LED systems for industrial lighting and floodlights 4 Smart GEWISS S.p.A. Registered Office: Via A. Volta, 1 - 24069 CENATE SOTTO (Bergamo) - Italy Tel. +39 035 946 111 - Fax +39 035 945 222 - [email protected] - www.gewiss.com Sole Shareholder company - Bergamo Register of Companies / VAT/TAX CODE (IT) 00385040167 - REA 107496 - Share capital 60,000,000.00 EUR fully paid up. PB 22 329 EN - 04 .15

Smart 4 [ ] Floodlights RGBW systems Smart [4] is available in RGBW colour versions To enhance open spaces, geometries and volumes of buildings with a high architectural value, Smart [4] offers solutions for decorative and scenographic lighting.With the new RGBW versions (Red, Green, Blue and White), you can create different lighting scenes (controlled via a DMX control unit) by selecting the single colour or pre-configured colour scenes.

Intelligence is the ability to adapt to the environment, resorting to the best solutions in terms of effectiveness and efficiency, in any situation. Smart [4] is the new lighting device from GEWISS that interprets intelligence in precisely this way, transforming its practical and application versatility into its most distinguishing feature. The new GEWISS device is designed, in fact, to offer sustainable light in a wide variety of contexts where good performance is essential. Smart [4] can be a floodlight, high bay or luminaire as needed, offering different photometries according to the various situations. The horizontal and vertical modularity of the new product combines with the easy installation and maintenance, the use of “green” materials and unmistakable Italian style. A unique range that comes in three different versions – COMFORT, PERFORMANCE, EFFICIENCY – to ensure optimum lighting results in terms of chromatic yield, control and quantity of light flux. And that's not all. Smart [4] can be managed by means of advanced systems like DALI and DALI READY, or even wireless systems (via a smartphone, tablet, PC or supervisor panel). And for architectural or decorative applications, Smart [4] has RGBW colour versions to create different lighting scenes. Energy efficiency, lighting quality, an immediate return on the investment, quick and easy set-up: these are the characteristics that make Smart [4] a truly smart product. TRULY SUSTAINABLE LIGHTING 4 Smart PB 22329 IT Smart 4_EN_OK.indd 3 06/07/15 15:53

Smart [ 4 ] Choose your set-up This version is distinguished by the optimum flux control and high chromatic yield index, guaranteeing excellent visual comfort. COMFORT Colour Render Index: 80 Max. efficiency: 89 lm/W PERFORMANCE Colour Render Index: 80 Max. efficiency: 94 lm/W EFFICIENCY Colour Render Index: 70 Max. efficiency: 101 lm/W The perfect balance between lighting power and light quality. The High Power LED offers the best in terms of lighting efficiency and the amount of flux. 04 PB 22329 IT Smart 4_EN_OK.indd 4 06/07/15 15:53

Smart 4 [ ] Choose your set-up Set-up COMFORT 100° diffused 60° average 30° restricted 10° spotlight Elliptical Asymmetrical HIGH BAY vacuum metallised polycarbonate TIR COLLIMATORtransparent polycarbonate PRINTED CIRCUIT (PCB) + LED SECONDARY LENSES plexiglass 05 PB 22329 IT Smart 4_EN_OK.indd 5 06/07/15 15:53

Set-up PERFORMANCE Elliptical 60° average Asymmetrical HIGH BAY polycarbonate metallised polycarbonate PRINTED CIRCUIT (PCB) + LED 06 PB 22329 IT Smart 4_EN_OK.indd 6 06/07/15 15:53

Smart 4 [ ] Choose your set-up Set-up EFFICIENCY Elliptical 60° average 100° diffused Asymmetrical PRINTED CIRCUIT (PCB) + LED HIGH BAY vacuum metallised polycarbonate SECONDARY LENS plexiglass 07 PB 22329 IT Smart 4_EN_OK.indd 7 06/07/15 15:53

Thermal sizing Dissipator design The heat produced while the LED chip is working must be correctly dissipated to avoid any alteration of the quantitative and qualitative performance (e.g. lighting efficiency, average lifespan, spectral emissions). Gewiss has decided to create a dissipator in die-cast aluminium with a very low copper content, sized so as to guarantee the correct functioning of the diodes. Careful preliminary studies, carried out using dedicated software and validated by sample testing, ensure optimal working conditions. Heat exchange Heat dispersion in the lighting device is guaranteed by the correct size of the passive dissipator (located directly in contact with the printed circuit board) and by heat paths that promote heat exchange between the device and the external environment.Smart [4], designed according to integrated thermal criteria, uses even the smallest movement of the air to dissipate the heat. Virtual simulation of the passive dissipator, thermal behaviour inside it and in the surrounding environment. 08 PB 22329 IT Smart 4_EN_OK.indd 8 06/07/15 15:53

