SMART CONTROL SYSTEMS www.scolmore.com

call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Contents   Range Overview  a4 Typical Installations  a6 Smart Switches   a9 Smart Touch Controllers  a13      Receivers   a14  Wiring Accessories  a17 Switching & Dimmer Functions  a26 Pairing Sequence  a27 a2 Leading the way in smart automation •   Universal input switch converts up to 4 push-button switches - enabling existing devices to be connected  to the system. •   Operates on 868MHz frequency band which  provides robust communications. Complete control •   Allows portable and remote control up to  a distance of 200m  •   Control and adjustment of lights, on/off or create  lighting scenes.  •   Control shutters, blinds, gates, latches  and garage doors •  Manual or automatic control  •  Monitor window or door opening •  Simulate occupancy when you are away from home Why Click ®  INELS? •   Complete control of lighting and small power means energy is only consumed when needed - reducing your energy bills and carbon footprint.  •   No additional cables or wall cutting needed.  Receivers can be installed behind light fittings or  into suitable installation boxes and can be utilised  with existing wiring. •   Flexible positioning makes Click ®  Inels ideal for   installation within existing or newly constructed  buildings. With Click ®  Inels, you can move switches   freely and re-locate when required. Switches can be mounted on glass, wood or walls etc. •   Smart Switches are mainly powered by battery and  so do not require any wiring or additional power supply.

call: 01827 63454 fax: 01827 63362 email: [email protected] visit: www.scolmore.com a3 2 Way   Retractive / Momentary  Switches Live IN 2 Way Strappers (if applicable) RFDEL-71B  Switch Input Neutral Live OUT Permanent  Live IN Our Click ® Smart Dimming NEW Retractive Switch Control: For more information please visit  SHORT PRESS:  Turn On  /  Off PRESS & HOLD: Dim Up / Down • Never have to worry about changing the dimmer in the future if the dimmable LED source is changed • Compatible with the majority of  dimmable LED sources available • Suitable for dimming a single 5W  dimmable LED source • Will dim up to 160W of dimmable LED, halogen and CFL. • Select between capacitive, LED,  resistive and inductive loads •  7 programming options.

a4 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Range Overview Smart Switches 2 Channel   Switch Controller 4 Channel   Switch Controller 4 Channel Remote Switch   Controller Key Fob 4 Channel Universal   RF Switch Adapter Advanced Control of  Multiple RF Devices 40 Channel Remote  Control Wireless Window/ Door Contact   RF Compact PIR Sensor  (Indoor use only) RF Magnetic Door/ Window Surface Contact Single Channel Switch  (DIN Rail Mount) Choice of Plate supplied  with 10AX 2 Way Ingot  Retractive Switch Module

a5 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Range Overview 1 Channel Multifunctional   Switching Receiver   c/w Switch Input Multifunctional   Dimming Receiver c/w Switch Input 6 Channel  Multifunctional  Switch Receiver 2000W Remote  dimmer unit Signal Repeater  (with un-switched 13A power outlet) 13A Multifunctional  Switching Socket 1 Channel Multifunctional  Switching Receiver   with Antenna  2 Channel Switch Receiver Dimming Receiver  1-10V Analogue  Output  Shutter Receiver (24V DC) Shutter Receiver 230V AC Receivers   160Va 1 Channel Multifunction Dimming  Receiver Pre-wired with Flow TM  Connector  16A 1 Channel Multifunction Switching  Receiver Pre-wired with Flow TM  Connector

a6 call: 01827 63454 fax: 01827 63362 email: [email protected] visit: www.scolmore.com Typical Installations Control of lighting (both internal and external) to create simulated occupancy Leave lighting to turn off automatically when you leave for work Have lighting, as well as audio devices such as radio’s switch on and off during  holidays to give your home that lived in appearance  Automatically switch on lights via presence detectors Additional switching for multiple use (all the family can have a key fob to put external lights on as they approach the home) Providing complete control via simple solutions Automatically turn off lighting and power when you want to. Central programmer   enables you to programme lighting and power seven days a week Last man out function – not sure if the upstairs lights are still on? Easily remedied by a master switch inside the front door to turn everything off when you leave and back on when you return  Providing switching for external power so that sockets on the outside of buildings are  only powered when you want to use them Automatically switch on/off Christmas lighting so that it is only on when you want it to be

