ESB40-40N-14 Installation Contactor (NO) 40 A - 4 NO - 0 NC - 12 V - Control Circuit 400 Hz

Name: ESB40-40N-14 Installation Contactor (NO) 40 A - 4 NO - 0 NC - 12 V - Control Circuit 400 Hz
Brand: ABB
SKU: 1SAE341111R1440
Availability: InStock

ESB40-40N-14 Installation Contactor (NO) 40 A - 4 NO - 0 NC - 12 V - Control Circuit 400 Hz by ABB is listed by 1 electrical wholesaler on Voltimum UK, including RS Components, and currently in stock. Trade price £149.41 excl. VAT. Voltimum+ members earn 82 points per unit.

The ESB40..N installation contactors are used to control single and three-phase loads up to 40 A and can be operated by AC or DC. These contactors are made for use in household applications as well as in industrial environments. The following benefits are provided: Hum-free operation, low power consumption and integrated overvoltage protection. Various contact combinations and accessories are available.

Product identifiers

SKU: 1SAE341111R1440

EAN: 4013614518591

GTIN: 4013614518591

MPN: ESB40-40N-14

Loyalty points: 82

Price: £ 149.41 Excl. VAT

Specifications

Hum-free	yes
Built-in depth	58
Slider for hand switch	no
Rated operating voltage
Rated operation current	40
With day/night function	no
Rated excitation voltage
Degree of protection (IP)	IP20
Max. load fluorescent lamp	-
Max. incandescent lamp load	-
Additional equipment possible	yes
Voltage type (operating voltage)	AC/DC
Voltage type (excitation voltage)	AC/DC
Width in number of modular spacings	3
Max. load fluorescent lamp (Duo circuit)	-
Number of contacts as normally open contact	4
Number of contacts as normally closed contact	0
Max. load fluorescent lamp (parallel compensated)	-
Utilization category according to EN IEC 60947-4-1	AC-1
