Easy9 Affordable circuit protection you can depend on

Schneider Electric is a global specialist in energy management. Established as a circuit breaker designer and manufacturer in France since 1920, Schneider Electric are the worldwide leader of electrical protection technologies, present in more than 100 countries.

Easy9 Affordable circuit protection you can depend on Contents Introduction A complete range of modular devices ..........................................................p.4 New Easy9 circuit protection provides long-lasting protection ......................p.6 Product information Insulated enclosures .................................................................................p.10 Metal enclosures .......................................................................................p.11 Switch-disconnectors ................................................................................p.12 RCCB residual current circuit breakers ......................................................p.13 Miniature circuit breaker ............................................................................p.14 RCBO residual current devices ..................................................................p.15 Product selector ........................................................................................p.16 Technical Technical information ................................................................................p.18

Easy9 Affordable circuit protection you can depend on A complete range of modular devices Just what you need from circuit protection We work closely with electricians worldwide to help bring safe electricity to homes and buildings around the globe. Now you can take pride in delivering to your customers the enhanced safety and peace of mind they deserve.

“I would recommend Easy9 to anyone” New, robust circuit protection from a brand you trust The new Easy9 range better supports your business as an electrician, helping you to be more effective through: A high-quality, user-friendly design Availability when and where you need it Reliability you can count on

New Easy9 circuit protection provides long-lasting protection Easy9 brings you the quality, peace of mind, and reliability of a high-end device at a mid-range price. Thanks to consistent design and high manufacturing standards, Easy9 is a durable range you can be proud to install. Guaranteed compliance to product standards Certification by independent authorities Since 1920 Leader in electrical switchgear Easy9 Affordable circuit protection you can depend on

Quality - 100% designed and manufactured by Schneider Electric- All sites with ISO 9000 certification - Brand selected everywhere for industry, hospitals and airports Availability - Always available at your distributor- Complete coverage of protection features- Large assortment of ratings Safety - Protection from electric shocks, overloads and short circuits- Compliance to standards Customer satisfaction - Highly reliable and safe circuit protection- Dependable power supply Time saving - Consistent design and connection features- One-stop shopping for all parts- Proven robustness to withstand wear and tear

Easy 9 at a glance Easy9 Affordable circuit protection you can depend on Installer-friendly wiring with only 1 screwdriver Schneider Electric warranty Comprehensive range Full compliance with international IEC standards 3rd party certification

Neutral terminal identification engraved Full trip indication on the front panel by position of handle On-Off engraved Clear and visible production information.Whatever the toggle position Full range coherence Class II front face

10 Easy9 Insulated enclosures Description The surface mounting enclosure consists of: ■ Surface mounting enclosure with: ■ Multiple cable entry points and rear knock out slots ■ Fixing holes with level adjustment ■ Secure fixed DIN rail ■ Earth terminal block and a neutral terminal blocks fitted as standard ■ Secure busbar shield ■ Configurable on site ■ Options for smoked transparent door ■ Standard consumer units up to 20 ways ■ Enclosure colour: White RAL 9003 Insulated Consumer Unit Smoked Front Consumer Unit Reference Reference Description No Ways EZ92CU 2 way EZ9 Consumer unit 2 EZ94CU EZ94SGCU 4 way EZ9 Consumer unit 4 EZ96CU EZ96SGCU 6 way EZ9 Consumer unit 6 EZ98CU EZ98SGCU 8 way EZ9 Consumer unit 8 EZ912CU 12 way EZ9 Consumer unit 12 EZ916CU 16 way EZ9 Consumer unit 16 EZ920CU 20 way EZ9 Consumer unit 20 Flexible Split Load Boards Reference Description No Ways EZ9FS12CU EZ9 Flexible split load board 12 EZ9FS16CU EZ9 Flexible split load board 16 Shower / Garage units Reference Description No Ways EZ9SHOWER6340 63A CU including 40A MCB 2 way enclosure + 63A 30mA RCCB and 40A MCB Electric shower supply EZ9SHOWER6345 63A CU including 50A MCB 2 way enclosure + 63A 30mA RCCB and 50A MCB Electric shower supply EZ9GARAGE63 63A CU including 6 & 16A MCB 2 way IP55 enclosure + 63A 30mA RCD, 6A and 16A MCB Electricity supply to a garage Consumer units with switch/RCD’s fitted Reference Description EZ9R4R4CU 4+4W EZ9 CU 100A Sw, 63A RCCB X 2 EZ9R6R6CU 6+6W EZ9 CU 100A Sw, 63A RCCB X 2 EZ9R6R6DCU 6+6W EZ9 CU 100A Sw, 80A RCCB X 2 EZ9R8R8DCU 8+8W EZ9 CU 100A Sw, 80A RCCB X 2 EZ9S2R5R5DCU 2+5+5W EZ9, 100A Sw, 80A RCCB X 2 EZ9S2R7R7DCU 2+7+7W EZ9, 100A Sw, 80A RCCB X 2 Smoked front Available Decemeber 2013 EZ9S2R5R5SGCU 2+5+5W EZ9, 100A Sw, 80A RCCB X 2 EZ9S2R7R7SGCU 2+7+7W EZ9, 100A Sw, 80A RCCB X 2 Available December 2013