a7 call: 01827 63454 fax: 01827 63362 email: [email protected] visit: www.scolmore.com Typical Installations Creating scenes to provide added ambience for any situation around the home Control children’s rooms to restrict use of TV / gaming etc. Provide timed access routes to create scenes such as “morning” or “bedtime”  to meet changing requirements of the occupier Use a bell push to switch a light on for the hard of hearing Create a bedtime route that turns all lights on and off to allow the occupier to get to bed without needing to switch lights on/off Change the use of a room – putting switches where you want them. Ideal for converting a downstairs room into a bedroom Switches can be mounted on any surface   – even glass Wireless switching up to 200 metres Interacts with building management systems to provide additional control Walkway lighting (hotels and commercial  properties with interconnecting buildings)

a8 Smart Switches

a9 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Switches   RFWB-20/G   2 Channel Wall Switch Controller - White  RFWB-40/G  4 Channel Wall Switch Controller - White No back box required.    Can be installed using the sticky pads (supplied) or screw fixings (not supplied) RF KEY/W   4 Channel Remote Key Fob - White   RF KEY/B   4 Channel Remote Key Fob - Black RFTP001  UK Switched Socket & Key Fob Test Pack  Wireless Smart Switches  |  Key Fob   Smart Switches Standards:  EN 60669, EN 300220, EN 301489 Dimensions:   85mm x 85mm x 16mm   64mm x 25mm x 10mm

a10 call: 01827 63454 fax: 01827 63362 email: [email protected] visit: www.scolmore.com Smart Switches Switches RFIM-40B Universal Input Switch  For use with standard retractive switches or 3 position centre ‘Off’ retractive switches RF PILOT Hand held 40 Channel Remote Controller Control individual receivers or scenes of up to 10 receivers with a single press RFSG-1M   230V~ Single Channel Switch (DIN Rail Mount) Can switch 12-230V AC/DC inputs. Transmits a continuous signal with input status ON or OFF. Programs to function 1 of switching receivers.  AN-E   External Antenna (3m fitted cable) For use with RFSA-61M, RFSA-66M & RFSG-1M  Universal Input Switch  | Wired Transmitters | Remote Controller For use with (RF Touch) unit only Standards:  EN 60669, EN 300220, EN 301489 Dimensions: 90mm x 17.5mm x 64mm,   41mm x 130mm x 18mm  Cable Length:  90mm 49mm x 49mm x 13mm Battery Type:  CR 2032,  AAA (x2)

a11 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Switches & Repeater Window Door Contact   |  Window Door Contact   |  Signal Repeater Switches   JA-82M  UPVC Wireless Window / Door Contact JA-83M  Wireless Magnetic Door/Window Surface Contact JA-83P    Wireless Compact PIR Sensor (Indoor use only)   For pairing with switching receivers only Standards:  EN 50130-4, EN 55022, EN 60950, EN 60669, EN 300220, EN 301489    EN 60730 / BS1363 Dimensions:   25mm x 192mm x 9mm, 31mm x 75mm x 23mm, 16mm x 56mm x 15mm 60mm x 85mm x 55mm,    60mm x 12mm x 80mm     Battery Type:   CR 2354 (x2), CR 123A (x1) Repeater RFRP-20/B      240V Signal Repeater      (with  un-switched 13A power outlet)   Extends the range up to 200m for up to 20 Smart Switches.

a12 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com   Smart Touch Controller

a13 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Standards:  EN 60730,  Dimensions:  94mm x 94mm x 24mm   Touch Screen Controllers   RFT-WBK  Smart Touch Controller - Black (RF Touch)  RFT-WWH  Smart Touch Controller - White (RF Touch)  Smart Touch Controller supplied with DC Adaptor. Can be hard wired into the rear of the unit via 230V supply. Control individual receivers or scenes of up to 20 receivers with a single press. Smart Touch Controller RF Touch

