ZUCCHINI  DISTRIBUTION  FUSE BOARD  TAP-OFF Zucchini busbar

Legrand is the global specialist in electrical and digital building infrastructures. Innovation is the driving force behind its development. With an increasing investment in research and development (circa 5% of sales) and more than 4,000 active patents, the Legrand Group is focused on maintaining a high rate of new product launches that present innovative solutions to the market.  built on local knowledge Global  strength LEGRAND’S POWER  DISTRIBUTION BUSINESS UNIT  From Zucchini transformers, through high power distribution and rising main busbar to Electrak powertrack, desk modules and lighting control, Legrand’s power distribution business unit provides market leading solutions to the increasing demands of today’s buildings. CSR USERS - Provide sustainable solutions- Play a driving role in  the electrical sector SOCIETY - Act ethically- Ensure responsible purchasing- Enable access to electricity for all EMPLOYEES - Respect human rights- Guarantee health and safety at work- Develop skills and promote diversity ENVIRONMENT - Reduce the Group’s  environmental footprint - Innovate for a circular  economy CORPORATE SOCIAL  RESPONSIBILITY Legrand’s 2014-2018 CSR roadmap is a natural extension to the governance and sustainable development approach in which the company has been engaged for many years. The CSR roadmap firmly asserts Legrand’s ongoing commitment to sustainable development.

1 CO NTE NT S Zucchini overview      MR busbar    Distribution fuse board tap-off     Ordering & technical information    02040608

2 ZUCCHINI        the specialist in busbar systems     A leading name in busbar power distribution systems, Zucchini  continues to strengthen its position within the industrial and  commercial markets whilst developing innovative solutions for  the residential sector.Zucchini busbar is manufactured in state-of-the-art production  facilities, including one of the most technically advanced  aluminium plating processing units in Europe. These exceptional  manufacturing capabilities enable Legrand to offer a fully tested  range of products that are superior in terms of quality and design. All Zucchini busbar trunking systems are certified to  IEC EN 61439-6 by third party test houses CESI/RINA and  are manufactured in accordance with ISO 9001 : 2008  quality standards.

3 The Zucchini range of prefabricated busbars is one of the most  comprehensive on the market, ranging from 25 A lighting through  to 6300 A high power systems. Zucchini busbar is widely used  for power distribution in industrial, commercial and high rise  residential applications.   An extensive range...  LB PLUS is the range of  Zucchini busbars designed  for electrical distribution  within low power  applications.It offers simplicity, high  performance and easy  installation and can  meet all lighting and  power demands from  25 A to 63 A. Zucchini medium power  busbars offer speed,  simplicity and flexibility  during planning and  installation. MR offers the  perfect solution for rising  mains up to 1000 A and  is ideal for commercial  and high rise residential  applications. SCP is the Zucchini  busbar range used for  the transportation and  distribution of high power.Ranging from 630 A to  6300 A the dimensions  of super compact and its  ‘sandwich’ construction  enhance resistance to  short circuit stresses.  RCP is made to meet  the demands of extreme  environments. It can be  used indoors or outdoors  and provides high levels  of mechanical strength,  chemical resistance,  ingress and impact  protection, and continuity  of service in the event  of fire. LB PLUS - LOW POWER  BUSBAR SYSTEM MR - MEDIUM POWER  BUSBAR SYSTEM SCP - HIGH POWER  BUSBAR SYSTEM RCP IP68 -  RESIN BUSBAR To find out more visit www.legrand.co.uk

4 The perfect power distribution solution for  commercial and high rise residential buildings   MR is available with aluminium or copper conductors and has a large range of tap-off boxes including the new distribution fuse board. Tap-offs range from 16 to 1000 A, allowing the supply and protection of a wide range of loads using devices such as fuses, MCBs and MCCBs. ZUCCHINI MR - MEDIUM RATING BUSBAR

