The synthesis of perfection IEC 309 HP Brochure IEC 309 HP - 2.indd   3 02/07/15   09:45

IEC 309 HP 2 Brochure IEC 309 HP - 2.indd   2 02/07/15   09:45

Perfection is a state of completeness and flawlessness. It's the quality of what is excellent, free of defects and with no further room for improvement. We speak of "perfection" when something is perfect in itself, in its very substance, and when it fulfils its aim. GEWISS interprets perfection as a search for solutions that guarantee the best in terms of technology, performance, reliability, practicality and safety. A perfection that takes on a tangible form in a range of products offering unbeatable quality of use. Where every single design choice conveys technical, practical and style excellence. Where each tiny part is designed to ensure optimum quality and style. Nothing is left to chance. Compromises are not acceptable. Because perfection accepts no compromise. Perfection  without  compromise Brochure IEC 309 HP - 2.indd   3 02/07/15   09:45

GEWISS has always been a point of reference in the production of  systems for energy distribution and management: in over    40 years, GEWISS has manufactured and sold more than 100 million  socket-outlets and plugs, establishing itself as a reliable partner for the entire  electro-technical market. IEC 309 HP - HIGH PERFORMANCE is a complete range of straight plugs and straight  and flush-mounting socket-outlets for currents from 16A to 125A with an IP44/IP54 and IP66/IP67 degree of protection (the straight versions have also a degree of IP68/IP69, unique worldwide). The product is at the top of its segment in terms of reliability, practicality,  IEC 309 HP 4 Brochure IEC 309 HP - 2.indd   4 02/07/15   09:45

performance and technical characteristics when it comes to industrial connections.    The devices are distinguished by their coordinated, modern, practical design that makes them instantly recognisable and adds extra value to the entire GEWISS system of industrial connections.The new GEWISS range is based on three elements: three atoms that together form a single molecule. Three key features that guided the technical and style development of each part. To ensure an innovative, perfect product. Reliability, practicality, performance: with the IEC 309 HP range, perfection has found its ideal form.  16 32 63 125 Brochure IEC 309 HP - 2.indd   5 02/07/15   09:45

Brochure IEC 309 HP - 2.indd   6 02/07/15   09:45

Straight IP44 / IP54 Straight IP44 / IP54 10° flush-mounting IP44 / IP54 Straight IP66 / IP67 / IP68 / IP69 Straight IP66 / IP67 / IP68 / IP69 10° flush-mounting IP66 / IP67 Straight IP44 / IP54 Straight IP44 / IP54 10° flush-mounting IP44 / IP54 Straight IP66 / IP67 / IP68 / IP69 Straight IP66 / IP67 / IP68 / IP69 10° flush-mounting IP66 / IP67 Plugs Socket-outlets 16 32 16 32 63 125 63 125 The IEC 309 HP range Brochure IEC 309 HP - 2.indd   7 02/07/15   09:46

4 IP degrees for total protection  16 32   63 125 Apart from the IP66/IP67 degrees of protection envisaged by current Standards, the IEC 309 HP plugs and connectors have two additional degrees of protection - the first and only situation of its kind in the electrotechnical field: IP68 and IP69. The IP68 level allows the product to be immersed at considerable depth, while IP69 ensures that dust or liquids cannot enter, even with notable pressure at high temperatures. In addition, the nickel-plating on plug pins and sleeves offers the best protection against corrosion, oxidation and abrasion, even in applications with critical environmental conditions or in the presence of aggressive substances (e.g. marine/port installations). These characteristics reveal the excellent quality of the product, guaranteeing first class performance throughout its lifecycle. Easy, secure wiring  16 32   63 125 To make the wiring operations quicker and easier, the products of the  IEC 309 HP range are supplied with oriented terminals and fully loosened screws and lockscrews. The tip of the tightening tool is “caged” in the terminal seat to avoid any risk of it slipping and causing injury. The earth terminal is raised above the others to ensure maximum safety. The 63 and 125A versions are equipped with screw plate terminals with indirect tightening for optimum contact surface and pressure, even when using non-terminated cables. Excellent resistance to stress  16 32   63 125 The structural design includes rubberised surfaces the areas most at risk of knocks, and the use of high performance technopolymers. In this way, the socket-outlets and plugs offer optimum resistance to mechanical stress (IK09, equivalent to 10J), even at low temperatures (down to -25°C) and in real heavy-duty conditions. This means the range guarantees performance levels markedly higher than both regulations and market standards. IEC 309 HP 8 Brochure IEC 309 HP - 2.indd   8 02/07/15   09:46

Reliability Secure body/grip closure  63 125 In the 63-125A versions, the body-grip closure system (using stainless steel screws in brass inserts) ensures the right closure pressure and stability of the sealing gaskets in the various conditions of use and strain, even after being re-tightened again and again. For the utmost reliability of the body-grip coupling, the screws are fitted with an anti-slackening device; they are captive, and are supplied already loosened. The inserts have a wider contrast flange and are “embedded” in the straight connectors/plugs body. This type of coupling requires no particular rotation or handling, even when using cables with a larger section or insulation. Safe, easy and comfortable use  16 32   63 125 The special shape and the rubberised surfaces in the 63 and 125A versions ensure the best possible grip in any usage conditions, even when wearing work gloves and in the presence of water or moisture. The integration of the dual cable gland and cable clamp function in one single device drastically reduces installation times, resulting also in improved practicality and ease of cable tightening (even by hand). In the 63-125A versions, the rear part of the ring nut has a wide, firm base for safe opening and closing operations using tools. The nib on the body of versions up to 63A can be used as a coupling point for hanging the products up while it's being used. Brochure IEC 309 HP - 2.indd   9 02/07/15   09:46

Green materials  16 32   63 125 To ensure greater safety for people, animals and electrical safety equipment in the event of a fire, all the products of this range are made from halogen-free materials (in accordance with EN50267-2-2). The technopolymers also guarantee high resistance to UV rays and chemical agents. 16 32  Wiring times cut by half The 16-32A versions have screw wiring and quick spring wiring. Two technologies that guarantee extremely easy wiring operations and long-lasting connections resistant to knocks or vibrations. The technical and functional solutions applied in the quick wiring versions (i.e. levers that are easy to open or close, and coloured for quick polarity identification) mean that connection times are halved compared with traditional versions. Innovative, quick assembly  16 32   The SAFE LOCK body/grip closure system (common to all the 16-32A mobile versions) uses ¼ turn rotation coupling and anti-slackening friction. Closure is guaranteed by a ¼ turn safety screw that does not weaken with from repeated use. The user-friendly references on the product itself, and the click that indicates effective closure, ensure practicality, easy use, quick assembly, and the certainty of perfect coupling. Performance  &  Practicality IEC 309 HP 10 Brochure IEC 309 HP - 2.indd   10 02/07/15   09:46

16 32 63 125  Storage protection To ensure better protection and preservation during transport and storage, the products are individually packaged. The bar code on each pack allows the product to be identified, and also meets the latest logistic and commercial requirements. Solutions for any application  16 32   63 125 The IEC 309 HP range meets all the application needs of the industrial environment, both in terms of regulations and performance. The devices are manufactured to include every possible earth hour reference, thus opening the door to a world of new applications and installation situations in the most specialised and heavy duty contexts. Brochure IEC 309 HP - 2.indd   11 02/07/15   09:46

Industrial socket-outlets and plugs, energy and service distribution terminals, boards for work sites, surface-mounting distribution boards, interlocked switched socket-outlets: GEWISS offers an integrated system of pioneering industrial connections. Products that look beyond, that are designed and built to meet every possible need - even the most complex ones. A complete, innovative range that makes GEWISS the specialist and ideal partner for energy distribution and management systems. An advanced  connection system 68 Q-DIN range System of  surface-  mounting  distribution  boards 68 ACS range System of  worksite  boards  certified  EN 61439-4 IEC 309 HP 12 Brochure IEC 309 HP - 2.indd   12 02/07/15   09:46

SAT SOFTWARE IEC 309 range System of socket-outlets   and plugs (flush-mounting,  surface-mounting and 90°)   and multipliers/adapters 68 Q-MC range System of floor-mounting  boards for marine and campsites  IB range System of interlocked switched   socket-outlets up to  125A. The systems for energy distribution and management combine perfectly with a  technologically advanced selection of protection devices. Solutions to meet the varying needs in every application context and guarantee quality, safety and practicality. With a technical/sales network, and a specific customer service, GEWISS  can help professionals in the pre- and after-sales stages and in developing bespoke solutions.  GEWISS has also developed a free technical software suite  for electrical sector professionals, to assist in preparing estimates and designing electrical systems. Always at your side System of low voltage   industrial socket-outlets   and plugs (16-125A) IEC 309 HP  range Brochure IEC 309 HP - 2.indd   13 02/07/15   09:46