a14 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Receivers

a15 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Single Channel Receivers  RFSAI-61B   16A Switching Receiver (Volt Free Contact) C/W Control Input    Can utilise retractive switch in conjunct with the 3V DC switch input. RFSA-61M       16A 1 Channel Multifunction Switching Receiver     (Volt free contact, normally open, normally closed) RFSC-61   13A 230V~ Multifunction Switching Socket Receiver   AN-E    External Antenna (3m fitted cable)    For use with RFSA-61M, RFSA-66M & RFSG-1M Single Channel Receivers  |  Multiple Channel Receivers  |  Shutter Receivers Receivers Standards:  EN 60669, EN 300220, EN 301489,  BS1363 Dimensions:  49mm x 49mm x 21mm,  60mm x 12mm x 80mm  90mm x 17.5mm x 64mm,   49mm x 49mm x 21mm, 49mm x 49mm x 13mm,   90mm x 52mm x 65mm Cable Length: 90mm    Relay Current Ratings:  AC1 Shutter Receivers RFJA-12B/24V   Shutter Receiver 12-24V (DC)  RFJA-12B/230V   Shutter Receiver 230V~ Multi Channel Receivers RFSA-62B    2 x 8A Multi-Channel Multifunction Switching Receiver    (230V~ live input supplies both live outputs) RFSA-66M    6 x 8A Multi-Channel Multifunction Switching Receiver   (volt free contacts, 3 x normally open with 3 x normally open, normally closed)

a16 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Receivers   RFSA-61F   16A 1 Channel Multifunction Switching Receiver Pre-wired with Flow TM  Connector RFDEL-71F    160Va 1 Channel Multifunction Dimming Receiver Pre-wired with Flow TM  Connector     Offers leading and trailing edge technology with trim facility.   Compatible with most dimmable LED light sources. RFDEL-71B    160Va 1 Channel Multifunction Dimming Receiver C/W 230V ~ Switch Input   Offers leading and trailing edge technology with trim facility.   Compatible with most dimmable LED light sources.   Can utilise retractive switch in conjunction with the 230V~ switch input. RFDAC-71B    16A 1 Channel Multifunction Dimming Receiver     0(1)-10V 1 Channel Multifunction Dimming Receiver. Complete with 230V~ 16A ON/OFF Switch Control Dimming Unit   DIM-6   2000W Dimming Unit (Not Wireless)  To control wirelessly the unit must be wired in conjunction with the RFDAC-71B or RFSAI-61B Standards:  EN 60669, EN 300220, EN 301489 Dimensions:    49mm x 49mm x 21mm,  105mm x 90mm x 65mm 260mm x 52mm x 25mm Cable Length: 90mm Receivers Multiple Channel Receivers  |  Dimming Unit

a17 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Smart Wiring Accessories VP AB BK - SMART1 ®  ® ®     Explanation of code:

a18 Deco TM  Smart  Switches Smart Switches Smart Switches   VP BK-SMART1  1G Plate 1 Aperture Supplied with 1 x 10AX 2 Way Ingot Retractive Switch Module - Black VP WH-SMART1   1G Plate 1 Aperture Supplied with 1 x 10AX 2 Way Ingot Retractive Switch Module - White VP BK-SMART2   1G Plate 2 Apertures Supplied with 2 x 10AX 2 Way Ingot Retractive Switch Modules - Black VP WH-SMART2   1G Plate 2 Apertures Supplied with 2 x 10AX 2 Way Ingot Retractive Switch Modules - White VP BK-SMART3   1G Plate 3 Apertures Supplied with 3 x 10AX 2 Way Ingot Retractive Switch Modules - Black VP WH-SMART3   1G Plate 3 Apertures Supplied with 3 x 10AX 2 Way Ingot Retractive Switch Modules - White VP BK-SMART4   2G Plate 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Ingot Retractive Switch Modules - Black VP WH-SMART4   2G Plate 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Ingot Retractive Switch Modules - White VP BK-SMART6   2G Plate 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Ingot Retractive Switch Modules - Black VP WH-SMART6   2G Plate 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Ingot Retractive Switch Modules - White Replace   with desired finish, listed below. Standards:  BS EN 60669  Back Box Depth:  16mm Minimum   Cable Size:  4 x 1.5mm² / 2 x 2.5mm² Dimensions:  1 Gang (88mm x 88mm x 8mm), 2 Gang (146mm x 88mm x 8mm),   Deco TM   Satin Chrome (SC), Black Nickel (BN), Pearl Nickel (PN) and Stainless Steel (SS). Georgian Style (GCBR) plates are manufactured from cast brass. Please note: Antique Brass and Black Nickel are only available with black inserts.    VP - Plate Style   BN - Plate Finish  BK - Insert Colour SMART1 - Product No.

