Optocoupler module Nominal input voltage: 5 VDC Output voltage range: 20 … 28.8 VDC gray
Optocoupler module; Nominal input voltage: 5 VDC; Output voltage range: 20 … 28.8 VDC; Limiting continuous current: 0.1 A; 3-wire connection/high-side switching; Frequency: 100 kHz; Red status indicator; Module width: 6 mm; gray
Product identifiers
SKU: 859-753
EAN: 4066966423389
GTIN: 4066966423389
MPN: 859-753
Loyalty points:
1
Price: £ 26.72 Excl. VAT
Categories
ETIM Group
Specifications
| Input voltage | 4 - 6.25 |
| Output voltage | 20 - 28.8 |
| With LED indication | yes |
| Type of digital output | Electronic |
| Type of output voltage | DC |
| Rated operation current Ie | 0.1 |
| Type of voltage (input voltage) | DC |
