Line choke - 2 mH - 18 A - 1 phase - 30 W - for variable speed drive
This line choke can be used to provide improved protection against overvoltages on the line supply. It can also be used to reduce harmonic distortion of the current produced by the drive. This product is compliant with IEC 61800-5-1 (VDE 0160 level 1 high-energy overvoltages on the line supply). Its rated current is equal to 18A and its value of inductance to 2mH. It is compatible with Altivar 31, Altivar 32, Altivar 312, Altivar machine ATV320, Lexium 05 and Lexium 32.
Product identifiers
SKU: VZ1L018UM20
EAN: 3389110890846
GTIN: 3389110890846
MPN: VZ1L018UM20
Loyalty points:
1
Price: £ 167.00 Excl. VAT
Categories
ETIM Group
Specifications
| Rated current AC | |
| Rated inductance | 2 mH |
| Resonance frequency | - |
| Rated clock frequency | - |
| Degree of protection (IP) | IP00 |
| Rated operating frequency | |
| Degree of protection (NEMA) | - |
| Number of poles, primary side | 1 |