11 Easy9 Metal enclosures Description The surface mounting enclosure consists of: ■ Metal surface mounting enclosure with: ■ Multiple cable entry points and rear knock out slots ■ Secure fixed DIN rail ■ Earth terminal block and a neutral terminal blocks fitted as standard ■ Secure busbar shield ■ Standard consumer units up to 16 ways ■ Enclosure colour: White RAL 9003. Metal Consumer Unit Reference Description No Ways EZ92MCU 2 Way Metal EZ9 Consumer Unit 2 EZ94MCU 4 Way Metal EZ9 Consumer Unit 4 EZ96MCU 6 Way Metal EZ9 Consumer Unit 6 EZ98MCU 8 Way Metal EZ9 Consumer Unit 8 EZ912MCU 12 Way Metal EZ9 Consumer Unit 12 EZ916MCU 16 Way Metal EZ9 Consumer Unit 16

12 Easy9 Switch-disconnectors 2P Easy9 control switches Rating (Ie) 63 A EZ9S16263 100 A EZ9S16291 Voltage rating (Ue) 400 V, 50/60 Hz Width in 9-mm modules 4 Functions The switch-disconnectors are used for: ■ Control (opening and closing of circuits under load). ■ Disconnection of on-load electrical circuits already protected against overloads and short-circuits. Certified compliant BSEN60947-3 Connection 6.5 mm PZ2 20 mm Rigid copper cables y 50 mm 2 Tightening torque: 3.5 Nm Flexible copper cables y 35 mm 2 Tightening torque: 3.5 Nm

13 Easy9 Functions ■ Tripping in case of leakage current only. ■ One RCCB protects several circuits when fitted upstream of a group of circuit breakers. Certified compliant BSEN61008-1 Additional feature Endurance (O-C) Electrical 2000 cycles Mechanical 5000 cycles Conditional rated short circuit current (Inc/IDc) With fuse 3000 A With Easy9 MCB 3000 A Operating temperature -5°C to +60°C Storage temperature -40°C to +85°C Electrical feeding By the top and the bottom RCCB residual current circuit breakers 2P Residual current circuit breakers AC Rating (In) 30 mA 100 mA 300 mA 63 A EZ9R33263 EZ9R53263 EZ9R63263 80 A EZ9R33280 - - Voltage rating (Ue) 127 - 230 V, 50/60 Hz Width in 9-mm modules 4 Connection DB406037 6.5 mm 16 mm PZ2 Rigid copper cables 1 to 35 mm 2 Tightening torque: 3.5 Nm Flexible copper cables 1 to 25 mm 2 Tightening torque: 3.5 Nm

