GEWISS was founded more than 40 years ago and, right from the start, the search for quality and the development of first class solutions have been the guiding values behind every action and decision. Over the years, this innovative vocation has taken the form of a business model based above all on continuous investment in R&D.The constant testing of new materials and technologies, the global vision of the lighting concept and the formalisation of design elements bearing the unmistakable Italian design - these are the deepest and most intimate features of GEWISS lighting solutions. The perfect chemistry has enabled GEWISS to become a global partner for the creation of lighting systems for indoor and outdoor sports facilities.The range includes floodlights, high bays and watertight luminaires designed to offer the best lighting performance for sports events at every level, from professional to semi-professional and amateur. 3 PB 22359 EN Cata prog Light 0316_EN.indd   3 15/04/16   11:43

FOOTBALL BASKETBALL VOLLEYBALL TENNIS STANDARD FOOTBALL Average lighting  [lx]  Page 500 10 200 12 75 14 7-A-SIDE FOOTBALL Average lighting  [lx]  Page 200 16 75 18 5-A-SIDE FOOTBALL Average lighting  [lx]  Page 200 20 75 22 Average lighting  [lx]  Page 200 30 75 32 Average lighting  [lx]  Page 500 40 200 42 75 44 Average lighting  [lx]  Page 300 52 200 54 5-A-SIDE FOOTBALL Average lighting  [lx]  Page 750 24 500 26 200 28 Average lighting  [lx]  Page 750 34 500 36 200 38 Average lighting  [lx]  Page 750 46 500 48 200 50 Average lighting  [lx]  Page 750 56 500 58 300 60 O U TD O OR IN D O O R 4 Contents PB 22359 EN Cata prog Light 0316_EN.indd   4 15/04/16   11:43

SWIMMING SQUASH BOCCE COMPLEMENTARY AREAS Average lighting  [lx]  Page 300 62 200 64   Page An overview  of the GEWISS  range 82 Example of  sports facilities  layout 84 List of products 1.1  Car park 1.2  Northern  stand 1.3  Southern  stand 1.4  Access path 86 1.5  Storehouse 1.6  Local team  changing  rooms 1.7  Guest team  changing  rooms 87 1.8  Technical  premises 1.9  Office 88 1.10 Referee 1  changing  room 1.11  Referee 2  changing  room 89 Average lighting  [lx]  Page 500 66 300 68 200 70 Average lighting  [lx]  Page 300 78 200 80 Average lighting  [lx]  Page 750 72 500 74 300 76 5 PB 22359 EN Cata prog Light 0316_EN.indd   5 15/04/16   11:44

Smart [4] 2.0 is the new lighting device whose strength lies in its multi-faceted nature. It can provide sustainable light for the most varied contexts (from industrial to sports, indoor and outdoor) where the crucial aspect is the lighting performance. It can be a floodlight, high bay or  Smart [ 4 ] 2.0 luminaire, offering different photometry ranges depending on the context. The horizontal and vertical modularity of this product combines with easy installation and maintenance, using “green” materials and displaying the unmistakable Italian style. 6 GEWISS solutions PB 22359 EN Cata prog Light 0316_EN.indd   6 15/04/16   11:44

Lighting boundaries are pushed further with the Stadium range: outdoor floodlights for lighting particularly large areas. Lamps with a maximum power of 2000W, combined with a symmetrical or asymmetrical, diffused or restricted optic. Bodies in die-cast aluminium treated with trivalent passivation and painted with polyester powders. High bays in 99.85 aluminium, anodised and polished. To guarantee long-lasting performance results, all the versions are fitted with an anti-condensation device in Gore-Tex® for internal pressure compensation.  Smart [3] is the new range of LED watertight luminaires that completes the Smart selection. Ideal for use in installation contexts with heights of less than 4 metres, the latest GEWISS lighting devices stand out for their elegant Italian design, excellent energy performance, optimum impact resistance and quick and easy installation. Stadium Smart [ 3 ] 7 PB 22359 EN Cata prog Light 0316_EN.indd   7 15/04/16   11:44

We provide light for sport This collection aims to spread a lighting culture from the design and installation viewpoint, providing the basic information needed to create sport facilities lighting systems of the best quality, from design through to installation.Apart from skilled professionals and qualified installers, these solutions will also be useful for those wanting to acquire further knowledge about the design and application aspects of lighting, such as students of professional technical colleges and aspiring lighting designers.The design sheets refer to sports fields of standard sizes, and the projects were developed in compliance with EN 12193, envisaging various levels of lighting to meet the needs of a range of activities from amateur to semi-professional and professional level.To provide complete support, beyond just the basic lighting project, the designs are accompanied by a layout illustrating the electrotechnical aspects of the installation, indicating the characteristics of the system components (e.g. the control panel, auxiliary circuits and protective or command circuit breakers).  8 Lighting for sports facilities PB 22359 EN Cata prog Light 0316_EN.indd   8 15/04/16   11:44

9 PB 22359 EN Cata prog Light 0316_EN.indd   9 15/04/16   11:44

0 5 10 15 20 -5 -10 -15 -20 Asse y (m) -40 -35 -30 -25 25 35 40 30 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) -25 -30 -35 -40 -45 -50 -55 25 30 35 40 45 50 55 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 430 660 770 630 170 170 ø14 ø14 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 2000W/842 Lamp flux (lm) 220,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 28 Number of floodlights 48 Number of floodlights per high mast 12 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. ASYMMETRICAL  STADIUM FLOODLIGHT -  2000W - GW 84 668 FLOODLIGHT POSITIONING Lighting  tower Position of  devices in X Position of   devices in Y Position of   devices in Z Device rotation   X°; Y°; Z° 1 -33.00 -38.00 27.00 0°; 0°; 140° 1 -32.00 -38.00 27.00 0°; 0°; 140° 1 -31.00 -38.00 27.00 0°; 0°; 135° 1 -30.00 -38.00 27.00 0°; 0°; 55° 1 -29.00 -38.00 27.00 0°; 0°; 50° 1 -28.00 -38.00 27.00 0°; 0°; 50° 1 -33.00 -37.00 28.00 0°; 0°; 140° 1 -32.00 -37.00 28.00 0°; 0°; 140° 1 -31.00 -37.00 28.00 0°; 0°; 135° 1 -30.00 -37.00 28.00 0°; 0°; 55° 1 -29.00 -37.00 28.00 0°; 0°; 50° 1 -28.00 -37.00 28.00 0°; 0°; 50° GRID 21x15 EAv [lx] 594 Emin/EAv 0.71 GR 30 CRI 80 No. floodlights 48 floodlight height [m] 27-28  KEY 400.0 lx500.0 lx600.0 lx700.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] I 500 0.7 50 60 PLAY AREA DIMENSIONS Length [m] 105 Width [m] 65 Grid points (length) 21 Grid points (width) 15 10 OU T D O OR REQUISITES Standard football - 500 lx - High-level competitions Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   10 15/04/16   11:44

The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 264 171 AUX 1 2 3 Id 4 5 20 Id 18 19 Id 16 17 Id 14 15 Id 12 13 Id 10 11 Id 8 9 Id 6 7 Id NEUTRO FASE Kpp1 P1 P2 Kpp2 P3 Kpp3 P4 Kpp4 P5 Kpp5 P6 Kpp6 P7 Kpp7 P8 Kpp8 Km1a Kpp1 Kpp2 Km1b Kpp3 Km2a Kpp4 Km2b Kpp5 Km3a Kpp6 Km3b Kpp7 Km4a Kpp8 Km4b STANDARD ELECTRICAL SCHEME -System power: 96kW, three-phase Line description Main device Surge protec- tive device Lamp High mast   1 - Km 1a High mast   1 - Km 1b High mast   2 - Km 2a High mast   2 - Km 2b High mast   3 - Km 3a High mast   3 - Km 3b High mast   4 - Km 4a High mast   4 - Km 4b Auxiliaries  circuit Power 96.000 kW 0.000 kW 12.000 kW 12.000 kW 12.000 kW 12.000 kW 12.000 kW 12.000 kW 12.000 kW 12.000 kW 0.000 kW Operating current Ib [A] 154.14 0.00 19.27 19.27 19.27 19.27 19.27 19.27 19.27 19.27 0.00 Rated current In [A] 200.00 100.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 6.00 Article description MTX250 N  36kA 4P  200A TM1 Disconnect- able fuse  holder 3P+N  22x58 690V  100A Surge protec- tive device  3P+N 25kA  Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MT60 MCB D25  4P + BD 4P 63A  30mA A-IR  Contactor 4NO  230V 24A MT60 MCB D25  4P + BD 4P 63A  30mA A-IR  Contactor 4NO  230V 24A MT60 MCB D25  4P + BD 4P 63A  30mA A-IR  Contactor 4NO  230V 24A MT60 MCB D25  4P + BD 4P 63A  30mA A-IR  Contactor 4NO  230V 24A MT60 MCB D25  4P + BD 4P 63A  30mA A-IR  Contactor 4NO  230V 24A MT60 MCB D25  4P + BD 4P 63A  30mA A-IR  Contactor 4NO  230V 24A MT60 MCB D25  4P + BD 4P 63A  30mA A-IR  Contactor 4NO  230V 24A MT60 MCB D25  4P + BD 4P 63A  30mA A-IR  Contactor 4NO  230V 24A MDC60 C6 2P  Id=30mA AC Code GW D7 216 GW 96 314 GW D6 405 GW 96 592 GW 92 489 +  GW D6 715 GW 92 489 +  GW D6 715 GW 92 489 +  GW D6 715 GW 92 489 +  GW D6 715 GW 92 489 +  GW D6 715 GW 92 489 +  GW D6 715 GW 92 489 +  GW D6 715 GW 92 489 +  GW D6 715 GW 94 125 Breaking capacity [kA] 36.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 6.00 RCCB GW 94 586 GW 94 586 GW 94 586 GW 94 586 GW 94 586 GW 94 586 GW 94 586 GW 94 586 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 45 057 CVX630M - Structure 600x1600 1 GW 45 077 CVX630M - Pair of side panels 1 GW 45 157 CVX630M - Glass door IP55 1 GW 45 202 Kit for modular devices on DIN rail 600x200 5 GW 45 273 CVX630K/M Kit for MTX250 600x200 1 GW 45 304 CVX630K Blank front panel 2 GW 45 411 Double DIN rail 24M 1 GW 45 526 Pair of supports for terminal block 1 GW 45 541 4-pole divider 250A 1 S TANDARD   PUSH - BUTTON PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 105 12-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 8 GW 74 501 1 NO contact 10A 250V 8 GW 74 511 Lamp-holder - BA95 coupling 8 GW 74 518 Lamp - BA95 coupling 8 GW 74 521 Black cap 4 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW D7 216 MCB 4P MTX250 N 36KA 200A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 400V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 489 MCB 4P D25 10KA 4M 8 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 8 GW D6 715 Contactor 230V 4NO 24A 8 GW D6 644 Latching relay 1NO 16A 230V 8 GW 94 125 RCBO 2P C6 6KA AC/0.03 2M 1 S TANDARD   AUXILIARIES   CIRCUIT 11 PB 22359 EN Cata prog Light 0316_EN.indd   11 15/04/16   11:44

0 5 10 15 20 -5 -10 -15 -20 Asse y (m) -40 -35 -30 -25 25 35 40 30 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) -25 -30 -35 -40 -45 -50 -55 25 30 35 40 45 50 55 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 430 660 770 630 170 170 ø14 ø14 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 2000W/842 Lamp flux (lm) 220,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 27 Number of floodlights 16 Number of floodlights per high mast 4 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. ASYMMETRICAL  STADIUM FLOODLIGHT -  2000W - GW 84 668 FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -27.00 -36.00 0°; 0°; 50° 1 -28.00 -36.00 0°; 0°; 60° 1 -29.00 -36.00 0°; 0°; 135° 1 -30.00 -36.00 0°; 0°; 140° 4 27.00 -36.00 0°; 0°; 130° 4 28.00 -36.00 0°; 0°; 120° 4 29.00 -36.00 0°; 0°; 45° 4 30.00 -36.00 0°; 0°; 40° GRID 21x15 EAv [lx] 216 Emin/EAv 0.65 GR 30 CRI 80 No. floodlights 16 floodlight height [m] 27 KEY   150.0 lx200.0 lx250.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] II 200 0.6 50 60 PLAY AREA DIMENSIONS Length [m] 105 Width [m] 65 Grid points (length) 21 Grid points (width) 15 12 OU T D O OR REQUISITES Standard football - 200 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   12 15/04/16   11:44

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 3 4 5 6 7 8 9 10 11 12 13 Id Id Id Id Id AUX 6 7 8 STANDARD ELECTRICAL SCHEME -System power: 32kW, three-phase Line description Main device Surge protec- tive device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  circuit Power 32.000 kW 0.000 kW 8.000 kW 8.000 kW 8.000 kW 8.000 kW 8.000 kW 8.000 kW 8.000 kW 8.000 kW 0.000 kW Operating current Ib [A] 51.38 0.00 12.85 12.85 12.85 12.85 12.85 12.85 12.85 12.85 0.00 Rated current In [A] 63.00 50.00 16.00 24.00 16.00 24.00 16.00 24.00 16.00 24.00 6.00 Article description MTHP160  D63 4P Disconnectable  fuse holder  3P+N 22x58  690V 50A Surge protec- tive device  3P+N 25kA  Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MCB MT60  D16 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO  230V AC/DC  24A - 2M MCB MT60  D16 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO  230V AC/DC  24A - 2M MCB MT60  D16 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO  230V AC/DC  24A - 2M MCB MT60  D16 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO  230V AC/DC  24A - 2M MDC60 C6 2P  Id=30mA AC Code GW 93 396 GW 96 314 GW D6 405 GW 96 592 GW 92 487 GW D6 715 GW 92 487 GW D6 715 GW 92 487 GW D6 715 GW 92 487 GW D6 715 GW 94 125 Breaking capacity [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 GW 94 586 GW 94 586 GW 94 586 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows - 28 mod. 4 GW 46 428 F Blank panel 1M. 515MM 1 GW 46 438 F Pair of uprights 1 GW 46 446 Set of 4 galvanised fixing brackets 1 GW 46 533 F Double rail 28M 1 GW 44 698 4-pole terminal block 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 93 396 MCB 4P D63 10KA 6M 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 400V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 487 MCB 4P D16 6KA 4M 4 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 4 GW D6 715 Contactor 230V 4NO 24A 4 GW D6 644 Latching relay 1NO 16A 230V 4 GW 94 125 RCBO 2P C6 6KA AC/0.03 2M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 13 PB 22359 EN Cata prog Light 0316_EN.indd   13 15/04/16   11:44

55 50 45 40 35 30 25 -55 -50 -45 -40 -35 -30 -25 Asse x (m) -20 -15 -10 -5 20 15 10 5 0 30 40 35 25 -25 -30 -35 -40 Asse y (m) -20 -15 -10 -5 20 15 10 5 0 430 660 770 630 170 170 ø14 ø14 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 2000W/842 Lamp flux (lm) 220,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 25 Number of floodlights 8 Number of floodlights per high mast 2 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. ASYMMETRICAL  STADIUM FLOODLIGHT -  2000W - GW 84 668 FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -29.75 -36.00 0°; 0°; 140° 1 -28.75 -36.00 0°; 0°; 35° 2 -29.75 36.00 0°; 0°; -140° 2 -28.75 36.00 0°; 0°; -35° 3 29.75 36.00 0°; 0°; -40° 3 28.75 36.00 0°; 0°; -145° 4 29.75 -36.00 0°; 0°; 40° 4 28.75 -36.00 0°; 0°; 145° GRID 21x15 EAv [lx] 99 Emin/EAv 0.61 GR 30 CRI 80 No. floodlights 8 floodlight height [m] 25 KEY 60.0 lx80.0 lx 100.0 lx120.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] III 75 0.5 55 20 PLAY AREA DIMENSIONS Length [m] 105 Width [m] 65 Grid points (length) 21 Grid points (width) 15 14 OU T D O OR REQUISITES Standard football - 75 lx - Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   14 15/04/16   11:44

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 R 2 3 4 5 6 7 8 9 10 11 12 13 Id AUX STANDARD ELECTRICAL SCHEME -System power: 16kW, three-phase Line description Main device Surge protec- tive device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  circuit Power 16.000 kW 0.000 kW 4.000 kW 4.000 kW 4.000 kW 4.000 kW 4.000 kW 4.000 kW 4.000 kW 4.000 kW 0.000 kW Operating current Ib [A] 25.68 0.00 6.42 6.42 6.42 6.42 6.42 6.42 6.42 6.42 0.00 Rated current In [A] 40.00 40.00 10.00 24.00 10.00 24.00 10.00 24.00 10.00 24.00 6.00 Article description MT100  D40 4P +  BD 4P 63A  30mA A-IR Disconnectable  fuse holder  3P+N 22x58  690V 40A Surge protec- tive device  3P+N 25kA  Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MT60 D10 4P Contactor 4 NO 230V AC/DC  24A - 2M MT60 D10 4P Contactor 4 NO 230V AC/DC  24A - 2M MT60 D10 4P Contactor  4 NO  230V AC/DC  24A - 2M MT60 D10 4P Contactor  4 NO  230V AC/DC  24A - 2M MTC60 C6  1P+N Code GW 92 791 GW 96 314 GW D6 405 GW 96 592 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 90 225 Breaking capacity [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 +  GW 90 893 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows - 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM 1 GW 46 438 F Pair of uprights 1 GW 46 446 Set of 4 galvanised fixing brackets 1 GW 46 533 F Double rail 28M 1 GW 44 698 4-pole terminal block 8M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 92 791 MCB 4P D40 10KA 4M 1 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 1 GW 90 893 Adjustable reset RM TOP 4P 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 486 Compact MCB 4P D10 6KA 4M 4 GW D6 715 Contactor 230V 4NO 24A 4 GW D6 644 Latching relay 1NO 16A 230V 4 GW 90 225 Compact MCB 1P+N C 6 6KA 1M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 15 PB 22359 EN Cata prog Light 0316_EN.indd   15 15/04/16   11:44

