CONNECT Radio System   | 1 Simple and intelligent –   for the safest connections Ultimate and CONNECT Radio System P105889

2 |  CONNECT Radio System  Your customers'  expectations of comfort and safety are increasing Living space  modernisation is  a growing market

CONNECT Radio System   | 3 The market for living space modernisation is still among the fastest growing in the  construction industry. The need to renovate and modernise is correspondingly high. There are plenty of reasons to modernise one's own home: the children have moved out, the interior decoration is getting old or the garden needs to bathe in a bright atmosphere. Update residential properties –simple, fast and flexible Connect yourself  to new business opportunities! Smart  modernisation Easy  installation … … with CONNECT  radio system… ...provides an increase in sales volume. Offer your customers smart and cost efficient solutions Modernise the clever way  The CONNECT radio system is the perfect solution for anyone who wants to modernise their electrical installation. It offers a great amount of flexibility, comfort and safety where the control of functions like lighting, blinds or multimedia is concerned.   All without having to install new cables. Finally, the new CONNECT radio system works “comfortably without cables” and ensures very safe connections. See on the following pages how exactly that works.

4 |  CONNECT Radio System  Reliable function,  reliable radio connections Secure and innovative: more than  one way to the desired radio receiver  The CONNECT radio system finds new ways  of transmitting the radio signal. To be specific: always the best way. Sometimes it leads directly to the target receiver and sometimes it is  forwarded via another receiver – depending on which receiver is currently best receiving the radio signal.  The re-routing technology makes this possible. Your benefit: always the most reliable radio connections.  Reliable function with reliable radio connections is the be-all and end-all of a mature radio system; this is precisely what the CONNECT radio system offers.  CONNECT with  re-routing technology for reliable functionality  Always in dialogue:  Transmitter and receiver Transmitters and receivers are in dialogue for optimal transmission of the radio signal. That means it is not a case of sending out a one-way radio signal; instead, it is constantly checked that the receiver really has received the radio signal. The receiver sends a response when it has received the signal from the transmitter.  If the reception acknowledgment is missing once (e.g. due to a reflective wall), the  CONNECT radio system automatically searches for another way to transmit the radio signal to the receiver. For example, via another radio  receiver in an adjacent room that can forward the signal to the actual receiver. Perfect conditions for a reliable, trouble-free radio system in which, by the way, up to 100 participants can be networked together. Without re-routing technology With re-routing technology Radio  transmitter Radio receiver Reflective wall No way through: With reflective walls or obstacles, the receiver waits for the radio signal in vain. Radio  transmitter Radio receiver Reflective wall The most reliable solution: The signal of the  CONNECT radio system continuously and  automatically searches further “stopovers” for the  best path to the desired receiver.  Re-routing technology Radio receiver Radio receiver P111094 P111094

CONNECT Radio System   | 5 More information visit: www.z-wavealliance.org Z-Wave TM : Basis of the CONNECT radio  system and established worldwide As new as the possibilities are thanks to the  innovative re-routings, the technical standard the CONNECT radio system is based on is proven: Z-Wave TM . A technical standard   created by numerous prominent manufac turers and successfully established worldwide. There are various solutions based on Z-Wave TM  from  suppliers like Black & Decker, Hunter Douglas, Universal Electronics and Danfoss. Interference-free: signal received  on 868 MHz radio frequency  To protect you from interference, the CONNECT radio system uses the frequency 868 MHz, which has been specially reserved for short-distance radio. This means a low possibility of interference from other control, identification and positioning systems and audio devices transmitting in parallel.  Schneider Electric technology:  Safe and environmentally friendly The CONNECT radio system does not permanently transmit signals, only when a radio transmitter is actuated (sensor network). The radio transmission capacity is negligible in comparison to wireless DECT mobile telephones, mobile phones or WLAN systems, for example, and is completely safe in terms of building biology. The transmission capacity of DECT mobile telephones and mobile phones is up to 10.000 times higher than that of the  CONNECT radio system. Up to 10.000 times lower in comparison to mobile telephones:  the energy consumption of the CONNECT radio system Radio system transmission capacities P111093

6 |  CONNECT Radio System  P128213

CONNECT Radio System   | 7 Imagine you could control not only your television, DVD player and other audio devices, but also building functions such as lights and blinds, all with a single remote control.  Schneider Electric makes it happen – with the new CONNECT radio universal remote control. Its attractive and slender design is impressive, and it combines two kinds of technology in one device: infrared and radio. With it, up to four AV devices  or Schneider Electric IR components can be controlled via infrared. At the same time, it allows you to operate CONNECT radio system devices. If a device cannot be found in the extensive IR database, the integrated learning function makes it possible to easily save IR codes from other remote controls. In this way, you remain flexible and also operate new devices with the CONNECT radio universal remote control in future. LED indication for acknowledge from the RF receiver Infra-red control of up to 4 AV devices  Integrated control for Schneider Electric IR components  IR Learning function –  even not listed IR codes can be adapted to the remote Lighting and blind control via the CONNECT radio system Programming with Easy CONNECT: direct teach-in of several devices  into the remote control – without software Programming with Easy tool: the convenient programming method in  connection with the CONNECT radio configuration tool Scene control or direct control of 12 groups and scenes Attractive and slim design CONNECT radio universal remote control Everything under control Product features P127171