Smart [4] is a huge step forward for the entire lighting sector, because it even pre-empts the regulatory developments currently being examined. In fact, the European Community is carrying out a series of pilot studies relating to the Product Environmental Footprint (PEF) with the aim, in the near future, of facilitating the spread of goods and services whose impact is quantified, monitored and communicated, and therefore managed to ensure continuing improvement. IMQ-Eco certification IMQ Eco is a national, voluntary certification issued by a third party (Istituto Italiano Marchio di Qualità) to confirm the truthfulness and impartiality of the declarations concerning the environmental, ecological or energy characteristics of a product. It is obtained thanks to the high percentage of recyclability of the product Smart [4] (83.1% of recyclability for GW L1 111). Life cycle evaluation Smart [4] is designed to optimise the efficiency of production plants, with a particular focus on the phases linked to the end consumer: distribution, use and end of working life. The result is a product with a high degree of efficiency for the same performance levels, and certified at international level. In recent years, GEWISS has taken the road of environmental sustainability, as demonstrated in the creation of increasingly innovative and eco-compatible products that optimise production plant efficiency. Starting from a purely voluntary interest, GEWISS has gone on to develop items that consider the whole life cycle, offering the end consumer a product that uses electricity with optimum efficiency standards whilst still maintaining the same level of performance.The design and production approach adopted with Choose your set-up Smart 4 [ ] A new design and technological approach: eco-design Environmental certifications for a truly green product 09 PB 22329 IT Smart 4_EN_OK.indd 9 06/07/15 15:53

10 PB 22329 IT Smart 4_EN_OK.indd 10 06/07/15 15:53

YEARS E X T E N D E D WARRANTY Industrial lighting A lighting device for industrial environments, logistics centres and parking areas.- Frame in technopolymer - Dissipator in die-cast aluminium with very low copper content - Tempered glass, 4mm thick- Fixing plate in galvanised steel Smart 4 [ ] Smart [ 4 ] LB|HB - Fixing spring in pre-stressed steel wire / steel cables- IP66- IK08- GLOW WIRE TEST 850°C- Versions complying with DIN 18032-3 for installation in covered sports facilities 11 PB 22329 IT Smart 4_EN_OK.indd 11 06/07/15 15:53

716 163 71 71 700 504 253 71 383 486 163 71 700 253 71 Colours Grey RAL 7037 Smart [4] LB - 2+2L - IP66 - IK08 - GLOW WIRE TEST 850°C Smart [4] LB - 2L - IP66 - IK08 - GLOW WIRE TEST 850°C Smart [4] HB - 4+4L - IP66 - IK08 - GLOW WIRE TEST 850°C 5+5L - IP66 - IK08 - GLOW WIRE TEST 850°C Smart [4] HB - 4x4L - IP66 - IK08 - GLOW WIRE TEST 850°C 4x5L - IP66 - IK08 - GLOW WIRE TEST 850°C Smart [4] LB - 4L - IP66 - IK08 - GLOW WIRE TEST 850°C 5L - IP66 - IK08 - GLOW WIRE TEST 850°C Low-bay lighting devices High-bay lighting devices HB 4+4L HB 5+5L HB 4x4L HB 4x5L LB 4L LB 5L 12 PB 22329 IT Smart 4_EN_OK.indd 12 06/07/15 15:53

