LINIAN sizing guide
Linian

LINIAN sizing guide

Find the right LINIAN clip for your cables with their detailed size guide.

Linian

LINIAN sizing guide

Published: 26 February 2026 · Category: Product Catalogues & Brochures

Find the right LINIAN clip for your cables with their detailed size guide.

From this document

Sizing Guide 1 2021 Standard Fire Rated Soft Skin Cable Cable size Nominal cable cross sectional area Cable overall diameter 2021 Sizing Guide 2 Standard Fire Rated Soft Skin Cable Recommended clip size Part number DISCLAIMER: sizing may vary (x) = colour i.e. B for black, R for Red, W for white and GALV for Galvanised slightly according to manufacturer Cable size Recommended clip size Part number DISCLAIMER: sizing may vary (x) = colour i.e. B for black, R for Red, W for white and GALV for Galvanised Nominal cable cross Cable overall diameter slightly according to manufacturer 1mm 12.1mm 12-14mm Superclip (single cable only) 1LS(X)1214 1.5mm 13.3mm 12-14mm Superclip (single cable only) 1LS(X)1214 2.5mm 16.3mm 15-18mm Superclip (single cable only) 1LS(X)1518 1.5mm 17.5mm 15-18mm Superclip (single cable only) 1LS(X)1518 2.5mm 21.7mm 20-22mm Superclip (single cable only) 1LS(X)2022 1.5mm 20.5mm 20-22mm Superclip (single cable only) 1LS(X)2022 sectional area 7 CORE 2 CORE 1mm 8mm 6-8mm Single ( x 1 cable) OR 6-8mm Double ( x 2 cables) 1LC(X)608 OR 1LC(X)682 1.5mm 8.1mm 6-8mm Single ( x 1 cable) OR 6-8mm Double ( x 2 cables) 1LC(X)608 OR 1LC(X)682 2.5mm 9.5mm 9-11mm Single (x 1 cable) OR 9-11mm Double (x 2 cable) 1LC(X)911 OR 1LC(X)9112 4mm 11.6mm 9-11mm Single (x 1 cable) OR 9-11mm Double (x 2 cable) 1LC(X)911 OR 1LC(X)9112 12 CORE 3 CORE 1mm 8.2mm 6-8mm Single ( x 1 cable) OR 6-8mm Double ( x 2 cables) 1LC(X)608 OR 1LC(X)682 1.5mm 8.4mm 6-8mm Single ( x 1 cable) OR 6-8mm Double...
