Contactors and motor protection for rolling stock application
ABB

Contactors and motor protection for rolling stock application

ABB supports the high levels of expectations for safe means of transport.

ABB

Contactors and motor protection for rolling stock application

Published: 4 July 2018 · Category: Product Catalogues & Brochures

ABB supports the high levels of expectations for safe means of transport.

From this document

— C ATA LO G Contactors and motor protection for rolling stock application Motor rated operational powers and currents The currents given below concern standard three-phase four-pole cage motors (1500 r.p.m. at 50 Hz 1800 r.p.m. at 60 Hz). These values are given for guidance and may vary according to the motor manufacturer and depending on the number of poles. Motor nominal current: standardized values in blue colour (according to IEC 60947-4-1 Annex G) Motor power 220 V 230 V 240 V 380 V 400 V 415 V 440 V 500 V 660 V 690 V kW 0.06 0.09 0.12 0.18 0.25 0.37 0.55 0.75 1.1 1.5 2.2 3 4 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110 132 160 200 250 315 355 400 500 560 630 710 800 900 1000 A 0.37 0.54 0.73 1 1.6 2.0 2.7 3.5 4.9 6.6 8.9 11.8 15.7 20.9 28.2 39.7 53.3 63.8 75.3 100 120 146 177 240 291 355 418 509 637 782 983 1109 1255 1545 1727 1928 2164 2446 2760 3042 A 0.35 0.52 0.7 1 1.5 1.9 2.6 3.3 4.7 6.3 8.5 11.3 15 20 27 38 51 61 72 96 115 140 169 230 278 340 400 487 609 748 940 1061 1200 1478 1652 1844 2070 2340 2640 2910 A 0.34 0.50 0.67 1 1.4 1.8 2.5 3.2 4.5 6 8.1 10.8 14.4 19.2 25.9 36.4 48.9 58.5 69 92 110 134 162 220 266 326 383 467 584 717 901 1017 1150 1416 1583 1767 1984 2243 2530 2789 A 0.21 0.32 0.46 0.63 0.9 1.2 1.6 2.0 2.8 3.8 5.2 6.8 8.9 12.1 16.3 23.2 30.5 36.8 43.2 57.9 69 84 102 139 168 205 242 295 368 453 568 642 726 895 1000 1116 1253 1417 1598 1761 A 0.2 0.3 0.44 0.6 0.85 1.1 1.5 1.9 2.7 3.6 4.9 6.5 8.5 11.5 15.5 22 29 35 41 55 66 80 97 132 160 195 230 280...