Smart 4 [ ] Industrial lighting Smart [4] LB-HB COMFORT Smart [4] - LB 2L Smart [4] - LB 2+2L Smart [4] - LB 4L Smart [4] - LB 5L Smart [4]-HB 4+4L Smart [4]-HB 5+5L Smart [4]-HB 4x4L Smart [4]-HB 4x5L Lumen output 1 2,710 lm 5,150 lm 5,420 lm 6,170 lm 10,840 lm 12,340 lm 21,680 lm 24,680 lm System power 31W 62W 62W 69W 124W 138W 248W 276W Equivalent power 1x58W FD 2x58W FD 2x58W FD 2x58W FD 250W ME 250W ME 400W ME 400W ME System efficiency 87 lm/W 83 lm/W 87 lm/W 89 lm/W 87 lm/W 89 lm/W 87 lm/W 89 lm/W Lifetime (L80) 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h Colour temperature 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K CRI ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 Weight (kg) 2.3 kg 4.1 kg 4 kg 4 kg 7.4 kg 7.4 kg 13.4 kg 13.4 kg Installation Ceiling • • • • • • • • Trunking • • • • • • • • Rod (ties) • • • • • • • • Rod (plate) • • • • • • • • Suspension • • • • • • • • Bracket • • • • • • • • Stand Alone 100° GW L1 011 GW L1 041 GW L1 071 GW L1 111 GW L1 311 GW L1 341 GW L1 371 GW L1 411 60° GW L1 012 GW L1 042 GW L1 072 GW L1 112 GW L1 312 GW L1 342 GW L1 372 GW L1 412 30° GW L1 013 GW L1 043 GW L1 073 GW L1 113 GW L1 313 GW L1 343 GW L1 373 GW L1 413 Elliptic GW L1 014 GW L1 044 GW L1 074 GW L1 114 GW L1 314 GW L1 344 GW L1 374 GW L1 414 DALI Ready 100° GW L1 011 DR GW L1 041 DR GW L1 071 DR GW L1 111 DR GW L1 311 DR GW L1 341 DR GW L1 371 DR GW L1 411 DR 60° GW L1 012 DR GW L1 042 DR GW L1 072 DR GW L1 112 DR GW L1 312 DR GW L1 342 DR GW L1 372 DR GW L1 412 DR 30° GW L1 013 DR GW L1 043 DR GW L1 073 DR GW L1 113 DR GW L1 313 DR GW L1 343 DR GW L1 373 DR GW L1 413 DR Elliptic GW L1 014 DR GW L1 044 DR GW L1 074 DR GW L1 114 DR GW L1 314 DR GW L1 344 DR GW L1 374 DR GW L1 414 DR DALI 100° GW L1 011 D GW L1 041 D GW L1 071 D GW L1 311 D GW L1 371 D GW L1 411 D 60° GW L1 012 D GW L1 042 D GW L1 072 D GW L1 312 D GW L1 372 D GW L1 412 D 30° GW L1 013 D GW L1 043 D GW L1 073 D GW L1 313 D GW L1 373 D GW L1 413 D Elliptic GW L1 014 D GW L1 044 D GW L1 074 D GW L1 314 D GW L1 374 D GW L1 414 D Wireless 100° GW L1 011 RF GW L1 041 RF GW L1 071 RF GW L1 311 RF GW L1 371 RF GW L1 411 RF 60° GW L1 012 RF GW L1 042 RF GW L1 072 RF GW L1 312 RF GW L1 372 RF GW L1 412 RF 30° GW L1 013 RF GW L1 043 RF GW L1 073 RF GW L1 313 RF GW L1 373 RF GW L1 413 RF Emergency 4 100° GW L1 091 E GW L1 092 E GW L1 093 E GW L1 391 E GW L1 392 E Complementary items Smart [4] - LB 2L Smart [4] - LB 2+2L Smart [4] - LB 4L Smart [4] - LB 5L Smart [4]-HB 4+4L Smart [4]-HB 5+5L Smart [4]-HB 4x4L Smart [4]-HB 4x5L Items for Bracket GW L1 921 GW L1 922 GW L1 923 GW L1 923 GW L1 924 GW L1 924 GW L1 925 GW L1 925 installation Fixed suspension kit • • • • • • • • Adjustable suspension kit GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 Rod fixing kit • • GW L1 926 GW L1 926 4 x GW L1 926 4 x GW L1 926 • • Kit for surface-mounting/ceiling-mounting • • • • GW L1 927 GW L1 927 GW L1 928 GW L1 928 Fast Cleaner cover • • • GW L1 929 • • • • Spare parts Spare glass GW L1 906 GW L1 906 GW L1 907 GW L1 907 GW L1 907 GW L1 907 GW L1 907 GW L1 907 Interface DALI/DALI Ready GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 • Standard • Accessory • Not envisaged 1 In reference to the version with 100° diffused optic - Stand Alone 13 PB 22329 IT Smart 4_EN_OK.indd 13 06/07/15 15:53

