Philips - Coreline - LED Range - Catalogue - 2016

Whether for a new building or renovation of an existing space, customers want lighting solutions that provide quality of light and substantial energy and maintenance savings. The new CoreLine range of LED luminaires oers stylish, energy-saving, aordable, and easy-to-install lighting solutions - viable replacements for traditional lighting technologies across numerous applications.

Product guide For every space, every solution LED Range CoreLine

3 2 26 Overview products Case studies See how the different sensors can make your installation more flexible and optimise energy savings. Get the full specifications for every product in the range. Maximise energy savings as well as user comfort with our ready-to-use product combinations. Go online for a complete CoreLine resource. Read the story behind the development of CoreLine. 22 30 6 Application bundles CoreLine website Tailor made 18 Overview controls CoreLine LED Range Index Meet CoreLine: the complete range of LED lighting 4 8 Introduction 20, 24 & 29 The complete range Discover every CoreLine product available today.

5 4 www.philips.co.uk/coreline Whether for a new building or renovation of an existing space, customers want lighting solutions that provide quality of light and substantial energy and maintenance savings. The new CoreLine range of LED luminaires offers stylish, energy-saving, affordable, and easy-to-install lighting solutions - viable replacements for traditional lighting technologies across numerous applications. For every space, every solution Using LED lighting technology across the range allows longer lifetimes, which means reduced maintenance and fewer replacement parts, plus energy savings of up to 75% compared with traditional lighting fixtures - all leading to more sustainable lighting solutions.

7 6 CoreLine LED Range Tailor made Tailor made Riemer Adema Product Manager at Philips Lighting “Installers have given us valuable insights on design trade-offs and installation.” CoreLine products are developed with the installer’s perspective in mind.” to a new technology without compromising anything. They get an amazing quality of light with all the added benefits of LED - energy savings and long lifetime.” How was the range developed?“For all CoreLine products, as they were being designed, samples were shown to installers. We wanted to validate the concept and get feedback from them at an early stage. That helped us get the functional specifications right and create products that were easy to install. What makes the CoreLine range special?“CoreLine products are developed with the installer’s perspective in mind. What makes CoreLine special is that we have created a range of products that help clients move We used architecture studies to see how to fit in the LED board and driver. Next, the design and R&D teams stepped in, and finally the products were manufactured and tested. The marketing and sales teams then prepared the product introduction, and the range went on sale.” How did you incorporate installer feedback?“Let me give you an example. CoreLine Wall-mounted was co-developed with a partner installer, right from the initial drawing stage up until the product launch. The installer gave us valuable insights on design trade-offs and installation specifics. It’s all in the details. Things like two-hand installation, a good fit for different power cable diameters, etc. It’s those little things that make a really big difference.” How has the market responded to CoreLine?“We are hearing great things from our installers, and they are getting good feedback from their clients. The range is sold everywhere in Europe - but also in Russia, Turkey and the Middle East, and even in New Zealand and Australia. We’ve also seen great response from our wholesale partners, who have embraced CoreLine because it offers such a complete solution.” What are the latest developments? “I think the biggest change has been adding lighting controls. Installers tell us that their clients are really interested in this, and rightly so. Controls can increase the energy savings by up to 80%, and they also enhance the level of comfort and well-being. To make things simpler for installers, we added our own matching controls for each CoreLine product. Now we can guarantee compatibility, so that the combination of luminaire and control always works.”