14 Easy9 Certified compliant BS EN 60898-1 Additional feature According to EN 60898-1 Breaking capacity (Icn) Ph/N 230 V AC 6000 A Additional characteristics Endurance (O-C) Electrical 4,000 cycles Mechanical 10,000 cycles Operating temperature -5°C to +60°C Storage temperature -40°C to +85°C 1P Circuit breakers Rating (In) Curve B Curve C 3 A EZ9F16103 - 6 A EZ9F16106 EZ9F66106 10 A EZ9F16110 EZ9F66110 16 A EZ9F16116 EZ9F66116 20 A EZ9F16120 E29F66120 25 A EZ9F16125 - 32 A EZ9F16132 E29F66132 40 A EZ9F16140 E29F66140 50 A EZ9F16150 E29F66150 Width in 9-mm modules 2 Miniature circuit breaker Connection 6.5 mm PZ2 16 mm Rigid copper cables 3 to 25 A 1 to 25 mm 2 Tightening torque: 2 Nm 32 to 50 A 1 to 35 mm 2 Tightening torque: 3.5 Nm Flexible copper cables 3 to 25 A 1 to 16 mm 2 Tightening torque: 2 Nm 32 to 50 A 1 to 25 mm 2 Tightening torque: 3.5 Nm

15 Easy9 Connection 14 mm 5.5 mm PZ2 16 mm Rigid copper cables L in 1 to 25 mm 2 Tightening torque: 2 Nm L and N out 1 to 16 mm 2 Tightening torque: 2 Nm Flexible copper cables L in 1 to 16 mm 2 Tightening torque: 2 Nm L and N out 1 to 10 mm 2 Tightening torque: 2 Nm RCBO residual current devices Functions ■ Protection from short-circuits. ■ Protection of cable from overloads. ■ Protection of persons from electric shocks by direct contact (30 mA sensitivity) ■ Can be fitted instead of a miniature circuit breaker for complete protection of one circuit. The Earth Reference Cable "FE": enables RCD to protect users from electric shocks, even in case of supply neutral loss, neutral conductor breakage or supply voltage drop (FE= Functional Earth). 1P+N Easy9 RCBO type A 30 mA Rating (In) B curve 6 A EZ9D16806 10 A EZ9D16810 16 A EZ9D16816 20 A EZ9D16820 25 A EZ9D16825 32 A EZ9D16832 40 A EZ9D16840 50 A EZ9D16850 Voltage rating (Ue) 230 V AC, 50 Hz Width in 9-mm modules 2 Certified compliant BS EN 61009-1

16 Easy9 OR Product selector Insulated Consumer Unit Smoked front Consumer Unit Metal Consumer Unit Reference Reference Reference Description No Ways EZ92CU EZ92MCU 2 way EZ9 Consumer unit 2 EZ94CU EZ94SGCU EZ94MCU 4 way EZ9 Consumer unit 4 EZ96CU EZ96SGCU EZ96MCU 6 Way EZ9 Consumer unit 6 EZ98CU EZ98SGCU EZ98MCU 8 way EZ9 Consumer unit 8 EZ912CU EZ912MCU 12 way EZ9 Consumer unit 12 EZ916CU EZ916MCU 16 way EZ9 Consumer unit 16 EZ920CU 20 way EZ9 Consumer unit 20 Select consumer units with switch/RCD’s fitted Reference Description Un/P Ways RCD1 ways RCD2 ways Split boards EZ9R4R4CU 4+4 W EZ9 CU 100A Sw, 63A RCCB X 2 4 4 EZ9R6R6CU 6+6W EZ9 CU 100A Sw, 63A RCCB X 2 6 6 EZ9R6R6DCU 6+6W EZ9 CU 100A Sw,80A RCCB X 2 6 6 EZ9R8R8DCU 8+8W EZ9 CU 100A Sw, 80A RCCB X 2 8 8 High integrity boards EZ9S2R5R5DCU 2+5+5W EZ9, 100A Sw, 80A RCCB X 2 2 5 5 EZ9S2R7R7DCU 2+7+7W EZ9 100A Sw, 80A RCCB X 2 2 7 7 Smoked front Available December 2013 EZ952R5R55GCU 2+5+5W EZ9, 100A Sw, 80A RCCB X 2 2 5 5 EZ952R7R75GCU 2+5+5W EZ9 100A Sw, 80A RCCB X 2 2 7 7 Incoming Devices Reference Device Rating Description EZ9S16263 Switch 63A Easy9 Switch Disconnector 2P 63A 400V EZ9S16291 Switch 100A Easy9 Switch Disconnector 2P 100A 400V EZ9R33263 RCCB 63A, 30mA Easy9 RCCB 2P 63A 30mA AC-type 230V Residual Current Circuit Breaker EZ9R33280 RCCB 80A, 30mA Easy9 RCCB 2P 80A 30mA AC-type 230V Residual Current Circuit Breaker For split load applications select a split load kit Reference Description Rating EZ963R30KIT2 RCCB and cables 63A 30mA EZ980R30KIT2 RCCB and cables 80A 30mA Available December 2013

