Categories
Features
|
EFDE0006
|
FALSE
|
|
EFDE0007
|
FALSE
|
|
EFDE0048
|
FALSE
|
|
EFDE0049
|
TRUE
|
|
Kv value
|
|
|
Kvs value
|
65
|
|
Axle height
|
-
|
|
Connection 1
|
Flange
|
|
Connection 2
|
Flange
|
|
Stroke length
|
30 mm
|
|
Housing material
|
Cast iron
|
|
Material quality
|
Cast iron EN-GJL-250 (GG 25)
|
|
Surface protection
|
Other
|
|
Control ratio (Svo)
|
-
|
|
Characteristic curve
|
Equal percentage
|
|
Suitable for cooling
|
FALSE
|
|
Suitable for heating
|
FALSE
|
|
Automatic flow control
|
FALSE
|
|
Length of connection 1
|
-
|
|
Length of connection 2
|
-
|
|
Suitable for tap water
|
TRUE
|
|
Flange compression class
|
PN 16
|
|
Min. pressure difference
|
1 bar
|
|
Article compression class
|
PN 16
|
|
Contour code connection 1
|
V
|
|
Contour code connection 2
|
V
|
|
Leakage loss of Kvs value
|
0.05 %
|
|
With flow measuring point
|
FALSE
|
|
Suitable for process water
|
TRUE
|
|
With coupling connection 1
|
TRUE
|
|
With coupling connection 2
|
TRUE
|
|
Working length connection 1
|
-
|
|
Working length connection 2
|
-
|
|
Nominal diameter connection 1
|
2 1/2 inch (65)
|
|
Nominal diameter connection 2
|
2 1/2 inch (65)
|
|
Medium temperature (continuous)
|
|
|
Outer pipe diameter connection 1
|
65 mm
|
|
Outer pipe diameter connection 2
|
65 mm
|
|
Max. pressure difference in opened position
|
1 bar
|