9 8 the complete range The quality and light levels delivered by the CoreLine range enable point-for-point replacement of similar traditional lighting fixtures. Simply remove the old fixture and fit the new innovative LED CoreLine solution; virtually no need for expensive rewiring or new ceiling configurations. Want increased lighting comfort & additional energy savings? CoreLine Waterproof CoreLine Tempo CoreLine Integrated Spot CoreLine Downlight CoreLine High-bay CoreLine Surface-mounted CoreLine Trunking CoreLine Batten CoreLine Panel CoreLine Wall-mounted Mini Pentura CoreLine Recessed CoreLine By simply adding lighting controls with CoreLine luminaires - significant additional savings can be made on costs associated with energy and carbon; reducing the payback time of the installation. Lighting need only be on where and when needed. Movement and presence detection controls can help you to simply achieve this - reducing costs, whilst still ensuring comfort and safety. CoreLine dedicated controls; the clear choice for many applications. The look and feel of CoreLine solutions is consistent - ease of installation, coupled with quality finishes across the range, ensures CoreLine is the clear choice for LED. The installer touch-points are highlighted with green colours, which are consistent across the CoreLine range. The product label is recognisable with a QR tag. CoreLine LED Range The complete range

11 10 CoreLine LED Range Product overview CoreLine Panel CoreLine Recessed CoreLine Downlight Benefits • General lighting - replacing conventional TL-D & TL-5 • 3.3 x longer lifetime• Slim design & 35 mm height• Office compliant optic available - VAR-PC version Application General lighting Benefits • Substantial energy savings and longer lifetime reduce operational cost • One-for-one replacement from conventional luminaires to LED luminaires • Covers more professional applications due to DALI dimming and aluminium reflector Application General lighting in corridors / Retail stores / Reception areas / Indoor circulation areas Savings over life £171 Savings over life £168 TL-D / TL-5 CoreLine Recessed Wattage 63 W 72 W 40.5 W40.5 W Lifetime 25,000 hrs 15,000 hrs 50,000 hrs 50,000 hrs CFL EM CoreLine Downlight Wattage Mini Wattage Compact 54 W 66 W 11 W 22 W Lifetime 10,000 hrs 50,000 hrs Benefits • General lighting - replacing conventional TL-D & TL-5 • 3.3 x longer lifetime• Efficacy (lm/w) 83 lm/w • Warranty: 3 year• Easy connection Application General lighting TL-D / TL-5 CoreLine Panel Wattage 63 W 72 W 41 W 41 W Lifetime 25,000 hrs 15,000 hrs 50,000 hrs 50,000 hrs 75% 45% 40% Up to Up to Up to energy savings energy savings energy savings Based on UK average of 12p/kW hours including maintenance and lamp replacement cost. Savings over life 1100 lm £222 2100 lm £244

Halogen CoreLine Integrated Spot Wattage 54 W 10 W Lifetime 2,000 hrs 40,000 hours T5 Mini Pentura Wattage 14 W 7 W Lifetime 19,000 hrs 50,000 hrs 13 12 CoreLine LED Range Product overview CoreLine Surface-mounted CoreLine Integrated Spot Mini Pentura Benefits • IP65 Fire-rated LED Spot • Interchange bezels: • White Matt, White, Polished Chrome, Satin Nickel finishes • Quick Connect wiring function • Special reflector to replicate Halogen look • Dimmable as standard • Insulation cover supplied as standard– allows downlights to be IC rated • Driverless Technology Application Circulation areas / Kitchens / Bathrooms Benefits • Ultra-thin design for under-cabinet / shelf lighting and cove lighting • 40% energy saving • Easy to install – coupling part- integrated in the housing, all accessories are included in the box • Install and forget – no maintenance or lamp replacement • Homogenous light line effect (no dots or shadows) Application Under-cabinet lighting / under-shelf lighting / Cove lighting Benefits • General lighting - replacing conventional TL-D & TL-5 • 3.3 x longer lifetime• Slim design & 40 mm height• Suspension set available for suspended applications Application General lighting TL-D / TL-5 CoreLine Surface-mounted Wattage 63 W 72 W 40.5 W 40.5 W Lifetime 25,000 hrs 15,000 hrs 50,000 hrs 50,000 hrs Savings over life £66 Savings over life £171 Savings over life £330 40% 95% 45% Up to Up to Up to energy savings energy savings energy savings Based on UK average of 12p/kW hours including maintenance and lamp replacement cost.