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) -30 -35 30 35 0 5 10 15 -5 -10 -15 Asse y (m) -20 -25 20 25 1 1 1 1 1 1 1 1 1 1 1 1 430 660 770 630 170 170 ø14 ø14 CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 1000W/842 Lamp flux (lm) 100,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 16 Number of floodlights 12 Number of floodlights per high mast 3 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters.  ASYMMETRICAL  STADIUM FLOODLIGHT  1000W - GW 84 667 FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -16.50 -23.00 0°; 0°; 140° 1 -15.50 -23.00 0°; 0°; 100° 1 -14.50 -23.00 0°; 0°; 50° 2 -16.50 23.00 0°; 0°; -140° 2 -15.50 23.00 0°; 0°; -100° 2 -14.50 23.00 0°; 0°; -50° 3 16.50 23.00 0°; 0°; -40° 3 15.50 23.00 0°; 0°; -80° 3 14.50 23.00 0°; 0°; -130° 4 16.50 -23.00 0°; 0°; 40° 4 15.50 -23.00 0°; 0°; 80° 4 14.50 -23.00 0°; 0°; 130° GRID 19x13 EAv [lx] 211 Emin/EAv 0.67 GR 30 CRI 80 No. floodlights 12 floodlight height [m] 16 PROPOSED SOLUTION KEY   150.0 lx200.0 lx250.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] II 200 0.6 50 60 PLAY AREA DIMENSIONS Length [m] 60 Width [m] 40 Grid points (length) 19 Grid points (width) 13 16 OU T D O OR REQUISITES 7-a-side football - 200 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   16 15/04/16   11:44

132 171 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 3 4 5 6 7 8 9 10 11 12 13 Id Id Id Id Id AUX STANDARD ELECTRICAL SCHEME -System power: 12kW, three-phase Line description Main device Surge protec- tive device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  circuit Power 12.000 kW 0.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 0.000 kW Operating current Ib [A] 19.27 0.00 4.82 4.82 4.82 4.82 4.82 4.82 4.82 4.82 0.00 Rated current In [A] 32.00 50.00 10.00 24.00 10.00 24.00 10.00 24.00 10.00 24.00 6.00 Article description MT100 D32 4P Disconnectable  fuse holder  3P+N 22x58  690V 50A Surge protec- tive device  3P+N 25kA  Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MCB MT60 D10 4P +  BD 4P 63A  30mA A-IR Contactor   4 NO  230V AC/DC  24A - 2M MCB MT60 D10 4P +  BD 4P 63A  30mA A-IR Contactor  4 NO  230V AC/DC  24A - 2M MCB MT60 D10 4P +  BD 4P 63A  30mA A-IR Contactor   4 NO  230V AC/DC  24A - 2M MCB MT60 D10 4P +  BD 4P 63A  30mA A-IR Contactor  4 NO  230V AC/DC  24A - 2M MDC60 C6 2P  Id=30mA AC Code GW 92 790 GW 96 314 GW D6 405 GW 96 592 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 94 125 Breaking capacity [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 GW 94 586 GW 94 586 GW 94 586 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 46 206 Polyester board with window 800x585x300 1 GW 46 423 F Panel without windows - 28 mod. 4 GW 46 428 F Blank panel 1M. 515MM 1 GW 46 438 F Pair of uprights 1 GW 46 446 Set of 4 galvanised fixing brackets 1 GW 46 533 F Double rail 28M 1 GW 44 698 4-pole terminal block 8M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 92 790 MCB 4P D32 10KA 4M 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 400V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 486 MCB 4P D10 6KA 4M 4 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 4 GW D6 715 Contactor 230V 4NO 24A 4 GW D6 644 Latching relay 1NO 16A 230V 4 GW 94 125 RCBO 2P C6 6KA AC/0.03 2M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 17 PB 22359 EN Cata prog Light 0316_EN.indd   17 15/04/16   11:44

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) -30 -35 30 35 0 5 10 15 -5 -10 -15 Asse y (m) -20 -25 20 25 1 1 1 1 1 1 1 1 430 660 770 630 170 170 ø14 ø14 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 1000W/842 Lamp flux (lm) 100,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 17 Number of floodlights 8 Number of floodlights per high mast 2 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters.  VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] III 75 0.5 55 20 ASYMMETRICAL STADIUM  FLOODLIGHT 1000W   GW 84 667 FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -15.00 -23.00 0°; 0°; 60° 1 -16.00 -23.00 0°; 0°; 135° 2 -15.00 23.00 0°; 0°; -60° 2 -16.00 23.00 0°; 0°; -135° 3 15.00 23.00 0°; 0°; -120° 3 16.00 23.00 0°; 0°; -45° 4 15.00 -23.00 0°; 0°; 120° 4 16.00 -23.00 0°; 0°; 45° GRID 19x13 EAv [lx] 140 Emin/EAv 0.65 GR 30 CRI 80 No. floodlights 8 floodlight height [m] 17 KEY   80.0 lx 100.0 lx120.0 lx140.0 lx160.0 lx180.0 lx PLAY AREA DIMENSIONS Length [m] 60 Width [m] 40 Grid points (length) 19 Grid points (width) 13 18 OU T D O OR REQUISITES 7-a-side football - 75 lx - Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   18 15/04/16   11:44

1 R 2 3 4 5 6 7 8 9 10 11 12 13 Id AUX 132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 STANDARD ELECTRICAL SCHEME -System power: 8kW, three-phase Line description Main device Surge protec- tive device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  circuit Power 8.000 kW 0.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 0.000 kW Operating current Ib [A] 19.32 0.00 9.66 9.66 9.66 9.66 9.66 9.66 9.66 9.66 0.00 Rated current In [A] 20.00 20.00 16.00 20.00 16.00 20.00 16.00 20.00 16.00 20.00 6.00 Article description MCB MT100  D20 4P +  BD 4P 63A  30mA A-IR Disconnectable  fuse holder  3P+N 22x58  690V 100A Surge protec- tive device  3P+N 25kA  Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MT60 D16 2P Contactor  2 NO  230V AC   20A -1M MT60 D16 2P Contactor  2 NO  230V AC   20A -1M MT60 D16 2P Contactor  2 NO  230V AC   20A -1M MT60 D16 2P Contactor  2 NO  230V AC   20A -1M MTC60 C6  1P+N Code GW 92 788 GW 96 314 GW D6 405 GW 96 592 GW 92 447 GW D6 703 GW 92 447 GW D6 703 GW 92 447 GW D6 703 GW 92 447 GW D6 703 GW 90 225 Breaking capacity [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 +  GW 90 893 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 46 205 Polyester board with window 650x515x250 1 GW 46 422 F Panel without windows 24 mod. 3 GW 46 427 F Blank panel 1M. 515MM 1 GW 46 437 F Pair of uprights 1 GW 46 446 Set of 4 galvanised fixing brackets 1 GW 46 532 F Double rail 24M 1 GW 44 696 4-pole terminal block 4M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 92 788 MCB 4P D20 10KA 4M 1 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 1 GW 90 893 Adjustable reset RM TOP 4P 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 447 MCB 2P D16 6KA 2M 4 GW D6 703 Contactor 230V 2NO 20A 4 GW D6 644 Latching relay 1NO 16A 230V 4 GW 90 225 Compact MCB 1P+N C 6 6KA 1M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 19 PB 22359 EN Cata prog Light 0316_EN.indd   19 15/04/16   11:44

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 0 5 10 15 -5 -10 -15 Asse y (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION CALCULATION RESULTS GRID 13x7 EAv [lx] 205 Emin/EAv 0.75 GR 17 CRI 80 No. floodlights 16 floodlight height [m] 12   TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical   Power system (W) 232 Lumen output (lm) 25,560 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 12 Number of floodlights 16 Number of floodlights per high mast 4 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -13.00 -11.50 0°; 0°; 130° 1 -12.00 -11.50 0°; 0°; 100° 1 -11.00 -11.50 0°; 0°; 70° 1 -10.00 -11.50 0°; 0°; 35° 4 13.00 -11.50 0°; 0°; 50° 4 12.00 -11.50 0°; 0°; 80° 4 11.00 -11.50 0°; 0°; 110° 4 10.00 -11.50 0°; 0°; 145° KEY   150.0 lx200.0 lx300.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] II 200 0.6 50 60 PLAY AREA DIMENSIONS Length [m] 40 Width [m] 20 Grid points (length) 13 Grid points (width) 7 20 OU T D O OR REQUISITES 5-a-side football - 200 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   20 15/04/16   11:45

132 171 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 3.8kW, three-phase Line description Main device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  line Power 3.800 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.000 kW Operating current Ib [A] 6.00 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 0.00 Rated current In [A] 32.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 6.00 Article description Control switch   disconnector  4P 32A Surge protective  device 3P+N  25kA Aux. Type  1+2 + fuse  holder 22x58  - 16M Triple red  signalling lamp  with fuse holder  230V 10.3x38  - 5M MCB MT60  C25 4P + BD 4P 63A 30mA A-IR Contactor 25A 4NO - 230VAC/ 220V  DC - 2M MCB MT60  C25 4P + BD 4P 63A 30mA A-IR Contactor 25A 4NO - 230VAC/ 220V  DC - 2M MCB MT60  C25 4P + BD 4P 63A 30mA A-IR Contactor 25A 4NO - 230V AC/ 220V DC - 2M MCB MT60  C25 4P + BD 4P 63A 30mA A-IR Contactor 25A 4NO - 230V AC/ 220V DC - 2M MDC60 C6 2P Id=30mA AC Code GW 96 134 GW D6 405 GW 96 592 GW 92 089 GW D6 715 GW 92 089 GW D6 715 GW 92 089 GW D6 715 GW 92 089 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 GW 94 586 GW 94 586 GW 94 586 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 mod.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 1 GW 46 533 F  Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 089 MCB 4P C25 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 3.5M 4 GW 96 134 Switch disconnector 4P 32A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 21 PB 22359 EN Cata prog Light 0316_EN.indd   21 15/04/16   11:45

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 0 5 10 15 -5 -10 -15 Asse y (m) 1 1 1 1 1 1 1 1 1 1 1 1 741 700 74 282 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 116 Lumen output (lm) 12,780 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 10 Number of floodlights 12 Number of floodlights per high mast 3 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. ASYMMETRICAL SMART [4] 2.0  FLOODLIGHT   GW S4 156 GS FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -13.00 -11.00 0°; 0°; 135° 1 -12.00 -11.00 0°; 0°; 90° 1 -13.00 -11.00 0°; 0°; 35° 4 10.00 -11.00 0°; 0°; 145° 4 11.00 -11.00 0°; 0°; 90° 4 12.00 -11.00 0°; 0°; 45° GRID 13x7 EAv [lx] 83 Emin/EAv 0.61 GR 18 CRI 80 No. floodlights 12 floodlight height [m] 10  KEY 60.0 lx90.0 lx 120.0 lx150.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] III 75 0.5 55 20 PLAY AREA DIMENSIONS Length [m] 40 Width [m] 20 Grid points (length) 13 Grid points (width) 7 22 OU T D O OR REQUISITES 5-a-side football - 75 lx - Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   22 15/04/16   11:45

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 1 2 3 4 5 10 11 6 7 8 9 12 STANDARD ELECTRICAL SCHEME -System power: 1.4kW, single-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 mod. EN 50022 1 GW 46 204 Polyester board with window 650X405X200 1 GW 46 421 F Panel without windows 18 mod. 3 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 2 GW 46 531 F Quick-assembly double rail 18M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  line Power 1.400 kW 0.350 kW 0.350 kW 0.350 kW 0.350 kW 0.350 kW 0.350 kW 0.350 kW 0.350 kW 0.000 kW Operating current Ib [A] 6.80 1.70 1.70 1.70 1.70 1.70 1.70 1.70 1.70 0.00 Rated current In [A] 32.00 16.00 25.00 16.00 25.00 16.00 25.00 16.00 25.00 6.00 Article description Control switch   disconnector  2P 32A Surge protec- tive device  1P+N 25kA  Aux. Type 1+2  + fuse holder  22x58 - 8M Red signalling  lamp with fuse  holder 230V  10.3x38 - 3M MCB MT60  C16 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/  220V DC - 2M MCB MT60  C16 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC 2M MCB MT60  C16 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC 2M MCB MT60  C16 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 92 047 GW D6 712 GW 92 047 GW D6 712 GW 92 047 GW D6 712 GW 92 047 GW D6 712 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 4.50 RCCB GW 94 566 GW 94 566 GW 94 566 GW 94 566 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 92 047 MCB 2P C16 6KA 2M 4 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 566 Residual current device 2P IN 63A Immun. A/0.03 2M 4 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 4 23 PB 22359 EN Cata prog Light 0316_EN.indd   23 15/04/16   11:45

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 0 5 10 15 -5 -10 -15 Asse y (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 52 FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -21.00 -11.00 0°; 0°; 90° 2 -20.00 -11.00 0°; 0°; 90° 3 -19.00 -11.00 0°; 0°; 90° 4 -17.50 -11.00 0°; 0°; 90° 5 -16.00  -11.00 0°; 0°; 90° 6 -14.50 -11.00 0°; 0°; 90° 7 -12.50 -11.00 0°; 0°; 90° 8 -10.00 -11.00 0°; 0°; 90° 9 -8.00 -11.00 0°; 0°; 90° 10 -6.00 -11.00 0°; 0°; 90° 11 -4.00 -11.00 0°; 0°; 90° 12 -2.50 -11.00 0°; 0°; 90° 13 -1.00 -11.00 0°; 0°; 90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 15x9 EAv [lx] 778 Emin/EAv 0.85 CRI 80 No. floodlights 52 floodlight height [m] 10 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. KEY   500.0 lx600.0 lx700.0 lx800.0 lx900.0 lx 1000.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] I 750 0.7 60 PLAY AREA DIMENSIONS Length [m] 40 Width [m] 20 Grid points (length) 15 Grid points (width) 9 24 REQUISITES IN D O O R 5-a-side football - 750 lx - High-level competitions Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   24 15/04/16   11:45

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. STANDARD ELECTRICAL SCHEME -System power: 12.0kW, three-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 mod.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 4 GW 46 423 F Panel without windows 28 mod. 1 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 093 MCB 4P C63 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 4 GW 96 176 Control switch disconnector 4P 63A AC22B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 724 Contactor 40A 4NO 230V 3M 4 S TANDARD   AUXILIARIES   CIRCUIT Line description Main device Lamp Line 1 km1 Line 2 km2 Line 3 km3 Line 4 km4 Auxiliaries  line Power 12.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 0.000 kW Operating current Ib [A] 19.20 4.80 4.80 4.80 4.80 4.80 4.80 4.80 4.80 0.00 Rated current In [A] 63.00 63.00 40.00 63.00 40.00 63.00 40.00 63.00 40.00 6.00 Article description Control   switch discon- nector 4P 63A Surge protec- tive device  3P+N 25kA Aux.  Type 1+2 + fuse  holder 22x58  - 16M Triple red  signalling  lamp with fuse  holder 230V  10.3x38 - 5M MT60 C63  4P+ BD 4P 63A  30mA S Contactor 40A 4NO - 230V AC/ 220V DC - 3M MT60 C63 4P+ BD 4P 63A  30mA S Contactor 40A 4NO - 230V AC/ 220V DC - 3M MT60 C63  4P+ BD 4P 63A  30mA S Contactor 40A 4NO - 230V AC/ 220V DC - 3M MT60 C63  4P+ BD 4P 63A  30mA S Contactor 40A 4NO - 230V AC/ 220V DC - 3M MDC60 C6 2P Id=30mA AC Code GW 96 176 GW D6 405 GW 96 592 GW 92 093 GW D6 724 GW 92 093 GW D6 724 GW 92 093 GW D6 724 GW 92 093 GW D6 724 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW94 532 GW 94 532 GW 94 532 GW 94 532 25 PB 22359 EN Cata prog Light 0316_EN.indd   25 15/04/16   11:45

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 0 5 10 15 -5 -10 -15 Asse y (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 34 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters.  CALCULATION RESULTS Lighting project for indoor sports centre. GRID 15x9 EAv [lx] 504 Emin/EAv 0.83 CRI 80 No. floodlights  34 floodlight height [m] 10 FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 - 21.00 -11.00 0°; 0°; 90° 2 - 19.00 -11.00 0°; 0°; 90° 3 - 17.00 -11.00 0°; 0°; 90° 4 - 15.00 -11.00 0°; 0°; 90° 5 - 13.00 -11.00 0°; 0°; 90° 6 - 10.00 -11.00 0°; 0°; 90° 7 - 6.00 -11.00 0°; 0°; 90° 8 - 3.00 -11.00 0°; 0°; 90° 9 0.00 -11.00 0°; 0°; 90° KEY   300.0 lx400.0 lx500.0 lx600.0 lx700.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] II 500 0.7 60 PLAY AREA DIMENSIONS Length [m] 40 Width [m] 20 Grid points (length) 15 Grid points (width) 9 26 REQUISITES IN D O O R 5-a-side football - 500 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   26 15/04/16   11:45

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 STANDARD ELECTRICAL SCHEME -System power: 8.0kW, three-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 mod.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp Line 1 km1 Line 2 km2 Line 3 km3 Line 4 km4 Auxiliaries  line Power 8.000 kW 2.100 kW 2.100 kW 1.900 kW 1.900 kW 2.100 kW 2.100 kW 1.900 kW 1.900 kW 0.000 kW Operating current Ib [A] 12.60 3.30 3.30 3.00 3.00 3.30 3.30 3.00 3.00 0.00 Rated current In [A] 40.00 40.00 25.00 40.00 25.00 40.00 25.00 40.00 25.00 6.00 Article description MT100  D40 4P Surge protec- tive device  3P+N 25kA Aux.  Type 1+2 + fuse  holder 22x58  - 16M Triple red  signalling  lamp with fuse  holder 230V  10.3x38 - 5M MT60 C40  4P+ BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C40  4P+ BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C40 4P+ BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60  C40 4P + BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MDC60 C6 2P Id=30mA AC Code GW 92 791 GW D6 405 GW 96 592 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 532 GW 94 532 GW 94 532 GW 94 532 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 091 MCB 4P C40 6KA 4M 4 GW 92 791 MCB 4P D40 10KA 4M 1 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 4 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 27 PB 22359 EN Cata prog Light 0316_EN.indd   27 15/04/16   11:45