17 Easy9 Product selector Select devices and accessories Select outgoing devices or accessories SP 6kA MCBs (B curve) Reference Description Current Rating EZ9F16103 MCB (B curve) 3A EZ9F16106 MCB (B curve) 6A EZ9F16110 MCB (B curve) 10A EZ9F16116 MCB (B curve) 16A EZ9F16120 MCB (B curve) 20A EZ9F16125 MCB (B curve) 25A EZ9F16132 MCB (B curve) 32A EZ9F16140 MCB (B curve) 40A EZ9F16150 MCB (B curve) 50A Accessories Reference Description EZ9LKIT Door lock kit (for metal enclosure only) EZ9EARTHKIT Additional earth terminals for clean earth or high integrity earthing EZ916BKIT Replacement/spare main busbar SQODNBP Blanking plate SP 6kA MCBs (C curve) Reference Description Current Rating EZ9F66106 MCB (C curve) 6A EZ9F66110 MCB (C curve) 10A EZ9F66116 MCB (C curve) 16A EZ9F66120 MCB (C curve) 20A EZ9F66132 MCB (C curve) 32A EZ9F66140 MCB (C curve) 40A EZ9F66150 MCB (C curve) 50A SP 6kA 1 module RCBO (B curve) Reference Description Current rating EZ9D16806 RCBO 30mA 1 Module 1P&N 6A EZ9D16810 RCBO 30mA 1 Module 1P&N 10A EZ9D16816 RCBO 30mA 1 Module 1P&N 16A EZ9D16820 RCBO 30mA 1 Module 1P&N 20A EZ9D16825 RCBO 30mA 1 Module 1P&N 25A EZ9D16832 RCBO 30mA 1 Module 1P&N 32A EZ9D16840 RCBO 30mA 1 Module 1P&N 40A EZ9D16850 RCBO 30mA 1 Module 1P&N 50A

18 Easy9 Technical information

19 Easy9 Insulated Units Ref No. No Ways Height (mm) Width (mm) Depth (mm) EZ92CU 2 240 189 127 EZ94CU 4 240 224 127 EZ96CU 6 240 260 127 EZ98CU 8 240 296 127 EZ912CU 12 240 368 127 EZ916CU 16 240 440 127 EZ920CU 20 240 510 127 EZ9R4R4CU 8 240 368 127 EZ9R6R6CU 12 240 440 127 EZ9R6R6DCU 12 240 440 127 EZ9S2R5R5DCU 12 240 440 127 EZ9R8R8DCU 16 240 510 127 EZ9S2R7R7DCU 16 240 510 127 EZ9FS12CU 12 240 368 127 EZ9FS16CU 16 240 440 127 EZ94SGCU 4 240 224 127 EZ96SGCU 6 240 260 127 EZ98SGCU 8 240 296 127 EZ9S2R5R5SGCU 12 240 440 127 EZ9S2R7R7SGCU 16 240 510 127 EZ9F512CU 12 240 440 127 EZ9F516CU 16 240 510 127 Metal Units Ref No. No Ways Height (mm) Width (mm) Depth (mm) EZ92MCU 2 247 186 111 EZ94MCU 4 247 222 111 EZ96MCU 6 247 258 111 EZ98MCU 8 247 294 111 EZ912MCU 12 247 366 111 EZ916MCU 16 247 438 111 EZ9FS12MCU 12 247 366 111 EZ9FS16MCU 16 247 438 111 Technical information Note: Incoming and outgoing devices must be selected separately from the devices section - only applies to EZ9 CU and EZ9 MCU Incoming devices available • Switch disconnector 63A & 100A • RCCB’s 63A/30mA 80A/30mA Max. busbar splits - for split load 8 way 2+4 to 4+2 12 way 4+6 to 6+4 16 way 6+8 to 8+6 Technical data Max. busbar current (A) 100A Max. operating voltage 230/240V @ 50Hz Max. cable capacity 25 mm2 (earth and neutral bars) Certification BS EN 61439-3

