Crabtree - Product Catalogue - Wiring Accessories and Part M Building Regulations - 2011
Product Catalogue
2011 wiring accessories and part M building regulations ELECTRIUM SALES LIMITED A SIEMENS COMPANY Commercial Centre, Lakeside Plaza, Walkmill Lane, Bridgtown, Cannock WS11 0XE. eMail: [email protected] Web: www.electrium.co.uk UK SALES Telephone: 01543 455010 Facsimile: 01543 455011 eMail: [email protected] TECHNICAL Telephone: 01543 438310 Facsimile: 01543 438311 eMail: [email protected] EXPORT SALES Telephone: +44 1543 455049 Facsimile: +44 1543 455048 eMail: [email protected] Although every effort has been made to ensure accuracy in the compilation of the technical detail within this publication, specifications and performance data are constantly changing. Latest details can be obtained from Crabtree. Publication No. B2045 11/10 Printed in England. DUBAI OFFICE Telephone: +971 4 3660687 Facsimile: +971 4 3660676 eMail: [email protected] New Part M 4pp_Layout 1 24/05/2011 10:43 Page 1
20AX GRID SWITCHES l 20AX 1 way Grid Switch 4450/GRY 20AX 2 way Grid Switch 4550/GRY 20AX DP Grid Switch 4460/GRY 20AX Intermediate Switch 4535/GRY 7009 5170/GRY 4170/GRY 4172/GRY 5572/GRY 6902 4450/GRY 4460/GRY 4550/GRY SEEK LIGHT l LED Seek / Night Light 7009 l Fits all Crabtree 1 Gang in size light switch plates. l The seek light comes on when the switch is turned off. l The seek light requires a filament type bulb to operate correctly. Dimensions 94mm x 94mm 10AX CORINTHIAN PLATE SWITCH l BS EN 60669 - 1 10AX 1 Gang 2 way SP 5170/GRY 10AX 2 Gang 2 way SP 5172/GRY 10AX 3 Gang 2 way SP 5173/GRY 20AX 1 Gang Intermediate 5175/GRY 10AX 1 Gang Retractive 5177/GRY Dimensions 86mm x 86mm Fully rated for fluorescent or inductive loads. l Clip on trim conceals fixing screws 10AX PLATE SWITCHES l BS EN 60669 - 1 10AX 1 Gang 2 way SP 4170/GRY 10AX 2 Gang 2 way SP 4172/GRY 10AX 1 Gang Intermediate 4175/GRY Dimensions 86mm x 86mm Fully rated for fluorescent or inductive loads. GRID PLATES l 1 Gang Plate for Capital grid 5571/GRY 2 Gang Plate for Capital grid 5572/GRY 3 Gang Plate for Capital grid 5573/GRY 4 Gang Plate for Capital grid 5574/GRY 6 Gang Plate for Capital grid 5576/GRY GRID YOKES l 1 Gang Capital grid 6901 2 Gang Capital grid 6902 3 Gang Capital grid 6903 4 Gang Capital grid 6904 6 Gang Capital grid 6906 Dimensions 1 Gang 86mm x 86mm2 Gang 146mm x 86mm 10AX GRID SWITCHES l BS EN 60669 - 1 10AX 1 way Grid Switch 4430/GRY 10AX 2 way Grid Switch 4530/GRY 10A Retractive Grid Switch 4489/GRY 4304/D/GRY 4307/3/GRY 4827/3/GRY 4013/3/GRY 7091/GRY 7094/GRY 7069 7063 7172 13A SWITCHED SOCKET OUTLETS l BS 1363 1 Gang DP 4304/D/GRY 1 Gang DP fitted with neon indicator 4304/3D/GRY 2 Gang DP Outboard Rockers 4307/GRY 2 Gang DP Outboard Rockers with neon indicator 4307/3/GRY Dimensions 1 Gang 86mm x 86mm2 Gang 146mm x 86mm l Shallow back projection for ease of installation in a 25mm deep back box l Fitted with two earth terminals for use where compliance with BS7671: 2008 regulation 543 - 7 ( IEE wiring Regulations ) 13A FUSED CONNECTION UNITS l BS 1363 DP Switched 4827/GRY DP Switched with neon indicator 4827/3/GRY Dimensions 86mm x 86mm l Fitted with knock - out position in bottom edge of plate for use with orwithout cord outlet. Suitable for flexible cord up to 10mm outside diameter l Shallow back projection for ease of installation in a 25mm deep back box 32A DP CONTROL SWITCH l BS EN 60669 - 1 Fitted with neon indicator 4013/3/GRY Dimensions 86mm x 86mm l Fitted with knock - out position in bottom edge of plate for use with orwithout cord outlet. Suitable for flexible cord up to 10 mm outside diameter COMMUNICATION PLATE l BS 5733 Where Applicable 2 module moulded 7091/GRY 4 module moulded 7094/GRY Dimensions 86mm x 86mm Dimensions 1 Gang 86mm x 86mm2 Gang 146mm x 86mm COMMUNICATION MODULES l RJ45 Cat 5e Euro Module 7172 TV Outlet (male) 7065 TV Outlet (female) 7067 F Type Satellite Euro Module 7069 Triplex unit (TV, FM, Sat) 7063 Blank 1 Module 7081 Blank 1/2 Module 7081/2 Dimensions 25 x 50mm (1 Module)(except 7063 - 50mm x 50mm) For other Communication Modules please refer to Page 23 of the Crabtree 2010Wiring Accessories Catalogue. New Part M 4pp_Layout 1 24/05/2011 10:43 Page 3