15 14 CoreLine Waterproof CoreLine Batten CoreLine Wall-mounted Benefits • General lighting - replacing conventional TL-D • 3.3 x longer lifetime• Installation flexibility & lengths same as TL-D • Excellent performance & light quality with frosted diffuser Application General lighting / Assembly lines / Cove lighting Benefits • General lighting - replacing traditional wall-mounted luminaires • 5 x longer lifetime• IP65 & IK10 with built-in controls• Dimmable Application Corridors / Staircases / Public entrance areas / Bathrooms / Emergency exits / Car parks / Outdoor safety lighting Benefits • Industrial lighting - replacing conventional TL-D & TL-5 • 3.3 x longer lifetime• Installation flexibility and lengths same as TL-D • Excellent performance & sleek design• IP65 & IK08 rated Application Car parks / Warehouses / General lighting TL-D CoreLine Waterproof Wattage 2 x 18 W 1 x 36 W 2 x 36 W 1 x 58 W 2 x 58 W 17 W20 W38 W29 W57 W Lifetime 15,000 hrs 50,000 hrs TL-D CoreLine Batten Wattage 2 x 18 W 2 x 36 W 20 W 40 W Lifetime 15,000 hrs 50,000 hrs Electronic PL-C CoreLine Wall-mounted Wattage 1 x 18 W 2 x 18 W 2 x 26 W 8 W 18 W 24 W Lifetime 10,000 hrs 50,000 hrs Savings over life LED12S £131 LED16S £177 Savings over life LED19S £96 LED38S £166 Savings over life LED40S £175 LED60S £285 55% 40% 50% Up to Up to Up to energy savings energy savings energy savings CoreLine LED Range Product overview Based on UK average of 12p/kW hours including maintenance and lamp replacement cost.

17 16 CoreLine Tempo CoreLine Trunking CoreLine High-bay Benefits • Replacement for conventional TL-D & TL-5 • 3.6 x longer lifetime• Reduced maintenance & best lumens per £ solution • Excellent beam shapes & sparkle for product enhancement Application Supermarkets / Warehouses / Assembly areas Benefits • Industrial lighting - point-for-point replacement of 250 W & 400 W conventional HPI high-bays • 5 x longer lifetime• Reduced maintenance• Excellent performance & light quality - CRI ≥ 80 Application Warehouses / Industry / Exhibition halls / Supermarkets Benefits • Point-to-point replacement from 70 W to 250 W conventional floodlight • More light control. Light where is needed • Instant light, long lifetime• Reliable Quality: Die-casting aluminium housing guarantees robustness, vibration-proof, wind force protection Application General outdoor / Area lighting / Industrial Areas / Billboards / Car parks / Building facades energy savings Savings over life £1111 HPI CoreLine High-bay Wattage 250 W 400 W 85 W 155 W Lifetime 10,000 hrs 50,000 hrs Savings over life £480 TL-D EM CoreLine Trunking Wattage 133 W 62 W (1.7 m) Lifetime 15,000 hrs 70,000 hrs Savings over life £666 HID CoreLine Tempo Wattage 70 W150 W250 W 40 W80 W120 W Lifetime 20,000 hrs 50,000 hrs Based on UK average of 12p/kW hours including maintenance and lamp replacement cost. 66% 55% 50% Up to Up to Up to energy savings energy savings CoreLine LED Range Product overview

2 4 3 5 1 19 18 Overview controls Benefits • Up to 30% additional energy savings • Small, unobtrusive sensor - detects subtle movement• Increased lifespan of installation - turns off lighting when not required Presence Detector LRM1011 Benefits • Up to 50% additional energy savings • Movement detector unit replaces traditional light switch• Retrofit possible (use LRM1033)• Increased lifespan of installation - turns off lighting when not required Movement Detector LRM1032 Benefits • Up to 70% additional energy savings • Daylight override sensor prevents switch on if enough daylight is available • Up to 20 years usage• Increased lifespan of installation - turns off lighting when not required • Wall and ceiling mounting possibility• IP54 Movement Detector LRM1040 Open plan office example Restroom example Small car park example Calculate total cost of ownership in 5 steps CoreLine LED Range TCO Many clients renew their lighting installation for the great energy savings LED offers. But there’s more: LEDs have a much longer lifetime and lower maintenance costs. All of these factors together determine the Total Cost of Ownership (TCO) - a very useful selling point that shows the long-term savings LED brings. With these five simple steps, you can instantly show your clients their TCO savings! Determine which conventional product is used in the installation Type in the average price Determine key usage data The online tool automatically calculates the TCO Start the online TCO calculator go to: www.philips.co.uk/coreline Luminaire Detector Mains to luminaire Presence Detector LRM1000 Benefits • Up to 30% additional energy savings • Increased lifespan of installation - turns off lighting when not required • Detects subtle movement• Surface mounted sensor installation Classroom example

