FLAM-GUARD Fire Resistant Cables
British Cables Company

FLAM-GUARD Fire Resistant Cables

PERFORMANCE UNDER FIRE CONDITIONS

British Cables Company

FLAM-GUARD Fire Resistant Cables

Published: 9 January 2024 · Category: Product Catalogues & Brochures

PERFORMANCE UNDER FIRE CONDITIONS

From this document

FLAM-GUARD FIRE RESISTANT CABLES PERFORMANCE UNDER FIRE CONDITIONS ‘Standard’ Cables – Requirements ‘Standard’ cables are required to meet the below circuit integrity requirements; A minimum 30-minute survival time when tested to BS EN 50200 (PH 30) for fire alarm circuits or minimum 60-minute survival time (PH 60), for emergency lighting circuits. ‘Standard’ cables must also meet the requirements of BS EN 50200 Annex E. Test Description Temperature Test Duration BS EN 50200 (PH30) Resistance to Fire and Mechanical Shock 830ºC 30 Mins Fire with Mechanical Shock BS EN 50200 (PH60) Resistance to Fire and Mechanical Shock 830ºC 1 Hour Fire with Mechanical Shock BS EN 50200 (Annex E) Resistance to Fire, Mechanical Shock & Water 830ºC 15 Mins Fire with Mechanical Shock + 15 Mins Fire, Mechanical Shock and Water Spray ‘Enhanced’ Cables – Requirements ‘Enhanced’ cables are required to meet the below circuit integrity requirements; A minimum 120-minute survival time when tested to BS EN 50200 (PH 120) for both fire alarm circuits and emergency lighting circuits. ‘Enhanced’ cables must also meet the requirements of BS 8434-2. Test Description BS EN 50200 (PH120) Resistance to Fire & Mechanical Shock 830 ºC 2 Hours Fire with Mechanical Shock BS 8434-2 Resistance to Fire, Mechanical Shock & Water 930 ºC 1 Hour Fire with Mechanical Shock + 1 Hour Fire, Mechanical Shock and Water Spray FLAM-GUARD FIRE RESISTANT CABLES Temperature Test Duration FLAM-GUARD 100 (FG100) SINGLE CORE FIRE...

Open the PDF