0 5 10 15 -5 -10 -15 A sse y (m) -25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 14 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -19.00 -11.00 0°; 0°; 90° 2 -14.00 -11.00 0°; 0°; 90° 3 -7.00 -11.00 0°; 0°; 90° 4 -0.00 -11.00 0°; 0°; 90° 11 0.00 11.00 0°; 0°; -90° 12 7.00 11.00 0°; 0°; -90° 13 14.00 11.00 0°; 0°; -90° 14 19.00 11.00 0°; 0°; -90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 15x9 EAv [lx] 213 Emin/EAv 0.81 CRI 80 No. floodlights 14 floodlight height [m] 10 KEY 150.0 lx200.0 lx250.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] III 200 0.5 20 PLAY AREA DIMENSIONS Length [m] 40 Width [m] 20 Grid points (length) 15 Grid points (width) 9 28 REQUISITES IN D O O R 5-a-side football - 200 lx - Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   28 15/04/16   11:46

1 3 2 4 5 6 7 8 1 5 7 85 132 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 P1 Kpp1 NEUTRO Kpp1 Km1 FASE Km2 Kpp2 Kpp2 P2 The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. STANDARD ELECTRICAL SCHEME -System power: 3.3kW, three-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 696 4-pole terminal block 4 mod.EN 50022 1 GW 46 205 Polyester board with window 650X515X250 1 GW 46 422 F Panel without windows 24 mod. 3 GW 46 427 F Blank panel 1M. 515MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 532 F Quick-assembly double rail 24M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 102 2-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 2 GW 74 501 1 NO contact 10A 250V 2 GW 74 511 Lamp-holder - BA95 coupling 2 GW 74 518 Lamp - BA95 coupling 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 091 MCB 4P C40 6KA 4M 2 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 2 GW 96 134 Switch disconnector 4P 32A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 2 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 2 S TANDARD   AUXILIARIES   CIRCUIT Line description Main device Lamp Line 1 km1 Line 2 km2 Auxiliaries line Power 3.300 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 0.000 kW Operating current Ib [A] 5.20 2.60 2.60 2.60 2.60 0.00 Rated current In [A] 32.00 40.00 25.00 40.00 25.00 6.00 Article description Control switch discon- nector 4P 32A Surge protective device  3P+N 25kA Aux. Type  1+2 + fuse holder  22x58 - 16M Triple red signalling  lamp with fuse holder  230V 10.3x38 - 5M MT60 C40  4P+ BD 4P 63A 30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C40  4P+ BD 4P 63A 30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 134 GW D6 405 GW 96 592 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 6.00 4.50 RCCB GW 94 532 GW 94 532 29 PB 22359 EN Cata prog Light 0316_EN.indd   29 15/04/16   11:46

0 5 10 15 -5 -10 -15 Asse x (m) 0 5 10 -5 -10 Asse y (m) -20 20 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 10 Number of floodlights 12 Number of floodlights per high mast 3 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT GW S4 176 GS FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -9.00 -10.50 0°; 0°; 130° 1 -8.00 -10.50 0°; 0°; 90° 1 -7.00 -10.50 0°; 0°; 55° 2 -9.00 10.50 0°; 0°; -130° 2 -8.00 10.50 0°; 0°; -90° 2 -7.00 10.50 0°; 0°; -55° 3 9.00 10.50 0°; 0°; -50° 3 8.00 10.50 0°; 0°; -90° 3 7.00 10.50 0°; 0°; -125° 4 9.00 -10.50 0°; 0°; 50° 4 8.00 -10.50 0°; 0°; 90° 4 7.00 -10.50 0°; 0°; 125° GRID 13x7 EAv [lx] 221 Emin/EAv 0.78 GR 21 CRI 80 No. floodlights 12 floodlight height [m] 10 KEY   50.0 lx 100.0 lx150.0 lx200.0 lx250.0 lx300.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] II 200 0.6 50 60 PLAY AREA DIMENSIONS Length [m] 28 Width [m] 15 Grid points (length) 13 Grid points (width) 7 30 OU T D O OR REQUISITES Basketball - 200 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   30 15/04/16   11:46

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 3 4 5 6 7 8 9 10 11 12 1 5 7 9 11 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. STANDARD ELECTRICAL SCHEME -System power: 2.8kW, single-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 MOD.EN 50022 1 GW 46 205 Polyester board with window 650X515X250 1 GW 46 422 F Panel without windows 24 mod. 3 GW 46 427 F Blank panel 1M. 515MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 532 F Quick-assembly double rail 24M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 S TANDARD   AUXILIARIES   CIRCUIT Line description Main device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  line Power 2.800 kW 0.700 kW 0.700 kW 0.700 kW 0.700 kW 0.700 kW 0.700 kW 0.700 kW 0.700 kW 0.000 kW Operating current Ib [A] 13.60 3.40 3.40 3.40 3.40 3.40 3.40 3.40 3.40 0.00 Rated current In [A] 32.00 20.00 25.00 20.00 25.00 20.00 25.00 20.00 25.00 6.00 Article description Control switch   disconnector  2P 32A Surge protec- tive device  1P+N 25kA  Aux. Type 1+2  + fuse holder  22x58 - 8M Red signalling  lamp with fuse  holder 10.3x38   230V - 3M MCB MT60  C20 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/  220V DC - 2M MCB MT60  C20 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MCB MT60  C20 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MCB MT60  C20 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MDC60 C6  2P Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 92 048 GW D6 712 GW 92 048 GW D6 712 GW 92 048 GW D6 712 GW 92 048 GW D6 712 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94566 GW 94 566 GW 94 566 GW 94 566 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 92 048 MCB 2P C20 6KA 2M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 566 Residual current device 2P IN 63A Immun. A/0.03 2M 4 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 4 31 PB 22359 EN Cata prog Light 0316_EN.indd   31 15/04/16   11:46

0 5 10 15 -5 -10 -15 Asse x (m) 0 5 10 -5 -10 Asse y (m) -20 20 1 1 1 1 1 1 1 1 741 700 74 282 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 116 Lumen output (lm) 12,780 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 9 Number of floodlights 8 Number of floodlights per high mast 2 ASYMMETRICAL SMART [4] 2.0   FLOODLIGHT   GW S4 156 GS FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -8.00 -10.00 0°; 0°; 125° 1 -7.00 -10.00 0°; 0°; 70° 4 7.00 -10.00 0°; 0°; 105° 4 8.00 -10.00 0°; 0°; 55° 2 -8.00 10.00 0°; 0°; -125° 2 -7.00 10.00 0°; 0°; -70° 4 7.00 10.00 0°; 0°; -105° 4 8.00 10.00 0°; 0°; -55° CALCULATION RESULTS GRID 13x7 EAv [lx] 80 Emin/EAv 0.62 GR 19 CRI 80 No. floodlights 8 floodlight height [m] 9 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. KEY   30.0 lx60.0 lx90.0 lx 120.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] III 75 0.5 55 20 PLAY AREA DIMENSIONS Length [m] 28 Width [m] 15 Grid points (length) 13 Grid points (width) 7 32 OU T D O OR REQUISITES Basketball - 75 lx- Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   32 15/04/16   11:46

1 2 3 4 5 10 11 6 7 8 9 12 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 STANDARD ELECTRICAL SCHEME -System power: 1.0kW, single-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 mod.EN 50022 1 GW 46 204 Polyester board with window 650X405X200 1 GW 46 421 F Panel without windows 18 mod. 3 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 2 GW 46 531 F Quick-assembly double rail 18M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 92 046 MCB 2P C10 6KA 2M 4 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 566 Residual current device 2P IN 63A Immun. A/0.03 2M 4 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  line Power 1.000 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.000 kW Operating current Ib [A] 4.40 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 0.00 Rated current In [A] 32.00 10.00 25.00 10.00 25.00 10.00 25.00 10.00 25.00 6.00 Article description Control switch   disconnector  2P 32A Surge protec- tive device  1P+N 25kA  Aux. Type 1+2  + fuse holder  22x58 - 8M Red signalling  lamp with fuse  holder 10.3x38   230V - 3M MCB MT60  C10 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MCB MT60  C10 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MCB MT60  C10 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MCB MT60  C10 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 92 046 GW D6 712 GW 92 046 GW D6 712 GW 92 046 GW D6 712 GW 92 046 GW D6 712 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 4.50 RCCB GW 94 566 GW 94 566 GW 94 566 GW 94 566 33 PB 22359 EN Cata prog Light 0316_EN.indd   33 15/04/16   11:46

0 5 10 -5 -10 Asse y (m) 15 -15 0 5 10 15 -5 -10 -15 Asse x (m) -20 20 -25 25 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 40 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -15.00 -11.00 0°; 0°; 90° 2 -14.00 -11.00 0°; 0°; 90° 3 -13.00 -11.00 0°; 0°; 90° 4 -12.00 -11.00 0°; 0°; 90° 5 -10.00 -11.00 0°; 0°; 90° 6 -8.50 -11.00 0°; 0°; 90° 7 -6.50 -11.00 0°; 0°; 90° 8 -4.50 -11.00 0°; 0°; 90° 9 -3.00 -11.00 0°; 0°; 90° 10 -1.00 -11.00 0°; 0°; 90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 13x7 EAv [lx] 764 Emin/EAv 0.88 CRI 80 No. floodlights 40 floodlight height [m] 10 KEY   300.0 lx400.0 lx500.0 lx 600.0 l x 700.0 lx800.0 lx900.0 lx 1000.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] I 750 0.7 60 PLAY AREA DIMENSIONS Length [m] 28 Width [m] 15 Grid points (length) 13 Grid points (width) 7 34 REQUISITES IN D O O R Basketball - 750 lx - High-level competitions Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   34 15/04/16   11:46

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 1 3 1 5 7 9 11 2 7 8 10 11 12 4 5 6 9 STANDARD ELECTRICAL SCHEME -System power: 9.4kW, three-phase Line description Main device Lamp Line   1 km1 Line   2 km2 Line   3 km3 Line   4 km4 Auxiliaries  line Power 9.400 kW 2.350 kW 2.350 kW 2.350 kW 2.350 kW 2.350 kW 2.350 kW 2.350 kW 2.350 kW 0.000 kW Operating current Ib [A] 14.80 3.70 3.70 3.70 3.70 3.70 3.70 3.70 3.70 0.00 Rated current In [A] 63.00 50.00 40.00 50.00 40.00 50.00 40.00 50.00 40.00 6.00 Article description Control switch   disconnector   4P 63A Surge protective  device 3P+N  25kA Aux. Type  1+2 + fuse  holder 22x58  - 16M Triple red  signalling lamp  with fuse holder  230V 10.3x38  - 5M MT60 C50 4P + BD 4P 63A  30mA S Contactor  40A 4NO - 230V AC/  220V DC - 3M MT60 C50 4P   + BD 4P 63A  30mA S Contactor  40A 4NO - 230V AC  /220V DC - 3M MT60 C50 4P  + BD 4P 63A  30mA S Contactor  40A 4NO - 230V AC  /220V DC - 3M MT60 C50 4P   + BD 4P 63A  30mA S Contactor  40A 4NO - 230V AC  /220V DC - 3M MDC45 C6 2P Id=30mA AC Code GW 96 176 GW D6 405 GW 96 592 GW 92 092 GW D6 724 GW 92 092 GW D6 724 GW 92 092 GW D6 724 GW 92 092 GW D6 724 GW 94 025 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 4.50 RCCB GW 94 532 GW 94 532 GW 94 532 GW 94 532 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 MOD.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 092 MCB 4P C50 6KA 4M 4 GW 94 025 RCBO C.2P C 6 4.5KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 4 GW 96 176 Control switch disconnector 4P 63A AC22B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 724 Contactor 40A 4NO 230V 3M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 35 PB 22359 EN Cata prog Light 0316_EN.indd   35 15/04/16   11:46

0 5 10 15 -5 -10 -15 Asse x (m) -20 20 -25 25 0 5 10 -5 -10 Asse y (m) 15 -15 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 28 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -14.00 -11.00 0°; 0°; 90° 2 -13.00 -11.00 0°; 0°; 90° 3 -12.00 -11.00 0°; 0°; 90° 4 -10.00 -11.00 0°; 0°; 90° 5 -7.00 -11.00 0°; 0°; 90° 6 -4.00 -11.00 0°; 0°; 90° 7 -2.00 -11.00 0°; 0°; 90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 13x7 EAv [lx] 530 Emin/EAv 0.89 CRI 80 No. floodlights 28 floodlight height [m] 10 KEY   200.0 lx300.0 lx400.0 lx500.0 lx600.0 lx700.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] II 500 0.7 60 PLAY AREA DIMENSIONS Length [m] 28 Width [m] 15 Grid points (length) 13 Grid points (width) 7 36 REQUISITES IN D O O R Basketball - 500 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   36 15/04/16   11:46

1 3 1 5 7 9 11 2 10 11 12 4 5 6 7 8 9 132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 6.6kW, three-phase Line description Main device Lamp Line   1 km1 Line   2 km2 Line   3 km3 Line   4 km4 Auxiliaries  line Power 6.600 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 0.000 kW Operating current Ib [A] 10.40 2.60 2.60 2.60 2.60 2.60 2.60 2.60 2.60 0.00 Rated current In [A] 40.00 32.00 25.00 32.00 25.00 32.00 25.00 32.00 25.00 6.00 Article description Control switch  disconnector  4P 40A Surge protective  device   3P+N 25kA Aux.  Type 1+2 + fuse  holder 22x58  - 16M Triple red signal- ling lamp with  fuse holder 230V  10.3x38 - 5M MDC45 C32 4P Id=30mA A Contactor 25A  4NO - 230V AC  /220V DC - 2M MDC45 C32 4P Id=30mA A Contactor 25A  4NO - 230V AC  /220V DC - 2M MDC45 C32 4P Id=30mA A Contactor 25A  4NO - 230V AC  /220V DC - 2M MDC45 C32 4P Id=30mA A Contactor 25A  4NO - 230V AC  /220V DC - 2M MDC45 C6 2P Id=30mA AC Code GW 96 135 GW D6 405 GW 96 592 GW 94 270 GW D6 715 GW 94 270 GW D6 715 GW 94 270 GW D6 715 GW 94 270 GW D6 715 GW 94 025 Breaking capacity Icn/Icu [kA] 4.50 4.50 4.50 4.50 4.50 RCCB GW 94 532 GW 94 532 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 MOD.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 94 025 RCBO C.2P C 6 4.5KA AC/0.03 2M 1 GW 94 270 RCBO C.4P C32 4.5KA AC/0.03 4M 4 GW 96 135 Switch disconnector 4P 40A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 37 PB 22359 EN Cata prog Light 0316_EN.indd   37 15/04/16   11:46

0 5 10 15 -5 -10 -15 Asse x (m) -20 20 -25 25 0 5 10 -5 -10 Asse y (m) 15 -15 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560  ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 10 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -12.00 -11.00 0°; 0°; 90° 2 -7.00 -11.00 0°; 0°; 90° 3 0.00 -11.00 0°; 0°; 90° 8 0.00 11.00 0°; 0°; -90° 9 7.00 11.00 0°; 0°; -90° 10 12.00 11.00 0°; 0°; -90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 13x7 EAv [lx] 202 Emin/EAv 0.78 CRI 80 No. floodlights 10 floodlight height [m] 10 KEY   50.0 lx 100.0 lx150.0 lx200.0 lx250.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] III 200 0.5 20 PLAY AREA DIMENSIONS Length [m] 28 Width [m] 15 Grid points (length) 13 Grid points (width) 7 38 REQUISITES IN D O O R Basketball - 200 lx- Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   38 15/04/16   11:47

85 132 P1 Kpp1 NEUTRO Kpp1 Km1 FASE Km2 Kpp2 Kpp2 P2 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 1 3 2 4 5 6 7 8 STANDARD ELECTRICAL SCHEME -System power: 2.4kW, single-phase Line description Main device Lamp Line 1 km1 Line 2 km2 Auxiliaries   line Power 2.400 kW 1.200 kW 1.200 kW 1.200 kW 1.200 kW 0.000 kW Operating current Ib [A] 11.20 5.60 5.60 5.60 5.60 0.00 Rated current In [A] 32.00 32.00 40.00 32.00 40.00 6.00 Article description Control switch discon- nector 2P 32A Surge protective device  1P+N 25kA Aux. Type  1+2 + fuse holder  22x58 - 8M Red signalling lamp  with fuse holder 230V  10.3x38 - 3M MDC60 C32 2P Id=30mA A Contactor 40A 2NO - 230V AC/ 220V DC - 3M MDC60 C32 2P Id=30mA A Contactor 40A 2NO - 230V AC/ 220V DC - 3M MDC45 C6 1P+N Id=300mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 94 330 GW D6 721 GW 94 330 GW D6 721 GW 94 015 Breaking capacity Icn/Icu [kA] 6.00 6.00 4.50 RCCB S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 mod. EN 50022 1 GW 46 204 Polyester board with window 650X405X200 1 GW 46 421 F Panel without windows 18 mod. 3 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 531 F Quick-assembly double rail 18M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 102 2-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 2 GW 74 501 1 NO contact 10A 250V 2 GW 74 511 Lamp-holder - BA95 coupling 2 GW 74 518 Lamp - BA95 coupling 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 94 015 RCBO C.1P+N C 6 4.5KA AC/0.3 2M 1 GW 94 330 RCBO C.2P C32 6KA AC/0.03 2M 2 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 2 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 721 Contactor 40A 2NO 230V 3M 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 39 PB 22359 EN Cata prog Light 0316_EN.indd   39 15/04/16   11:47

0 5 10 -5 -10 Asse y (m) 0 5 10 15 -5 -10 -15 Asse x (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560  TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 9 Number of floodlights 16 Number of floodlights per high mast 4 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -8.00 -8.00 0°; 0°; 100° 1 -7.00 -8.00 0°; 0°; 96° 1 -6.00 -8.00 0°; 0°; 92° 1 -5.00 -8.00 0°; 0°; 67° 4 5.00 -8.00 0°; 0°; 113° 4 6.00 -8.00 0°; 0°; 88° 4 7.00 -8.00 0°; 0°; 84° 4 8.00 -8.00 0°; 0°; 80° GRID 13x9 EAv [lx] 502 Emin/EAv 0.71 GR 19 CRI 80 No. floodlights 16 floodlight height [m] 9  PROPOSED SOLUTION KEY 300.0 lx   400.0 lx500.0 lx600.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] I 500 0.7 50 60 PLAY AREA DIMENSIONS Length [m] 24 Width [m] 15 Grid points (length) 13 Grid points (width) 9 40 OU T D O OR REQUISITES Volleyball - 500 lx - High-level competitions Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   40 15/04/16   11:47