16A AND 32A LOW VOLTAGE INDUSTRIAL PLUGS AND SOCKET-OUTLETS TO IEC 309 STANDARDS - IEC 309 HP Rated   current (In) Rated  voltage (Un) Frequency Poles Reference h Straight plugs IP44/IP54 Straight plugs IP66/IP67/IP68/IP69 Fast wiring Screw wiring Fast wiring Screw wiring 16A 100 ÷ 130V 50/60 Hz 2P+E 4 GW 60 001 FH GW 60 001 H GW 60 023 FH GW 60 023 H 3P+E 4 GW 60 002 FH GW 60 002 H GW 60 024 FH GW 60 024 H 3P+N+E 4 GW 60 003 FH GW 60 003 H GW 60 025 FH GW 60 025 H 200 ÷ 250V 50/60 Hz 2P+E 6 GW 60 004 FH GW 60 004 H GW 60 026 FH GW 60 026 H 3P+E 9 GW 60 005 FH GW 60 005 H GW 60 027 FH GW 60 027 H 3P+N+E 9 GW 60 006 FH GW 60 006 H GW 60 028 FH GW 60 028 H 380 ÷ 415V 50/60 Hz 2P+E 9 GW 60 007 FH GW 60 007 H GW 60 029 FH GW 60 029 H 3P+E 6 GW 60 008 FH GW 60 008 H GW 60 030 FH GW 60 030 H 3P+N+E 6 GW 60 009 FH GW 60 009 H GW 60 031 FH GW 60 031 H 480 ÷ 500V 50/60 Hz 2P+E 7 GW 60 701 H GW 60 735 H 3P+E 7 GW 60 010 H GW 60 032 H 3P+N+E 7 GW 60 011 H GW 60 033 H 600 ÷ 690V 50/60 Hz 3P+E 5 GW 60 702 H GW 60 736 H 3P+N+E 5 GW 60 703 H GW 60 737 H 50V 100 ÷ 300 Hz 2P+E 10 GW 60 704 H GW 60 738 H 3P+E 10 GW 60 705 H GW 60 739 H 3P+N+E 10 GW 60 706 H GW 60 740 H 50V 300 ÷ 500 Hz 2P+E 2 GW 60 707 H GW 60 741 H 3P+E 2 GW 60 708 H GW 60 742 H 3P+N+E 2 GW 60 709 H GW 60 743 H 440 ÷ 460V 60 Hz 3P+E 11 GW 60 710 H GW 60 744 H 3P+N+E 11 GW 60 711 H GW 60 745 H 380V / 440V 50 Hz / 60 Hz 3P+E 3 GW 60 712 H GW 60 746 H 3P+N+E 3 GW 60 713 H GW 60 747 H transf. 50/60 Hz 2P+E 12 GW 60 714 H GW 60 748 H 3P+E 12 GW 60 715 H GW 60 749 H 50 ÷ 250V D.C. 2P+E 3 GW 60 716 H GW 60 750 H 250V D.C. 2P+E 8 GW 60 717 H GW 60 751 H 32A 100 ÷ 130V 50/60 Hz 2P+E 4 GW 60 012 FH GW 60 012 H GW 60 034 FH GW 60 034 H 3P+E 4 GW 60 013 FH GW 60 013 H GW 60 035 FH GW 60 035 H 3P+N+E 4 GW 60 014 FH GW 60 014 H GW 60 036 FH GW 60 036 H 200 ÷ 250V 50/60 Hz 2P+E 6 GW 60 015 FH GW 60 015 H GW 60 037 FH GW 60 037 H 3P+E 9 GW 60 016 FH GW 60 016 H GW 60 038 FH GW 60 038 H 3P+N+E 9 GW 60 017 FH GW 60 017 H GW 60 039 FH GW 60 039 H 380 ÷ 415V 50/60 Hz 2P+E 9 GW 60 018 FH GW 60 018 H GW 60 040 FH GW 60 040 H 3P+E 6 GW 60 019 FH GW 60 019 H GW 60 041 FH GW 60 041 H 3P+N+E 6 GW 60 020 FH GW 60 020 H GW 60 042 FH GW 60 042 H 480 ÷ 500V 50/60 Hz 2P+E 7 GW 60 718 H GW 60 752 H 3P+E 7 GW 60 021 H GW 60 043 H 3P+N+E 7 GW 60 022 H GW 60 044 H 600 ÷ 690V 50/60 Hz 3P+E 5 GW 60 719 H GW 60 753 H 3P+N+E 5 GW 60 720 H GW 60 754 H 50V 100 ÷ 300 Hz 2P+E 10 GW 60 721 H GW 60 755 H 3P+E 10 GW 60 722 H GW 60 756 H 3P+N+E 10 GW 60 723 H GW 60 757 H 50V 300 ÷ 500 Hz 2P+E 2 GW 60 724 H GW 60 758 H 3P+E 2 GW 60 725 H GW 60 759 H 3P+N+E 2 GW 60 726 H GW 60 760 H 440 ÷ 460V 60 Hz 3P+E 11 GW 60 727 H GW 60 761 H 3P+N+E 11 GW 60 728 H GW 60 762 H 380V / 440V 50 Hz / 60 Hz 3P+E 3 GW 60 729 H GW 60 145 H 3P+N+E 3 GW 60 730 H GW 60 763 H transf. 50/60 Hz 2P+E 12 GW 60 731 H GW 60 764 H 3P+E 12 GW 60 732 H GW 60 765 H 50 ÷ 250V D.C. 2P+E 3 GW 60 733 H GW 60 766 H 250V D.C. 2P+E 8 GW 60 734 H GW 60 767 H For further commercial information, refer to the BUILDING catalogue. IEC 309 HP 14 Brochure IEC 309 HP - 2.indd   14 02/07/15   09:46

