Ty-Rap ®  Detectable Cable Ties Detectable by metal detectors

Ty-Rap ®  Detectable Cable Ties  No more secret ingredients The Ty-Rap ®  detectable cable ties and accessories from ABB incorporate a unique  patented compound that can be detected by X-Ray equipment, metal detectors and visual inspection equipment. Those products are particularly recommended for applications in food, pharmaceutical and other contamination-sensitive industries using detection systems, where cable tie installation residuals (cut tails) and/or accessories are not allowed in the finished product. By specifying the Ty-Rap ®  detectable cable ties and accessories  of ABB for your plant you help reducing the risk of product conta-mination. Another great aspect of the detectable products of ABB: they help your business achieve a great step towards meeting the HACCP EU-directive. The HACCP directive is a systematic preventative approach to food safety that addresses physical, chemical and biological hazards as a means of prevention rather than finished product inspection. The Ty-Rap ®  detectable cable ties and accessories made of  detectable Nylon (NDT) and Polypropylene (PDT) are compliant to the FDA regulation, which means the products are intended for use in the proximity of food processing, handling and packaging operations. Main applications for detectable products: - Food and beverage processing- Pharmaceutical production- Chemical and compounds manufacturing- Tire and airbag manufacturing-  Any other contamination-sensitive industry using detection  equipment Detection methods Metal Detection Ty-Rap ®  Detectable Cable Ties have been tested and are rated  at 1.5 mm diameter ferrous sphere setting. Therefore sensitive enough to be picked up by nearly every metal detector in service. X-Ray Detection X-Rays are the future of the detection industry. Depending on the density of the product being verified, Ty-Rap ®  Detectable Cable Ties  reach an impressive differential of between 200 and 2000 on the X-Ray grey scale. Visual Detection Visual detection systems detect surface irregularities and volume changes. This method is often used in beverage and chemical processing plants. The bright blue colour ensures an easy visual detection. Features-  Detectable by metal detectors set at minimum 1.5 mm diameter  ferrous sphere -  Detectable by X-Ray equipment -  Bright blue colour for an easy visual detection-  Help achieve the HACCP EU-Directive, compliant to the FDA  regulation -  Halogen free-  Available in standard Polyamide 6.6 (all references ending with  NDT) or in buoyant Polypropylene (all references ending with PDT) version for liquid-processing applications -  All the advantages of the standard Ty-Rap ®  cable ties as “The  Grip of Steel” locking device which offers superior performance -  Available in 5 different sizes in convenient small bags with   Euroslot HACCP= Hazard Analysis Critical Control PointsHACCP is a system, which identifies specific hazards and preventative measuresfor their control to minimize the risk of producing defective products and services. Tested by Thermo Electron Corporation, Minneapolis, MN, USA Tested by Smiths Detection, Alcoa, TN, USA

Ty-Rap ®  Detectable Cable Ties  Detectable Cable Ties and Accessories GID Nummer Product ref. Mounting method Width Length For tie width  up to Mounting hole  diameter  (2x) Quantity [mm] [mm] [mm] [mm] [pieces] 7TAG009660R0023 TC5344A-NDT self-adhesive /screw 19,1 19,1 3,6 3 100 7TAG009660R0024 TC5344A-PDT self-adhesive /screw 19,1 19,1 3,6 3 100 7TAG009660R0013 TC344A-NDT self-adhesive /screw 19,1 19,1 3,6 3 1000 7TAG009660R0025 TC5347A-NDT self-adhesive /screw 29 29 7,6 4,4 100 7TAG009660R0026 TC5347A-PDT self-adhesive /screw 29 29 7,6 4,4 100 7TAG009660R0014 TC347A-NDT self-adhesive /screw 29 29 7,6 4,4 1000 2-way and 4-way entry mounting bases GID Nummer Product ref. Mounting  method Width Length For tie width up to Mounting hole  diameter Quantity [mm] [mm] [mm] [mm] [pieces] 7TAG009660R0017 TC5141-NDT screw 11,1 17 4,8 3,8 100 7TAG009660R0018 TC5141-PDT screw 11,1 17 4,8 3,8 100 7TAG009660R0010 TC141-NDT screw 11,1 17 4,8 3,8 500 7TAG009660R0019 TC5142-NDT screw 14,2 23,4 7,6 5,2 100 7TAG009660R0020 TC5142-PDT screw 14,2 23,4 7,6 5,2 100 7TAG009660R0011 TC142-NDT screw 14,2 23,4 7,6 5,2 500 Saddle support GID Nummer Product ref. Mounting Width Length For tie width Mounting hole  Quantity method   up to ø D1 ø D2 [mm] [mm] [mm] [mm] [mm] [pieces] 7TAG009660R0015 TC5102-NDT screw 12,7 19,1 4,8 4,4 8,7 100 7TAG009660R0008 TC102-NDT screw 12,7 19,1 4,8 4,4 8,7 1000 7TAG009660R0009 TC102-PDT screw 12,7 19,1 4,8 4,4 8,7 1000 Srew-mounted miniature bases GID Nummer Product ref. Mounting method Width Length For tie width up to Quantity [mm] [mm] [mm] [pieces] 7TAG009660R0021 TC5342A-NDT self-adhesive 29 29 4,8  100 7TAG009660R0022 TC5342A-PDT self-adhesive 29 29 4,8 100 7TAG009660R0012 TC342A-NDT self-adhesive 29 29 4,8 1000 Low profile plates Surface preparation: surface should be cleaned with alcohol-based cleaner before application. Installation: Surface must be clean and dry prior to application of accessory. Allow 15-minute setting time for maximum adhesion performance of synthetic rubber adhesive (SRA). GID Reference Product ref. Length Width Bundle diameter from ... to Minimum tensile  strength Quantity  Tooling [mm] [mm] [mm] [pieces] 7TAG009660R0029 TY523M-NDT 92 2,4 2 - 16 80 100 ERG50 7TAG009660R0031 TY524M-NDT 140 3,6 2 - 29 180 100 ERG50 7TAG009660R0032 TY525M-NDT 186 4,8 3,5 - 45 220 100 ERG50 / ERG120 7TAG009660R0036 TY528M-NDT 360 4,8 3,5 - 102 220 100 ERG50 / ERG120 7TAG009660R0034 TY527M-NDT 340 7,0 6 - 90 540 50 ERG120 7TAG009660R0030 TY523M-PDT 92 2,4 2 - 16 50 100 ERG50 7TAG009660R0033 TY525M-PDT 186 4,8 3,5 - 45 130 100 ERG50 7TAG009660R0037 TY528M-PDT 360 4,8 3,5 - 102 130 100 ERG50 7TAG009660R0035 TY527M-PDT 340 7,0 6 - 90 270 50 ERG120 Ty-Rap ®  - Detectable Cable Ties