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 3.8kW, three-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 mod.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  line Power 3.800 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.000 kW Operating current Ib [A] 6.00 1.50 1.50 1.50 1.50 1.50 1.50 1.50 1.50 0.00 Rated current In [A] 32.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 6.00 Article description Control switch   disconnector  4P 32A Surge protec- tive device  3P+N 25kA Aux.  Type 1+2 + fuse  holder 22x58  - 16M Triple red  signalling  lamp with fuse  holder 230V  10.3x38 - 5M MCB MT60  C25 4P + BD 4P 63A 30mA A-IR Contactor 25A 4NO - 230V AC/ 220V DC - 2M MCB MT60  C25 4P + BD 4P 63A 30mA A-IR Contactor 25A 4NO - 230V AC/ 220V DC - 2M MCB MT60  C25 4P + BD 4P 63A 30mA A-IR Contactor 25A 4NO - 230V AC/ 220V DC - 2M MCB MT60  C25 4P + BD 4P 63A 30mA A-IR Contactor 25A 4NO - 230V AC/ 220V DC - 2M MDC60  C6 2P Id=30mA AC Code GW 96 134 GW D6 405 GW 96 592 GW 92 089 GW D6 715 GW 92 089 GW D6 715 GW 92 089 GW D6 715 GW 92 089 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 GW 94 586 GW 94 586 GW 94 586 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 089 MCB 4P C25 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 3.5M 4 GW 96 134 Switch disconnector 4P 32A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 41 PB 22359 EN Cata prog Light 0316_EN.indd   41 15/04/16   11:47

0 5 10 -5 -10 Asse y (m) 0 5 10 15 -5 -10 -15 Asse x (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 741 700 74 282 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 116 Lumen output (lm) 12,780 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 9 Number of floodlights 16 Number of floodlights per high mast 4 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. ASYMMETRICAL SMART [4] 2.0   FLOODLIGHT   GW S4 156 GS FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -9.00 -8.00 0°; 0°; 100° 1 -8.00 -8.00 0°; 0°; 90° 1 -7.00 -8.00 0°; 0°; 90° 1 -6.00 -8.00 0°; 0°; 65° 4 6.00 -8.00 0°; 0°; 115° 4 7.00 -8.00 0°; 0°; 90° 4 8.00 -8.00 0°; 0°; 90° 4 9.00 -8.00 0°; 0°; 80° GRID 13x9 EAv [lx] 236  Emin/EAv 0.72 GR 19 CRI 80 No. floodlights 16  floodlight height [m] 9 KEY   200.0 lx250.0 lx300.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] II 200 0.6 50 60 PLAY AREA DIMENSIONS Length [m] 24 Width [m] 15 Grid points (length) 13 Grid points (width) 9 42 OU T D O OR REQUISITES Volleyball - 200 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   42 15/04/16   11:47

132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 3 4 5 6 7 8 9 10 11 12 1 5 7 9 11 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 1.8kW, single-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 mod.EN 50022 1 GW 46 205 Polyester board with window 650X515X250 1 GW 46 422 F Panel without windows 24 mod. 3 GW 46 427 F Blank panel 1M. 515MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 532 F Quick-assembly double rail 24M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  line Power 1.800 kW 0.450 kW 0.450 kW 0.450 kW 0.450 kW 0.450 kW 0.450 kW 0.450 kW 0.450 kW 0.000 kW Operating current Ib [A] 8.80   2.20 2.20 2.20 2.20 2.20 2.20 2.20 2.20 0.00 Rated current In [A] 32.00 16.00 25.00 16.00 25.00 16.00 25.00 16.00 25.00 6.00 Article description Control switch   disconnector  2P 32A Surge protec- tive device  1P+N 25kA  Aux. Type 1+2  + fuse holder  22x58 - 8M Red signalling  lamp with fuse  holder 10.3x38   230V - 3M MCB MT60  C16 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/  220V DC - 2M MCB MT60  C16 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MCB MT60  C16 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MCB MT60  C16 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/ 220V DC - 2M MDC60   C6 2P Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 92 047 GW D6 712 GW 92 047 GW D6 712 GW 92 047 GWD6 712 GW 92 047 GW D6 712 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 566 GW 94 566 GW 94 566 GW 94 566 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 92 047 MCB 2P C16 6KA 2M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 566 Residual current device 2P IN 63A Immun. A/0.03 2M 4 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 4 43 PB 22359 EN Cata prog Light 0316_EN.indd   43 15/04/16   11:47

0 5 10 15 -5 -10 -15 Asse x (m) 0 5 10 -5 -10 Asse y (m) 1 1 1 1 1 1 1 1 741 700 74 282 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 116 Lumen output (lm) 12,780 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 9 Number of floodlights 8 Number of floodlights per high mast 2 ASYMMETRICAL SMART [4] 2.0   FLOODLIGHT   GW S4 156 GS VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] III 75 0.5 55 20 CALCULATION RESULTS GRID 13x9 EAv [lx] 127 Emin/EAv 0.64 GR 18 CRI 80 No. floodlights 8 floodlight height [m] 9 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -7.00 -8.00 0°; 0°; 90° 1 -6.00 -8.00 0°; 0°; 90° 4 6.00 -8.00 0°; 0°; 90° 4 7.00 -8.00 0°; 0°; 90° 2 -7.00 8.00 0°; 0°; 90° 2 -6.00 8.00 0°; 0°; 90° 3 6.00 8.00 0°; 0°; 90° 3 7.00 8.00 0°; 0°; 90° KEY   90.0 lx 120.0 lx150.0 lx PLAY AREA DIMENSIONS Length [m] 24 Width [m] 15 Grid points (length) 13 Grid points (width) 9 44 OU T D O OR REQUISITES Volleyball - 75 lx- Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   44 15/04/16   11:47

1 2 3 4 5 10 11 6 7 8 9 12 132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 1.0kW, single-phase S TANDARD   DISTRIBUTION   BOARD S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  line Power 1.000 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.250 kW 0.000 kW Operating current Ib [A] 4.40 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 0.00 Rated current In [A] 32.00 10.00 25.00 10.00 25.00 10.00 25.00 10.00 25.00 6.00 Article description Control switch   disconnector  2P 32A Surge protec- tive device  1P+N 25kA  Aux. Type 1+2  + fuse holder  22x58 - 8M Red signalling  lamp with fuse  holder 10.3x38  230V - 3M MCB MT60  C10 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/  220V DC - 2M MCB MT60  C10 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/  220V DC - 2M MCB MT60  C10 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/  220V DC - 2M MCB MT60  C10 2P + BD 2P 63A 30mA A-IR Contactor 25A 2NO - 230V AC/  220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 92 046 GW D6 712 GW 92 046 GW D6 712 GW 92 046 GW D6 712 GW 92 046 GW D6 712 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 4.50 RCCB GW 94 566 GW 94 566 GW 94 566 GW 94 566 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 92 046 MCB 2P C10 6KA 2M 4 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 566 Residual current device 2P IN 63A Immun. A/0.03 2M 4 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 4 DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 mod.EN 50022 1 GW 46 204 Polyester board with window 650X405X200 1 GW 46 421 F Panel without windows 18 mod. 3 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 2 GW 46 531 F Quick-assembly double rail 18M 1 45 PB 22359 EN Cata prog Light 0316_EN.indd   45 15/04/16   11:47

0 5 10 -5 -10 Asse y (m) 15 -15 0 5 10 15 -5 -10 -15 Asse x (m) -20 20 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -13.00 -9.00 0°; 0°; 90° 2 -11.50 -9.00 0°; 0°; 90° 3 -10.00 -9.00 0°; 0°; 90° 4 -8.00 -9.00 0°; 0°; 90° 5 -6.00 -9.00 0°; 0°; 90° 6 -4.00 -9.00 0°; 0°; 90° 7 -2.00 -9.00 0°; 0°; 90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 13x9 EAv [lx] 768 Emin/EAv 0.85 CRI 80 No. floodlights 28 floodlight height [m] 10 TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 28  KEY 400.0 lx500.0 lx600.0 lx700.0 lx800.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] I 750 0.7 60 PLAY AREA DIMENSIONS Length [m] 24 Width [m] 15 Grid points (length) 13 Grid points (width) 9 46 REQUISITES IN D O O R Volleyball - 750 lx - High-level competitions Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   46 15/04/16   11:47

1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 6.6kW, three-phase Line description Main device Lamp Line 1 km1 Line 2 km2 Line 3 km3 Line 4 km4 Auxiliaries  line Power 6.600 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 0.000 kW Operating current Ib [A] 10.40 2.60 2.60 2.60 2.60 2.60 2.60 2.60 2.60 0.00 Rated current In [A] 32.00 32.00 25.00 32.00 25.00 32.00 25.00 32.00 25.00 6.00 Article description Control switch  disconnector  4P 32A Surge protective  device  3P+N 25kA Aux.  Type 1+2 + fuse  holder 22x58  - 16M Triple red  signalling lamp  with fuse holder  230V 10.3x38  - 5M MT60 C32 4P + BD 4P 63A  30mA S Contactor 25A  4NO - 230V AC  / 220V DC - 2M MT60 C32 4P  + BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC  /220V DC - 2M MT60 C32 4P  + BD 4P 63A  30mA S Contactor  25A 4NO - 230V AC  /220V DC - 2M MT60 C32 4P   + BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC  /220V DC - 2M MDC60 C6 2P Id=30mA AC Code GW 96 134 GW D6 405 GW 96 592 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 532 GW 94 532 GW 94 532 GW 94 532 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 MOD.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 090 MCB 4P C32 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 4 GW 96 134 Switch disconnector 4P 32A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 47 PB 22359 EN Cata prog Light 0316_EN.indd   47 15/04/16   11:47

0 5 10 -5 -10 Asse y (m) 15 -15 0 5 10 15 -5 -10 -15 Asse x (m) -20 20 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 20 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -13.00 -9.00 0°; 0°; 90° 2 -11.00 -9.00 0°; 0°; 90° 3 -8.00 -9.00 0°; 0°; 90° 4 -5.00 -9.00 0°; 0°; 90° 5 -2.00 -9.00 0°; 0°; 90° 6 2.00 -9.00 0°; 0°; 90° 7 5.00 -9.00 0°; 0°; 90° 8 8.00 -9.00 0°; 0°; 90° 9 11.00 -9.00 0°; 0°; 90° 10 13.00 -9.00 0°; 0°; 90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 13x9 EAv [lx] 544 Emin/EAv 0.84 CRI 80 No. floodlights 20 floodlight height [m] 10 KEY   300.0 lx350.0 lx400.0 lx450.0 lx500.0 lx550.0 lx600.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] II 500 0.7 60 PLAY AREA DIMENSIONS Length [m] 24 Width [m] 15 Grid points (length) 13 Grid points (width) 9 48 REQUISITES IN D O O R Volleyball - 500 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   48 15/04/16   11:48

1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 4.8kW, three-phase Line description Main device Lamp Line 1 km1 Line 2 km2 Line 3 km3 Line 4 km4 Auxiliaries  line Power 4.800 kW 1.200 kW 1.200 kW 1.200 kW 1.200 kW 1.200 kW 1.200 kW 1.200 kW 1.200 kW 0.000 kW Operating current Ib [A] 7.60 1.90 1.90 1.90 1.90 1.90 1.90 1.90 1.90 0.00 Rated current In [A] 32.00 32.00 25.00 32.00 25.00 32.00 25.00 32.00 25.00 6.00 Article description Control switch  disconnector  4P 32A Surge protective  device 3P+N  25kA Aux. Type  1+2 + fuse  holder 22x58  - 16M Triple red  signalling lamp  with fuse holder  230V 10.3x38  - 5M MT60 C32 4P  + BD 4P 63A  30mA S Contactor  25A 4NO - 230V AC  /220V DC - 2M MT60 C32 4P   + BD 4P 25A  30mA S Contactor  25A 4NO - 230V AC  /220V DC - 2M MT60 C32 4P + BD 4P 63A  30mA S Contactor  25A 4NO - 230V AC  /220V DC - 2M MT60 C32 4P + BD 4P 25A  30mA S Contactor 25A 4NO - 230V AC  /220V DC - 2M MDC60 C6 2P Id=30mA AC Code GW 96 134 GW D6 405 GW 96 592 GW 92 090 GW D6 715 GW 92090 GW D6 715 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 532 GW 94 522 GW 94 532 GW 94 522 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 mod. EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 518 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 090 MCB 4P C32 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 522 Residual current device 4P IN 25A INSTANT. A/0.03 3.5M 2 GW 94 532 Residual current device 4P IN 63A INSTANT. A/0.03 3.5M 2 GW 96 134 Switch disconnector 4P 32A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 49 PB 22359 EN Cata prog Light 0316_EN.indd   49 15/04/16   11:48

0 5 10 -5 -10 Asse y (m) 15 -15 0 5 10 15 -5 -10 -15 Asse x (m) -20 20 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 8 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -10.00 -9.00 0°; 0°; 90° 2 -4.50 -9.00 0°; 0°; 90° 3 4.50 -9.00 0°; 0°; 90° 4 10.00 -9.00 0°; 0°; 90° 5 -10.00 9.00 0°; 0°; -90° 6 -4.50 9.00 0°; 0°; -90° 7 4.50 9.00 0°; 0°; -90° 8 10.00 9.00 0°; 0°; -90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 13x9 EAv [lx] 239 Emin/EAv 0.79 CRI 80 No. floodlights 8 floodlight height [m] 10 KEY 100.0 lx150.0 lx200.0 lx250.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] III 200 0.5 20 PLAY AREA DIMENSIONS Length [m] 24 Width [m] 15 Grid points (length) 13 Grid points (width) 9 50 REQUISITES IN D O O R Volleyball - 200 lx- Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   50 15/04/16   11:48

85 132 P1 Kpp1 NEUTRO Kpp1 Km1 FASE Km2 Kpp2 Kpp2 P2 1 3 2 4 5 6 7 8 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 STANDARD ELECTRICAL SCHEME -System power: 1.9kW, single-phase Line description Main device Lamp Line 1 km1 Line 2 km2 Auxiliaries line Power 1.900 kW 0.950 kW 0.950 kW 0.950 kW 0.950 kW 0.000 kW Operating current Ib [A] 9.0 4.50 4.50 4.50 4.50 0.00 Rated current In [A] 32.00 25.00 40.00 25.00 40.00 6.00 Article description Control switch discon- nector 2P 32A Surge protective   device 1P+N 25kA Aux.  Type 1+2 + fuse holder  22x58 - 8M Red signalling lamp  with fuse holder 230V  10.3x38 - 3M MDC60 C25 2P Id=30mA A Contactor 40A 2NO - 230V AC/ 220V DC - 3M MDC60 C25 2P Id=30mA A Contactor 40A 2NO - 230V AC/ 220V DC - 3M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 94 329 GW D6 721 GW 94 329 GW D6 721 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 6.00 4.50 RCCB S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 mod. EN 50022 1 GW 46 204 Polyester board with window 650X405X200 1 GW 46 421 F Panel without windows 18 mod. 3 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 531 F Quick-assembly double rail 18M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 102 2-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 2 GW 74 501 1 NO contact 10A 250V 2 GW 74 511 Lamp-holder - BA95 coupling 2 GW 74 518 Lamp - BA95 coupling 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 329 RCBO C.2P C25 6KA AC/0.03 2M 2 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 2 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 721 Contactor 40A 2NO 230V 3M 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 51 PB 22359 EN Cata prog Light 0316_EN.indd   51 15/04/16   11:48

The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 0 5 10 15 20 -5 -10 -15 -20 Asse y (m) 1 1 1 1 1 1 1 1 1 1 1 1 430 660 770 630 170 170 ø14 ø14 PROPOSED SOLUTION CALCULATION RESULTS GRID 15x7 EAv [lx] 308 Emin/EAv 0.73 GR 26 CRI 80 No. floodlights 12 floodlight height [m] 14 FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -11.00 -20.00 0°; 0°; 140° 1 -10.00 -20.00 0°; 0°; 125° 1 -9.00 -20.00 0°; 0°; 50° 2 -11.00 20.00 0°; 0°; -140° 2 -10.00 20.00 0°; 0°; -125° 2 -9.00 20.00 0°; 0°; -50° 3 11.00 20.00 0°; 0°; -40° 3 10.00 20.00 0°; 0°; -55° 3 9.00 20.00 0°; 0°; -130° 4 11.00 -20.00 0°; 0°; 40° 4 10.00 -20.00 0°; 0°; 55° 4 9.00 -20.00 0°; 0°; 130° TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 1000W/842 Lamp flux (lm) 100,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 14 Number of floodlights 12 Number of floodlights per high mast 3 ASYMMETRICAL  STADIUM  FLOODLIGHT 1000W   GW 84 667 KEY 200.0 lx250.0 lx300.0 lx350.0 lx PLAY AREA DIMENSIONS Length [m] 36 Width [m] 36 Grid points (length) 15 Grid points (width) 7 VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] II 300 0.7 50 60 52 OU T D O OR REQUISITES Tennis - 300 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   52 15/04/16   11:48

132 171 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 3 4 5 6 7 8 9 10 11 12 13 Id Id Id Id Id AUX STANDARD ELECTRICAL SCHEME -System power: 12kW, three-phase Line description Main device Surge protec- tive device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  circuit Power 12.000 kW 0.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 0.000 kW Operating current Ib [A] 19.27 0.00 4.82 4.82 4.82 4.82 4.82 4.82 4.82 4.82 0.00 Rated current In [A] 32.00 50.00 10.00 24.00 10.00 24.00 10.00 24.00 10.00 24.00 6.00 Article description MT100 D32 4P Disconnectable  fuse holder  3P+N  22x58  690V 50A Surge protec- tive device  3P+N 25kA Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4NO 230V AC/DC  24A - 2M MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4NO 230V AC/DC  24A - 2M MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4NO 230V AC/DC  24A - 2M MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4NO 230V AC/DC  24A - 2M MDC60 C6 2P Id=30mA AC Code GW 92 790 GW 96 314 GW D6 405 GW 96 592 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW 96 712 GW 94 125 Breaking capacity [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 GW 94 586 GW 94 586 GW 94 586 S TANDARD   DISTRIBUTION   BOARD S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 92 790 MCB 4P D32 10KA 4M 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 400V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 486 MCB 4P D10 6KA 4M 4 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 4 GW D6 715 Contactor 230V 4NO 24A 4 GW D6 644 Latching relay 1NO 16A 230V 4 GW 94 125 RCBO 2P C6 6KA AC/0.03 2M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 46 206 Polyester board with window 800x585x300 1 GW 46 423 F Panel without windows - 28 mod. 4 GW 46 428 F Blank panel 1M. 515MM 1 GW 46 438 F Pair of uprights 1 GW 46 446 Set of 4 galvanised fixing brackets 1 GW 46 533 F Double rail 28M 1 GW 44 698 4-pole terminal block 8M 1 53 PB 22359 EN Cata prog Light 0316_EN.indd   53 15/04/16   11:48