16A AND 32A LOW VOLTAGE INDUSTRIAL PLUGS AND SOCKET-OUTLETS TO IEC 309 STANDARDS - IEC 309 HP Rated   current (In) Rated  voltage (Un) Frequency Poles Reference h Straight plugs IP44/IP54 Straight plugs IP66/IP67/IP68/IP69 Fast wiring Screw wiring Fast wiring Screw wiring 16A 100 ÷ 130V 50/60 Hz 2P+E 4 GW 60 001 FH GW 60 001 H GW 60 023 FH GW 60 023 H 3P+E 4 GW 60 002 FH GW 60 002 H GW 60 024 FH GW 60 024 H 3P+N+E 4 GW 60 003 FH GW 60 003 H GW 60 025 FH GW 60 025 H 200 ÷ 250V 50/60 Hz 2P+E 6 GW 60 004 FH GW 60 004 H GW 60 026 FH GW 60 026 H 3P+E 9 GW 60 005 FH GW 60 005 H GW 60 027 FH GW 60 027 H 3P+N+E 9 GW 60 006 FH GW 60 006 H GW 60 028 FH GW 60 028 H 380 ÷ 415V 50/60 Hz 2P+E 9 GW 60 007 FH GW 60 007 H GW 60 029 FH GW 60 029 H 3P+E 6 GW 60 008 FH GW 60 008 H GW 60 030 FH GW 60 030 H 3P+N+E 6 GW 60 009 FH GW 60 009 H GW 60 031 FH GW 60 031 H 480 ÷ 500V 50/60 Hz 2P+E 7 GW 60 701 H GW 60 735 H 3P+E 7 GW 60 010 H GW 60 032 H 3P+N+E 7 GW 60 011 H GW 60 033 H 600 ÷ 690V 50/60 Hz 3P+E 5 GW 60 702 H GW 60 736 H 3P+N+E 5 GW 60 703 H GW 60 737 H 50V 100 ÷ 300 Hz 2P+E 10 GW 60 704 H GW 60 738 H 3P+E 10 GW 60 705 H GW 60 739 H 3P+N+E 10 GW 60 706 H GW 60 740 H 50V 300 ÷ 500 Hz 2P+E 2 GW 60 707 H GW 60 741 H 3P+E 2 GW 60 708 H GW 60 742 H 3P+N+E 2 GW 60 709 H GW 60 743 H 440 ÷ 460V 60 Hz 3P+E 11 GW 60 710 H GW 60 744 H 3P+N+E 11 GW 60 711 H GW 60 745 H 380V / 440V 50 Hz / 60 Hz 3P+E 3 GW 60 712 H GW 60 746 H 3P+N+E 3 GW 60 713 H GW 60 747 H transf. 50/60 Hz 2P+E 12 GW 60 714 H GW 60 748 H 3P+E 12 GW 60 715 H GW 60 749 H 50 ÷ 250V D.C. 2P+E 3 GW 60 716 H GW 60 750 H 250V D.C. 2P+E 8 GW 60 717 H GW 60 751 H 32A 100 ÷ 130V 50/60 Hz 2P+E 4 GW 60 012 FH GW 60 012 H GW 60 034 FH GW 60 034 H 3P+E 4 GW 60 013 FH GW 60 013 H GW 60 035 FH GW 60 035 H 3P+N+E 4 GW 60 014 FH GW 60 014 H GW 60 036 FH GW 60 036 H 200 ÷ 250V 50/60 Hz 2P+E 6 GW 60 015 FH GW 60 015 H GW 60 037 FH GW 60 037 H 3P+E 9 GW 60 016 FH GW 60 016 H GW 60 038 FH GW 60 038 H 3P+N+E 9 GW 60 017 FH GW 60 017 H GW 60 039 FH GW 60 039 H 380 ÷ 415V 50/60 Hz 2P+E 9 GW 60 018 FH GW 60 018 H GW 60 040 FH GW 60 040 H 3P+E 6 GW 60 019 FH GW 60 019 H GW 60 041 FH GW 60 041 H 3P+N+E 6 GW 60 020 FH GW 60 020 H GW 60 042 FH GW 60 042 H 480 ÷ 500V 50/60 Hz 2P+E 7 GW 60 718 H GW 60 752 H 3P+E 7 GW 60 021 H GW 60 043 H 3P+N+E 7 GW 60 022 H GW 60 044 H 600 ÷ 690V 50/60 Hz 3P+E 5 GW 60 719 H GW 60 753 H 3P+N+E 5 GW 60 720 H GW 60 754 H 50V 100 ÷ 300 Hz 2P+E 10 GW 60 721 H GW 60 755 H 3P+E 10 GW 60 722 H GW 60 756 H 3P+N+E 10 GW 60 723 H GW 60 757 H 50V 300 ÷ 500 Hz 2P+E 2 GW 60 724 H GW 60 758 H 3P+E 2 GW 60 725 H GW 60 759 H 3P+N+E 2 GW 60 726 H GW 60 760 H 440 ÷ 460V 60 Hz 3P+E 11 GW 60 727 H GW 60 761 H 3P+N+E 11 GW 60 728 H GW 60 762 H 380V / 440V 50 Hz / 60 Hz 3P+E 3 GW 60 729 H GW 60 145 H 3P+N+E 3 GW 60 730 H GW 60 763 H transf. 50/60 Hz 2P+E 12 GW 60 731 H GW 60 764 H 3P+E 12 GW 60 732 H GW 60 765 H 50 ÷ 250V D.C. 2P+E 3 GW 60 733 H GW 60 766 H 250V D.C. 2P+E 8 GW 60 734 H GW 60 767 H 16A AND 32A LOW VOLTAGE INDUSTRIAL PLUGS AND SOCKET-OUTLETS TO IEC 309 STANDARDS - IEC 309 HP Straight connectors IP44/IP54 Straight connectors IP66/IP67/IP68/IP69 10° flush-mounting socket-outlets IP44/IP54 10° flush-mounting socket-outlets IP66/IP67 APPLICATIONS Fast wiring Screw wiring Fast wiring Screw wiring Fast wiring Screw wiring Fast wiring Screw wiring GW 62 001 FH GW 62 001 H GW 62 023 FH GW 62 023 H GW 62 201 FH GW 62 201 H GW 62 224 FH GW 62 224 H Standard  use GW 62 002 FH GW 62 002 H GW 62 024 FH GW 62 024 H GW 62 202 FH GW 62 202 H GW 62 225 FH GW 62 225 H GW 62 003 FH GW 62 003 H GW 62 025 FH GW 62 025 H GW 62 203 FH GW 62 203 H GW 62 226 FH GW 62 226 H GW 62 004 FH GW 62 004 H GW 62 026 FH GW 62 026 H GW 62 205 FH GW 62 205 H ( ) GW 62 227 FH GW 62 227 H GW 62 005 FH GW 62 005 H GW 62 027 FH GW 62 027 H GW 62 206 FH GW 62 206 H GW 62 228 FH GW 62 228 H GW 62 006 FH GW 62 006 H GW 62 028 FH GW 62 028 H GW 62 207 FH GW 62 207 H GW 62 229 FH GW 62 229 H GW 62 007 FH GW 62 007 H GW 62 029 FH GW 62 029 H GW 62 208 FH GW 62 208 H GW 62 230 FH GW 62 230 H GW 62 008 FH GW 62 008 H GW 62 030 FH GW 62 030 H GW 62 209 FH GW 62 209 H GW 62 231 FH GW 62 231 H GW 62 009 FH GW 62 009 H GW 62 031 FH GW 62 031 H GW 62 210 FH GW 62 210 H GW 62 232 FH GW 62 232 H GW 62 701 H GW 62 735 H GW 62 801 H GW 62 835 H Use with special  voltages GW 62 010 H GW 62 032 H GW 62 211 H GW 62 233 H GW 62 011 H GW 62 033 H GW 62 212 H GW 62 234 H GW 62 702 H GW 62 736 H GW 62 802 H GW 62 836 H GW 62 703 H GW 62 737 H GW 62 803 H GW 62 837 H GW 62 704 H GW 62 738 H GW 62 804 H GW 62 838 H Use with  high frequencies GW 62 705 H GW 62 739 H GW 62 805 H GW 62 839 H GW 62 706 H GW 62 740 H GW 62 806 H GW 62 840 H GW 62 707 H GW 62 741 H GW 62 807 H GW 62 841 H GW 62 708 H GW 62 742 H GW 62 808 H GW 62 842 H GW 62 709 H GW 62 743 H GW 62 809 H GW 62 843 H GW 62 710 H GW 62 744 H GW 62 810 H GW 62 844 H Marine, port and  naval installations GW 62 711 H GW 62 745 H GW 62 811 H GW 62 845 H GW 62 712 H GW 62 746 H GW 62 812 H GW 62 846 H Refrigerated containers GW 62 713 H GW 62 747 H GW 62 813 H GW 62 847 H GW 62 714 H GW 62 748 H GW 62 814 H GW 62 848 H Isolation  transformers GW 62 715 H GW 62 749 H GW 62 815 H GW 62 849 H GW 62 716 H GW 62 750 H GW 62 816 H GW 62 850 H Use with  direct current GW 62 717 H GW 62 751 H GW 62 817 H GW 62 851 H GW 62 012 FH GW 62 012 H GW 62 034 FH GW 62 034 H GW 62 213 FH GW 62 213 H GW 62 235 FH GW 62 235 H Standard  use GW 62 013 FH GW 62 013 H GW 62 035 FH GW 62 035 H GW 62 214 FH GW 62 214 H GW 62 236 FH GW 62 236 H GW 62 014 FH GW 62 014 H GW 62 036 FH GW 62 036 H GW 62 215 FH GW 62 215 H GW 62 237 FH GW 62 237 H GW 62 015 FH GW 62 015 H GW 62 037 FH GW 62 037 H GW 62 216 FH GW 62 216 H GW 62 238 FH GW 62 238 H GW 62 016 FH GW 62 016 H GW 62 038 FH GW 62 038 H GW 62 217 FH GW 62 217 H GW 62 239 FH GW 62 239 H GW 62 017 FH GW 62 017 H GW 62 039 FH GW 62 039 H GW 62 218 FH GW 62 218 H GW 62 240 FH GW 62 240 H GW 62 018 FH GW 62 018 H GW 62 040 FH GW 62 040 H GW 62 219 FH GW 62 219 H GW 62 241 FH GW 62 241 H GW 62 019 FH GW 62 019 H GW 62 041 FH GW 62 041 H GW 62 220 FH GW 62 220 H GW 62 242 FH GW 62 242 H GW 62 020 FH GW 62 020 H GW 62 042 FH GW 62 042 H GW 62 221 FH GW 62 221 H GW 62 243 FH GW 62 243 H GW 62 718 H GW 62 752 H GW 62 818 H GW 62 852 H Use with special  voltages GW 62 021 H GW 62 043 H GW 62 222 H GW 62 244 H GW 62 022 H GW 62 044 H GW 62 223 H GW 62 245 H GW 62 719 H GW 62 753 H GW 62 819 H GW 62 853 H GW 62 720 H GW 62 754 H GW 62 820 H GW 62 854 H GW 62 721 H GW 62 755 H GW 62 821 H GW 62 855 H Use with  high frequencies GW 62 722 H GW 62 756 H GW 62 822 H GW 62 856 H GW 62 723 H GW 62 757 H GW 62 823 H GW 62 857 H GW 62 724 H GW 62 758 H GW 62 824 H GW 62 858 H GW 62 725 H GW 62 759 H GW 62 825 H GW 62 859 H GW 62 726 H GW 62 760 H GW 62 826 H GW 62 860 H GW 62 727 H GW 62 761 H GW 62 827 H GW 62 861 H Marine, port and  naval installations GW 62 728 H GW 62 762 H GW 62 828 H GW 62 862 H GW 62 729 H GW 62 128 H GW 62 829 H GW 62 283 H Refrigerated containers GW 62 730 H GW 62 763 H GW 62 830 H GW 62 863 H GW 62 731 H GW 62 764 H GW 62 831 H GW 62 864 H Isolation  transformers GW 62 732 H GW 62 765 H GW 62 832 H GW 62 865 H GW 62 733 H GW 62 766 H GW 62 833 H GW 62 866 H Use with  direct current GW 62 734 H GW 62 767 H GW 62 834 H GW 62 867 H ( ) NOTE: available also- GW62204: industrial socket IEC 309 std. 16A 2P+E - 62x62 mm - IP44- GW62392: Domestic socket German std. 16A 2P+E - 85x75 mm - IP54 - GW62393: Domestic socket German std. 16A 2P+E - 50x50 mm - IP54- GW62394: Domestic socket French std. 16A 2P+E - 50x50 mm - IP54 Brochure IEC 309 HP - 2.indd   15 02/07/15   09:46

