Thorn - Product Brochure - Cetus LED - 2015
Thorn - Product Brochure - Cetus LED -2015
Thorn Contractor Range Telephone: 0844 855 4810 email: [email protected] website: www.thornlighting.co.uk/CTUL CONTACT DETAILS Fast. Simple. Affordable. We offer products with outstanding quality, easy installation and competitive prices. All of this is provided to you in close cooperation with your local wholesaler. Save time. Save money. Save energy. With our comprehensive portfolio you can realise smaller and larger projects in a fast, cost-effective and energy-efficient manner. According to project requirements, solutions with conventional technology as well as up-to-date LED luminaires can be implemented - depending on your budget. Cetus LED DOWNLIGHT Fast. Simple. Affordable. Replaces 1x26W and 2x26W CFL Up to 65% Energy saving Product Dimensions Ordering Guide Description Wattage Wt (Kg) SAP Code Cat. No. CETUS LED 1000 HF 830 13 0.70 96242095 CU1000Z3K CETUS LED 1000 HF 840 13 0.70 96242096 CU1000Z4K CETUS LED 2000 HF 830 25 0.70 96242097 CU2000Z3K CETUS LED 2000 HF 840 25 0.70 96242098 CU2000Z4K Emergency versionsCETUS LED 1000 HF E3 830 16.5 1.75 96242209 CU1000ZE3K CETUS LED 1000 HF E3 840 16.5 1.75 96242099 CU1000ZE4K CETUS LED 2000 HF E3 830 28.5 1.75 96242210 CU2000ZE3K CETUS LED 2000 HF E3 840 28.5 1.75 96242100 CU2000ZE4K Ø190mm (200mm Maximum) 215 88 100x50 30 CETUS LED 1000LM Ø190mm (200mm Maximum) 215 88 145x50 30 CETUS LED 2000LM Ø190mm (200mm Maximum) 215 97 145x305 35 CETUS LED E3 Sample layouts Mounting height 2.8m Work Plane Floor Maintenance factor 0.80 Reflectances Ceiling: 70% Wall: 50% Floor: 20% Luminaire CETUS LED 2000 HF 840 Lamp LED Lumens 2000 lm Lux 207 lx Mounting height 3.0m Work Plane 0.75m Maintenance factor 0.80 Reflectances Ceiling: 70% Wall: 50% Floor: 20% Luminaire CETUS LED 2000 HF 840 Lamp LED Lumens 2000 lm Lux 502 lx 21m 2m 10m 6m Reception Area - 10m x 6m x 3m - 20 luminaires Corridor - 21m x 2m x 2.8m - 9 luminaires 2m 2m
• Tool free installation directly out of the box • Only 88mm overall height to allow installation into low and restricted ceiling voids • Flexible installation - suitable for 1-35mm ceiling thickness Installation • Remote driver for ease and flexibility of installation Energy and cost savings Based on: Office area - 10m x 6m x 3m Lux level - 502lx Luminaires - 20 LED vs 20 compact fluorescent (Cetus 2x26W HF) Usage - 14hrs/day, 5 days per week, 3640hrs/year. Energy price - £0.15/KWh 63% EnErgy Saving £453 annual Saving 13yRS lifE TiME • 1000lm or 2000lm LED, one for one replacement for traditional 1x26W or 2x26W compact fluorescent downlights • Only 13W or 25W total load, up to 65% energy saving vs fluorescent equivalents • 80Llm/W – exceeding building regulation requirements • 50 000 hours rated life, equivalent to 13 years at 14 hours per day operation • Choice of 3000K warm white or 4000K cool white to suit application use • Integral 3 hour emergency option reduces installation time and complexity Performance • White aluminium body/reflector with spring steel fixing clips • Sealed to IP44 as standard, suitable for use in bathrooms without the need for separate attachments • Remote driver for ease and flexibility of installation Construction Standards 1000lm or 2000lm LED, direct replacement for 1x26W or 2x26W CFL LED
