www.osram.com/backlighting 1 Check list Light ceiling/wall application Contact details   Date: Contact name Company/department Country E-mail Phone OSRAM distribution partner Room details Room dimensions [mm] Length: Width: Height: Type of material(e.g. concrete, wood, wallpaper, plaster, rock, carpet) Walls: Floor: Ceiling (excluding light ceiling): Please attach sketch or drawing of the room! Notes Light ceiling/wall details Type of application  Light ceiling  Light wall Type of lighting  Direct backlighting  Sidelighting  Decorative (low lux level)  General lighting (high lux level) Required illuminance level (lux level) On the fl oor: On the reference plane: On the wall: Desired color/color temperature  3000 K  RGBW  4000 K  Tunable white  6500 K Dimming solution  Yes  No Light management system Light ceiling/wall dimensions [mm] Length: Width: Height: Light ceiling mounting height [mm] Please attach sketch or drawing of light ceiling/wall if it's not rectangular or circular! Type of light-emitting surface material Transmission [%]: Manufacturer Product designation Thickness [mm]: Please select Please select

Check list  |   Light ceiling/wall application 2 OSRAM GmbH | Marcel-Breuer-Strasse 6 | 80807 Munich | Germany Fon +49 89 6213-0 | Fax +49 89 6213-2020 | [email protected] Sketch/drawing Please note: You can also send further documents via e-mail attachment.