63A AND 125A LOW VOLTAGE INDUSTRIAL PLUGS AND SOCKET-OUTLETS TO IEC 309 STANDARDS - IEC 309 HP Rated current (In) Rated voltage (Un) Frequency Poles Reference h Straight plugs IP44/IP54 63A 100 ÷ 130V 50/60 Hz 2P+E 4 GW 61 013 H 3P+E 4 GW 61 014 H 3P+N+E 4 GW 61 015 H 200 ÷ 250V 50/60 Hz 2P+E 6 GW 61 016 H 3P+E 9 GW 61 017 H 3P+N+E 9 GW 61 018 H 380 ÷ 415V 50/60 Hz 2P+E 9 GW 61 019 H 3P+E 6 GW 61 020 H 3P+N+E 6 GW 61 021 H 480 ÷ 500V 50/60 Hz 2P+E 7 3P+E 7 3P+N+E 7 600 ÷ 690V 50/60 Hz 3P+E 5 3P+N+E 5 50V 100 ÷ 300 Hz 2P+E 10 3P+E 10 3P+N+E 10 50V 300 ÷ 500 Hz 2P+E 2 3P+E 2 3P+N+E 2 440 ÷ 460V 60 Hz 3P+E 11 3P+N+E 11 50 ÷ 250V D.C. 2P+E 3 250V D.C. 2P+E 8 125A 100 ÷ 130V 50/60 Hz 2P+E 4 3P+E 4 3P+N+E 4 200 ÷ 250V 50/60 Hz 2P+E 6 3P+E 9 3P+N+E 9 380 ÷ 415V 50/60 Hz 2P+E 9 3P+E 6 3P+N+E 6 480 ÷ 500V 50/60 Hz 2P+E 7 3P+E 7 3P+N+E 7 600 ÷ 690V 50/60 Hz 3P+E 5 3P+N+E 5 50V 100 ÷ 300 Hz 2P+E 10 3P+E 10 3P+N+E 10 50V 300 ÷ 500 Hz 2P+E 2 3P+E 2 3P+N+E 2 440 ÷ 460V 60 Hz 3P+E 11 3P+N+E 11 Note: plugs fitted with drive contact.( ) socket-outlets with drive contact and direct screw wiring( ) socket-outlets with clean contact IP67. For further commercial information, refer to the BUILDING catalogue. IEC 309 HP 16 Brochure IEC 309 HP - 2.indd   16 02/07/15   09:46

63A AND 125A LOW VOLTAGE INDUSTRIAL PLUGS AND SOCKET-OUTLETS TO IEC 309 STANDARDS - IEC 309 HP Rated current (In) Rated voltage (Un) Frequency Poles Reference h Straight plugs IP44/IP54 63A 100 ÷ 130V 50/60 Hz 2P+E 4 GW 61 013 H 3P+E 4 GW 61 014 H 3P+N+E 4 GW 61 015 H 200 ÷ 250V 50/60 Hz 2P+E 6 GW 61 016 H 3P+E 9 GW 61 017 H 3P+N+E 9 GW 61 018 H 380 ÷ 415V 50/60 Hz 2P+E 9 GW 61 019 H 3P+E 6 GW 61 020 H 3P+N+E 6 GW 61 021 H 480 ÷ 500V 50/60 Hz 2P+E 7 3P+E 7 3P+N+E 7 600 ÷ 690V 50/60 Hz 3P+E 5 3P+N+E 5 50V 100 ÷ 300 Hz 2P+E 10 3P+E 10 3P+N+E 10 50V 300 ÷ 500 Hz 2P+E 2 3P+E 2 3P+N+E 2 440 ÷ 460V 60 Hz 3P+E 11 3P+N+E 11 50 ÷ 250V D.C. 2P+E 3 250V D.C. 2P+E 8 125A 100 ÷ 130V 50/60 Hz 2P+E 4 3P+E 4 3P+N+E 4 200 ÷ 250V 50/60 Hz 2P+E 6 3P+E 9 3P+N+E 9 380 ÷ 415V 50/60 Hz 2P+E 9 3P+E 6 3P+N+E 6 480 ÷ 500V 50/60 Hz 2P+E 7 3P+E 7 3P+N+E 7 600 ÷ 690V 50/60 Hz 3P+E 5 3P+N+E 5 50V 100 ÷ 300 Hz 2P+E 10 3P+E 10 3P+N+E 10 50V 300 ÷ 500 Hz 2P+E 2 3P+E 2 3P+N+E 2 440 ÷ 460V 60 Hz 3P+E 11 3P+N+E 11 63A AND 125A LOW VOLTAGE INDUSTRIAL PLUGS AND SOCKET-OUTLETS TO IEC 309 STANDARDS - IEC 309 HP Straight plugs  IP66/IP67/IP68/IP69 Straight connectors  IP44/IP54 Straight connectors IP66/IP67/IP68/IP69 10° flush-mounting fixed  socket-outlets  IP44/IP54 10° flush-mounting fixed  socket-outlets  IP66/IP67 APPLICATIONS GW 61 045 H GW 63 013 H GW 63 045 H GW 63 213 H GW 63 246 H Standard  use GW 61 046 H GW 63 014 H GW 63 046 H GW 63 214 H GW 63 247 H GW 61 047 H GW 63 015 H GW 63 047 H GW 63 215 H GW 63 248 H GW 61 048 H GW 63 016 H GW 63 048 H GW 63 216 H GW 63 249 H GW 63 048 PH GW 63 249 PH GW 61 049 H GW 63 017 H GW 63 049 H GW 63 217 H GW 63 250 H GW 61 050 H GW 63 018 H GW 63 050 H GW 63 218 H GW 63 251 H GW 61 051 H GW 63 019 H GW 63 051 H GW 63 219 H GW 63 252 H GW 61 052 H GW 63 020 H GW 63 052 H GW 63 220 H GW 63 253 H GW 63 052 PH GW 63 253 PH GW 61 053 H GW 63 021 H GW 63 053 H GW 63 221 H GW 63 254 H GW 63 053 PH GW 63 254 PH GW 61 056 H GW 63 056 H GW 63 257 H Use with special  voltages GW 61 054 H GW 63 054 H GW 63 255 H GW 61 055 H GW 63 055 H GW 63 256 H GW 61 057 H GW 63 057 H GW 63 258 H GW 61 058 H GW 63 058 H GW 63 259 H GW 61 059 H GW 63 059 H GW 63 260 H Use with  high frequencies GW 61 060 H GW 63 060 H GW 63 261 H GW 61 061 H GW 63 061 H GW 63 262 H GW 61 062 H GW 63 062 H GW 63 263 H GW 61 063 H GW 63 063 H GW 63 264 H GW 61 064 H GW 63 064 H GW 63 265 H GW 61 065 H GW 63 065 H GW 63 266 H Marine, port and  naval installations GW 61 066 H GW 63 066 H GW 63 267 H GW 61 067 H GW 63 067 H GW 63 268 H Use with  direct current GW 61 068 H GW 63 068 H GW 63 269 H GW 60 664 H GW 62 664 H GW 62 965 H Standard  use GW 60 056 H GW 62 056 H GW 62 257 H GW 60 057 H GW 62 057 H GW 62 258 H GW 60 665 H GW 62 665 H GW 62 966 H GW 60 058 H GW 62 058 H GW 62 259 H GW 60 059 H GW 62 059 H GW 62 260 H GW 60 666 H GW 62 666 H GW 62 967 H GW 60 060 H GW 62 060 H GW 62 261 H GW 62 261 PH GW 62 060 PH GW 68 785 GW 60 061 H GW 62 061 H GW 62 262 H GW 62 262 PH GW 62 061 PH GW 68 786 GW 60 667 H GW 62 667 H GW 62 968 H Use with special  voltages GW 60 062 H GW 62 062 H GW 62 263 H GW 60 063 H GW 62 063 H GW 62 264 H GW 60 668 H GW 62 668 H GW 62 969 H GW 60 669 H GW 62 669 H GW 62 970 H GW 60 670 H GW 62 670 H GW 62 971 H Use with  high frequencies GW 60 671 H GW 62 671 H GW 62 972 H GW 60 672 H GW 62 672 H GW 62 973 H GW 60 673 H GW 62 673 H GW 62 974 H GW 60 674 H GW 62 674 H GW 62 975 H GW 60 675 H GW 62 675 H GW 62 976 H GW 60 676 H GW 62 676 H GW 62 977 H Marine, port and  naval installations GW 60 677 H GW 62 677 H GW 62 978 H Brochure IEC 309 HP - 2.indd   17 02/07/15   09:46

