12 way Metal Easy9 Consumer Unit

This Easy9 product is an empty consumer unit. It can be surface or flush mounted. Enclosure: can be modified to suit split and configuration on site Flexible split load configuration option: ensures mainstream applications can be catered for with a single consumer unit Rigid metal DIN rail: solid to avoid flexing and raised for cabling flexibility Secure busbar guard: requires tool for removal, ensuring more safety for you New MCB style blanking module: additional end user safety feature, requiring enclosure cover to be removed first The dimensions are (W) 392.8mm x (H) 276.8mm x (D) 119.55mm. The product weight is 5.85 kg. The color of the consumer unit is white (RAL 9003). The enclosure is made of metal. The degree of protection is IPXX D on top and IP3X with cover. According to IEC 62262 standard, the degree of protection is IK05. This consumer unit complies with BS 7671 amendment 3 and BS EN 61439-3 standards.