0 5 10 15 20 -5 -10 -15 -20 Asse y (m) 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 1 1 1 1 1 1 1 1 1 1 1 1 430 660 770 630 170 170 ø14 ø14 PROPOSED SOLUTION CALCULATION RESULTS GRID 15x7 EAv [lx] 242 Emin/EAv 0.66 GR 27 CRI 80 No. floodlights 8 floodlight height [m] 13 FLOODLIGHT POSITIONING Lighting  tower Position of devices X Position of devices Y Device rotation X°; Y°; Z° 1 -12.00 -20.00 0°; 0°; 120° 1 -11.00 -20.00 0°; 0°; 55° 2 -12.00 20.00 0°; 0°; -120° 2 -11.00 20.00 0°; 0°; -55° 3 12.00 20.00 0°; 0°; -60° 3 11.00 20.00 0°; 0°; -125° 4 12.00 -20.00 0°; 0°; 60° 4 11.00 -20.00 0°; 0°; 125° TECHNICAL DATA OF THE LAMP  Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 1000W/842 Lamp flux (lm) 100,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 13 Number of floodlights 8 Number of floodlights per high mast 2 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. ASYMMETRICAL  STADIUM FLOODLIGHT  1000W   GW 84 667 KEY 150.0 lx200.0 lx250.0 lx300.0 lx PLAY AREA DIMENSIONS Length [m] 36 Width [m] 36 Grid points (length) 15 Grid points (width) 7 VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] III 200 0.6 55 20 54 OU T D O OR REQUISITES Tennis - 200 lx- Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   54 15/04/16   11:48

132 171 1 R 2 3 4 5 6 7 8 9 10 11 12 13 Id AUX NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 STANDARD ELECTRICAL SCHEME -System power: 8kW, three-phase Line description Main device Surge protec- tive device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  circuit Power 8.000 kW 0.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 0.000 kW Operating current Ib [A] 19.32 0.00 9.66 9.66 9.66 9.66 9.66 9.66 9.66 9.66 0.00 Rated current In [A] 20.00 20.00 16.00 20.00 16.00 20.00 16.00 20.00 16.00 20.00 6.00 Article description MCB MT100   D20 4P +  BD 4P 63A 30mA A-IR Disconnect- able fuse holder  3P+N 22x58 690V  100A Surge protec- tive device  3P+N 25kA Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MT60 D16 2P Contactor  2NO 230V AC - 20A  1M MT60 D16 2P Contactor  2NO 230V AC - 20A  1M MT60 D16 2P Contactor  2NO 230V AC - 20A  1M MT60 D16 2P Contactor  2NO 230V AC - 20A  1M MTC60 C6  1P+N Code GW 92 788 GW 96 314 GW D6 405 GW 96 592 GW 92 447 GWD6703  GW 92 447 GWD6703 GW 92 447 GWD6703 GW 92 447 GWD6703 GW 90 225 Breaking capacity [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 +  GW 90 893 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 46 205 Polyester board with window 650x515x250 1 GW 46 422 F Panel without windows 24 mod. 3 GW 46 427 F Blank panel 1M. 515MM 1 GW 46 437 F Pair of uprights 1 GW 46 446 Set of 4 galvanised fixing brackets 1 GW 46 532 F Double rail 24M 1 GW 44 696 4-pole terminal block 4M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 92 788 MCB 4P D20 10KA 4M 1 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 1 GW 90 893 Adjustable reset RM TOP 4P 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 447 MCB 2P D16 6KA 2M 4 GW D6 703 Contactor 230V 2NO 20A 4 GW D6 644 Latching relay 1NO 16A 230V 4 GW 90 225 Compact MCB 1P+N C 6 6KA 1M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 55 PB 22359 EN Cata prog Light 0316_EN.indd   55 15/04/16   11:48

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 0 5 10 15 -5 -10 -15 Asse y (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 36 ASYMMETRICAL SMART [4]  2.0 FLOODLIGHT   GW S4 176 GS Lighting project for indoor sports centre. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -18.00 -9.00 0°; 0°; 90° 2 -17.00 -9.00 0°; 0°; 90° 3 -16.00 -9.00 0°; 0°; 90° 4 -13.00 -9.00 0°; 0°; 90° 5 -10.00 -9.00 0°; 0°; 90° 6 -7.50 -9.00 0°; 0°; 90° 7 -5.00 -9.00 0°; 0°; 90° 8 -3.00 -9.00 0°; 0°; 90° 9 -1.00 -9.00 0°; 0°; 90° GRID 15x7 EAv [lx] 773 Emin/EAv 0.80 CRI 80 No. floodlights 36 floodlight height [m] 10 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. KEY 500.0 lx600.0 lx700.0 lx800.0 lx900.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] I 750 0.7 60 PLAY AREA DIMENSIONS Length [m] 36 Width [m] 18 Grid points (length) 15 Grid points (width) 7 56 REQUISITES IN D O O R Tennis - 750 lx - High-level competitions Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   56 15/04/16   11:48

132 171 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 8.4kW, three-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 mod.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 091 MCB 4P C40 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 4 GW 96 134 Switch disconnector 4P 32A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp Line 1 km1 Line 2 km2 Line 3 km3 Line 4 km4 Auxiliaries  line Power 8.400 kW 2.100 kW 2.100 kW 2.100 kW 2.100 kW 2.100 kW 2.100 kW 2.100 kW 2.100 kW 0.000 kW Operating current Ib [A] 13.20 3.30 3.30 3.30 3.30 3.30 3.30 3.30 3.30 0.00 Rated current In [A] 32.00 40.00 25.00 40.00 25.00 40.00 25.00 40.00 25.00 6.00 Article description Control   switch discon- nector 4P 32A Surge protec- tive device  3P+N 25kA Aux.  Type 1+2 + fuse  holder 22x58  - 16M Triple red  signalling  lamp with fuse  holder 230V  10.3x38 - 5M MT60 C40  4P+ BD 4P 63A 30mA  S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C40  4P+ BD 4P 63A 30mA A Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C40 4P+ BD 4P 63A 30mA A Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C40  4P+ BD 4P 63A 30mA A Contactor 25A 4NO - 230V AC/ 220V DC - 2M MDC60 C6  2P Id=30mA AC Code GW 96 134 GW D6 405 GW 96 592 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 532 GW 94 532 GW 94 532 GW 94 532 57 PB 22359 EN Cata prog Light 0316_EN.indd   57 15/04/16   11:48

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 0 5 10 15 -5 -10 -15 Asse y (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 24 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. ASYMMETRICAL SMART [4]  2.0 FLOODLIGHT   GW S4 176 GS Lighting project for indoor sports centre. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -17.00 -9.00 0°; 0°; 90° 2 -15.00 -9.00 0°; 0°; 90° 3 -11.50 -9.00 0°; 0°; 90° 4 -8.50 -9.00 0°; 0°; 90° 5 -5.50 -9.00 0°; 0°; 90° 6 -2.00 -9.00 0°; 0°; 90° GRID 15x7 EAv [lx] 526 Emin/EAv 0.75 CRI 80 No. floodlights 24 floodlight height [m] 10  KEY 300.0 lx400.0 lx500.0 lx600.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] II 500 0.7 60 PLAY AREA DIMENSIONS Length [m] 36 Width [m] 18 Grid points (length) 15 Grid points (width) 7 58 REQUISITES IN D O O R Tennis - 500 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   58 15/04/16   11:49

132 171 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 5.6kW, three-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 mod.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 4 GW 46 423 F Panel without windows 28 mod. 1 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 galvanised steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 090 MCB 4P C32 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 4 GW 96 134 Switch disconnector 4P 32A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp Line 1 km1 Line 2 km2 Line 3 km3 Line 4 km4 Auxiliaries  line Power 5.600 kW 1.400 kW 1.400 kW 1.400 kW 1.400 kW 1.400 kW 1.400 kW 1.400 kW 1.400 kW 0.000 kW Operating current Ib [A] 8.80 2.20 2.20 2.20 2.20 2.20 2.20 2.20 2.20 0.00 Rated current In [A] 32.00 32.00 25.00 32.00 25.00 32.00 25.00 32.00 25.00 6.00 Article description Control switch  disconnector  4P 32A Surge protec- tive device  3P+N 25kA Aux.  Type 1+2 + fuse  holder 22x58  - 16M Triple red  signalling  lamp with fuse  holder 230V  10.3x38 - 5M MT60 C32  4P+ BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC/  220V DC - 2M MT60 C32  4P+ BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C32  4P+ BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C32  4P+ BD 4P 63A  30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MDC60 C6  2P Id=30mA AC Code GW 96 134 GW D6 405 GW 96 592 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 532 GW 94 532 GW 94 532 GW 94 532 59 PB 22359 EN Cata prog Light 0316_EN.indd   59 15/04/16   11:49

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 0 5 10 15 -5 -10 -15 Asse y (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 TECHNICAL DATA OF THE FLOODLIGHTS  Floodlight assembly height (m) 10 Number of floodlights 14 ASYMMETRICAL SMART [4]   2.0 FLOODLIGHT   GW S4 176 GS FLOODLIGHT POSITIONING Device  Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -15.50 -9.00 0°; 0°; 90° 2 -13.00 -9.00 0°; 0°; 90° 3 -5.00 -9.00 0°; 0°; 90° 4 0.00 -9.00 0°; 0°; 90° 11 0.00 9.00 0°; 0°; -90° 12 5.00 9.00 0°; 0°; -90° 13 13.00 9.00 0°; 0°; -90° 14 15.50 9.00 0°; 0°; -90° The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. GRID 15x7 EAv [lx] 302 Emin/EAv 0.79 CRI 80 No. floodlights 14 floodlight height [m] 10 Lighting project for indoor sports centre. KEY 200.0 lx250.0 lx300.0 lx350.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] III 300 0.5 20 PLAY AREA DIMENSIONS Length [m] 36 Width [m] 18 Grid points (length) 15 Grid points (width) 7 60 REQUISITES IN D O O R Tennis - 300 lx- Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   60 15/04/16   11:49

1 3 2 1 5 7 4 5 7 8 6 85 132 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 P1 Kpp1 NEUTRO Kpp1 Km1 FASE Km2 Kpp2 Kpp2 P2 STANDARD ELECTRICAL SCHEME -System power: 3.3kW, three-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 696 4-pole terminal block 4 mod.EN 50022 1 GW 46 205 Polyester board with window 650X515X250 1 GW 46 422 F Panel without windows 24 mod. 3 GW 46 427 F Blank panel 1M. 515MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 532 F Quick-assembly double rail 24M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 102 2-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 2 GW 74 501 1 NO contact 10A 250V 2 GW 74 511 Lamp-holder - BA95 coupling 2 GW 74 518 Lamp - BA95 coupling 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 091 MCB 4P C40 6KA 4M 2 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 2 GW 96 134 Switch disconnector 4P 32A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 2 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp Line 1 km1 Line 2 km2 Auxiliaries line Power 3.300 kW 1.650 kW 1.650 kW 1.650 kW 1.650 kW 0.000 kW Operating current Ib [A] 5.20 2.60 2.60 2.60 2.60 0.00 Rated current In [A] 32.00 40.00 25.00 40.00 25.00 6.00 Article description Control switch   disconnector 4P 32A Surge protective device  3P+N 25kA Aux. Type  1+2 + fuse holder  22x58 - 16M Triple red signalling  lamp with fuse holder  230V 10.3x38 - 5M MT60 C40  4P+ BD 4P 63A 30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C40  4P+ BD 4P 63A 30mA S Contactor 25A 4NO - 230V AC/  220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 134 GW D6 405 GW 96 592 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 6.00 4.50 RCCB GW 94 532 GW 94 532 61 PB 22359 EN Cata prog Light 0316_EN.indd   61 15/04/16   11:49

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) -30 -35 30 35 0 5 10 15 -5 -10 -15 Asse y (m) -20 20 1 1 1 1 1 1 1 1 1 1 1 1 430 660 770 630 170 170 ø14 ø14 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 1000W/842 Lamp flux (lm) 100,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 14 Number of floodlights 12 Number of floodlights per high mast 3 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. ASYMMETRICAL  STADIUM FLOODLIGHT  1000W   GW 84 667 FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -16.50 -15.00 0°; 0°; 140° 1 -15.50 -15.00 0°; 0°; 90° 1 -14.50 -15.00 0°; 0°; 45° 2 -16.50 15.00 0°; 0°; -140° 2 -15.50 15.00 0°; 0°; -90° 2 -14.50 15.00 0°; 0°; -45° 3 16.50 15.00 0°; 0°; -40° 3 15.50 15.00 0°; 0°; -90° 3 14.50 15.00 0°; 0°; -135° 4 16.50 -15.00 0°; 0°; 40° 4 15.50 -15.00 0°; 0°; 90° 4 14.50 -15.00 0°; 0°; 135° GRID 17x7 EAv [lx] 380 Emin/EAv 0.71 GR - CRI 80 No. floodlights 12 floodlight height [m] 14 KEY   50.0 lx 100.0 lx150.0 lx200.0 lx250.0 lx300.0 lx350.0 lx400.0 lx450.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] II 300 0.7 - 60 PLAY AREA DIMENSIONS Length [m] 50 Width [m] 21 Grid points (length) 17 Grid points (width) 7 62 OU T D O OR REQUISITES Swimming - 300 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   62 15/04/16   11:49

132 171 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 3 4 5 6 7 8 9 10 11 12 13 Id Id Id Id Id AUX STANDARD ELECTRICAL SCHEME -System power: 12kW, three-phase Line description Main device Surge protec- tive device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  circuit Power 12.000 kW 0.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 3.000 kW 0.000 kW Operating current Ib [A] 19.27 0.00 4.82 4.82 4.82 4.82 4.82 4.82 4.82 4.82 0.00 Rated current In [A] 32.00 50.00 10.00 24.00 10.00 24.00 10.00 24.00 10.00 24.00 6.00 Article description MT100 D32 4P Disconnectable  fuse holder  3P+N 22x58 690V 50A Surge protec- tive device  3P+N 25kA Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO 230V AC/DC  24A - 2M MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO 230V AC/DC  24A - 2M MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO 230V AC/DC  24A - 2M MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO 230V AC/DC  24A - 2M MDC60 C6 2P Id=30mA AC Code GW 92 790 GW 96 314 GW D6 405 GW 96 592 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 94 125 Breaking capacity [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 GW 94 586 GW 94 586 GW 94 586 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows - 28 mod. 4 GW 46 428 F Blank panel 1M. 515MM 1 GW 46 438 F Pair of uprights 1 GW 46 446 Set of 4 galvanised fixing brackets 1 GW 46 533 F Double rail 28M 1 GW 44 698 4-pole terminal block 8M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 92 790 MCB 4P D32 10KA 4M 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 400V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 486 MCB 4P D10 6KA 4M 4 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 4 GW D6 715 Contactor 230V 4NO 24A 4 GWD6644 Latching relay 1NO 16A 230V 4 GW 94 125 RCBO 2P C6 6KA AC/0.03 2M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 63 PB 22359 EN Cata prog Light 0316_EN.indd   63 15/04/16   11:49

-25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) -30 -35 30 35 0 5 10 15 -5 -10 -15 Asse y (m) -20 20 1 1 1 1 1 1 1 1 430 660 770 630 170 170 ø14 ø14 PROPOSED SOLUTION CALCULATION RESULTS TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Stadium Optic Asymmetrical  Lamp MHN-LA 1000W/842 Lamp flux (lm) 100,000 TECHNICAL DATA OF THE HIGH MASTS Number of high masts 4 High mast height (m. above ground) 14 Number of floodlights 8 Number of floodlights per high mast 2 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. VALUES REQUIRED Class EAv [lx] Emin/EAv GR Colour rendering  index [CRI] III 200 0.5 - 20 ASYMMETRICAL  STADIUM FLOODLIGHT  1000W - GW 84 667 FLOODLIGHT POSITIONING Lighting  tower Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -16.00 -15.00 0°; 0°; 125° 1 -15.00 -15.00 0°; 0°; 45° 2 -16.00 15.00 0°; 0°; -125° 2 -15.00 15.00 0°; 0°; -45° 3 16.00 15.00 0°; 0°; -55° 3 15.00 15.00 0°; 0°; -135° 4 16.00 -15.00 0°; 0°; 55° 4 15.00 -15.00 0°; 0°; 135° GRID 17x7 EAv [lx] 252 Emin/EAv 0.71 GR - CRI 80 No. floodlights 8 floodlight height [m] 14 KEY 50.0 lx 100.0 lx150.0 lx200.0 lx250.0 lx300.0 lx350.0 lx PLAY AREA DIMENSIONS Length [m] 50 Width [m] 21 Grid points (length) 17 Grid points (width) 7 64 OU T D O OR REQUISITES Swimming - 200 lx - Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   64 15/04/16   11:49

132 171 1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 3 4 5 6 7 8 9 10 11 12 13 Id Id Id Id Id AUX STANDARD ELECTRICAL SCHEME -System power: 8kW, three-phase Line description Main device Surge protec- tive device Lamp High mast 1 km1 High mast 2 km2 High mast 3 km3 High mast 4 km4 Auxiliaries  circuit Power 8.000 kW 0.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 2.000 kW 0.000 kW Operating current Ib [A] 12.85 0.00 3.21 3.21 3.21 3.21 3.21 3.21 3.21 3.21 0.00 Rated current In [A] 20.00 20.00 10.00 24.00 10.00 24.00 10.00 24.00 10.00 24.00 6.00 Article description MT100 D20 4P Disconnectable  fuse holder  3P+N 22x58  690V 100A Surge protec- tive device  3P+N 25kA Type 1+2 Triple red  signalling  lamp with fuse  holder 230V MCB MT60   D10 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO 230V AC/DC  24A - 2M MCB MT60 D10 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO 230V AC/DC  24A - 2M MCB MT60 D10 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO 230V AC/DC  24A - 2M MCB MT60 D10 4P +  BD 4P 63A 30mA A-IR Contactor  4 NO 230V AC/DC  24A - 2M MDC60 C6 2P Id=30mA AC Code GW 92 788 GW 96 314 GW D6 405 GW 96 592 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 92 486 GW D6 715 GW 94 125 Breaking capacity [kA] 10.00 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 586 GW 94 586 GW 94 586 GW 94 586 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows - 28 mod. 4 GW 46 428 F Blank panel 1M. 515MM 1 GW 46 438 F Pair of uprights 1 GW 46 446 Set of 4 galvanised fixing brackets 1 GW 46 533 F Double rail 28M 1 GW 44 698 4-pole terminal block 8M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 92 788 MCB 4P D20 10KA 4M 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 400V 100A 1 GW D6 405 Surge protective device 3P+N 25KA TYPE 1+2 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 92 486 MCB 4P D10 6KA 4M 4 GW 94 586 Residual current device 4P IN 63A Immun. A/0.03 4 GW D6 715 Contactor 230V 4NO 24A 4 GW D6 644 Latching relay 1NO 16A 230V 4 GW 94 125 RCBO 2P C6 6KA AC/0.03 2M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 65 PB 22359 EN Cata prog Light 0316_EN.indd   65 15/04/16   11:49