The codes with the suffix “N” refer to the products of the new range of IP67 vertical interlocked switched socket-outlets, and correspond to the product codes of the previous range without the letter “N”  (apart from the Automatika version); they can therefore be installed on the Q-DIN boards of the old SBF versions, allowing any replacement or modification even on boards already installed.Using the GW 66 715 N adapters for 16-32A versions, and GW 66 716 N for 63A versions, they can also be installed on the Q-DIN boards or modular bases of the old CBF IP55 versions. VERTICAL SOCKET-OUTLETS - 67 IB VERTICAL SOCKET-OUTLETS  FOR HEAVY DUTY USE - 66 IB Rated   current (In) Rated  voltage (Un) Poles Reference h Vertical   socket-outlets  with RCB, without  back-mounting box (AUTOMATIKA) Vertical  socket-outlets  with RCB, with  back-mounting box (AUTOMATIKA) Vertical   socket-outlets with  rotary switch,  without  back-mounting box (SBF) Vertical   socket-outlets with  rotary switch, with  back-mounting box (SBF) Vertical   socket-outlets  with fuse-holder  base, without  back-mounting box (CBF) Vertical   socket-outlets with  fuse-holder base,  with back-mounting  box (CBF) Vertical   socket-outlets   with rotary switch,   without  back-mounting box Vertical   socket-outlets   with rotary switch,  with back-mounting  box Vertical socket-out- lets with fuse-holder  base, without  back-mounting box IP67 IP67 IP67 IP67 IP67 IP67 IP66 IP66 IP66 16A 20 ÷ 25V 2P w.r. GW 66 359 N GW 66 259 N GW 66 886 100 ÷ 130V 2P+E 4 GW 66 151 N GW 66 051 N GW 66 301 N GW 66 201 N GW 66 323 N GW 66 223 N GW 66 535 GW 66 501 GW 66 801 3P+E 4 GW 66 152 N GW 66 052 N GW 66 302 N GW 66 202 N GW 66 324 N GW 66 224 N GW 66 536 GW 66 502 GW 66 802 3P+N+E 4 GW 66 153 N GW 66 053 N GW 66 303 N GW 66 203 N GW 66 325 N GW 66 225 N GW 66 537 GW 66 503 GW 66 803 200 ÷ 250V 2P+E 6 GW 66 154 N GW 66 054 N GW 66 304 N GW 66 204 N GW 66 326 N GW 66 226 N GW 66 538 GW 66 504 GW 66 804 3P+E 9 GW 66 155 N GW 66 055 N GW 66 305 N GW 66 205 N GW 66 327 N GW 66 227 N GW 66 539 GW 66 505 GW 66 805 3P+N+E 9 GW 66 156 N GW 66 056 N GW 66 306 N GW 66 206 N GW 66 328 N GW 66 228 N GW 66 540 GW 66 506 GW 66 806 380 ÷ 415V 2P+E 9 GW 66 157 N GW 66 057 N GW 66 307 N GW 66 207 N GW 66 329 N GW 66 229 N GW 66 541 GW 66 507 GW 66 807 3P+E 6 GW 66 158 N GW 66 058 N GW 66 308 N GW 66 208 N GW 66 330 N GW 66 230 N GW 66 542 GW 66 508 GW 66 808 3P+N+E 6 GW 66 159 N GW 66 059 N GW 66 309 N GW 66 209 N GW 66 331 N GW 66 231 N GW 66 543 GW 66 509 GW 66 809 480 ÷ 500V 3P+E 7 GW 66 310 N GW 66 210 N GW 66 332 N GW 66 232 N GW 66 544 GW 66 510 GW 66 810 3P+N+E 7 GW 66 311 N GW 66 211 N GW 66 333 N GW 66 233 N GW 66 545 GW 66 511 GW 66 811 32A 100 ÷ 130V 2P+E 4 GW 66 162 N GW 66 062 N GW 66 312 N GW 66 212 N GW 66 334 N GW 66 234 N GW 66 546 GW 66 512 GW 66 812 3P+E 4 GW 66 163 N GW 66 063 N GW 66 313 N GW 66 213 N GW 66 335 N GW 66 235 N GW 66 547 GW 66 513 GW 66 813 3P+N+E 4 GW 66 164 N GW 66 064 N GW 66 314 N GW 66 214 N GW 66 336 N GW 66 236 N GW 66 548 GW 66 514 GW 66 814 200 ÷ 250V 2P+E 6 GW 66 165 N GW 66 065 N GW 66 315 N GW 66 215 N GW 66 337 N GW 66 237 N GW 66 549 GW 66 515 GW 66 815 3P+E 9 GW 66 166 N GW 66 066 N GW 66 316 N GW 66 216 N GW 66 338 N GW 66 238 N GW 66 550 GW 66 516 GW 66 816 3P+N+E 9 GW 66 167 N GW 66 067 N GW 66 317 N GW 66 217 N GW 66 339 N GW 66 239 N GW 66 551 GW 66 517 GW 66 817 380 ÷ 415V 2P+E 9 GW 66 168 N GW 66 068 N GW 66 318 N GW 66 218 N GW 66 340 N GW 66 240 N GW 66 552 GW 66 518 GW 66 818 3P+E 6 GW 66 169 N GW 66 069 N GW 66 319 N GW 66 219 N GW 66 341 N GW 66 241 N GW 66 553 GW 66 519 GW 66 819 3P+N+E 6 GW 66 170 N GW 66 070 N GW 66 320 N GW 66 220 N GW 66 342 N GW 66 242 N GW 66 554 GW 66 520 GW 66 820 480 ÷ 500V 3P+E 7 GW 66 321 N GW 66 221 N GW 66 343 N GW 66 243 N GW 66 555 GW 66 521 GW 66 821 3P+N+E 7 GW 66 322 N GW 66 222 N GW 66 344 N GW 66 244 N GW 66 556 GW 66 522 GW 66 822 380/440V 3P+E 3 GW 66 357 N GW 66 257 N GW 66 358 N GW 66 258 N GW 66 557 GW 66 523 GW 66 823 63A 100 ÷ 130V 2P+E 4 GW 67 356 N GW 67 256 N GW 66 345 N GW 67 245 N GW 66 524 3P+E 4 GW 67 357 N GW 67 257 N GW 66 346 N GW 67 246 N GW 66 525 3P+N+E 4 GW 67 358 N GW 67 258 N GW 66 347 N GW 67 247 N GW 66 526 200 ÷ 250V 2P+E 6 GW 67 359 N GW 67 259 N GW 66 348 N GW 67 248 N GW 66 527 3P+E 9 GW 67 360 N GW 67 260 N GW 66 349 N GW 67 249 N GW 66 528 3P+N+E 9 GW 67 361 N GW 67 261 N GW 66 350 N GW 67 250 N GW 66 529 380 ÷ 415V 2P+E 9 GW 67 362 N GW 67 262 N GW 66 351 N GW 67 251 N GW 66 530 3P+E 6 GW 67 363 N GW 67 263 N GW 66 352 N GW 67 252 N GW 66 531 3P+N+E 6 GW 67 364 N GW 67 264 N GW 66 353 N GW 67 253 N GW 66 532 480 ÷ 500V 3P+E 7 GW 67 365 N GW 67 265 N GW 66 354 N GW 67 254 N GW 66 533 3P+N+E 7 GW 67 366 N GW 67 266 N GW 66 355 N GW 67 255 N GW 66 534 Vertical surface-mounting  socket-outlets with electric  interlock, with circuit breaker  protection 125A 100 ÷ 130V 3P+E 4 GW 66 581 3P+N+E 4 GW 66 582 200 ÷ 250V 3P+E 9 GW 66 583 3P+N+E 9 GW 66 584 380 ÷ 415V 3P+E 6 GW 66 585 3P+N+E 6 GW 66 586 480 ÷ 500V 3P+E 7 GW 66 587 3P+N+E 7 GW 66 588 For further commercial information, refer to the BUILDING catalogue. IEC 309 HP 18 Brochure IEC 309 HP - 2.indd   18 02/07/15   09:46