8 |  CONNECT Radio System  Movement detectors are the ideal solution for automatic all-round building protection. They bring light to precisely those dark places where extra security is necessary. With the RF Argus 220 CONNECT movement detector and the remote control you and your customer can conveniently adjust current twilight thresholds and switch-on times. All that without having to climb a ladder. Up to four RF Argus 220 CONNECT devices and CONNECT switch actuators can be networked and set via the remote control (permanent ON, permanent OFF, automatic, sensitivity, switching duration).  Large wiring compartment with sufficient room  for quick wiring Anti-crawl protection and integrated rear view monitoring for maximum security Angle of detection 220° Perfect detection quality thanks to special  resolution lenses with 3 wide-area levels,448 switching segments and a range of max. 16 m  With the radio configuration tool CONNECT, you can not only conveniently and easily connect the RF Argus 220 CONNECT with the radio network, but also teach receivers and use function modules such as scene, message and alarm.  If you connect the Argus movement detector to other CONNECT radio receivers, the outside and garage lights will be switched on automatically when you arrive home, as will be the hall light after a time delay if required. You can also use the light-sensitive switch function of the Argus movement detector for other radio receivers, for even more convenience at home.  Safety and design RF Argus 220 CONNECT movement detector Product features RF Argus 220 CONNECT, Aluminium  P125673

CONNECT Radio System   | 9 End users can conveniently set the RF Argus 220 CONNECT to their individual needs via radio Network up to 4 movement detectors and CONNECT switch actuators One push of a button and the lighting stays  on/off permanently for the next 6 hours  (adjustable) Simply specify the twilight threshold for switching on the outdoor lights automatically via radio Increase/decrease the switching duration  by 30 seconds  Measure and set the movement sensitivity CONNECT radio receiver, 1-gang universal dimmer CONNECT radio receiver, 1-gang change-over relay CONNECT radio receiver, 2-gang switch CONNECT radio receiver, 1-gang switch CONNECT radio receiver, 1-gang switch, 2-pole Whether in a ceiling void or wall cavity - the CONNECT radio receiver can be remote controlled with all radio transmitters of the CONNECT radio system. Always a good connection CONNECT radio receivers RF Argus 220 CONNECT remote control Remote control unit for RF Argus 220 CONNECT  P125672 P131562 P131562 P131562 P131562 P131562

10 |  CONNECT Radio System  Excellent design Modern coating, brushed metal effect. For a sheer design look. Stainless Steel A pearly, pastel coating, for a gentle feeling. Pearl Nickel Luxurious coating, gold mirror effect. For an even brighter room. Polished Brass High-end coating, smoked mirror effect. Luxuriuous and modern surroundings. Black Nickel A classical finishing, emphasised  by a shiny coating for an original feeling. Painted White A design coating, mirror effect.  A high-tech feeling for modern interiors. Polished Chrome Ultimate screwless flat plate - six different finishes for all interior design  possibilities.

CONNECT Radio System   | 11 Easy to install The installation is very easy. In 3 simple steps... 1. Screw the retaining frame to the back box.2. Click in the push-button.3. Click on the Ultimate front plate. Less is more Move – the little roundradio push-button for mobile switching CONNECT radio push-button, Move, with wall bracket Deluxe bathing: With Move, you can use lighting to  get the right atmosphere when you’re in the tub Move is for anyone who wants to be even more flexible. The little round radio push-button can be easily removed from its respective wall  bracket and used as a radio remote control. You can snap it back into the frame when you’re done  or screw it alone to any place on the wall you like. For example, when you want to dim the lighting from the bathroom mirror, or if lighting is to be added to the closet or dressing room and you want to switch it on conveniently with Move.

12 |  CONNECT Radio System  Design that clicks with your style Meet the Ultimate family Design is all around us, we see today’s clean, sophisticated design language in many of the things that we use everyday, from our cars to our computers and televisions. The Connect range of push button front plates have been designed to fully complement the Ultimate screwless flat plate range of wiring accessories. Ultimate screwless flat plate provides one of the most comprehensive ranges of beautifully crafted, sleek, sophisticated fittings on the market.  More choice, more style, and packed with innovative technical features for easy installation.   Easy-fit screwless front plate simply but securely clips onto the mounting system  Even with the front plate removed access to live parts is restricted  Minimal back projection to allow installation using standard flush mounting boxes   for both new and retrofits  Comprehensive range from dimmers to data communication outlets  Large plate footprint avoids the need for additional decorating on retrofits