Lowering lifetime  installation costs MR features a monobloc electrical jointing system.  The shearhead bolt on the monobloc allows for fast  assembly of the run and guarantees long-term reliability  and safety.As well as being quick to install, Zucchini MR busbar  is easy to upgrade if existing installations need to be  modified. The vast choice of elbows, tees and other  accessories make any configuration possible, with  bespoke solutions also available on request.  SWITCHBOARD -   TRANSFORMER FEED  UNIT HORIZONTAL ELBOW VERTICAL ELBOW TAP-OFF BOXES Tap-off boxes  are available  empty or   pre-fitted with  circuit breakers  and meters Pre-installed joint  covers guarantee  mechanical  rigidity and  maintain IP 55  protection System is   certified to   IEC EN 61439-6,  the international  standard for  busbar trunking  systems Trunking lengths  are available in  single and double  sided versions,  and with either 4  or 5 conductors 5

6 ZUCCHINI  Distribution fuse board tap-off  The space saving solution that meets the demands of high rise residential developments

7 COMPACT IN DESIGN,  UNIQUE IN FUNCTIONALITY The latest addition to Zucchini’s impressive tap-off collection is designed to save space and time on site. It is an all-in-one tap-off and distribution board for cut-out fuses, where apartments can be individually isolated safely while the board remains live. Plugging directly onto the busbar, it eliminates the need for separate tap-offs and wall mounted fuse boards. Plug-in solution,  saving installation  time on site  Fully shrouded for safe isolation during operation Able to feed up to 12 individual apartments Quality design with generous  space for wiring Gland plates fitted on either side and  in the base for  easy cable exit

8 n  Dimensions All dimensions (mm) are nominal Plug-in tap-offs for the Zucchini MR busbar system   Fully shrouded to allow individual fuses to be removed while board   remains live  Space saving, tap-off mounts directly onto the rising main busbar   Supplied with base and side access gland plates for cable exit  Type tested to BS EN 61439 / IEC 61439 parts 1 and 6  Fuse-link type BS 88-3 distribution fuse board tap-offs for Zucchini MR busbar R-type and J-type cut-out fuse carriers Front view – 12-way and 9-way R-type 448 250 290 440 248 170130 1033 1008 120 80 1000 150 190 440 1008 Side view – 12-way and 9-way R-type 448 250 290 440 248 170130 1033 1008 120 80 1000 150 190 440 1008 Bottom view – 12-way and 9-way R-type 448 250290440 248 170 130 1033 1008 120 80 1000 150 190 440 1008 Pack Cat. Nos. With R-type fuse carriers 100 A max. single pole fuse carriers  Fuses not included 1 50414R3SP100 MR/MRF 3 way metal tap-off 1 50414R6SP100 MR/MRF 6 way metal tap-off 1 50414R9SP100 MR/MRF 9 way metal tap-off 1 50414R12SP100 MR/MRF 12 way metal tap-off With J-type fuse carriers 250 A max. triple pole fuse carriers  Fuses not included 1 50414J3TP250 MR/MRF 3 way metal tap-off

9 With an ingress protection rating of IP68 and ranging from 630 A to 6300 A, RCP is ideal for the distribution of high power energy in external environments.  RCP is manufactured with either aluminium or copper conductors which are completely embedded  in an epoxy resin, that provides mechanical strength and electrical insulation.  RCP resin busbar has good performance in fire conditions and exceeds the requirements stipulated in IEC 60331-1 : 2009 for continuity of service in the event of fire. EdM transformers are renowned for quality. Manufactured within a state-of-the-art production facility with attention to detail being paramount, each transformer undergoes rigorous testing prior to despatch. Legrand has many years experience in the production of dry transformers cast under vacuum in epoxy resin up to 36 kV. The ‘GreenT.HE’ range of high efficiency transformers conforms to IEC 60076-11 and EU regulation 548/2014. RCP resin busbar, made to meet the demands of extreme environments