VERTICAL SOCKET-OUTLETS  FOR HEAVY DUTY USE - 66 IB Vertical   socket-outlets   with fuse-holder  base, with  back-mounting box Vertical   socket-outlets   for modular  applications, without  back-mounting box Vertical   socket-outlets  for modular  applications, with  back-mounting box IP66 IP66 IP66  GW 66 998 GW 66 951 GW 66 824 GW 66 974 GW 66 952 GW 66 825 GW 66 975 GW 66 953 GW 66 826 GW 66 976 GW 66 954 GW 66 827 GW 66 977 GW 66 955 GW 66 828 GW 66 978 GW 66 956 GW 66 829 GW 66 979 GW 66 957 GW 66 830 GW 66 980 GW 66 958 GW 66 831 GW 66 981 GW 66 959 GW 66 832 GW 66 982 GW 66 960 GW 66 833 GW 66 983 GW 66 961 GW 66 834 GW 66 984 GW 66 962 GW 66 835 GW 66 985 GW 66 963 GW 66 836 GW 66 986 GW 66 964 GW 66 837 GW 66 987 GW 66 965 GW 66 838 GW 66 988 GW 66 966 GW 66 839 GW 66 989 GW 66 967 GW 66 840 GW 66 990 GW 66 968 GW 66 841 GW 66 991 GW 66 969 GW 66 842 GW 66 992 GW 66 970 GW 66 843 GW 66 993 GW 66 971 GW 66 844 GW 66 994 GW 66 972 GW 66 845 GW 66 995 GW 66 973 GW 66 846 GW 66 996 GW 66 847 GW 66 866 GW 66 848 GW 66 867 GW 66 849 GW 66 868 GW 66 850 GW 66 869 GW 66 851 GW 66 870 GW 66 852 GW 66 871 GW 66 853 GW 66 872 GW 66 854 GW 66 873 GW 66 855 GW 66 874 GW 66 856 GW 66 875 GW 66 857 GW 66 876 Vertical surface-mounting   socket-outlets with electric   interlock, with residual current  circuit breaker protection GW 66 591GW 66 592GW 66 593GW 66 594GW 66 595GW 66 596GW 66 597GW 66 598 COMBIBLOC COMPACT SOCKET-OUTLETS HORIZONTAL SOCKET-OUTLETS - 44 IB Compact   socket-outlets   with rotary switch,  without   back-mounting box Compact   socket-outlets   with rotary switch,   with   back-mounting box Compact   socket-outlets   with rotary switch,  without   back-mounting box Compact   socket-outlets   with rotary switch,   with   back-mounting box Horizontal   socket-outlets   with rotary switch,  without   back-mounting box Horizontal   socket-outlets   with rotary switch,   with   back-mounting box Horizontal   socket-outlets   with fuse-holder base,  without   back-mounting box Horizontal   socket-outlets   with fuse-holder  base, with   back-mounting box IP44 IP44 IP55 IP55 IP44 IP44 IP44 IP44 GW 66 423 GW 66 401 GW 66 467 GW 66 445 GW 66 101 GW 66 001 GW 66 123 GW 66 023 GW 66 424 GW 66 402 GW 66 468 GW 66 446 GW 66 102 GW 66 002 GW 66 124 GW 66 024 GW 66 425 GW 66 403 GW 66 469 GW 66 447 GW 66 103 GW 66 003 GW 66 125 GW 66 025 GW 66 426 GW 66 404 GW 66 470 GW 66 448 GW 66 104 GW 66 004 GW 66 126 GW 66 026 GW 66 427 GW 66 405 GW 66 471 GW 66 449 GW 66 105 GW 66 005 GW 66 127 GW 66 027 GW 66 428 GW 66 406 GW 66 472 GW 66 450 GW 66 106 GW 66 006 GW 66 128 GW 66 028 GW 66 429 GW 66 407 GW 66 473 GW 66 451 GW 66 107 GW 66 007 GW 66 129 GW 66 029 GW 66 430 GW 66 408 GW 66 474 GW 66 452 GW 66 108 GW 66 008 GW 66 130 GW 66 030 GW 66 431 GW 66 409 GW 66 475 GW 66 453 GW 66 109 GW 66 009 GW 66 131 GW 66 031 GW 66 110 GW 66 010 GW 66 132 GW 66 032 GW 66 111 GW 66 011 GW 66 133 GW 66 033 GW 66 434 GW 66 412 GW 66 478 GW 66 456 GW 66 112 GW 66 012 GW 66 134 GW 66 034 GW 66 435 GW 66 413 GW 66 479 GW 66 457 GW 66 113 GW 66 013 GW 66 135 GW 66 035 GW 66 436 GW 66 414 GW 66 480 GW 66 458 GW 66 114 GW 66 014 GW 66 136 GW 66 036 GW 66 437 GW 66 415 GW 66 481 GW 66 459 GW 66 115 GW 66 015 GW 66 137 GW 66 037 GW 66 438 GW 66 416 GW 66 482 GW 66 460 GW 66 116 GW 66 016 GW 66 138 GW 66 038 GW 66 439 GW 66 417 GW 66 483 GW 66 461 GW 66 117 GW 66 017 GW 66 139 GW 66 039 GW 66 440 GW 66 418 GW 66 484 GW 66 462 GW 66 118 GW 66 018 GW 66 140 GW 66 040 GW 66 441 GW 66 419 GW 66 485 GW 66 463 GW 66 119 GW 66 019 GW 66 141 GW 66 041 GW 66 442 GW 66 420 GW 66 486 GW 66 464 GW 66 120 GW 66 020 GW 66 142 GW 66 042 GW 66 121 GW 66 021 GW 66 143 GW 66 043 GW 66 122 GW 66 022 GW 66 144 GW 66 044 Brochure IEC 309 HP - 2.indd   19 02/07/15   09:46

COMBIBLOC    RANGE IP44/55 compact protected  watertight socket-outlets -  16/32A GW 66 491 GW 66 492 GW 66 493 44 IB  HORIZONT AL RANGE Horizontal socket-outlets  IP44,   without fuse-holder base (SBF) 16/32A GW 68 006 N (14 modules) GW 68 009 N (14 modules) GW 68 019 N (10 modules) Horizontal socket-outlets  IP44,   with fuse-holder base (CBF) 16/32A GW 68 014 N (20 modules) COMPLEMENTARY ITEMS MODULAR BASES DISTRIBUTION BOARDS 1 socket-outlet 2 socket-outlets 3 socket-outlets 1 socket-outlet 2   socket-outlets 3 socket-outlets 4   socket-outlets 67 IB  VER TICAL RANGE IP67 vertical socket-outlets   with rotary switch (SBF),   with fuse-holder base (CBF),   AUTOMATIKA 16/32A   and SELV 24V GW 66 690 GW 66 691 GW 66 694 GW 68 025 N (10 modules) GW 68 010 N (14 modules) GW 68 022 N (20 modules) 1 socket-outlet  63A 2 socket-out- lets 16/32A GW 68 015 N (20 modules) IP67 vertical socket-outlets   with rotary switch (SBF)   or fuse-holder   base (CBF) 63A GW 66 693 66 IB RANGE FOR HEA VY -DUTY USE IP66 vertical socket-outlets  for heavy-duty use 16/32A GW 66 696 GW 66 697 GW 66 698 IP66 vertical socket-outlets   for heavy-duty use 63A GW 66 700 For further commercial information, refer to the BUILDING catalogue. IEC 309 HP 20 Brochure IEC 309 HP - 2.indd   20 02/07/15   09:46