Smart [4] LB-HB PERFORMANCE Smart [4] - LB 2L Smart [4] - LB 2+2L Smart [4] - LB 4L Smart [4] - LB 5L Smart [4]-HB 4+4L Smart [4]-HB 5+5L Smart [4]-HB 4x4L Smart [4]-HB 4x5L Lumen output 1 2,780 lm 5,560 lm 5,560 lm 6,470 lm 11,110 lm 12,940 lm 22,220 lm 25,880 lm System power 31W 62W 62W 69W 124W 138W 248W 276W Equivalent power 1x58W FD 2x58W FD 2x58W FD 2x58W FD 250W ME 250W ME 400W ME 400W ME System efficiency 90 lm/W 90 lm/W 90 lm/W 94 lm/W 90 lm/W 94 lm/W 90 lm/W 94 lm/W Lifetime (L80) 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h Colour temperature 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K CRI ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 Weight (kg) 2.3 kg 4.1 kg 4 kg 4 kg 7.4 kg 7.4 kg 13.4 kg 13.4 kg Installation Ceiling • • • • • • • • Trunking • • • • • • • • Rod (ties) • • • • • • • • Rod (plate) • • • • • • • • Suspension • • • • • • • • Bracket • • • • • • • • Stand Alone 60° GW L2 012 GW L2 042 GW L2 072 GW L2 112 GW L2 412 GW L2 442 GW L2 472 GW L2 512 Elliptic GW L2 014 GW L2 044 GW L2 074 GW L2 114 GW L2 414 GW L2 444 GW L2 474 GW L2 514 Wireless 60° GW L2 012 RF GW L2 042 RF GW L2 072 RF / GW L2 412 RF / GW L2 472 RF GW L2 512 RF Elliptic GW L2 014 RF GW L2 044 RF GW L2 074 RF / GW L2 414 RF / GW L2 474 RF GW L2 514 RF Complementary items Smart [4] - LB 2L Smart [4] - LB 2+2L Smart [4] - LB 4L Smart [4] - LB 5L Smart [4]-HB 4+4L Smart [4]-HB 5+5L Smart [4]-HB 4x4L Smart [4]-HB 4x5L Items for Bracket GW L1 921 GW L1 922 GW L1 923 GW L1 923 GW L1 924 GW L1 924 GW L1 925 GW L1 925 installation Fixed suspension kit • • • • • • • • Adjustable suspension kit GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 Rod fixing kit • • GW L1 926 GW L1 926 4 x GW L1 926 4 x GW L1 926 • • Kit for surface-mounting/ceiling-mounting • • • • GW L1 927 GW L1 927 GW L1 928 GW L1 928 Fast Cleaner cover • • • GW L1 929 • • • • Spare parts Spare glass GW L1 906 GW L1 906 GW L1 907 GW L1 907 GW L1 907 GW L1 907 GW L1 907 GW L1 907 Interface DALI/DALI Ready GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 • Standard • Accessory • Not envisaged 1 In reference to the version with 100° diffused optic - Stand Alone 14 PB 22329 IT Smart 4_EN_OK.indd 14 06/07/15 15:53

Smart 4 [ ] Industrial lighting Smart [4] LB-HB EFFICIENCY Smart [4] - LB 2L Smart [4] - LB 2+2L Smart [4] - LB 4L Smart [4] - LB 5L Smart [4]-HB 4+4L Smart [4]-HB 5+5L Smart [4]-HB 4x4L Smart [4]-HB 4x5L Lumen output 1 3,000 lm 6,000 lm 6,000 lm 6,990 lm 12,000 lm 13,980 lm 24,000 lm 27,950 lm System power 31W 62W 62W 69W 124W 138W 248W 276W Equivalent power 1x58W FD 2x58W FD 2x58W FD 2x58W FD 250W ME 250W ME 400W ME 400W ME System efficiency 97 lm/W 97 lm/W 97 lm/W 101 lm/W 97 lm/W 101 lm/W 97 lm/W 101 lm/W Lifetime (L80) 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h 80,000h Colour temperature 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K 4,000K CRI ≥ 70 ≥ 70 ≥ 70 ≥ 70 ≥ 70 ≥ 70 ≥ 70 ≥ 70 Weight (kg) 2.3 kg 4.1 kg 4 kg 4 kg 7.4 kg 7.4 kg 13.4 kg 13.4 kg Installation Ceiling • • • • • • • • Trunking • • • • • • • • Rod (ties) • • • • • • • • Rod (plate) • • • • • • • • Suspension • • • • • • • • Bracket • • • • • • • • Stand Alone 100° GW L2 211 GW L2 241 GW L2 271 GW L2 311 GW L2 611 GW L2 641 GW L2 671 GW L2 711 60° GW L2 212 GW L2 242 GW L2 272 GW L2 312 GW L2 612 GW L2 642 GW L2 672 GW L2 712 Wireless Elliptic GW L2 214 GW L2 244 GW L2 274 GW L2 314 GW L2 614 GW L2 644 GW L2 674 GW L2 714 Complementary items Smart [4] - LB 2L Smart [4] - LB 2+2L Smart [4] - LB 4L Smart [4] - LB 5L Smart [4]-HB 4+4L Smart [4]-HB 5+5L Smart [4]-HB 4x4L Smart [4]-HB 4x5L Items for Bracket GW L1 921 GW L1 922 GW L1 923 GW L1 923 GW L1 924 GW L1 924 GW L1 925 GW L1 925 installation Fixed suspension kit • • • • • • • • Adjustable suspension kit GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 GW L1 901 Rod fixing kit • • GW L1 926 GW L1 926 4 x GW L1 926 4 x GW L1 926 • • Kit for surface-mounting/ceiling-mounting • • • • GW L1 927 GW L1 927 GW L1 928 GW L1 928 Fast Cleaner cover • • • GW L1 929 • • • • Spare parts Spare glass GW L1 906 GW L1 906 GW L1 907 GW L1 907 GW L1 907 GW L1 907 GW L1 907 GW L1 907 Interface DALI/DALI Ready GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 GW L1 941 • Standard • Accessory • Not envisaged 1 In reference to the version with 100° diffused optic - Stand Alone 15 PB 22329 IT Smart 4_EN_OK.indd 15 06/07/15 15:53