20 Easy9 Switch-disconnectors Characteristics Main characteristics Operating category AC-22 A Permissible rated short-time withstand current (Icw) 12 Ie, 1 secondConditional rated short-circuit current (Inc) 5000 A Rated short-circuit closing current (Icm) 15 Ie Additional characteristics Degree of protection (IEC 60529) Device only IP20 Endurance (O-C) Mechanical 40 -100 A 8500 cycles Electrical 40-100 A 1500 cycles Operating temperature -5°C to +55°C Storage temperature -5°C to +70°C Tropicalisation (IEC 60068-1) Treatment 2 (relative humidity 95 % to 55°C) Weight (g) Type Easy9 switch- disconnector 2P 175 Dimensions (mm) 2P 45 61 73 5.5 45 36 82 3 Position contact indicationSuitable for isolation according to BSEN 60947-3 standardManual control on front face by O-I lever

21 Easy9 Characteristics Main characteristics Rated impulse withstand voltage (Uimp) 4 kV According to IEC 61008-1 Making and breaking capacity (Im/IDm) 500 A Additional characteristics Degree of protection (IEC 60529) Device only IP20 Hazardous substances RoHS 2003 compliant Tropicalisation (IEC 60068-1) Treatment 2 (relative humidity 95 % to 55°C) Dimensions (mm) 5.5 68 45 61 45 62 2P 82 7 36 RCCB residual current circuit breakers Positive contact indication.Fault tripping indication on the front panel by the position of the handle (O - I engraved) Weight (g) Type Easy9 RCCB 2P 195

22 Easy9 Characteristics Main characteristics Voltage rating (Ue) 230/400 V AC Operating frequency 50/60 Hz Electrical feeding By the top and bottom Additional characteristics Degree of protection (IEC 60529) Device only IP20 Hazardous substances RoHS 2003 compliant Tropicalisation (IEC 60068-1) Treatment 2 (relative humidity 95 % to 55°C) Weight (g) Type Easy9 MCB 1P 100 Dimensions (mm) 45 5.5 61 72 45 5 70 18 1P 82 Miniature circuit breaker 6 kA Fault tripping indication on the front panel by the position of the handle (O - I engraved) Easy9 circuit breakers combine the following functions: Circuit protection against short-circuit currents.Circuit protection against overload currents.

23 Easy9 Weight (g) Type Easy9 RCBO 1P+N 180 Characteristics Main characteristics Endurance (O-C) Electrical 4000 cycles Mechanical 10000 cycles Additional characteristics Degree of protection Device only IP20 Overvoltage category (IEC 60364) IV Operating temperature -15°C to +60°C Storage temperature -40°C to +85°C Hazardous substances RoHS 2003 compliant Tropicalisation (IEC 60068-1) Treatment 2 (relative humidity 95 % to 55°C) Test "T" Operating test button, on the front panel RCBO residual current devices 6 kA Dimensions (mm) 50 5.5 61 72 45 5 110 18 44 Fault tripping indication on the front panel by the position of the handle (O - I engraved) Certified compliant BS EN 61009-1 Cable length 1000 mm

24 Easy9 MCB selection chart for household appliances Appliance Capacity MCB rating (A) Tripping curves Air conditioner 1 ton 16 "C" 1.5 ton 20 2 ton 20 3 ton 25 Refrigerator 165 litres 2 285 litres 2 Water heater 1 kW 6 "B" 3 kW 16 Electric kettle 1.5 kW 10 Food processor (50 % load) 200 W 1 "C" Vacuum cleaner 50 W 0.5 Toaster 1.2 kW 6 "B" Cooking range 750 W 4 2 kW 10 4.5 kW 25 Room heater 1 kW 6 2 kW 10 Washing machine 300 W 2 "C" 1.3 kW 10 Electric iron 750 W 6 "B" 1.25 kW 6 Time current tripping curves t(s) 0,01 0,1 1 10 100 1000 I / In 1 3...5 6.4...9.6 C B Miniature circuit breakers Selection