a19 Smart Switches ®  Smart  Switches Smart Switches   FP BK-SMART1   1G Plate 1 Aperture Supplied with 1 x 10AX 2 Way Ingot Retractive Switch Module - Black FP WH-SMART1   1G Plate 1 Aperture Supplied with 1 x 10AX 2 Way Ingot Retractive Switch Module - White FP BK-SMART2   1G Plate 2 Apertures Supplied with 2 x 10AX 2 Way Ingot Retractive Switch Modules - Black FP WH-SMART2   1G Plate 2 Apertures Supplied with 2 x 10AX 2 Way Ingot Retractive Switch Modules - White FP BK-SMART3   1G Plate 3 Apertures Supplied with 3 x 10AX 2 Way Ingot Retractive Switch Modules - Black FP WH-SMART3   1G Plate 3 Apertures Supplied with 3 x 10AX 2 Way Ingot Retractive Switch Modules - White FP BK-SMART4   2G Plate 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Ingot Retractive Switch Modules - Black FP WH-SMART4   2G Plate 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Ingot Retractive Switch Modules - White FP BK-SMART6   2G Plate 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Ingot Retractive Switch Modules - Black FP WH-SMART6   2G Plate 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Ingot Retractive Switch Modules - White Replace   with desired finish, listed below. Standards:  BS EN 60669  Back Box Depth:  25mm Minimum   Cable Size:  4 x 1.5mm² / 2 x 2.5mm² Dimensions:  1 Gang (88mm x 88mm x 1.3mm ), 2 Gang (146mm x 88mm x 1.3mm )  Excluding gasket Define ®  plates are coated stainless steel, they are available in the following finishes: Brushed Steel (BS), Black Nickel (BN), Pearl Nickel (PN), Polished Chrome (CH)  and Stainless Steel (SS).    FP - Plate Style   BN - Plate Finish  BK - Insert Colour SMART1 - Product No.

a20 Smart Switches SIN BK-SMART1   1G Insert 1 Aperture Supplied with 1 x 10AX 2 Way Ingot Retractive Switch Module - Black SIN PW-SMART1   1G Insert 1 Aperture Supplied with 1 x 10AX 2 Way Ingot Retractive Switch Module - White SIN BK-SMART2   1G Insert 2 Apertures Supplied with 2 x 10AX 2 Way Ingot Retractive Switch Modules - Black SIN PW-SMART2   1G Insert 2 Apertures Supplied with 2 x 10AX 2 Way Ingot Retractive Switch Modules - White SIN BK-SMART3   1G Insert 3 Apertures Supplied with 3 x 10AX 2 Way Ingot Retractive Switch Modules - Black SIN PW-SMART3   1G Insert 3 Apertures Supplied with 3 x 10AX 2 Way Ingot Retractive Switch Modules - White SIN BK-SMART4   2G Insert 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Ingot Retractive Switch Modules - Black SIN PW-SMART4   2G Insert 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Ingot Retractive Switch Modules - White SIN BK-SMART6   2G Insert 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Ingot Retractive Switch Modules - Black SIN PW-SMART6   2G Insert 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Ingot Retractive Switch Modules - White TM  Smart  Switches Standards:  BS EN 60669  Back Box Depth:  25mm Minimum   Cable Size:  4 x 1.5mm² / 2 x 2.5mm² Dimensions:  1 Gang (86mm x 86mm x 4mm), 2 Gang (146mm x 86mm x 4mm)  Definity TM  plates are coated stainless steel, available in the following finishes: Brushed Steel (BS), Polished Chrome (CH) and Stainless Steel (SS).   White (PW) & Black (BK) are also available, produced from polycarbonate.     SIN  SS - ‘INGOT’ Switch Finish (if applicable)   BK - Insert Colour SMART1 - Product No. Smart Switches Replace   with desired finish, listed below. Please see overleaf for Smart Switch cover plates.