CONNECT Radio System   | 13 CONNECT 4-gang radio transmitter Increased flexibility Multi-gang options For installations which require multi-gang assemblies for centralised control, the Ultimate grid system provides a comprehensive mix and match design. Wouldn’t it be great if the light switches on the grid plate could be integrated on to the CONNECT radio network? They can… Our solution is the CONNECT 4-gang radio transmitter, which is a battery powered device designed for installation within the mounting box of an Ultimate grid plate. There is no limitation as to the size of the grid plate which can be used – simply install more than one 4-gang radio transmitters. When wired to a series of retractive switch modules, the CONNECT 4-gang radio transmitter will send signals to the assigned CONNECT radio receivers to switch or dim the lighting. With a range of approximately 30 meters, the receivers don’t even need to be located within the same room.

14 |  CONNECT Radio System  Application examples

CONNECT Radio System   | 15 The Schneider Electric solution:   CONNECT radio remote control stores scene settings which can be easily programmed via the radio     configurator software.   Only one radio receiver required to control the curtains.   Integrated controls for your TV, DVD and stereo on the same remote control. Living room: Watching TV  Controlling the blinds via radio frequency with a remote control doesn‘t mean one more remote control cluttering the living room table. In fact, it means the opposite: the CONNECT remote control works with TV sets and DVD players as well. L Ceiling & wall lights TV & DVD player Blinds Universal dimmer  reciever N Change-over relay receiver Universal remote control IR signal P127301

16 |  CONNECT Radio System  Office meeting room: The professional touch Create the perfect working environment for your client via the use of one 2-gang push button. A simple dimmer switch on one side to control the lighting, and a presentation scene set on the other side to lower the projector screen and dim the lighting at the front of the room. The Schneider Electric solution:   Wire universal dimmer receivers to the lighting and relay receivers to the    projector screen.  Use the radio configurator software to set a scene for presenting.  Program the second button on the 2-gang push button to be a    standalone dimmer. L Presentation screen Lighting Universal dimmer receiver Change-over relay receiver 2 gang push button Polished Brass N

CONNECT Radio System   | 17 The Schneider Electric solution:   Integrate curtains into the CONNECT radio network with the use of a relay receiver.  Dim all of the lighting through the use of universal dimmer receivers and plug   adaptors.  To install a grid plate larger than 4-gang, simply install more than one 4-gang    radio transmitter. Hotel room: Five star luxury To enable guests to fully relax, install dimming functions for the lighting and controls for the curtains from one Ultimate screwless grid plate, with the use of the CONNECT radio 4-gang transmitter and a selection of retractive switch grid modules.  L Blinds/ curtains Floor lamp Ceiling & wall lights Universal dimmer receiver Universal dimmer plug adapter Change-over relay receiver 4 gang transmitter N

18 |  CONNECT Radio System  Product Overview Controls and remote CONNECT radio  universal remote control CONNECT radio universal remote control: •  Combines infrared and radio•  Operates up to five AV devices or all IR  components via infrared and CONNECT radio system devices at the same time CONNECT radio  transmitter, 4-gang Universal radio  transmitters / router RF router CONNECT   230V RF transmitter  CONNECT, 2 channel  •  For integration into  any conventional switch range in the radio system CONNECT radio push-button, 1-gang CONNECT radio push-button,  2-gang CONNECT radio push-button,  Move Push-buttons To control the radio receiver• Extremely flat design• The ideal solution for retrofitting• Secured with screws or adhesive• Complements the Ultimate screwless flat plate     range of wiring accessories P127171 P115127 P131562 P131562

CONNECT Radio System   | 19 Plug adapter Radio receiver CONNECT radio receiver, 2-gang switch  CONNECT radio receiver, 1-gang universal dimmer  CONNECT radio receiver, 1-gang switch, 2-pole  CONNECT radio receiver, 1-gang switch  CONNECT radio plug adapter, switch,  CONNECT radio plug  adapter, universal dimmer For connecting external loads with the  CONNECT radio system•  Switching and dimming external loads with  British Standard plug (13A). •  Staircase lighting function, ON/OFF delay•  Adjustable dimming speed, brightness limit,  memory switched function Whether in a ceiling void or wall cavity the CONNECT radio receiver can be remote controlled with all radio transmitters of the CONNECT radio system. CONNECT radio receiver, 1-gang change-over relay Movement detector RF Argus 220 CONNECT, polarwhite  Remote control unit for RF Argus 220 CONNECT,  The detection range can be adapted optimally with the help of the spherical lens, which can be adjusted horizontally, vertically and axially. •  Provides adequate lighting in areas a good  distance from the light switch •  Can be installed very easily•  Low-level protection to prevent intruders   crawling underneath •  Can be cross-linked and adjusted   easily via radio P115156 P115157 P131562 P131562 P131562 P131562 P131562 P125687 P125672

20 |  CONNECT Radio System  Notes

CONNECT Radio System   | 21 Notes