21 20 CoreLine Recessed Panel Case study Philips CoreLine enriches library’s learning environment Installation of Philips CoreLine LED luminaires in the library at Millfield School in Somerset will deliver nearly £70,000 worth of energy savings over a 10 year period, while reducing the school’s carbon dioxide emissions by over 39 tonnes per annum. Millfield School was founded in 1935 and, along with its preparatory school, has some 1700 pupils and over 600 employees. The library was built in the late 1970s and the original lighting comprised surface-mounted T12 fluorescent luminaires sunk in concrete ‘pots’ with pine louvres. The school’s Head of Electrical, Andy Ellis, recalled: “The lighting quality wasn’t as good as we would have liked, with low light levels in some areas of the library, and the wooden slats in the ceiling gave the light a yellowy tinge. In addition, the system was not energy-efficient and had high maintenance requirements. It was also becoming increasingly difficult and expensive to source replacement lamps.” While there had been a desire to replace the lighting for some time, the complexity of the existing ceiling arrangement meant this would not be a standard luminaire replacement project. Having considered a number of options, the school adopted a proposal put forward by electrical wholesaler Electric Center and Philips Lighting. “One of the key problems was that simply removing the existing luminaires and louvres would leave gaps in the ceiling,” explained Chris Plant from Electric Center’s Taunton branch. “The proposed solution involved having the school’s estates department construct a ceiling that the CoreLine luminaires could be recessed into. “We therefore sent a number of CoreLine fittings to the school so that the estates staff could work with them in designing the ceiling, while also testing the performance of the luminaires. The ceiling space was restricted but sufficient to accommodate the low profile CoreLine design,” he added. The initial trial proved very successful and the 123 fluorescent fittings in the library have now been replaced with seventy 300mm x 1200mm CoreLine LED luminaires. Light level readings before and after the upgrade show that light levels have improved considerably. For example, illuminance levels on the middle floor computer area have increased from 124 lux to 724 lux, with similar results on the lower floor. The installed electrical load has been reduced from over 27kW to just 2.94kW. “Given that the lighting is on for at least 12 hours a day, we will also save a considerable amount of energy – around 700,000kWh over the next 10 years. Maintenance costs will also be reduced and the fact that our estates department was able to carry out the work reduced the installation costs considerably, giving us an even faster return on investment,” he concluded. The light quality is much better and the improved colour rendering has enhanced the décor of the spaces” Andy Ellis Head of Electrical

23 22 CoreLine LED Range Application bundles Application bundles Corridor CoreLine Downlight LED20S & Presence detector LRM1011 Industry CoreLine Waterproof LED60S & Movement detector LRM1040 Classroom CoreLine Surface-mounted LED34S VAR-PC & Presence detector LRM1000 Small car park CoreLine Waterproof LED40S & Movement detector LRM1040 Small storage CoreLine Batten LED38S & Movement detector LRM1032 With the introduction of LED technology, lighting has entered the 21 st century. Compared to conventional products, LED lamps and luminaires offer much lower energy consumption and a much longer lifetime. Also, as a digital light source, LED luminaires offer many new possibilities in terms of intelligent lighting. Getting the combination right To help installers make the most of the technical and commercial potential of LED, Philips has created special virtual packages called ‘Application bundles’. These bundles are based on real-life applications that will benefit from having the right combination of LED luminaires, or of luminaires and controls. As most elements are part of the popular CoreLine range, compatibility is guaranteed, and installation is hassle-free. Office CoreLine VAR-PC Recessed LED34S & Presence detector LRM1011 70% 75% 70% 70% 65% 80% Up to Up to Up to Up to Up to Up to energy savings energy savings energy savings energy savings energy savings energy savings