Efficiency and constant performance over time Performance Why choose a Power LED? From a photometric point of view, the main difference between a Power LED and a Midpower LED Array lies in the focus.In the case of the Array, the dimensions of the emitting area mean that part of the flux is not perfectly controlled by the high bay, whereas the focus is more accurate with Power LEDs. In addition, their reduced size makes it possible to use TIR lenses too, offering highly controlled photometric division with a notable usage coefficient.Power LEDs also offer better colour consistency over time, which producing a seemingly homogeneous colour in installations with a large number of lighting devices, and a colour yield more or less constant over time.The use of a high quality Power LED (high BIN) makes it possible to obtain identical colour performances - in other words, to create lighting systems where it's very difficult to detect any colour differences between the devices. In the case of a Midpower LED Array, the quality selection is generally more limited. Power LEDs The Smart [4] devices are equipped with Power LEDs.They provide a colour temperature of 4000K to guarantee high levels of light efficiency, low flux decay, long duration and excellent colour performance. Colour consistency over time Neon - 3,600K - CRI 70 Smart [4] - 4,000K - CRI 80 16 PB 22329 IT Smart 4_EN_OK.indd 16 06/07/15 15:53

SAVINGS OF 65% PAYBACK IN 15 MONTHS + HIGHER COSTS - LESS LIGHT - LOWER COSTS + MORE LIGHT Yesterday, without Smart [ 4 ] Today, with Smart [ 4 ] 17 PB 22329 IT Smart 4_EN_OK.indd 17 06/07/15 15:53

Energy consumption New system Comparison between traditional and LED technologies Obsolete or poorly maintained system Comparison between traditional and LED technologies 0 0 100 % % % % 100 80 80 60 60 40 40 20 20 Watertight luminaire (T8) Watertight luminaire (T8) Smart [4] LB Smart [4] LB 0 0 100 100 80 80 60 60 40 40 20 20 Industrial high bay (HID) Industrial high bay (HID) Smart [4] HB Smart [4] HB up to 50% less up to 70% less up to 60% less up to 80% less 18 PB 22329 IT Smart 4_EN_OK.indd 18 06/07/15 15:53

0 1000 2000 3000 4000 5000 6000 7000 8000 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 0,10 €/kWh0,13 €/kWh0,16 €/kWh0,18 €/kWh sempre acceso (8.760h) Smart 4 [ ] Industrial lighting Payback Improving lighting without changing the existing electrical system Payback expected for the hours worked, energy cost and condition of the system based on the hours of use and the energy cost EXPECTED PAYBACK (YEARS) Smart [4] LB (1) Example: assembly line - Three shifts over 220 working days: approx. 5,300 hours per year - Correctly maintained system and average energy cost: € 0.16/kWh - Expected payback: just over 4 years - Always switched on: 8,760 hours per year - System poorly maintained or obsolete, and energy cost below the average: € 0.13/kWh - Expected payback: 2 years Example: underground parking area ANNU AL OPER ATING HOURS 19 PB 22329 IT Smart 4_EN_OK.indd 19 06/07/15 15:53

+ + + + + Configuration The Smart[4] system includes a complete range of fixing systems for every type of application Smart [4] LB 2L and Smart [4] LB 2+2L Smart [4] LB 4L|5L STANDARD STANDARD adjustable suspension cables bracket BRACKET fixing TRUNKING/BUS BAR fixing ADJUSTABLE SUSPENSION fixing CEILING mounting ROD fixing STANDARD adjustable suspension cables plate bracket ADJUSTABLE SUSPENSION fixing CEILING mounting TRUNKING/BUS BAR fixing STANDARD BRACKET fixing Fixing suitable for use in sports contexts, in accordance with DIN 18032-3 20 PB 22329 IT Smart 4_EN_OK.indd 20 06/07/15 15:54