Easy9 25 Circuit protection MCB current rating Single-phase circuit Cable cross section (in mm 2 ) 1.5 2.5 4 6 10 16 25 35 Type of installation Maximum rating of the circuit breaker used there (in Ampere) A: in conduit or directly in thermally insulated wall, moulding, architrave, window frame Single core 10 16 25 32 40 50 80 80 Multicore 10 16 25 32 40 50 70 80 B: in conduit in a wall, in conduit trunking or cable duct on a wall, in building cavity Single core 16 20 32 40 50 70 100 125 Multicore 16 20 25 32 50 50 80 80 C: direct on a wall, suspended from ceilings, on unperforated cable tray, in masonry wall Single core or multicore 16 25 32 40 63 80 100 125 D: in conduit in the ground Multicore or single core 20 25 32 40 50 70 80 80 D: directly in the ground Multicore or single core 20 25 32 40 63 80 100 125 E: in free-air, on cable ladder, on perforated cable tray Multicore d u 0.3 d 20 25 40 40 70 80 100 125 Miniature circuit breakers Selection of circuit breakers according to the cables to be protected (BS 7671) ■ PVC-insulated, copper, flexible or rigid cable. ■ Ambient temperature: ■ 30°C in the open air (methods A, B, C, E) ■ 20°C if buried (method D), ■ For other situations, refer to BS 7671standard (or UK wiring regulations). Function ■ Protection from short-circuits. ■ Protection of cable from overload.

Easy9 26 Earth leakage protection Residual current devices Research worldwide shows that the intensity of current flowing through the body determines the extent and severity of an electric shock. Operating principle Protection from electric shocks by direct contact: ■ Injuries become serious when currents exceed 40 to 50 mA during one second. ■ Theoretically, a 150 mA current flows through the body when a person touches a 230 V energised conductor under dry conditions. By measuring the intensity difference between live and neutral conductors, RCDs actually detect the current flowing through the human body. If this current reaches the 30 mA limit, the RCD trips within a few milliseconds, so preventing injury or worse. Check RCDs regularly Test Perception 0.5 mA 10 mA 40 mA 80 mA 1 A Cardiac arrest Muscular contraction Burns respiratory Severe burns ventricular fibrilation Function ■ Protection of persons against electric shock by direct contact (30 mA). ■ Protection of installations against the risk of fire (300 mA). ■ Protection of persons against electric shock by indirect contact (100 mA to 300 mA). 30 mA 16 A 30 mA RCD Testing the RCD every 3 months enables detection of any event that may have impaired its operation

27 Easy9 Selection Residual current sensitivity Protection from Residential Non-residential Sensitivity Electric shocks by direct contact b Mandatory protection for all socket outlets b Mandatory protection for all electrical equipment in bathroom b Recommended for lighting circuits b Mandatory protection for all socket outlets b Mandatory protection for all equipement located b Close to water points b 30 mA b 10 mA for all applications where required by the standard (e.g.: jacuzzi, swimming pools, etc.) Fire ignited by leakage current b Recommended in old buildings (presence of dust or moisture) b Mandatory in all locations under risk of fire or explosion b Recommended in all premises under presence of dust, moisture, chemical agents… b 300 mA Electric shock by indirect contact b All circuits in case of "TT" earthing system b All circuits in case of "TT" earthing system b 100 mA or 300 mA Requirements from wiring regulation (411.3.3) Protection by means of a residual current protective device (RCD), shall be provided for: ■ Socket outlets with a rated current not exceeding 20 A, that are for ordinary persons and intended for general use, mobile equipment with a current rating not exceeding 32 A for use outdoors. ■ In rooms containing a bath or a shower. Current rating: shall not be in excess of upstream MCB current rating Bathroom Residual current devices Selection guide