25 24 CoreLine Wattage Lifetime Save up to Luminous Flux Colour Temp. CRI Product description EOC code Wall-mounted 24 W 50,000 hrs 55% 1600 lm 4000 K ≥ 80 WL120V LED16S/840 PSR WH 06633199 18 W 50,000 hrs 50% 1200 lm 4000 K ≥ 80 WL120V LED12S/840 PSR WH 06635599 8 W 50,000 hrs 55% 500 lm 4000 K ≥ 80 WL121V LED5S/840 PSR WH 06637999 24 W 50,000 hrs 55% 1600 lm 3000 K ≥ 80 WL120V LED16S/830 PSR WH 06639399 18 W 50,000 hrs 50% 1200 lm 3000 K ≥ 80 WL120V LED12S/830 PSR WH 06641699 8 W 50,000 hrs 55% 500 lm 3000 K ≥ 80 WL121V LED5S/830 PSR WH 06643099 24 W 50,000 hrs 55% 1600 lm 4000 K ≥ 80 WL120V LED16S/840 PSR MDU WH 24117200 18 W 50,000 hrs 50% 1200 lm 4000 K ≥ 80 WL120V LED12S/840 PSR MDU WH 24105900 8 W 50,000 hrs 55% 500 lm 4000 K ≥ 80 WL121V LED5S/840 PSR MDU WH 24290200 24 W 50,000 hrs 55% 1600 lm 3000 K ≥ 80 WL120V LED16S/830 PSR MDU WH 24111000 18 W 50,000 hrs 50% 1200 lm 3000 K ≥ 80 WL120V LED12S/830 PSR MDU WH 24099100 8 W 50,000 hrs 55% 500 lm 3000 K ≥ 80 WL121V LED5S/830 PSR MDU WH 24288900 Batten 40 W 50,000 hrs 40% 3800 lm 4000 K ≥ 80 BN120C LED38S/840 PSU L1200 89957999 20 W 50,000 hrs 40% 1900 lm 4000 K ≥ 80 BN120C LED19S/840 PSU L600 89955599 40 W 50,000 hrs 40% 3800 lm 4000 K ≥ 80 BN121C LED38S/840 PSU L1200 89958699 20 W 50,000 hrs 40% 1900 lm 4000 K ≥ 80 BN121C LED19S/840 PSU L600 89956299 40 W 50,000 hrs 40% 3800 lm 3000 K ≥ 80 BN120C LED38S/830 PSU L1200 89961699 20 W 50,000 hrs 40% 1900 lm 3000 K ≥ 80 BN120C LED19S/830 PSU L600 89959399 40 W 50,000 hrs 40% 3800 lm 3000 K ≥ 80 BN121C LED38S/830 PSU L1200 89962399 20 W 50,000 hrs 40% 1900 lm 3000 K ≥ 80 BN121C LED19S/830 PSU L600 89960999 Waterproof 17 W 50,000 hrs 53% 1800 lm 4000 K ≥ 80 WT120C LED18S/840 PSU L600 84045900 20 W 50,000 hrs 44% 2200 lm 4000 K ≥ 80 WT120C LED22S/840 PSU L1200 84046600 29 W 50,000 hrs 50% 3400 lm 4000 K ≥ 80 WT120C LED34S/840 PSU L1500 84047300 38 W 50,000 hrs 47% 4000 lm 4000 K ≥ 80 WT120C LED40S/840 PSU L1200 84048000 57 W 50,000 hrs 50% 6000 lm 4000 K ≥ 80 WT120C LED60S/840 PSU L1500 84049700 High-bay 155 W 50,000 hrs 61% 20,500 lm 4000 K ≥ 80 BY121P G3 LED205S/840 PSU WB GR 30145700 85 W 50,000 hrs 66% 10,500 lm 4000 K ≥ 80 BY120P G3 LED105S/840 PSU WB GR 30144000 155 W 50,000 hrs 61% 20,500 lm 4000 K ≥ 80 BY121P G3 LED205S/840 PSD WB GR 30147100 85 W 50,000 hrs 66% 10,500 lm 4000 K ≥ 80 BY120P G3 LED105S/840 PSD WB GR 30146400 n/a n/a n/a n/a n/a n/a BY121Z G2 MB (Mounting bracket) 29608199 n/a