0 5 10 15 -5 -10 -15 Asse y (m) -25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 30 -30 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]  2.0 FLOODLIGHT  GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 38 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -25.50 -11.70 0°; 0°; 90° 2 -24.00 -11.70 0°; 0°; 90° 3 -22.00 -11.70 0°; 0°; 90° 4 -20.00 -11.70 0°; 0°; 90° 5 -17.00 -11.70 0°; 0°; 90° 6 -13.00 -11.70 0°; 0°; 90° 7 -9.00 -11.70 0°; 0°; 90° 8 -5.50 -11.70 0°; 0°; 90° 9 -3.00 -11.70 0°; 0°; 90° 10 0.00 -11.70 0°; 0°; 90° CALCULATION RESULTS GRID 17x7 EAv [lx] 520 Emin/EAv 0.83 CRI 80 No. floodlights 38 floodlight height [m] 10 Lighting project for indoor sports centre. KEY 350.0 lx400.0 lx450.0 lx500.0 lx550.0 lx600.0 lx650.0 lx700.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] I 500 0.7 60 PLAY AREA DIMENSIONS Length [m] 50 Width [m] 21 Grid points (length) 17 Grid points (width) 7 66 REQUISITES IN D O O R Swimming - 500 lx - High-level competitions Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   66 15/04/16   11:49

1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 8.9kW, three-phase S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 MOD.EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 041 Illuminated green push-button 4 GW 74 201 1 NO contact 10A 250V 4 GW 74 211 Lamp-holder - BA95 coupling 4 GW 74 218 Lamp - BA95 coupling 4 GW 74 221 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 092 MCB 4P C50 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 4 GW 96 176 Control switch disconnector 4P 63A AC22B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW 96 623 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. Line description Main device Lamp Line 1 km1 Line 2 km2 Line 3 km3 Line 4 km4 Auxiliaries  line Power 8.900 kW 2.350 kW 2.350 kW 2.100 kW 2.100 kW 2.350 kW 2.350 kW 2.100 kW 2.100 kW 0.000 kW Operating current Ib [A] 14.0 3.70 3.70 3.30 3.30 3.70 3.70 3.30 3.30 0.00 Rated current In [A] 40.00 50.00 25.00 50.00 25.00 50.00 25.00 50.00 25.00 6.00 Article description Control switch  disconnector  4P 40A Surge protec- tive device  3P+N 25kA   Aux. Type 1+2  + fuse holder  22x58 - 16M Triple red signal- ling lamp with  fuse holder 230V  10.3x38 - 5M MT60 C50 4P   + BD 4P 63A  30mA  S Contactor 25A  4NO - 230V AC  / 220V DC - 2M MT60 C50 4P   + BD 4P 63A  30mA S Contactor 25A  4NO - 230V AC  / 220V DC - 2M MT60 C50 4P   + BD 4P 63A  30mA S Contactor 25A  4NO - 230V AC  / 220V DC - 2M MT60 C50 4P   + BD 4P 63A  30mA S Contactor 25A  4NO - 230V AC  / 220V DC - 2M MDC60 C6 2P Id=30mA AC Code GW 96 135 GW D6 405 GW 96 592 GW 92 092 GW D6 715 GW 92 092 GW D6 715 GW 92 092 GW D6 715 GW 92 092 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 532 GW 94 532 GW 94 532 GW 94 532 67 PB 22359 EN Cata prog Light 0316_EN.indd   67 15/04/16   11:49

0 5 10 15 -5 -10 -15 Asse y (m) -25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 30 -30 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm) 25,560 ASYMMETRICAL SMART [4]  2.0 FLOODLIGHT  GW S4 176 GS TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 22 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -23.50  -12.00 0°; 0°; 90° 2 -21.00  -12.00 0°; 0°; 90° 3 -18.00  -12.00 0°; 0°; 90° 4 -11.50  -12.00 0°; 0°; 90° 5 -5.00  -12.00 0°; 0°; 90° 6 0.00  -12.00 0°; 0°; 90° 7  5.00  -12.00 0°; 0°; 90° 8 11.50  -12.00 0°; 0°; 90° 9 18.00 -12.00 0°; 0°; 90° 10 21.00  -12.00 0°; 0°; 90° 11 23.50 -12.00 0°; 0°; 90° CALCULATION RESULTS GRID 17x7 EAv [lx] 301 Emin/EAv 0.81 CRI 80 No. floodlights 22 floodlight height [m] 10 Lighting project for indoor sports centre. KEY 200.0 lx250.0 lx300.0 lx350.0 lx400.0 lx450.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] II 300 0.7 60 PLAY AREA DIMENSIONS Length [m] 50 Width [m] 21 Grid points (length) 17 Grid points (width) 7 68 REQUISITES IN D O O R Swimming - 300 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   68 15/04/16   11:49

1 3 1 5 7 9 11 2 4 5 6 7 8 9 10 11 12 132 171 NEUTRO FASE P3 Kpp3 Kpp3 Km3 Kpp4 Kpp4 P4 P2 Kpp2 Kpp2 Km2 Km1 Kpp1 Kpp1 P1 Km4 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 10 1 11 10 12 1 13 12 STANDARD ELECTRICAL SCHEME -System power: 5.2kW, three-phase Line description Main device Lamp Line   1 km1 Line   2 km2 Line   3 km3 Line   4 km4 Auxiliaries   line Power 5.200 kW 1.400 kW 1.400 kW 1.200 kW 1.200 kW 1.400 kW 1.400 kW 1.200 kW 1.200 kW 0.000 kW Operating current Ib [A] 8.20 2.20 2.20 1.90 1.90 2.20 2.20 1.90 1.90 0.00 Rated current In [A] 40.00 32.00 25.00 32.00 25.00 32.00 25.00 32.00 25.00 6.00 Article description Control switch  disconnector  4P 40A Surge protective  device 3P+N  25kA Aux. Type  1+2 + fuse  holder 22x58  - 16M Triple red signal- ling lamp with  fuse holder 230V  10.3x38 - 5M MT60 C32 4P  + BD 4P 63A  30mA S Contactor 25A  4NO - 230V AC  / 220V DC - 2M MT60 C32 4P  + BD 4P 63A  30mA S Contactor 25A  4NO - 230V AC/  220V DC - 2M MT60 C32 4P  + BD 4P 63A  30mA S Contactor 25A  4NO - 230V AC/  220V DC - 2M MT60 C32 4P  + BD 4P 63A  30mA S Contactor 25A  4NO - 230V AC  / 220V DC - 2M MDC60 C6 2P Id=30mA AC Code GW 96 135 GW D6 405 GW 96 592 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 92 090 GW D6 715 GW 94 125 Breaking capacity Icn/Icu [kA] 6.00 6.00 6.00 6.00 6.00 RCCB GW 94 532 GW 94 532 GW 94 532 GW 94 532 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 698 4-pole terminal block 8 mod. EN 50022 1 GW 46 206 Polyester board with window 800X585X300 1 GW 46 423 F Panel without windows 28 mod. 4 GW 46 428 F Blank panel 1M. 585MM GR.RAL7035 1 GW 46 438 F Pair of uprights for boards 800X585X300 1 GW 46 446 Set of 4 steel brackets for fixing surface-mounting boards 1 GW 46 533 F Quick-assembly double rail 28M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 104 6-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 4 GW 74 501 1 NO contact 10A 250V 4 GW 74 511 Lamp-holder - BA95 coupling 4 GW 74 518 Lamp - BA95 coupling 4 GW 74 521 Black cap 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 090 MCB 4P C32 6KA 4M 4 GW 94 125 RCBO C.2P C 6 6KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 4 GW 96 135 Switch disconnector 4P 40A AC23B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 4 GW D6 405 Surge protective device 3P+N 25KA AUX TYPE 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 4 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 69 PB 22359 EN Cata prog Light 0316_EN.indd   69 15/04/16   11:49

0 5 10 15 -5 -10 -15 Asse y (m) -25 25 0 5 10 15 20 -5 -10 -15 -20 Asse x (m) 30 -30 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 751 99 504 533 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Floodlight Smart [4] 2.0 Optic Asymmetrical  Power system (W) 232 Lumen output (lm)  25,560 ASYMMETRICAL SMART [4]  2.0 FLOODLIGHT  GW S4 176 GS The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. FLOODLIGHT POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -24.00 -11.50 0°; 0°; 90° 2 -20.00 -11.50 0°; 0°; 90° 3 -12.00 -11.50 0°; 0°; 90° 4 -4.00 -11.50 0°; 0°; 90° 13 4.00 11.50 0°; 0°; -90° 14 12.00 11.50 0°; 0°; -90° 15 20.00 11.50 0°; 0°; -90° 16 24.00 11.50 0°; 0°; -90° CALCULATION RESULTS GRID 17x7 EAv [lx] 220 Emin/EAv 0.80 CRI 80 No. floodlights 16 floodlight height [m] 10 TECHNICAL DATA OF THE FLOODLIGHTS Floodlight assembly height (m) 10 Number of floodlights 16 Lighting project for indoor sports centre. KEY 150.0 lx200.0 lx250.0 lx300.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] III 200 0.5 20 PLAY AREA DIMENSIONS Length [m] 50 Width [m] 21 Grid points (length) 17 Grid points (width) 7 70 REQUISITES IN D O O R Swimming - 200 lx - Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   70 15/04/16   11:49

1 3 2 4 5 6 7 8 1 5 7 85 132 1 2 1 3 1 4 1 5 4 6 1 7 6 8 1 9 8 P1 Kpp1 NEUTRO Kpp1 Km1 FASE Km2 Kpp2 Kpp2 P2 STANDARD ELECTRICAL SCHEME -System power: 3.8kW, three-phase Line description Main device Lamp Line 1 km1 Line 2 km2 Auxiliaries line Power 3.800 kW 1.900 kW 1.900 kW 1.900 kW 1.900 kW 0.000 kW Operating current Ib [A] 6.00 3.00 3.00 3.00 3.00 0.00 Rated current In [A] 63.00 40.00 25.00 40.00 25.00 6.00 Article description Control switch discon- nector 4P 63A Surge protective device  3P+N 25kA Aux. Type  1+2 + fuse holder   22x58 - 16M Triple red signalling  lamp with fuse holder  230V 10.3x38 - 5M MT60 C40 4P + BD 4P 63A 30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MT60 C40 4P + BD 4P 63A 30mA S Contactor 25A 4NO - 230V AC/ 220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 176 GW D6 405 GW 96 592 GW 92 091 GW D6 715 GW 92 091 GW D6 715 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 6.00 4.50 RCCB GW 94 532 GW 94 532 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 696 4-pole terminal block 4 mod. EN 50022 1 GW 46 205 Polyester board with window 650X515X250 1 GW 46 422 F Panel without windows 24 mod. 3 GW 46 427 F Blank panel 1M. 515MM GR.RAL7035 1 GW 46 437 F Pair of uprights for boards 650X405X200 1 GW 46 532F Quick-assembly double rail 24M 1 S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 102 2-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 2 GW 74 501 1 NO contact 10A 250V 2 GW 74 511 Lamp-holder - BA95 coupling 2 GW 74 518 Lamp - BA95 coupling 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 3 GW 92 091 MCB 4P C40 6KA 4M 2 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 532 Residual current device 4P IN 63A Instant. A/0.03 3.5M 2 GW 96 176 Control switch disconnector 4P 63A AC22B 1 GW 96 312 Disconnectable fuse holder 3P+N 10.3X38 400V 32A 1 GW 96 314 Disconnectable fuse holder 3P+N 22X58 690V 1 GW 96 592 Triple red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 2 GW D6 405 Surge protective device 3P+N 25KA aux type 1+2 1 GW D6 715 Contactor 25A 4NO 230V 2M 2 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 71 PB 22359 EN Cata prog Light 0316_EN.indd   71 15/04/16   11:49

0 5 -5 Asse y (m) 0 5 -5 Asse x (m) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 0 0 76 1 1 0 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Ceiling-mounting luminaire SMART [3] Optic Opal Power system (W) 51 Lumen output (lm) 5977 Play area dimensions LED WATERTIGHT LUMINAIRE   SMART[3] 1600MM   GW S3 258 P TECHNICAL DATA OF THE WATERTIGHT LUMINAIRES Floodlight assembly height (m) 4.5 Number of floodlights 15 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. WATERTIGHT LUMINAIRES POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -4.00 -2.20    0°; 0°; 90° 2 -4.00 0.00 0°; 0°; 90° 3 -4.00 2.20 0°; 0°; 90° 4 -2.00 -2.20 0°; 0°; 90° 5 -2.00 0.00 0°; 0°; 90° 6 -2.00 2.20 0°; 0°; 90° 7 0.00 -2.20 0°; 0°; 90° 8 0.00 0.00 0°; 0°; 90° 9 0.00 2.20 0°; 0°; 90° 10 2.00 -2.20 0°; 0°; 90° 11 2.00 0.00 0°; 0°; 90° 12 2.00 2.20 0°; 0°; 90° 13 4.00 -2.20 0°; 0°; 90° 14 4.00 0.00 0°; 0°; 90° 15 4.00 2.20 0°; 0°; 90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 9x5 EAv [lx] 772 Emin/EAv 0.80 CRI 80 No. of luminaires 15 luminaire h. [m] 4.5 KEY 700.0 lx800.0 lx900.0 lx 1000.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] I 750 0.7 60 PLAY AREA DIMENSIONS Length [m] 9.75 Width [m] 6.40 Grid points (length) 9 Grid points (width) 5 72 REQUISITES IN D O O R Squash - 750 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   72 15/04/16   11:49

1 2 3 4 6 5 82 66 1 2 1 3 1 4 1 5 4 6 1 7 6 NEUTRO FASE Km1 Kpp1 Kpp1 P1 STANDARD ELECTRICAL SCHEME -System power: 0.77kW, single-phase Line description Main device Lamp Line 1 km1 Auxiliaries line Power 0.770 kW 0.770 kW 0.770 kW 0.000 kW Operating current Ib [A] 3.72 3.72 3.72 0.00 Rated current In [A] 32.00 20.00 25.00 6.00 Article description Control switch disconnector  2P 32A Surge protective device 1P+N  25kA Aux. Type 1+2 + fuse holder  22x58 - 8M Red signalling lamp with fuse  holder 230V 10.3x38 - 3M MDC60 C20 2P Id=30mA A Contactor 25A 2NO - 230V AC / 220V DC 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 94 328 GW D6 712 GW 94 005 Breaking capacity [kA] 6.00 4.50 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 MOD.EN 50022 1 GW 46 203 Polyester board with window 500X405X200 1 GW 46 421 F Panel without windows 18 mod. 2 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 436 F Pair of uprights for boards 500X405X200 1 GW 46 531 F Quick-assembly double rail 18M 1 S TANDARD   PUSH - BUTTON   CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 101 1-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 1 GW 74 501 1 NO contact 10A 250V 1 GW 74 511 Lamp-holder - BA95 coupling 1 GW 74 518 Lamp - BA95 coupling 1 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 328 RCBO C.2P C20 6KA A/0.03 2M 1 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 1 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 73 PB 22359 EN Cata prog Light 0316_EN.indd   73 15/04/16   11:49

0 5 -5 Asse y (m) 0 5 -5 Asse x (m) 1 1 1 1 1 1 1 1 1 1 1 2 0 0 76 1 1 0 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Ceiling-mounting luminaire SMART [3] Optic Opal Power system (W) 51 Lumen output (lm) 5977 LED WATERTIGHT LUMINAIRE   SMART[3] 1600MM   GW S3 258 P TECHNICAL DATA OF THE WATERTIGHT LUMINAIRES Floodlight assembly height (m) 4.5 Number of floodlights 10 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. WATERTIGHT LUMINAIRES POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -4.00 -1.75 0°; 0°; 90° 2 -4.00 1.75 0°; 0°; 90° 3 -2.00 -1.75 0°; 0°; 90° 4 -2.00 1.75 0°; 0°; 90° 5 0.00 -1.75 0°; 0°; 90° 6 0.00 1.75 0°; 0°; 90° 7 2.00 -1.75 0°; 0°; 90° 8 2.00 1.75 0°; 0°; 90° 9 4.00 -1.75 0°; 0°; 90° 10 4.00 1.75 0°; 0°; 90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 9x5 EAv [lx] 521 Emin/EAv 0.80 CRI 80 No. of luminaires 10 luminaire h. [m] 4.5 KEY 500.0 lx600.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] II 500 0.7 60 PLAY AREA DIMENSIONS Length [m] 9.75 Width [m] 6.40 Grid points (length) 9 Grid points (width) 5 74 REQUISITES IN D O O R Squash - 500 lx - Medium-level competitions Project compliant with: EN 12193 (2008): Class II PB 22359 EN Cata prog Light 0316_EN.indd   74 15/04/16   11:50