+ + + + + + + Smart [4] HB 4+4L|5+5L Smart [4] HB 4x4L|4x5L FIXED SUSPENSION fixing fixed suspension cables bracket plate CEILING mounting plate and spring BRACKET fixing ROD fixing STANDARD fixed suspension cables bracket plate and spring FIXED SUSPENSION fixing CEILING mounting STANDARD BRACKET fixing Smart 4 [ ] Industrial lighting Fixing suitable for use in sports contexts, in accordance with DIN 18032-3 21 PB 22329 IT Smart 4_EN_OK.indd 21 06/07/15 15:54

Installation The point-point replacement is the easiest, most economic and reliable solution, minimising the cost of the first installation and making it comparable with a simple relamping Standard kit for Smart [4] LB for ceiling mounting N.B. only one of the existing coupling points will be used Easy installation/replacement CEILING mounting 2. Electrical disconnection of device to be replaced 3. Mechanical disassembly of the device to be replaced 1. Device to be replaced 4. Installation of the new Gewiss spring 5. Mechanical connection of Smart [4] LB 6. Electrical connection of Smart [4] LB 22 PB 22329 IT Smart 4_EN_OK.indd 22 06/07/15 15:54

N.B. the accessory is used to position the focuses exactly at the same height as those of the replaced product. 1. Electrical disconnection of device to be replaced 2. Mechanical disconnection of device to be replaced 3. Installation of Gewiss suspension cables Standard kit for Smart [4] HB for suspension fixing 5. Electrical connection of Smart [4] HB 4. Mechanical connection of Smart [4] HB SUSPENSION fixing Smart 4 [ ] Industrial lighting 23 PB 22329 IT Smart 4_EN_OK.indd 23 06/07/15 15:54

Mesh Wireless systems In the Wireless version, Smart [4] can easily be managed by the latest type of mobile device, using Bluetooth 4.0 (BLE) (Group 1, 2). Thanks to a specific application, ON/OFF and dimmer commands can be applied to each lighting device. In addition, an endless number of groups and/or scenes can be created, with up to 127 devices (nodes) configured for each group. The network is of the Mesh type, to ensure the best signal reception; in fact, each node also acts as a repeater to guarantee quick, efficient system management. Movement sensors and RF ON commands can be integrated (Group 1, 2) in order to control the lighting devices of the associated groups (via a Bluetooth communication device). Group 1 Group 2 Group 3 24 PB 22329 IT Smart 4_EN_OK.indd 24 06/07/15 15:54

Lighting Management app For even easier and more user-friendly management, GEWISS has designed and produced an app in collaboration with Casambi. It can be downloaded free of charge from Apple Store and Google Play, and used to manage the lighting devices of a number of systems - it just takes a simple touch of the finger to control the lights quickly and easily. One single screen for controlling all the lamps With the Smart [4] app, you can control all the lights from one single screen, both individually and as a group. For example, you can create one group for the general lights of a warehouse and another for the lamps in the aisles between the shelves, and switch them all on and off simultaneously just with a single touch. Or you can adjust the light intensity to the required level to guarantee the best energy savings. “Nearby lamps” function Thanks to the “nearby lamps” function, lamps in the surrounding area can be detected and switched on or off. - Category: Lighting management - Version: 1.0 - Size: 9 MB - Compatibility: Ios 7.0 or Android 4.4 or subsequent versions - Languages: Italian/English/French/German Light control from a photo For an even easier and more realistic view of the situation, just take a photo of the room, building or outdoor area where the lights are installed, then position the lamp controls on the image. In this way, you can control the lights directly via the picture. Network sharing and authorizations The app allows you to set four different levels of sharing and control of the access points, deciding whether the network should be open to everyone or whether the user has to log on (specifying a user name and password). Smart 4 [ ] Industrial lighting 25 PB 22329 IT Smart 4_EN_OK.indd 25 06/07/15 15:54

DALI 1 DALI 2 DALI 3 DALI 4 DALI 5 DALI 6 DALI 7 GATEWAY DALI READY GATEWAY DALI READY System management Smart [4] offers different methods for managing the systems and measuring consumption DALI management DALI READY management The DALI protocol for controlling lighting devices allows you to create a versatile, user-friendly system with just a few components. The devices compatible with this Standard can be integrated in a system. One DALI line can manage up to 64 devices, in turn assigned to a maximum of 16 groups. Smart [4], thanks to the DALI protocol, can be controlled from a distance via push-buttons, interfaces and integration in existing Building Automation systems. This guarantees automatic regulation based on the light intensity levels detected by sensors (even of third parties). With the DALI READY architecture, you can control various lines of devices from a distance. The use of Gateway allows an interface with the DALI protocol, which in turn ensures the uniform control of all the devices connected on the same line (but not the precise regulation of a single device). 26 PB 22329 IT Smart 4_EN_OK.indd 26 06/07/15 15:54

