Categories
Features
|
Frequency
|
100 - 100 MHz
|
|
Connection 1
|
Other
|
|
Earthing via
|
-
|
|
Assembly width
|
-
|
|
Mounting method
|
On basic element
|
|
Limiting frequency
|
100 MHz
|
|
Nominal voltage AC
|
1 - 1 V
|
|
Nominal voltage DC
|
|
|
Nominal load current
|
0.75 A
|
|
Signal disconnection
|
-
|
|
Explosion-tested version
|
no
|
|
Signalling at the device
|
None
|
|
Degree of protection (IP)
|
-
|
|
Pro-active thermo-control
|
no
|
|
Max. continuous voltage AC
|
56.7 V
|
|
Max. continuous voltage DC
|
-
|
|
With remote signalling contact
|
no
|
|
Voltage protection level core/core
|
105 V
|
|
Voltage protection level core/earth
|
105 V
|
|
Lightning impulse current (10/350 µs)
|
2.5 kA
|
|
Nominal discharge surge current (8/20)
|
10 kA
|
|
Number of conductors (without earthing)
|
-
|
|
Voltage protection level core/signal ground
|
105 V
|
|
Voltage protection level signal ground/protective ground
|
105 V
|
