Key switch selector, metal, black, Ø22, key n°455, 3 positions, stay put, 2 NO

Key switch selector, metal, black, Ø22, key n°455, 3 positions, stay put, 2 NO

This Harmony XB4 modular black key selector switch (key no.455) has 3 positions, operates with a stay-put mechanism with key withdrawal on the center position. It has a metal bezel. This key selector switch provides a versatile interface for controlling your machines. It is easily installed into standard 22mm diameter cut-outs and connected to your control circuits with simple screw-clamp connections. It provides a secure manner for authorized staff to switch between process or machine operating modes. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments.

Product identifiers

SKU: XB4BG33
EAN: 3389110887150
GTIN: 3389110887150
MPN: XB4BG33

V+ Loyalty points:

21

Price range: £ 31.49 - £ 49.31 Excl. VAT

Videos

Promotional video

Specifications

Power loss -
Colour button Black
Hole diameter 22.5 mm
Spring-return no
Width opening -
Height opening -
Supply voltage
With front ring yes
With light source no
Suitable for lighting no
Degree of protection (IP) IP66
Degree of protection (NEMA) 13
Type of electric connection Screw connection
Number of contacts as normally open contact 2