n/a n/a n/a n/a n/a BY120Z G2 MB (Mounting bracket) 29607499 Trunking 124 W (3.4 m) 70,000 hrs 54% 4000 lm 4000 K ≥ 80 LL120X LED160S/840 PSD WB 7 WH 88143800 74 W (3.4 m) 70,000 hrs 51% to 7000 lm 4000 K ≥ 80 LL120X LED90S/840 PSU DA20 5 WH 88184100 62 W (1.7 m) 70,000 hrs 54% (per 1.5 m) 4000 K ≥ 80 LL121X LED80S/840 PSD WB 7 WH 88142100 37 W (1.7 m) 70,000 hrs 51% 4000 K ≥ 80 LL121X LED45S/840 PSU DA20 5 WH 88183400 Tempo 120 W 50,000 hrs 52% 13,200 lm 4000 K ≥ 80 BVP120 LED120/NW S 29587900 80 W 50,000 hrs 46% 8800 lm 4000 K ≥ 80 BVP120 LED80/NW S 29586200 40 W 50,000 hrs 43% 4400 lm 4000 K ≥ 80 BVP120 LED40/NW S 29585500 120 W 50,000 hrs 52% 13,200 lm 4000 K ≥ 80 BVP120 LED120/NW A 29590900 80 W 50,000 hrs 46% 8800 lm 4000 K ≥ 80 BVP120 LED80/NW A 29589300 40 W 50,000 hrs 43% 4400 lm 4000 K ≥ 80 BVP120 LED40/NW A 29588600 Overview products CoreLine Wattage Lifetime Save up to Luminous Flux Colour Temp. CRI Product description EOC code Downlight 11 W 50,000 hrs 80% 1100 lm 3000 K ≥ 80 DN130B LED10S/830 PSU PI6 WH 85222400 11 W 50,000 hrs 80% 1100 lm 4000 K ≥ 80 DN130B LED10S/840 PSU PI6 WH 85269900 22 W 50,000 hrs 75% 2100 lm 3000 K ≥ 80 DN130B LED20S/830 PSU PI6 WH 85224800 22 W 50,000 hrs 75% 2100 lm 4000 K ≥ 80 DN130B LED20S/840 PSU PI6 WH 85271200 11 W 50,000 hrs 80% 1100 lm 3000 K ≥ 80 DN131B LED10S/830 PSU PI6 ALU 85226200 11 W 50,000 hrs 80% 1100 lm 4000 K ≥ 80 DN131B LED10S/840 PSU PI6 ALU 85273600 22 W 50,000 hrs 75% 2100 lm 3000 K ≥ 80 DN131B LED20S/830 PSU PI6 ALU 85228600 22 W 50,000 hrs 75% 2100 lm 4000 K ≥ 80 DN131B LED20S/840 PSU PI6 ALU 85275000 Recessed 40.5 W 50,000 hrs 45% 3700 lm 4000 K ≥ 80 RC120B LED37S/840 PSU W60L60 89755199 24.5 W 50,000 hrs 55% 2700 lm 4000 K ≥ 80 RC120B LED27S/840 PSU W60L60 89756899 40.5 W 50,000 hrs 45% 3700 lm 4000 K ≥ 80 RC120B LED37S/840 PSU W30L120 89757599 24.5 W 50,000 hrs 55% 2700 lm 4000 K ≥ 80 RC120B LED27S/840 PSU W30L120 89758299 Panel 41 W 50,000 hrs 40% 3400 lm 4000 K ≥ 80 RC125B LED34S/840 PSU W60L60 06731400 41 W 50,000 hrs 40% 3400 lm 3000 K ≥ 80 RC125B LED34S/830 PSU W60L60 06732100 Mini Pentura 14W 50,000 hrs 60% 1100 lm 4000 K ≥ 80 BN130C LED10S/840 PSU L1185 29647099 14W 50,000 hrs 60% 1000 lm 3000 K ≥ 80 BN130C LED10S/830 PSU L1185 29648799 11W 50,000 hrs 60% 800 lm 4000 K ≥ 80 BN130C LED8S/840 PSU L885 29649499 11W 50,000 hrs 60% 800 lm 3000 K ≥ 80 BN130C LED8S/830 PSU L885 29650099 7W 50,000 hrs 67% 600 lm 4000 K ≥ 80 BN130C