"Two entries cable gland plate, PanelSeT SFN, PanelSet SF, for electrical enclosure W800 D800mm, fixed by clips"

Link copied
SKU
EAN
GTIN
MPN

"Two entries cable gland plate, PanelSeT SFN, PanelSet SF, for electrical enclosure W800 D800mm, fixed by clips" by Schneider Electric is listed by 2 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd and Control Components Anglia. It is currently in stock at 1 of them. Trade price £50.88 excl. VAT. Voltimum+ members earn 9 points per unit.

This is a multi-purpose 2-entry cable gland plate for PanelSeT SFN and PanelSeT SF electrical enclosures. The product is made of galvanised steel. It is suitable for enclosures with nominal width and depth of 800 and 800 mm respectively. The set contains one plate with 2-entry, polyurethane adhesive gasket with cross-section of 15 x 25 mm and fixing elements. The cable gland plate is to be mounted on enclosure bottom.

Voltimum+ Loyalty Programme Loyalty points: 9

Price: £ 50.88 Excl. VAT

Specifications

Type Straight
Model Other
Width 800 mm
Height 35 mm
EFSE0006 -
Material Steel
Thickness 1.5 mm
Thread type None
Surface protection Galvanised
Degree of protection (NEMA) Other
Suitable for nominal thread metric/PG
