
Explosion safety category for dust
|
None
|
|
Number of safety auxiliary contacts
|
0
|
|
Ambient temperature during operating
|
|
|
Number of contacts as change-over contact
|
0
|
|
Rated operation current Ie at AC-15, 24 V
|
10
|
|
Rated operation current Ie at DC-13, 24 V
|
6
|
|
Rated operation current Ie at AC-15, 125 V
|
5.5
|
|
Rated operation current Ie at AC-15, 230 V
|
3.1
|
|
Rated operation current Ie at DC-13, 125 V
|
0.6
|
|
Rated operation current Ie at DC-13, 230 V
|
0.4
|
|
Type of interface for safety communication
|
None
|
|
Number of contacts as normally open contact
|
1
|
|
Number of contacts as normally closed contact
|
1
|