COMPLEMENTARY ITEMS MODULAR BASES WITH WINDOW PANEL COVER/BOXES 1 socket-outlet 2 socket-outlets 3 socket-outlets Flanged lid Flush-mounting boxes (brick and plasterboard walls) Surface-mounting box GW 66 709 N GW 66 683 N (for brick walls) GW 66 678 N GW 66 683 PM (for plasterboard walls) GW 66 686 (for SBF) GW 66 680 N (for CBF) GW 66 781(6 modules) GW 66 782 (12 modules) GW 66 783 (18 modules) GW 66 707 GW 66 685 GW 66 784(6 modules) GW 66 498 GW 66 496 GW 66 681 (for brick walls) GW 66 676 GW 66 681 PM (for plasterboard walls) GW 66 682 (for brick walls) GW 66 677 GW 66 682 PM (for plasterboard walls) GW 27 401 IEC 309 range 74 PS range GW 27 403 IEC 309 HP range Domestic socket 50x50 mm Cannot be used for SELV 24V Brochure IEC 309 HP - 2.indd   21 02/07/15   09:46

For further commercial information, refer to the BUILDING catalogue. UNWIRED VERSIONS Type No. of EN 50022  modules Code Layout Pre-arrangement 5 GW 68 017 N 1 IEC 309 socket-outlet 16A IP44/67  or GW 27 401 or GW 27 403 watertight cap GW 68 018 N 2 IEC 309 socket-outlets 16A IP44/67  or GW 27401 or GW 27403 watertight cap GW 68 001 N 3 IEC 309 socket-outlets 16A IP44/67  or GW 27401 or GW 27403 watertight cap GW 68 031 N 3 IEC 309 socket-outlets 16A IP44/67  or GW 27 401 watertight cap and shockproof case GW 68 020 N 2 IEC 309 socket-outlets 16-32A IP44/67  or GW 27401 or GW 27403 watertight cap GW 68 026 N 4 domestic socket-outlets 50x50mm IP54 GW 68 032 N 4 domestic socket-outlets 50x50mm IP54 and shockproof case 10 GW 68 002 N Blank GW 68 003 N 2 IEC 309 socket-outlets 16A max 3P+E   IP44/67 or GW 27 401 watertight cap   2 IEC 309 socket-outlets 16-32A   IP44/67 or GW 27401 - GW 27403 watertight cap GW 68 019 N 2 horizontal interlocked switched socket-outlets 44 IB range   16-32A IP44 with rotary switch (SBF) GW 68 025 N 2 vertical interlocked switched socket-outlets 67 IB range   16-32A IP67 GW 68 027 N 3 domestic socket-outlets 50x50mm IP54   2 IEC 309 socket-outlets 16-32A IP44/67 14 GW 68 004 N Blank GW 68 005 N 3 IEC 309 socket-outlets 16-32A IP44/67  or GW 27 401 watertight cap GW 68 006 N 2 horizontal interlocked switched socket-outlets 44 IB range   16-32A IP44 with rotary switch (SBF) GW 68 007 N Blank GW 68 008 N 6 IEC 309 socket-outlets 16-32A IP44/67  or GW 27401 or GW 27403 watertight cap GW 68 009 N 4 horizontal interlocked switched socket-outlets 44 IB range   16-32A IP44 with rotary switch (SBF) GW 68 010 N 3 vertical interlocked switched socket-outlets 67 IB range   16-32A IP67 20 GW 68 012 N Blank GW 68 013 N 8 IEC 309 socket-outlets 16-32A IP44/67  or GW 27401 or GW 27403 watertight cap GW 68 021 N 4 IEC 309 socket-outlets 16-32A IP44/67  or GW 27401 or GW 27403 watertight cap  2 IEC 309 socket-outlets 63A GW 68 014 N 4 horizontal interlocked switched socket-outlets 44 IB range   16-32A IP44 with fuse-holder base (CBF) GW 68 015 N 4 vertical interlocked switched socket-outlets 67 IB range 16-32A IP67   4 IEC 309 2P+E socket-outlets 16A IP44/67   or GW 27401 - GW 27403 watertight cap GW 68 022 N 2 vertical interlocked switched socket-outlets 67 IB range 16-32A IP67   1 vertical interlocked switched socket-outlet 67 IB range 63A IP67 14 GW 68 023 N 14 gang additional module 20 GW 68 024 N 20 gang additional module IEC 309 HP 22 Brochure IEC 309 HP - 2.indd   22 02/07/15   09:46

WIRED VERSIONS Type No. of EN 50022 modules Code Layout Equipment Code Layout Equipment 5 GW 68 225 N 1 IEC 309 socket-outlet 2P+E 16A IP44 230V 1 10/16A Schuko domestic socket-outlet GW 68 227 N 1 IEC 309 socket-outlet 2P+E 16A IP44 230V GW 68 224 N 1 IEC 309 socket-outlet 2P+E 16A IP44 230V1 16A IEC 309 socket-outlet 3P+E IP44 400V 1 10/16A Schuko domestic socket-outlet GW 68 226 N 1 IEC 309 socket-outlet 2P+E 16A IP44 230V1 16A IEC 309 socket-outlet 3P+E IP44 400V GW 68 223 N 3 IEC 309 socket-outlets 2P+E 16A IP67 230V  with H07 RN-F 5m cable, 2P+E plug 16A IP67 230V  and shockproof case GW 68 217 N 3 16A IEC 309 2P+E socket-outlets IP67 230V with H07 RN-F 5m cable and plug 2P+E 16A IP67 230V 10 GW 68 202 N 2 IEC 309 2P+E 16A IP44 230V 1 16A IEC 309 socket-outlet 3P+E IP44 400V 1 10/16A Schuko domestic socket-outlet GW 68 228 N 1 IEC 309 socket-outlet 2P+E 16A IP44 230V1 16A IEC 309 socket-outlet 3P+E IP44 400V 1 16A IEC 309 socket-outlet 3P+N+E IP44 400V 1 10/16A Schuko domestic socket-outlet GW68232N DBO 2 vertical interlocked switched socket-outlets  2P+E 16A IP67 230V  with rotary switch GW68233N DBO 1 vert. interlocked switched socket-outlet 2P+E  16A IP67 230V 1 vertical interlocked switched socket-outlet  3P+E 16A IP67 400V with rotary switch GW 68 203 N 2 domestic socket-outlets 16A, German Std 2 IEC 309 socket-outlets 2P+E 16A IP44 230V  with H07 RN-F 5m cable   and 2P+E plug 16A IP44 230V GW 68 204 N 2 16A IEC 309 socket-outlets 2P+E IP67 230V2 16A IEC 309 socket-outlets 3P+E IP67 400V with H07 RN-F 5m cable and plug 3P+N+E 16A IP67 400V GW 68 216 N 4 IEC 309 socket-outlets 2P+E 16A IP67 400V  with H07 RN-F 5m cable  and plug 2P+E 16A IP67 400V GW 68 401 N 1 domestic socket-outlet 16A, German Std 2 16A IEC 309 socket-outlets 2P+E IP44 230V 1 16A IEC 309 3P+E socket-outlet IP44 400V with H07 RN-F 15m cable plug 3P+N+E 16A IP44 400V  and metal support 14 GW 68 205 N 2 16A IEC 309 socket-outlets 2P+E IP67 230V 1 16A IEC 309 socket-outlet 3P+E IP67 400V GW 68 229 N 2 16A IEC 309 socket-outlets 2P+E IP44 230V 1 16A IEC 309 socket-outlet 3P+E IP44 400V 1 16A IEC 309 socket-outlet 3P+N+E IP44 400V 1 32A IEC 309 socket-outlet 3P+E IP44 400V 1 10/16A Schuko domestic socket-outlet GW 68 411 N 2 domestic socket-outlets 16A, German Std 2 16A IEC 309 socket-outlets 2P+E IP44 230V2 16A IEC 309 socket-outlets 3P+E IP44 400V with H07 RN-F 25m cable plug 3P+N+E 16A IP44 400V  and metal support carriage   with cable winder drum GW 68 206 N 2 16A horizontal interlocked switched   socket-outlets 2P+E IP44 230V 1 16A horizontal interlocked switched   socket-outlet 3P+E IP44 400V 1 32A horizontal interlocked switched   socket-outlet 3P+E IP44 400V with rotary switch GW 68 207 N 2 16A vertical interlocked switched   socket-outlets 2P+E IP67 230V 1 16A vertical interlocked switched   socket-outlet 3P+E IP67 400V with rotary switch GW 68 230 N 2 16A vertical interlocked switched   socket-outlets 2P+E IP67 230V AUTOMATIKA 1 16A AUTOMATIKA vertical interlocked  switched socket-outlet 3P+N+E IP67 400V GW 68 231 N 1 16A AUTOMATIKA vertical interlocked  switched socket-outlet 2P+E IP67 230V 2 16A AUTOMATIKA vertical interlocked  switched socket-outlets 3P+N+E IP67 400V 20 GW 68 208 N 2 16A vertical interlocked switched   socket-outlets 2P+E IP67 230V 1 16A vertical interlocked switched   socket-outlet 3P+E IP67 400V 1 32A vertical interlocked switched   socket-outlet 3P+E IP67 400V with rotary switch GW 68 421 N 2 16A IEC 309 socket-outlets 2P+E IP44 230V2 16A IEC 309 socket-outlets 3P+E IP44 400V2 32A IEC 309 socket-outlets 3P+E IP44 400V 2 domestic socket-outlets 16A, German Std with H07 RN-F 35m cable plug 3P+N+E 32A IP44 400V  and metal support carriage   with cable winder drum GW 68 424 N 2 16A vertical interlocked switched   socket-outlets 2P+E IP67 230V 1 16A vertical interlocked switched   socket-outlet 3P+E IP67 400V 1 32A vertical interlocked switched   socket-outlet 3P+E IP67 400V with rotary switch with H07 RN-F 25m cable plug 3P+N+E 32A IP67 400V,and metal support carriage with cable winder drum ACS DBO DBO DBO DBO DBO ACS ACS DBO ACS DBO DBO DBO DBO ACS ACS ACS ACS ACS DBO DBO DBO Brochure IEC 309 HP - 2.indd   23 02/07/15   09:46