3 2 1 6 5 4 82 66 1 2 1 3 1 4 1 5 4 6 1 7 6 NEUTRO FASE Km1 Kpp1 Kpp1 P1 STANDARD ELECTRICAL SCHEME -System power: 0.50kW, single-phase Line description Main device Lamp Line 1 km1 Auxiliaries line Power 0.500 kW 0.500 kW 0.500 kW 0.000 kW Operating current Ib [A] 2.42 2.42 2.42 0.00 Rated current In [A] 32.00 16.00 25.00 6.00 Article description Control switch disconnector  2P 32A Surge protective device 1P+N  25kA Aux. Type 1+2 + fuse  holder 22x58 - 8M Red signalling lamp with fuse  holder 230V 10.3x38 - 3M MDC60 C16 2P Id=30mA A Contactor 25A 2NO - 230V AC/ 220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 94 327 GW D6 712 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 4.50 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 MOD.EN 50022 1 GW 46 203 Polyester board with window 500X405X200 1 GW 46 421 F Panel without windows 18 mod. 2 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 436 F Pair of uprights for boards 500X405X200 1 GW 46 531 F Quick-assembly double rail 18M 1 S TANDARD   PUSH - BUTTON   CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 101 1-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 1 GW 74 501 1 NO contact 10A 250V 1 GW 74 511 Lamp-holder - BA95 coupling 1 GW 74 518 Lamp - BA95 coupling 1 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 327 RCBO C.2P C16 6KA A/0.03 2M 1 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 1 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 75 PB 22359 EN Cata prog Light 0316_EN.indd   75 15/04/16   11:50

0 5 -5 Asse y (m) 0 5 -5 Asse x (m) 1 1 1 1 1 1 1 2 0 0 76 1 1 0 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP Maintenance factor 0.80 Ceiling-mounting luminaire SMART [3] Optic Opal Power system (W) 51 Lumen output (lm) 5977 LED WATERTIGHT LUMINAIRE   SMART[3] 1600MM   GW S3 258 P WATERTIGHT LUMINAIRES POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -3.00 -1.70 0°; 0°; 90° 2 -3.00 1.70 0°; 0°; 90° 3 0.00 -1.70 0°; 0°; 90° 4 0.00 1.70 0°; 0°; 90° 5 3.00 -1.70 0°; 0°; 90° 6 3.00 1.70 0°; 0°; 90° CALCULATION RESULTS Lighting project for indoor sports centre. GRID 9x5 EAv [lx] 322 Emin/EAv 0.77 CRI 80 No. of luminaires 6 luminaire h. [m] 4.5 TECHNICAL DATA OF THE WATERTIGHT LUMINAIRES Floodlight assembly height (m) 4.5 No. of luminaires 6 The lighting values actually measured may differ from the project ones due to the intrinsic tolerance levels of the light sources and devices, for their orientation, and for the different electricity supply  parameters. KEY 250.0 lx300.0 lx350.0 lx400.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] III 300 0.7 20 PLAY AREA DIMENSIONS Length [m] 9.75 Width [m] 6.40 Grid points (length) 9 Grid points (width) 5 76 REQUISITES IN D O O R Squash - 300 lx- Training activities Project compliant with: EN 12193 (2008): Class III PB 22359 EN Cata prog Light 0316_EN.indd   76 15/04/16   11:50

4 7 1 7 6 5 82 66 1 7 1 4 1 5 1 6 5 7 1 8 7 NEUTRO FASE Km1 Kpp1 Kpp1 P1 STANDARD ELECTRICAL SCHEME -System power: 0.3kW, single-phase Line description Main device Lamp Line 1 km1 Auxiliaries line Power 0.300 kW 0.300 kW 0.300 kW 0.000 kW Operating current Ib [A] 1.45 1.45 1.45 0.00 Rated current In [A] 32.00 10.00 25.00 6.00 Article description Control switch disconnector  2P 32A Surge protective device 1P+N  25kA Aux. Type 1+2 + fuse  holder 22x58 - 8M Red signalling lamp with fuse  holder 230V 10.3x38 - 3M MDC60 C10 2P Id=30mA A Contactor 25A 2NO - 230V AC / 220V DC 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 94 326 GW D6 712 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 4.50 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 MOD.EN 50022 1 GW 46 203 Polyester board with window 500X405X200 1 GW 46 421 F Panel without windows 18 mod. 2 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 436 F Pair of uprights for boards 500X405X200 1 GW 46 531 F Quick-assembly double rail 18M 1 S TANDARD   PUSH - BUTTON   CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 101 1-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 1 GW 74 501 1 NO contact 10A 250V 1 GW 74 511 Lamp-holder - BA95 coupling 1 GW 74 518 Lamp - BA95 coupling 1 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 326 RCBO C.2P C10 6KA A/0.03 2M 1 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 1 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 1 S TANDARD   AUXILIARIES   CIRCUIT The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. 77 PB 22359 EN Cata prog Light 0316_EN.indd   77 15/04/16   11:50

0 5 10 -5 -10 Asse y (m) 0 5 10 15 -5 -10 -15 Asse x (m) -20 20 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 0 0 76 1 1 0 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP  Maintenance factor 0.80 Ceiling-mounting luminaire SMART [3] Optic Transparent Power system (W) 51 Lumen output (lm) 6453 TECHNICAL DATA OF THE WATERTIGHT LUMINAIRES Floodlight assembly height (m) 4.5 No. of luminaires 16 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. WATERTIGHT LUMINAIRES POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -12.25 -1.00 0°; 0°; 90° 2 -12.25 1.00 0°; 0°; 90° 3 -8.75 -1.00 0°; 0°; 90° 4 -8.75 1.00 0°; 0°; 90° 5 -5.25 -1.00 0°; 0°; 90° 6 -5.25 1.00 0°; 0°; 90° 7 -1.75 -1.00 0°; 0°; 90° 8 -1.75 1.00 0°; 0°; 90° 9 1.75 -1.00 0°; 0°; 90° 10 1.75 1.00 0°; 0°; 90° 11 5.25 -1.00 0°; 0°; 90° 12 5.25 1.00 0°; 0°; 90° 13 8.75 -1.00 0°; 0°; 90° 14 8.75 1.00 0°; 0°; 90° 15 12.25 -1.00 0°; 0°; 90° 16 12.25 1.00 0°; 0°; 90° CALCULATION RESULTS LED WATERTIGHT LUMINAIRE  SMART[3] 1600MM   GW S3 258 T GRID 11x4 EAv [lx] 308 Emin/EAv 0.73 CRI 80 No. of luminaires 16 luminaire h. [m] 4.5 Lighting project for indoor sports centre. KEY 50.0 lx 100.0 lx150.0 lx200.0 lx250.0 lx300.0 lx350.0 lx400.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] I 300 0.7 60 PLAY AREA DIMENSIONS Length [m] 27.5 Width [m] 4 Grid points (length) 15 Grid points (width) 4 78 REQUISITES IN D O O R Bocce - 300 lx Medium-level competitions - Training Activities Project compliant with: EN 12193 (2008): Class I PB 22359 EN Cata prog Light 0316_EN.indd   78 15/04/16   11:50

1 2 3 4 6 5 85 132 P1 Kpp1 NEUTRO Kpp1 Km1 FASE Km2 Kpp2 Kpp2 P2 1 2 1 3 1 4 1 5 4 6 1 7 6 STANDARD ELECTRICAL SCHEME -System power: 0.82kW, single-phase Line description Main device Lamp Line 1 km1 Auxiliaries line Power 0.82 kW 0.82 kW 0.82 kW 0.000 kW Operating current Ib [A] 3.96 3.96 3.96 0.00 Rated current In [A] 32.00 20.00 25.00 6.00 Article description Control switch disconnector  2P 32A Surge protective device 1P+N  25kA Aux. Type 1+2 + fuse  holder 22x58 - 8M Red signalling lamp with fuse  holder 230V 10.3x38 - 3M MDC60 C20 2P Id=30mA A Contactor 25A 2NO - 230V AC/ 220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 94 328 GW D6 712 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 4.50 S TANDARD   DISTRIBUTION   BOARD DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 MOD.EN 50022 1 GW 46 203 Polyester board with window 500X405X200 1 GW 46 421 F Panel without windows 18 mod. 2 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 436 F Pair of uprights for boards 500X405X200 1 GW 46 531 F Quick-assembly double rail 18M 1 The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. S TANDARD   PUSH - BUTTON    CONTROL   PANEL PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 102 2-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 2 GW 74 501 1 NO contact 10A 250V 2 GW 74 511 Lamp holder - BA95 coupling 2 GW 74 518 Lamp - BA95 coupling 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 328 RCBO C.2P C20 6KA A/0.03 2M 1 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW 96 623 Latching relay 1NO 16A 230V 1 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 1 S TANDARD   AUXILIARIES   CIRCUIT 79 PB 22359 EN Cata prog Light 0316_EN.indd   79 15/04/16   11:50

0 5 10 -5 -10 Asse y (m) 0 5 10 15 -5 -10 -15 Asse x (m) -20 20 1 1 1 1 1 1 1 1 1 1 1 1 1 2 0 0 76 1 1 0 PROPOSED SOLUTION TECHNICAL DATA OF THE LAMP  Maintenance factor 0.80 Ceiling-mounting luminaire SMART [3] Optic Transparent Power system (W) 51 Lumen output (lm) 6453 TECHNICAL DATA OF THE WATERTIGHT LUMINAIRES Floodlight assembly height (m) 4.5 No. of luminaires 12 The lighting values actually measured may differ from the project ones due to the intrinsic  tolerance levels of the light sources and devices, for their orientation, and for the different  electricity supply parameters. WATERTIGHT LUMINAIRES POSITIONING Device Position of devices in   X Position of devices in   Y Device rotation X°; Y°; Z° 1 -13.75 0.00 0°; 0°; 90° 2 -11.25 0.00 0°; 0°; 90° 3 -8.75 0.00 0°; 0°; 90° 4 -6.25 0.00 0°; 0°; 90° 5 -3.75 0.00 0°; 0°; 90° 6 -1.25 0.00 0°; 0°; 90° 7 1.25 0.00 0°; 0°; 90° 8 3.75 0.00 0°; 0°; 90° 9 6.25 0.00 0°; 0°; 90° 10 8.75 0.00 0°; 0°; 90° 11 11.25 0.00 0°; 0°; 90° 12 13.75 0.00 0°; 0°; 90° CALCULATION RESULTS LED WATERTIGHT LUMINAIRE  SMART[3] 1600MM   GW S3 258 T GRID 11x4 EAv [lx] 228 Emin/EAv 0.71 CRI 80 No. of luminaires 12 luminaire h. [m] 4.5 Lighting project for indoor sports centre. KEY 50.0 lx 100.0 lx150.0 lx200.0 lx250.0 lx300.0 lx VALUES REQUIRED Class EAv [lx] Emin/EAv Colour rendering  index [CRI] II - III 200 0.5 - 0.7 60 - 20 PLAY AREA DIMENSIONS Length [m] 27.5 Width [m] 4 Grid points (length) 15 Grid points (width) 4 80 REQUISITES IN D O O R Bocce - 200 lx Medium-level competitions - Training Activities Project compliant with: EN 12193 (2008): Class II – III PB 22359 EN Cata prog Light 0316_EN.indd   80 15/04/16   11:50

1 2 3 4 6 5 85 132 P1 Kpp1 NEUTRO Kpp1 Km1 FASE Km2 Kpp2 Kpp2 P2 1 2 1 3 1 4 1 5 4 6 1 7 6 STANDARD ELECTRICAL SCHEME -System power: 0.62kW, single-phase Line description Main device Lamp Line 1 km1 Auxiliaries line Power 0.620 kW 0.620 kW 0.620 kW 0.000 kW Operating current Ib [A] 3.00 3.00 3.00 0.00 Rated current In [A] 32.00 16.00 25.00 6.00 Article description Control switch disconnector  2P 32A Surge protective device 1P+N  25kA Aux. Type 1+2 + fuse  holder 22x58 - 8M Red signalling lamp with fuse  holder 230V 10.3x38 - 3M MDC60 C16 2P Id=30mA A Contactor 25A 2NO - 230V AC/ 220V DC - 2M MDC45 C6 1P+N Id=30mA AC Code GW 96 114 GW D6 404 GW 96 581 GW 94 327 GW D6 712 GW 94 005 Breaking capacity Icn/Icu [kA] 6.00 4.50 S TANDARD   DISTRIBUTION   BOARD The electrical scheme shown here is merely an example; it can be modified to suit the installation requirements. It should not be considered as a substitute for the necessary electrical project, which must  be based on the technical standards. S TANDARD   PUSH - BUTTON    CONTROL   PANEL S TANDARD   AUXILIARIES   CIRCUIT DISTRIBUTION BOARD COMPONENTS Code Description Qty GW 44 691 2-pole terminal block 4 MOD.EN 50022 1 GW 46 203 Polyester board with window 500X405X200 1 GW 46 421 F Panel without windows 18 mod. 2 GW 46 426 F Blank panel 1M. 405MM GR.RAL7035 1 GW 46 436 F Pair of uprights for boards 500X405X200 1 GW 46 531 F Quick-assembly double rail 18M 1 PUSH-BUTTON PANEL COMPONENTS Code Description Qty GW 27 102 2-gang push-button panel IP66 1 GW 74 341 Illuminated green push-button 2 GW 74 501 1 NO contact 10A 250V 2 GW 74 511 Lamp-holder - BA95 coupling 2 GW 74 518 Lamp - BA95 coupling 2 COMPONENTS OF THE ELECTRICAL SCHEME AND AUXILIARIES CIRCUIT Code Description Qty GW 72 104 Cylindrical fuse type GG 10.3X38 500V 2A 1 GW 94 005 RCBO C.1P+N C 6 4.5KA AC/0.03 2M 1 GW 94 327 RCBO C.2P C16 6KA A/0.03 2M 1 GW 96 114 Switch disconnector 2P 32A AC23B 1 GW 96 215 Disconnectable fuse holder 1P+N 10.3X38 400V 32A 1 GW 96 218 Disconnectable fuse holder 1P+N 22X58 690V 1 GW 96 581 Single red indicator lamp 230V 1M 1 GW D6 644 Latching relay 1NO 16A 230V 1 GW D6 404 Surge protective device 1P+N 25KA AUX TYPE 1+2 1 GW D6 712 Contactor 25A 2NO 230V 2M 1 81 PB 22359 EN Cata prog Light 0316_EN.indd   81 15/04/16   11:50

1   LOW VOLTAGE DISTRIBUTION  BOARD 2   BOARDS 3   WIRING 4   DOMESTIC RANGE 5   DISTRIBUTION SYSTEMS 6   COMMAND SYSTEMS 7   CONNECTION SYSTEMS 8   LIGHTING 9   DOMOTICS DISTRIBUTION BO ARDS   UP T O  1,600A SEC OND AR Y   DISTRIBUTION BO ARDS NE TW ORK   CABLING COMM ANDS ENER GY SOCKE T- OUTLE TS DA TA SOCKE T- OUTLE TS TEMPER ATURE ADJUST MENT TECHNIC AL AL ARMS CONDUIT S JUNC TION BO XES   (FL USH-MOUNTING/  SURF ACE-MOUNTING) COMPONENT -HOLDER BO XES   (FL USH-MOUNTING/SURF ACE- MOUNTING) FL OOR OUTLE T BO XES COMM AND AND   EMER GENC Y SY STEMS IB SOCKE T- OUTLE T DISTRIBUTION  AND C ONNEC TION SY STEMS INDOOR  LIGHTING OUTDOOR  LIGHTING SUPER VISION LIGHTING C ONTR OL DRIVE C ONTR OL   (HOPPER WINDO W S/BLINDS) TEMPER ATURE ADJUST MENT ENER GY M ANA GEMENT TECHNIC AL AL ARMS SCENES CHANGING ROOM    STAND ACCESS PATH PARKING AREATECHNICAL  PREMISESSTOREHOUSE OFFICES 82 CO M P LE M ENT AR Y  ARE A S An overview of the GEWISS range Apart from lighting devices, the GEWISS range also includes solutions for protec-tion, management, connection and energy distribution: 20,000 products offering professionals the possibility to design complete systems for all sports facilities service infrastructures. PB 22359 EN Cata prog Light 0316_EN.indd   82 15/04/16   11:50

1   LOW VOLTAGE DISTRIBUTION  BOARD 2   BOARDS 3   WIRING 4   DOMESTIC RANGE 5   DISTRIBUTION SYSTEMS 6   COMMAND SYSTEMS 7   CONNECTION SYSTEMS 8   LIGHTING 9   DOMOTICS DISTRIBUTION BO ARDS   UP T O  1,600A SEC OND AR Y   DISTRIBUTION BO ARDS NE TW ORK   CABLING COMM ANDS ENER GY SOCKE T- OUTLE TS DA TA SOCKE T- OUTLE TS TEMPER ATURE ADJUST MENT TECHNIC AL AL ARMS CONDUIT S JUNC TION BO XES   (FL USH-MOUNTING/  SURF ACE-MOUNTING) COMPONENT -HOLDER BO XES   (FL USH-MOUNTING/SURF ACE- MOUNTING) FL OOR OUTLE T BO XES COMM AND AND   EMER GENC Y SY STEMS IB SOCKE T- OUTLE T DISTRIBUTION  AND C ONNEC TION SY STEMS INDOOR  LIGHTING OUTDOOR  LIGHTING SUPER VISION LIGHTING C ONTR OL DRIVE C ONTR OL    (HOPPER WINDO W S/BLINDS) TEMPER ATURE ADJUST MENT ENER GY M ANA GEMENT TECHNIC AL AL ARMS SCENES CHANGING ROOM    STAND ACCESS PATH PARKING AREATECHNICAL  PREMISESSTOREHOUSE OFFICES 83 PB 22359 EN Cata prog Light 0316_EN.indd   83 15/04/16   11:50

PLAY AREA 7-A-SIDE NORTH STANDS LOCAL  LOCKER ROOM REFEREE  LOCKER ROOM REFEREE  LOCKER ROOM TECHNICAL ROOM OFFICE NORTH PEDESTRIAN AREA SOUTH PEDESTRIAN AREA PARKING AREA WAREHOUSE GUEST  LOCKER ROOM SOUTH STANDS 1 4 4 4 7 7 2 2 5 5 5 8 8 8 3 3 9 9 9 4 4 7 7 7 5 5 5 8 8 8 6 6 9 9 9 KEY 1   LOW VOLTAGE DISTRIBUTION BOARD 2   BOARDS 3   WIRING 4   DOMESTIC RANGE 5   DISTRIBUTION SYSTEMS 6   COMMAND SYSTEMS 7   CONNECTION SYSTEMS 8   LIGHTING 9   DOMOTICS 84 CO M P LE M ENT AR Y  ARE A S Standard example of sports facilities layout PB 22359 EN Cata prog Light 0316_EN.indd   84 15/04/16   11:51