Emergency systems Smart [4] is available in versions equipped with electronic emergency devices Smart 4 [ ] Industrial lighting The emergency versions of Smart [4] combine the standard product with an advanced electronic device fitted with high-performance batteries. The batteries power the LED card at 10% of the nominal power, thereby guaranteeing a 3-hour autonomy. Technical characteristics- Autonomy: 3h - Recharging time: 24h - Accumulator type: NiCd - Degree of protection: IP65 - Operating temperature: 5°C Ta 25°C 27 PB 22329 IT Smart 4_EN_OK.indd 27 06/07/15 15:54

Certified according to DIN 18032-3 for installation in indoor sports facilities 28 PB 22329 IT Smart 4_EN_OK.indd 28 06/07/15 15:54

YEARS E X T E N D E D WARRANTY Floodlighting Smart [ 4 ] FL LED floodlights - Frame in technopolymer - Dissipator, glass holder and bracket coupling in die-cast aluminium with very low copper content - Tempered glass, 4mm thick - Fixing bracket in galvanised steel- IP66- IK08- Glow wire 850° Smart 4 [ ] 29 PB 22329 IT Smart 4_EN_OK.indd 29 06/07/15 15:54

282 253 740 716 700 77 533 508 486 191 163 74 770 745 716 191 163 74 383 425 77 253 269295 532 504 740 716 700 86 Smart [4] FL - 2L - IP66 - IK08 - GLOW WIRE TEST 850°C Smart [4] FL - 2+2L - IP66 - IK08 - GLOW WIRE TEST 850°C Smart [4] FL - 5 LEDs - IP66 - GLOW WIRE TEST 850°C Colours Grey RAL 7037 Smart [4] FL - 5+5L - IP66 - IK08 - GLOW WIRE TEST 850°C Smart [4] FL - 4x5L - IP66 - IK08 - Glow Wire 850° 30 PB 22329 IT Smart 4_EN_OK.indd 30 06/07/15 15:54

Smart [4] FL COMFORT Smart [4] - FL 2L Smart [4] - FL 2+2L Smart [4] - FL 5L Smart [4] - FL 5+5L Smart [4] - FL 4x5L Lumen output 1 2,710 lm 5,420 lm 6,170 lm 12,340 lm 24,680 lm System power 31W 62W 69W 138W 276W Equivalent power 35W MT 70W MT 100W MT 250W MT 400W MT System efficiency 87 lm/W 87 lm/W 89 lm/W 89 lm/W 89 lm/W Lifetime (L80) 80,000h 80,000h 80,000h 80,000h 80,000h Colour temperature 4,000K 4,000K 4,000K 4,000K 4,000K CRI ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 Weight (kg) 3 kg 5.1 kg 4.9 kg 8.5 kg 15.9 kg Installation Bracket • • • • • Stand Alone 100° GW L1 610 GW L1 640 GW L1 670 GW L1 710 GW L1 740 10° GW L1 611 GW L1 641 GW L1 671 GW L1 711 GW L1 741 30° GW L1 612 GW L1 642 GW L1 672 GW L1 712 GW L1 742 60° GW L1 613 GW L1 643 GW L1 673 GW L1 713 GW L1 743 Elliptical GW L1 614 GW L1 644 GW L1 674 GW L1 714 GW L1 744 Asymmetrical GW L1 615 GW L1 645 GW L1 675 GW L1 715 GW L1 745 RGBW 48° circular • • GW L1 793 GW L1 794 On request Complementary itemsSpare parts Spare glass GW L1 906 GW L1 906 GW L1 907 GW L1 907 GW L1 907 • Standard • Accessory • Not envisaged 1 In reference to the version with 10° spotlight optic - Stand Alone Smart 4 [ ] Floodlighting 31 PB 22329 IT Smart 4_EN_OK.indd 31 06/07/15 15:54

Smart [4] FL PERFORMANCE Smart [4] - FL 2L Smart [4] - FL 2+2L Smart [4] - FL 5L Smart [4] - FL 5+5L Smart [4] - FL 4x5L Lumen output 1 2,780 lm 5,560 lm 6,470 lm 12,940 lm 25,880 lm System power 31W 62W 69W 138W 276W Equivalent power 35W MT 70W MT 100W MT 250W MT 400W MT System efficiency 90 lm/W 90 lm/W 94 lm/W 94 lm/W 94 lm/W Lifetime (L80) 80,000h 80,000h 80,000h 80,000h 80,000h Colour temperature 4,000K 4,000K 4,000K 4,000K 4,000K CRI ≥ 80 ≥ 80 ≥ 80 ≥ 80 ≥ 80 Weight (kg) 3 kg 5.1 kg 4.9 kg 8.5 kg 15.9 kg Installation Bracket • • • • • Stand Alone 60° GW L3 013 GW L3 043 GW L3 073 GW L3 113 GW L3 143 Elliptical GW L3 014 GW L3 044 GW L3 074 GW L3 114 GW L3 144 Asymmetrical GW L3 015 GW L3 045 GW L3 075 GW L3 115 GW L3 145 Complementary itemsSpare parts Spare glass GW L1 906 GW L1 906 GW L1 907 GW L1 907 GW L1 907 • Standard • Accessory • Not envisaged 1 In reference to the version with 10° spotlight optic - Stand Alone 32 PB 22329 IT Smart 4_EN_OK.indd 32 06/07/15 15:54