B L A ø Type A B L 16A 2P + 72 87 148 3P + 81 95 148 3P+N+ 88 102.5 167 32A 2P + 93 108 178 3P + 93 108 178 3P+N+ 101 116 189 A B L L1 D ø Type A B D L L1 16A 2P + 30 28.5 57 134 97 3P + 34 32 62 134 97 3P+N+ 38 36 68 153 115 32A 2P + 40 41.5 71 162 115 3P + 40 41.5 71 162 115 3P+N+ 45 42 75 176 130 STRAIGHT PLUGS - IP44 / IP54 STRAIGHT CONNECTORS - IP66 / IP67 / IP68 / IP69 L1 L A ø Type A L L1 16A 2P + 72 130 96 3P + 81 130.5 96.5 3P+N+ 88 150 116 32A 2P + 93 158 114 3P + 93 158 114 3P+N+ 101 170 127 STRAIGHT PLUGS - IP66 / IP67 / IP68 / IP69 A B L C D ø A B L C D ø Type A B C D L 16A 2P + 47 29.5 57 50 148 3P + 50 32 62 55.5 148 3P+N+ 56.5 35.5 68 62.5 165 32A 2P + 59 39 71 64.5 176 3P + 59 39 71 64.5 176 3P+N+ 62 42 75 70.5 190 STRAIGHT CONNECTORS - IP44 / IP54 IEC 309 HP 24 Brochure IEC 309 HP - 2.indd   24 02/07/15   09:46

C = D = B A = = E I (SCREW) L(SPRING) H 10° Ø d F R C A G Type A B C D E F W H I L ød R 16A        2P + 60 85 60 75 4.2 38 22 37.5 49.5 61 56 -        3P + 60 85 60 75 4.2 35 25 37 51.5 61 62 -       3P+N+ 60 85 60 75 4.2 29 31 39.5 49 60 65 8 32A        2P + 70 95 60 80 4.2 32 38 46.5 60 68 68 8        3P + 70 95 60 80 4.2 32 38 46.5 60 68 68 8        3P+N+ 70 95 60 80 4.2 29.5 40.5 48.5 60 68 74 8 10° FLUSH-MOUNTING SOCKET-OUTLETS - IP44 / IP54 A R C F G Ø d C = D = B A = = L E H I (SCREW)Y (SPRING) 10° Type A B C D E F W H I L Y ød R 16A         2P + 60 85 60 75 4.2 38 22 42.5 48 72 60 56 -         3P + 60 85 60 75 4.2 35 25 43 50.5 81 60 62 -         3P+N+ 60 85 60 75 4.2 29 31 44.5 48.5 88 60 66 5 32A         2P + 70 95 60 80 4.2 32 38 51 60.5 93 68.5 68 7         3P + 70 95 60 80 4.2 32 38 51 60.5 93 68.5 68 7         3P+N+ 70 95 60 80 4.2 29.5 40.5 53 60.5 101 68.5 74 7 10° FLUSH-MOUNTING SOCKET-OUTLETS - IP66 / IP67 STRAIGHT PLUGS - IP44 / IP54 L H ØA Type A L H 63A 2P + 109 256 190 3P+ 3P+N + STRAIGHT PLUGS - IP66 / IP67 / IP68 / IP69 ØA L B Type A B L 63A 2P + 114 192 256 3P+ 3P+N + 125A 2P + 131 241 313 3P+ 3P+N + Brochure IEC 309 HP - 2.indd   25 02/07/15   09:46

10° FLUSH-MOUNTING SOCKET-OUTLETS - IP44 / IP54 10° FLUSH-MOUNTING SOCKET-OUTLETS - IP66 / IP67 Type A B C D E F W H I L ød R 63A         2P + 85 110 80 100 6 41 44 64 82 114 84 11         3P+        3P+N + 125A         2P +      90 114 90 114 6 43 47 76 108 131 95 13         3P+        3P+N + = = = H I 10° E D C = A B A C GF R ød H I L E C = = == D A A C GF R B 10° ød Type A B C D E F W H I ød R 63A        2P + 85 110 80 100 6 41 44 54 82 84 11        3P+      3P+N + STRAIGHT CONNECTORS - IP66 / IP67 / IP68 / IP69 B L ØA Type A B L 63A 2P + 114 118 273 3P+ 3P+N + 125A 2P + 130 131 335 3P+ 3P+N + STRAIGHT CONNECTORS - IP44 / IP54 BA L ØD ØC Type A B C D L 63A 2P + 68 54 96 100 268 3P+ 3P+N + IEC 309 HP 26 Brochure IEC 309 HP - 2.indd   26 02/07/15   09:46

TECHNICAL CHARACTERISTICS IEC 309 HP - HIGH PERFORMANCE ELECTRICAL CHARACTERISTICS Rated   current (In) Rated frequency Rated  voltage  (Un) Permissible overload No. of operations  carried out Breaking capacity  at 1.1 Un Insulation resistance (MΩ) 16 A 50/60 100 - 300 300 - 500 direct current 50 - 690 transformer 22 A 5000 20 A 10 MΩ 32 A 42 A 2000 40 A 63 A 50/60 100 - 300 300 - 500 direct current 50 - 690 V - 2000 79 A 10 MΩ 125 A 500 156 A MECHANICAL AND PHYSICAL CHARACTERISTICS Operating temperature Degree of   protection  (IP) Impact   resistance (IK) Heat resistance Resistance to abnormal heat and fire Thermo-pressure with ball Glow wire test -25°C - +40°C Straight versions : IP44/IP54 and IP66/IP67/IP68/IP69  IK 09 125°C (active parts) 80°C (passive parts) 850°C (active parts) 650°C (passive parts) Flush-mounting versions: IP44/IP54 and IP66/IP67 ( ) Although the international product standard IEC60 309 does not currently require it, these products have been voluntarily subjected to tests with degrees of protection higher than IP66/IP67.IP68: 2bar/6h in accordance with EN 60529 after ageing according to Standard EN 60309 (for compliance, refer to the table showing the tightening capacity of the cable fastener gland).IP69: in accordance with IEC 60529 after ageing according to Standard EN 60309. BEHAVIOUR WITH ATMOSPHERIC AND CHEMICAL AGENTS  Saline   solution Acids Bases Solvents Mineral  oil UV  rays Concentrated Diluted Concentrated Diluted Hexane Benzol Acetone Alcohol Resistant Not  resistant Limited  resistance Limited  resistance Resistant Resistant Resistant Resistant Resistant Resistant Resistant HIGH PERFORMANCE MATERIALS TIGHTENING CAPACITY OF THE TERMINALS (mm 2 ) Rated   current (In) Flexible cables Solid or twisted cables MIN. MAX. MIN. MAX. 16 A 1 2.5 1.5 4 32 A 2.5 6 2.5 10 63 A 6 16 6 25 125 A 16 50 25 70 TIGHTENING CAPACITY OF THE CABLE FASTENER CLAMP (mm) Rated current (In) Poles MIN. MAX. 16 A 2P + 7,5 13,8 3P + 7,5 13,8 3P + N + 9,2 19,9 32 A 2P + 9,2 19,9 3P + 9,2 19,9 3P + N + 9,2 19,9 63 A 2P + 16,1 37 3P + 17,9 37 3P + N + 19,9 37 125 A 2P + 24,7 38,5 3P + 27 49 3P + N + 29,9 49 WIRING INFORMATION ( )  Note: these values refer to flexible, rigid and twisted cables.( )  Contact SAT customer service for indications of the cable size to be used in order to maintain the IPX8 degree. Brochure IEC 309 HP - 2.indd   27 02/07/15   09:46
