Power catalogue 2018
Megger

Power catalogue 2018

Test instruments for the maintenance of electrical power systems

Megger

Power catalogue 2018

Published: 27 June 2019 · Category: Product Catalogues & Brochures

Test instruments for the maintenance of electrical power systems

From this document

Test instruments for the maintenance of electrical power systems New products Hand-held power quality analyser MPQ Series Unmatched capability in a smart easy to use package. See page 53 Advanced Earth Tester DET2/3 MPQ2000 Robust and compact automatic earth (ground) test instrument. See page 54 MPQ1000 DET2/3 Transformer Ohmmeter MTO106 6A Two Winding Transformer Ohmmeter See page 29 Battery Load Unit TORKEL950 Load or discharge testing on battery systems ranging upto 500 V. MTO106 TORKEL950 MVCT PD Scan See page 57 Current transformer and Voltage transformer tester MVCT Portable, light-weight and highly versatile CT and VT tester test set See page 27 Medium voltage switchgear substation surveying system PD Scan Hand-held tool for on-line detection of PD activity in MV cables and plant. See page 36 Cable test van system CENTRIX 2.0 Combining cable testing, cable diagnostics and cable fault techniques. See page 42 2 Test instruments for electrical power systems CENTRIX 2.0 www.megger.com INSULATION TESTING AND CABLE FAULT LOCATION CONTINUITY Cable test van systems P 40 - 43 DC diagnostic P4–5 Test van equipment P 44 - 45 DC highvoltage or withstand P6–7 Time domain reflectometers TDRs P 46 - 47 AC insulation testing P8–9 Portable cable fault systems P 48 - 49 Low resistance testing P 10 – 11 POWER PROTECTION Circuit breaker testing Cable fault pin-pointers P 50 Sheath fault locators P 51 Cable route tracing and identification P 52 GENERAL ELECTRICAL TEST Contact resistance...