LED6S/840 PSU L585 29651799 7W 50,000 hrs 67% 500 lm 3000 K ≥ 80 BN130C LED5S/830 PSU L585 29652499 4W 50,000 hrs 71% 300 lm 4000 K ≥ 80 BN130C LED3S/840 PSU L325 29653199 4W 50,000 hrs 71% 300 lm 3000 K ≥ 80 BN130C LED3S/830 PSU L325 29654899 CoreLine Integrated Spot 10W 40,000 hrs 95% 550 lm 3000 K ≥ 80 RS145B 830 PSR 40D WH MW 62391100 10W 40,000 hrs 95% 550 lm 3000 K ≥ 80 RS145B 830 PSR 40D WH PC 62392800 10W 40,000 hrs 95% 550 lm 3000 K ≥ 80 RS145B 830 PSR 40D WH SN 62393500 10W 40,000 hrs 95% 550 lm 3000 K ≥ 80 RS145B 830 PSR 40D WH WH 62394200 10W 40,000 hrs 95% 480 lm 4000 K ≥ 80 RS145B 840 PSR 40D WH MW 62395900 10W 40,000 hrs 95% 480 lm 4000 K ≥ 80 RS145B 840 PSR 40D WH PC 62396600 10W 40,000 hrs 95% 480 lm 4000 K ≥ 80 RS145B 840 PSR 40D WH SN 62397300 10W 40,000 hrs 95% 480 lm 4000 K ≥ 80 RS145B 840 PSR 40D WH WH 62398000 Surface-mounted 40.5 W 50,000 hrs 45% 3700 lm 4000 K ≥ 80 SM120V LED37S/840 PSU W60L60 89759999 24.5 W 50,000 hrs 55% 2700 lm 4000 K ≥ 80 SM120V LED27S/840 PSU W60L60 89760599 40.5 W 50,000 hrs 45% 3700 lm 4000 K ≥ 80 SM120V LED37S/840 PSU W20L120 89761299

27 26 The Philips CoreLine range is a high-quality series of LED luminaires and sensors that work seamlessly together. But Philips offers you much more – on our website, you’ll find a wide choice of free lighting tools that help you make the most of our products. From detailed case studies to helpful installation videos, these services complement our CoreLine products perfectly and help you do your work even better. CoreLine www.philips.co.uk/coreline What better way to discover new lighting solutions than to see how the products have been used before? Read up on our case studies and pick up some extra inspiration! Go on an interactive virtual 360° building tour to see CoreLine in action. Take the full tour to see every space, or choose the product or application you want to see. Showcase Case studies Deploying CoreLine products is a breeze with our specially developed installation videos. Get your step-by-step guide for every product in the range. Installation videos CoreLine LED Range Website is just the beginning

© 2015 Koninklijke Philips N.V. All rights reserved. Philips reserves the right to make changes inspecifications and/or to discontinue any product at any time without notice or obligation andwill not be liable for any consequences resulting from the use of this publication. www.philips.co.uk/corelineMay 2016
