| Built-in depth |
78 |
| IO link master |
no |
| With hard disc |
no |
| Screen diagonal |
15.6 |
| Type of display |
TFT |
| Max. main memory |
4096 |
| Supply voltage DC |
24 - 24 |
| With touch screen |
yes |
| Radio standard GSM |
no |
| Width of the front |
420 |
| With optical drive |
- |
| Height of the front |
283 |
| Integrated keyboard |
no |
| Radio standard GPRS |
no |
| Radio standard UMTS |
no |
| Operating temperature |
-20 - 55 |
| Rack-assembly possible |
yes |
| With floppy disc drive |
no |
| Front built-in possible |
yes |
| Supply voltage AC 50 Hz |
|
| Supply voltage AC 60 Hz |
|
| Number of free AGP-slots |
0 |
| Number of free ISA-slots |
0 |
| Number of free PCI-slots |
0 |
| Number of system buttons |
0 |
| Radio standard Bluetooth |
no |
| With other storage media |
yes |
| Mounting type, table foot |
no |
| Number of buttons with LED |
0 |
| Number of function buttons |
0 |
| Number of pixels, vertical |
- |
| Radio standard WLAN 802.11 |
no |
| Suitable for rail mounting |
no |
| Degree of protection (NEMA) |
- |
| Number of HW-interfaces PS2 |
0 |
| Number of HW-interfaces USB |
2 |
| Number of free PCMCIA-slots |
1 |
| Supporting protocol for ASI |
no |
| Supporting protocol for CAN |
no |
| Supporting protocol for KNX |
no |
| Supporting protocol for LON |
no |
| Number of HW-interfaces SCSI |
0 |
| Number of pixels, horizontal |
- |
| Number of HW-interfaces other |
1 |
| Number of interfaces PROFINET |
0 |
| Preinstalled operating system |
- |
| Suitable for safety functions |
no |
| Voltage type (supply voltage) |
DC |
| Wall mounting/direct mounting |
yes |
| Number of HW-interfaces RS-232 |
1 |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
1 |
| Supporting protocol for Modbus |
no |
| Supporting protocol for SERCOS |
no |
| Mounting type, gallows mounting |
no |
| Mouse-cursor control integrated |
no |
| Supporting protocol for SUCONET |
no |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces wireless |
0 |
| Supporting protocol for EtherCAT |
yes |
| Supporting protocol for INTERBUS |
no |
| Supporting protocol for PROFIBUS |
no |
| Customer individual configuration |
no |
| Supporting protocol for DeviceNet |
no |
| Supporting protocol for PROFIsafe |
no |
| Number of HW-interfaces serial TTY |
0 |
| Supporting protocol for EtherNet/IP |
no |
| Supporting protocol for PROFINET IO |
no |
| Supporting protocol for SafetyBUS p |
no |
| Supporting protocol for Data-Highway |
no |
| Supporting protocol for PROFINET CBA |
no |
| Degree of protection (IP), front side |
IP65 |
| Supporting protocol for INTERBUS-Safety |
no |
| Supporting protocol for DeviceNet Safety |
no |
| Supporting protocol for other bus systems |
no |
| Certified for UL hazardous location class I |
no |
| Number of HW-interfaces industrial Ethernet |
2 |
| Supporting protocol for Foundation Fieldbus |
no |
| Certified for UL hazardous location class II |
no |
| Certified for UL hazardous location class III |
no |
| Certified for UL hazardous location division 1 |
no |
| Certified for UL hazardous location division 2 |
no |
| Supporting protocol for AS-Interface Safety at Work |
no |
| Certified for UL hazardous location group D (propane) |
no |
| Certified for UL hazardous location group B (hydrogen) |
no |
| Certified for UL hazardous location group C (ethylene) |
no |
| Certified for UL hazardous location group A (acetylene) |
no |
| Certified for UL hazardous location group E (metal dusts) |
no |
| Certified for UL hazardous location group F (carbonaceous dusts) |
no |
| Certified for UL hazardous location group G (non-conductive dusts) |
no |
