Features
|
Depth
|
119 mm
|
|
Width
|
74 mm
|
|
Height
|
131 mm
|
|
EFI00008
|
-
|
|
EFI00040
|
-
|
|
EFI00049
|
-
|
|
EFI00332
|
-
|
|
EFI00846
|
-
|
|
Stabilized
|
yes
|
|
Power output
|
120 W
|
|
Built-in width
|
74 mm
|
|
Built-in height
|
131 mm
|
|
Modular version
|
no
|
|
Power consumption
|
135 VA
|
|
Short-circuit-proof
|
yes
|
|
Max. output current 1
|
-
|
|
Max. output current 2
|
|
|
Max. output current 3
|
|
|
Wall mounting possible
|
no
|
|
Rated supply voltage DC
|
480 - 820 V
|
|
Direct mounting possible
|
no
|
|
Degree of protection (IP)
|
IP20
|
|
Output voltage stabilized
|
yes
|
|
SIL according to IEC 61508
|
None
|
|
Suitable for rail mounting
|
yes
|
|
Degree of protection (NEMA)
|
1
|
|
Type of electric connection
|
Screw connection
|
|
1st secondary output voltage
|
24 - 24 V
|
|
2nd secondary output voltage
|
|
|
3rd secondary output voltage
|
|
|
Secondary voltage adjustable
|
no
|
|
Rated supply voltage AC 50 Hz
|
340 - 575 V
|
|
Rated supply voltage AC 60 Hz
|
340 - 575 V
|
|
Suitable for safety functions
|
no
|
|
Voltage type (supply voltage)
|
AC/DC
|
|
Nominal value output current 1
|
5 A
|
|
Nominal value output current 2
|
|
|
Nominal value output current 3
|
|
|
Nominal value output voltage 1
|
24 V
|
|
Nominal value output voltage 2
|
|
|
Nominal value output voltage 3
|
|
|
Width in number of modular spacings
|
-
|
|
Performance level according to EN ISO 13849-1
|
None
|