a21 Smart Switches  SINBK-SMART1   1G Insert 1 Aperture Supplied with 1 x 10AX 2 Way Retractive Switch Module - Black SINPW-SMART1   1G Insert 1 Aperture Supplied with 1 x 10AX 2 Way Retractive Switch Module - White SINBK-SMART2   1G Insert 2 Apertures Supplied with 2 x 10AX 2 Way Retractive Switch Modules - Black SINPW-SMART2   1G Insert 2 Apertures Supplied with 2 x 10AX 2 Way Retractive Switch Modules - White SINBK-SMART3   1G Insert 3 Apertures Supplied with 3 x 10AX 2 Way Retractive Switch Modules - Black SINPW-SMART3   1G Insert 3 Apertures Supplied with 3 x 10AX 2 Way Retractive Switch Modules - White SINBK-SMART4   2G Insert 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Retractive Switch Modules - Black SINPW-SMART4   2G Insert 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Retractive Switch Modules - White SINBK-SMART6   2G Insert 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Retractive Switch Modules - Black SINPW-SMART6   2G Insert 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Retractive Switch Modules - White TM  Smart  Switches Smart Switches Standards:  BS EN 60669  Back Box Depth:  25mm Minimum   Cable Size:  4 x 1.5mm² / 2 x 2.5mm² Dimensions:  1 Gang (86mm x 86mm x 4mm), 2 Gang (146mm x 86mm x 4mm)  Please see overleaf for Smart Switch cover plates. call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com

a22 Smart Switch Cover Plates TM  Smart  Switches Unfurnished Smart Switch Plates (Covers)   SCP401   1 Gang Plate Single Aperture for SMART1   SCP402   1 Gang Plate Twin Aperture for SMART2   SCP403   1 Gang Plate Triple Aperture for SMART3   SCP404   2 Gang Plate (2+2) Aperture for SMART4   SCP406   2 Gang Plate (3+3) Aperture for SMART6 Replace   with desired finish, listed below.     Definity TM  plates are coated stainless steel, available in the following finishes: Brushed Steel (BS), Polished Chrome (CH) and Stainless Steel (SS).   White (PW) & Black (BK) are also available, produced from polycarbonate.   SCP  401 - Product No  SS - Plate Colour.

a23 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Mode TM  Smart  Switches Smart Switches Smart Switches   CMA-SMART1  1G Plate 1 Aperture Supplied with 1 x 10AX 2 Way Retractive Switch Module CMA-SMART2   1G Plate 2 Apertures Supplied with 2 x 10AX 2 Way Retractive Switch Modules CMA-SMART3   1G Plate 3 Apertures Supplied with 3 x 10AX 2 Way Retractive Switch Modules CMA-SMART4   2G Plate 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Retractive Switch Modules CMA-SMART6   2G Plate 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Retractive Switch Modules Standards:  BS EN 60669  Back Box Depth:  16mm Minimum   Cable Size:  4 x 1.5mm² / 2 x 2.5mm²  Dimensions:  1 Gang (86mm x 86mm x 9.5mm), 2 Gang (146mm x 86mm x 9.5mm)

a24 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Polar TM  Smart  Switches Smart Switches   PRW-SMART1   1G Plate 1 Aperture Supplied with 1 x 10AX 2 Way Retractive Switch Module PRW-SMART2   1G Plate 2 Apertures Supplied with 2 x 10AX 2 Way Retractive Switch Modules PRW-SMART3   1G Plate 3 Apertures Supplied with 3 x 10AX 2 Way Retractive Switch Modules PRW-SMART4   2G Plate 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Retractive Switch Modules PRW-SMART6   2G Plate 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Retractive Switch Modules Standards:  BS EN 60669  Back Box Depth:  16mm Minimum   Cable Size:  4 x 1.5mm² / 2 x 2.5mm²  Dimensions:  1 Gang (86mm x 86mm x 11mm), 2 Gang (146mm x 86mm x 11mm)  Smart Switches