Smart [4] FL EFFICIENCY Smart [4] - FL 2L Smart [4] - FL 2+2L Smart [4] - FL 5L Smart [4] - FL 5+5L Smart [4] - FL 4x5L Lumen output 1 3,000 lm 6,000 lm 6,990 lm 13,980 lm 27,950 lm System power 31W 62W 69W 138W 276W Equivalent power 35W MT 70W MT 100W MT 250W MT 400W MT System efficiency 97 lm/W 97 lm/W 101 lm/W 101 lm/W 101 lm/W Lifetime (L80) 80,000h 80,000h 80,000h 80,000h 80,000h Colour temperature 4,000K 4,000K 4,000K 4,000K 4,000K CRI ≥ 70 ≥ 70 ≥ 70 ≥ 70 ≥ 70 Weight (kg) 3 kg 5.1 kg 4.9 kg 8.5 kg 15.9 kg Installation Bracket • • • • • Stand Alone 100° GW L3 210 GW L3 240 GW L3 270 GW L3 310 GW L3 240 60° GW L3 213 GW L3 243 GW L3 273 GW L3 313 GW L3 243 Elliptical GW L3 214 GW L3 244 GW L3 274 GW L3 314 GW L3 244 Asymmetrical GW L3 215 GW L3 245 GW L3 275 GW L3 315 GW L3 245 Complementary itemsSpare parts Spare glass GW L1 906 GW L1 906 GW L1 907 GW L1 907 GW L1 907 • Standard • Accessory • Not envisaged 1 In reference to the version with 10° spotlight optic - Stand Alone Smart 4 [ ] Floodlighting 33 PB 22329 IT Smart 4_EN_OK.indd 33 06/07/15 15:54

-4.0m -3.0m -2.0m -1.0m 0.0m 1.0m 2.0m 3.0m 4.0m 5.0m -5.0m -4.0m -3.0m -2.0m -1.0m 0.0m 1.0m 2.0m 3.0m 4.0m 5.0m lux V0H+ H0V- C90 C0 25 50 100 150 200 250 -4.0m -3.0m -2.0m -1.0m 0.0m 1.0m 2.0m 3.0m 4.0m 5.0m -5.0m -4.0m -3.0m -2.0m -1.0m 0.0m 1.0m 2.0m 3.0m 4.0m 5.0m lux V0H+ H0V- C90 C0 -4.0m -3.0m -2.0m -1.0m 0.0m 1.0m 2.0m 3.0m 4.0m 5.0m -5.0m -4.0m -3.0m -2.0m -1.0m 0.0m 1.0m 2.0m 3.0m 4.0m 5.0m lux V0H+ H0V- C90 C0 Smart [4] FL = Form + Function Smart [4] offers a complete photometric distribution range, with special reference to narrow beam optics that ensure an efficient, rational system; light flux waste can be avoided by directing the beam entirely onto the surface you want to illuminate. Example: outdoor areas GW L3 270 - 69W – 4000K – Ra70 - 6663lm equivalent 100W MH Smart [4] FL 5+5L – 60° PERFORMANCE optic Smart [4] FL 5L – 100° EFFICIENCY optic Example: sports facilities GW L3 113 - 138W – 4000K – Ra80 – 12941lm equivalent 250W MH Smart [4] FL 4x5L – 30° COMFORT optic Example: industrial area GW L1 742 - 276W – 4000K – Ra80 – 19354lm equivalent 400W MH H[m] D[m] Av. lux 5.00 2.73 1507 10.00 5.46 37715.00 8.18 167 20.00 10.91 9425.00 13.64 60 H[m] D[m] Av. lux 3.00 4.23 6186.00 8.46 1559.00 12.69 6912.00 16.92 3915.00 21.15 25 H[m] D[m] Av. lux 1.00 2.28 1113 2.00 4.56 2783.00 6.84 1244.00 9.11 70 5.00 11.39 45 34 PB 22329 IT Smart 4_EN_OK.indd 34 06/07/15 15:54