a25 call:  01827 63454     fax:   01827 63362    email:  [email protected]     visit:   www.scolmore.com Essentials TM  Smart  Switches Smart Switches   CL-SMART1  1G Insert 1 Aperture Supplied with 1 x 10AX 2 Way Ingot Retractive Switch Module - White CL-SMART2   1G Insert 2 Apertures Supplied with 2 x 10AX 2 Way Ingot Retractive Switch Modules - White CL-SMART3   1G Insert 3 Apertures Supplied with 3 x 10AX 2 Way Ingot Retractive Switch Modules - White CL-SMART4   2G Insert 2 x 2 Apertures Supplied with 4 x 10AX 2 Way Ingot Retractive Switch Modules - White CL-SMART6   2G Insert 2 x 3 Apertures Supplied with 6 x 10AX 2 Way Ingot Retractive Switch Modules - White Standards:  BS EN 60669  Back Box Depth:  40mm   Cable Size:  4 x 1.5mm² / 2 x 2.5mm²  Dimensions:  1 Gang (80mm x 80mm), 2 Gang (146mm x 80mm),  : 20mm Smart Switches

a26 call: 01827 63454 fax: 01827 63362 email: [email protected] visit: www.scolmore.com C - CAPACITIVE R - RESISTIVE L - INDUCTIVE L Switching & Dimmer Functions Function 1 Press button Press for ON, release for OFF Function 2 ‘On’ button Press for ON Function 3 ‘Off’ button Press for OFF Function 4 On/Off button Press for ON, press again for OFF Function 5 ‘Off’ delay Press for ON, device will turn off after pre-determined timeperiod as set in step 3 of programming (2 secs - 60 mins max)  Function 6 ‘On’ delay  Press to start timer. ‘On’ delay will be as pre-determined in step 3 of programming (2 secs -60mins) Function 1 Scene recall / OFF Press to recall scene, press to turn OFF Press button for morethan 1 second to setscene brightness Function 2 Scene recall /OFF - anti-tamper Press to recall scene, press again to turn OFF Press button for more than 3 seconds to set scene brightness  (avoids accidental scene setting) Function 3 Scene recall -fade ON / fade OFF - push to recall scene Press to recall scene Press button for morethan 1 second to setscene brightness Function 4 Scene recall /fade OFF Press to recall scene Press button for morethan 1 second to setscene brightness Function 5 Variable fade up to  Press to start fade up time to maximum brightness N/A Function 6 Variable fade down to  Press to start, fade down to OFF N/A Function 7 ON/OFF Press once for ON,press again for OFF N/A Functions

a27 call: 01827 63454 fax: 01827 63362 email: [email protected] visit: www.scolmore.com Pairing Sequence Follow these simple instructions when pairing  Smart Switches to receivers: Press & hold the ‘programming’ button on the receiver for 2  PROGRAMMING BUTTON STATUS LEDWILL FLASH PER SECOND PRESS AND HOLD FOR 2 SECONDS STEP 1 To assign the chosen switch device button & function, press the required button the number of times to match the function number required at one second intervals - SEE TABLE 1 on opposite page (e.g for switch function 2, press the button 2 times). PRESS THE NUMBER OF TIMES THAT CORRESPONDSTO THE DESIRED FUNCTION STEP 2 To exit programming mode press the ‘programming’  button for 1 second only. PRESS AND HOLD FOR 1 SECOND STEP 4 PRESS AND HOLD FOR 5 SECONDS STATUS LED WILL FLASH TWICEPER SECOND FUNCTIONBUTTON PRESS THE BUTTON  THAT CORRESPONDS  THE DESIRED FUNCTION  TO DELETE To set the time element, press & hold the ‘programming’ button  second interval). THE TIMER HAS NOW STARTED. When the required time period has elapsed, press the previously assigned  PRESS AND HOLD  5 SECONDS STATUS LEDWILL FLASH TWICE PER SECOND STEP 3 PRESS AND HOLD 8 SECONDS - THIS WILL DELETE ALL STORED FUNCTIONS. RELEASE PROGRAMMING BUTTON AND THEN PRESS FOR 1 SECOND TO EXIT FUNCTIONBUTTON