PLAY AREA 7-A-SIDE NORTH STANDS LOCAL  LOCKER ROOM REFEREE  LOCKER ROOM REFEREE  LOCKER ROOM TECHNICAL ROOM OFFICE NORTH PEDESTRIAN AREA SOUTH PEDESTRIAN AREA PARKING AREA WAREHOUSE GUEST  LOCKER ROOM SOUTH STANDS 4 4 4 4 2 2 2 2 5 5 5 5 8 8 8 8 9 9 9 9 7 7 5 5 8 8 9 9 85 PB 22359 EN Cata prog Light 0316_EN.indd   85 15/04/16   11:51

1.1  PARKING AREA 1.1.1  Lighting GW R5 272 ROAD [5] 2M 4000K 700mA 20 pcs GW 84 097 CONICAL STEEL HIGH MAST H=7M ABOVE GROUND 20 pcs 1.1.2  Power take-off outlet box GW 20 246 SOCKET-OUTLET 2P+E 16A DUAL AMP. ITALIAN/GERMAN STD. SY/WT 2 pcs GW 27 403 2-GANG BLANK WATERTIGHT CAP SYSTEM 2 pcs GW 66 304 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67 S.F.2P+E  16A 230V 6H SBF 1 pcs GW 66 309 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67  S.F.3P+N+E 16A 400V 6H SBF 1 pcs GW 66 709 N FLANGED COVER, 2 CAPS IP67 1 pcs GW 68 715 A EMPTY PEDESTALS WITH SINGLE-SIDED TAKE-OFF QMC 125B  LIGHT BLUE 1 pcs GW 68 731 W PANEL 3 INTERLOCKED SWITCHED SOCKET-OUTLETS  VERT. IP55 BIA 1 pcs GW 68 741 A PANEL WITH ENCLOSURE AZ 1 pcs GW 68 765 TERMINAL BLOCK FOR QMC: CABLES UP TO 16SQ.MM 1 pcs GW 94 167 RCBO C.4P C16 6KA AC/0.03 4M 2 pcs GW 96 135 CONTROL SWITCH DISCONNECTOR 4P 40A 1 pcs 1.1.3  Routing and boxes DX 59 401 ELECTRICAL BOX 200X200 12 pcs DX 35 003 FU15/ 75R.50M FLEXIBLE CABLE DUCT 300 m DX 58 203 FUM/ 75 COUPLING 12 pcs 1.2  NORTH STANDS 1.2.1  Lighting GW S3 136 T SMART [3] - 1200mm - 20W 40 pcs 1.2.2  Routing and boxes DX 25 732 RKB32-3M HEAVY SOLID CONDUIT, GREY 50 m DX 43 232 MS 32 MORBIDX BOX-CONDUIT COUPLING 40 pcs DX 25 720 RKB20-3M HEAVY SOLID CONDUIT, GREY 10 m DX 43 220 MS 20 MORBIDX BOX-CONDUIT COUPLING 44 pcs GW 44 208 BOX IP56 SMOOTH WALLS 240X190X90 20 pcs GW 50 604 SNAP-ON SUPPORT FOR CONDUIT D.32 GR.RAL7035 25 pcs GW 50 602 SNAP-ON SUPPORT FOR CONDUIT D.20 GR.RAL7035 5 pcs 1.2.3  Socket-outlets GW 66 204 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67 C.F.2P+E 16A  230V 6H SBF 1 pcs GW 66 209 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67  C.F.3P+N+E 16A 400V 6H SBF 1 pcs 1.3  SOUTH STANDS 1.3.1  Lighting GW S3 136 T SMART [3] - 1200mm - 20W 40 pcs 1.3.2  Routing and boxes DX 25 732 RKB32-3M HEAVY SOLID CONDUIT, GREY 50 m DX 43 232 MS 32 MORBIDX BOX-CONDUIT COUPLING 40 pcs DX 25 720 RKB20-3M HEAVY SOLID CONDUIT, GREY 10 m DX 43 220 MS 20 MORBIDX BOX-CONDUIT COUPLING 44 pcs GW 44 208 BOX IP56 SMOOTH WALLS 240X190X90 20 pcs GW 50 604 SNAP-ON SUPPORT FOR CONDUIT D.32 GR.RAL7035 25 pcs GW 50 602 SNAP-ON SUPPORT FOR CONDUIT D.20 GR.RAL7035 5 pcs 1.3.3  Socket-outlets GW 66 204 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67 C.F.2P+E 16A  230V 6H SBF 1 pcs GW 66 209 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67  C.F.3P+N+E 16A 400V 6H SBF 1 pcs 1.4  PEDESTRIANS AREA 1.4.1  Lighting GW S2 401 EXTRO LED 13W 4000K 220-240V 50-60HZ G 20 pcs GW 82 292 EXTRO COLUMN SING.H.1300 GRAPHITE GREY 20 pcs GW 82 297 RECTANGULAR BASE FOR EXTRO COLUMN GRAPHITE GREY 20 pcs 1.4.2  Routing and boxes DX 59 401 ELECTRICAL BOX 200X200 6 pcs DX 35 003 FU15/ 75R.50M FLEXIBLE CABLE DUCT 90 m DX 58 203 FUM/ 75 COUPLING 6 pcs 1.4.3  Commands GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 2 pcs GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 2 pcs GW 10 195 BLANKING MODULE 1M WHITE 2 pcs GW 10 051 TWO-WAY SWITCH 1M 1P 16AX WHITE 4 pcs GW 42 201 WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEMS,  WITH PUSH-BUTTON 2 pcs 1.4.4  Power take-off outlet box GW 20 246 SOCKET-OUTLET 2P+E 16A DUAL AMP. ITALIAN/GERMAN  STD. SY/WT 2 pcs GW 27 403 2-GANG BLANK WATERTIGHT CAP SYSTEM 2 pcs GW 66 304 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67 S.F.2P+E  16A 230V 6H SBF 1 pcs GW 66 309 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67  S.F.3P+N+E 16A 400V 6H SBF 1 pcs GW 66 709 N FLANGED COVER, 2 CAPS IP67 1 pcs GW 68 715 A EMPTY PEDESTALS WITH SINGLE-SIDED TAKE-OFF QMC  125B LIGHT BLUE 1 pcs Code Description Qty Code Description Qty 86 CO M P LE M ENT AR Y  ARE A S List of products PB 22359 EN Cata prog Light 0316_EN.indd   86 15/04/16   11:51

GW 68 731 W PANEL 3 INTERLOCKED SWITCHED SOCKET-OUTLETS  VERT. IP55 BIA 1 pcs GW 68 741 A PANEL WITH ENCLOSURE AZ 1 pcs GW 68 765 TERMINAL BLOCK FOR QMC: CABLES UP TO 16SQ.MM 1 pcs GW 94 167 RCBO C.4P C16 6KA AC/0.03 4M 2 pcs GW 96 135 CONTROL SWITCH DISCONNECTOR 4P 40A 1 pcs 1.5  WAREHOUSE 1.5.1  Lighting GW S3 236 T SMART [3] - 1200mm - 39W 12 pcs 1.5.2  Control panel GW 40 045 DECORATIVE ENCLOSURE 12M IP40 1 pcs GW 90 090 COMPACT MCB 4P C32 4.5KA 2M 1 pcs GW 90 286 COMPACT MCB 4P C10 6KA 2M 1 pcs GW D4 122 RCCB 4P 40A AC/0.03 4M 1 pcs 1.5.3  Socket-outlet board GW 20 246 SOCKET-OUTLET 2P+E 16A DUAL AMP. ITALIAN/GERMAN  STD. SY/WT 8 pcs GW 27 403 2-GANG BLANK WATERTIGHT CAP SYSTEM 8 pcs GW 46 446 SET OF 4 GALVANISED STEEL BRACKETS FOR FIXING  SURFACE-MOUNTING BOARDS 4 pcs GW 66 304 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67 S.F.2P+E  16A 230V 6H SBF 4 pcs GW 66 320 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67  S.F.3P+N+E 32A 400V 6H SBF 4 pcs GW 66 709 N FLANGED COVER, 2 CAPS IP67 4 pcs GW 68 010 N Q-DIN 14M 3 FLANGES VERTICAL INTERLOCKED SOCKET- OUTLET SBF IP65 4 pcs GW 90 247 COMPACT MCB 2P C16 6KA 1M 12 pcs GW 90 290 COMPACT MCB 4P C32 6KA 2M 4 pcs GW D4 122 RCCB 4P 40A AC/0.03 4M 4 pcs 1.5.4  Routing and boxes DX 25 720 RKB20-3M HEAVY SOLID CONDUIT, GREY 150 m DX 40 220 RKT/20G T-JOINT FOR INSPECTIONS, GREY 25 pcs DX 43 220 MS 20 MORBIDX BOX-CONDUIT COUPLING 42 pcs DX 40 120 RKS/20G NARROW RADIUS ELBOW 6 pcs GW 44 204 BOX IP56 SMOOTH WALLS 100X100X50 3 pcs GW 44 209 BOX IP56 SMOOTH WALLS 300X220X120 4 pcs GW 50 602 SNAP-ON SUPPORT FOR CONDUIT D.20 GR.RAL7035 75 pcs 1.5.5  Commands GW 27 003 3-GANG HORIZ. WATERTIGHT CONTAINER 2 pcs GW 20 576 TWO-WAY SWITCH 1P 16AX SY/WT 2 pcs GW 20 056 BLANKING MODULE, 1 MODULE SY/WT 4 pcs GW 70 403 BOX ROTARY SWITCH ISO.4P 16A BLACK HANDLE 1 pcs 1.6  LOCAL LOCKER ROOM 1.6.1  Lighting GW S3 136 T SMART [3] - 1200mm - 20W 11 pcs GW S2 801 ASTRID 75 - 11.5W LED G2 350mA WHITE 6 pcs 1.6.2  Control panel GW 40 225 TB DECORATIVE ENCLOSURE 8M MILK WHITE 1 pcs GW 90 026 COMPACT MCB 1P+N C10 4.5KA 1M 1 pcs GW 90 027 COMPACT MCB 1P+N C16 4.5KA 1M 1 pcs GW 94 008 RCBO C.1P+N C20 4.5KA AC/0.03 2M 1 pcs 1.6.3  Routing and boxes DX 15 120 FK15/20F MEDIUM PLIABLE CONDUIT, BLACK, WITH PROBE 100 m GW 48 005 FLUSH-MOUNTING JUNCTION BOX 160X130X70 2 pcs 1.6.4  Commands GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 8 pcs GW 10 195 BLANKING MODULE 1M WHITE 16 pcs GW 10 001 ONE-WAY SWITCH 1M 1P 16AX WHITE 8 pcs GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 8 pcs 1.6.5  Socket-outlets GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 4 pcs GW 10 195 BLANKING MODULE 1M WHITE 4 pcs GW 10 204 SOCKET-OUTLET 2M 2P+E 16A DUAL AMP.P30-17 ITAL- IAN/GERMAN STD.B. 4 pcs GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 4 pcs 1.6.6  Temperature adjustment GW 16 103 TB ONE PLATE 3P MILK WHITE 1 pcs GW 16 803 SUPPORTS, ITALIAN STD. 3P 1 pcs GW 24403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 1 pcs GW 10 195 BLANKING MODULE 1M WHITE 1 pcs GW 10 703 FLUSH-MOUNTING TIMED THERMOSTAT 2M 230V AC, WHITE 1 pcs 1.7  GUEST LOCKER ROOM 1.7.1  Lighting GW S3 136 T SMART [3] - 1200mm - 20W 11 pcs GW S2 801 ASTRID 75 - 11.5W LED G2 350mA WHITE 6 pcs 1.7.2  Control panel GW 40 225 TB DECORATIVE ENCLOSURE 8M MILK WHITE 1 pcs GW 90 026 COMPACT MCB 1P+N C10 4.5KA 1M 1 pcs Code Description Qty Code Description Qty 87 PB 22359 EN Cata prog Light 0316_EN.indd   87 15/04/16   11:51

GW 90 027 COMPACT MCB 1P+N C16 4.5KA 1M 1 pcs GW 94 008 RCBO C.1P+N C20 4.5KA AC/0.03 2M 1 pcs 1.7.3  Routing and boxes DX 15 120 FK15/20F MEDIUM PLIABLE CONDUIT, BLACK, WITH PROBE 100 m GW 48 005 FLUSH-MOUNTING JUNCTION BOX 160X130X70 2 pcs 1.7.4  Commands GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 8 pcs GW 10 195 BLANKING MODULE 1M WHITE 16 pcs GW 10 001 ONE-WAY SWITCH 1M 1P 16AX WHITE 8 pcs GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 8 pcs 1.7.5  Socket-outlets GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 4 pcs GW 10 195 BLANKING MODULE 1M WHITE 4 pcs GW 10 204 SOCKET-OUTLET 2M 2P+E 16A DUAL AMP.P30-17 ITALIAN/ GERMAN STD.B. 4 pcs GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 4 pcs 1.7.6  Temperature adjustment GW 16 103 TB ONE PLATE 3P MILK WHITE 1 pcs GW 16 803 SUPPORTS, ITALIAN STD. 3P 1 pcs GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 1 pcs GW 10 195 BLANKING MODULE 1M WHITE 1 pcs GW 10 703 FLUSH-MOUNTING TIMED THERMOSTAT 2M 230V AC, WHITE 1 pcs 1.8  TECHNICAL ROOM 1.8.1  Lighting GW S3 136 T SMART [3] - 1200mm - 20W 4 pcs 1.8.2  Control panel GW 44 698 4-POLE TERMINAL BLOCK 8 MOD. EN 50022 1 pcs GW 45 057 CVX630M - STRUCTURE 600X1600 1 pcs GW 45 077 CVX630M - PAIR OF SIDE PANELS H1600 1 pcs GW 45 157 CVX630M - GLASS DOOR IP55 600X1600 1 pcs GW 45 202 CVX630K - DIN PANEL KIT 600X200 7 pcs GW 45 304 CVX630K - SOLID PANEL 600X200 1 pcs GW 45 412 CVX630K - PROFILE G32 B600 1 pcs GW 45 526 CVX630K - 2 HORIZ. TERMINAL BLOCK SUPPORTS 45° 1 pcs GW 47 491 CVX630 - BRACKETS FOR SURFACE-MOUNTING 1 pcs GW 72 104 CYLINDRICAL FUSE TYPE GG 10.3X38 500V 2A 6 pcs GW 90 026 COMPACT MCB 1P+N C10 4.5KA 1M 1 pcs GW 90 028 COMPACT MCB 1P+N C20 4.5KA 1M 5 pcs GW 92 046 MINIATURE CIRCUIT BREAKER 2P C10 6KA 2M 1 pcs GW 92 086 MINIATURE CIRCUIT BREAKER 4P C10 6KA 4M 5 pcs GW 92 087 MINIATURE CIRCUIT BREAKER 4P C16 6KA 4M 2 pcs GW 92 088 MINIATURE CIRCUIT BREAKER 4P C20 6KA 4M 1 pcs GW 92 089 MINIATURE CIRCUIT BREAKER 4P C25 6KA 4M 2 pcs GW 92 090 MINIATURE CIRCUIT BREAKER 4P C32 6KA 4M 4 pcs GW 92 091 MINIATURE CIRCUIT BREAKER 4P C40 6KA 4M 3 pcs GW 92 093 MINIATURE CIRCUIT BREAKER 4P C63 6KA 4M 1 pcs GW 94 422 RESIDUAL CURRENT DEVICE 4P IN 25A INSTANT.AC/0.03 3.5M 6 pcs GW 94 423 RESIDUAL CURRENT DEVICE 4P IN 25A INSTANT.AC/0.3 3.5M 1 pcs GW 94 432 RESIDUAL CURRENT DEVICE 4P IN 63A INSTANT.AC/0.03 3.5M 3 pcs GW 94 433 RESIDUAL CURRENT DEVICE 4P IN 63A INSTANT.AC/0.3 3.5M 1 pcs GW 96 312 DISCONNECTABLE FUSE HOLDER 3P+N 10.3X38 690V 32A 2 pcs GW 96 446 CURRENT TRANSFORMER 100A 3 pcs GW 96 581 SINGLE RED INDICATOR LAMP 230V 1M 3 pcs GW 96 897 VOLTAGE/CURRENT MULTIMETER 1 pcs GW D4 124 RCCB 4P 40A AC/0.3 4M 1 pcs 1.8.3  Socket-outlet board GW 20 246 SOCKET-OUTLET 2P+E 16A DUAL AMP. ITALIAN/GERMAN  STD. SY/WT 2 pcs GW 27 403 2-GANG BLANK WATERTIGHT CAP SYSTEM 2 pcs GW 46 446 SET OF 4 GALVANISED STEEL BRACKETS FOR FIXING  SURFACE-MOUNTING BOARDS 1 pcs GW 66 304 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67 S.F.2P+E 16A  230V 6H SBF 1 pcs GW 66 320 N INTERLOCKED SWITCHED SOCKET-OUTLET IP67 S.F.3P+N+E  32A 400V 6H SBF 1 pcs GW 66 709 N FLANGED COVER, 2 CAPS IP67 1 pcs GW 68 010 N Q-DIN 14M 3 FLANGES VERTICAL INTERLOCKED SOCKET- OUTLET SBF IP65 1 pcs GW 90 247 COMPACT MCB 2P C16 6KA 1M 3 pcs GW 90 290 COMPACT MCB 4P C32 6KA 2M 1 pcs GW D4 122 RCCB 4P 40A AC/0.03 4M 1 pcs 1.8.4  Routing and boxes DX 25 720 RKB20-3M HEAVY SOLID CONDUIT, GREY 15 m DX 40 220 RKT/20G T-JOINT FOR INSPECTIONS, GREY 2 pcs DX 43 220 MS 20 MORBIDX BOX-CONDUIT COUPLING 4 pcs DX 40 120 RKS/20G NARROW RADIUS ELBOW 1 pcs GW 44 206 BOX IP56 SMOOTH WALLS 150X110X70 2 pcs GW 50 602 SNAP-ON SUPPORT FOR CONDUIT D.20 GR.RAL7035 8 pcs 1.8.5  LAN board GW 38 431 SOHO LAN BOARD 10'' 400x350x265 8U 1 pcs GW 38 441 SOHO PANEL 10'' SUPPLY SOCKET-OUTLETS 1 pcs GW 38 437 UNWIRED PANEL FOR 8 CONNECTORS 2 pcs GW 38 012 RJ45 SOCKET CAT.5e UTP TOOL LESS 16 pcs GW 38 189 CABLE LSZH CAT.5E UTP 24 AWG 50 m GW 38 439 SOHO BRACKET 10'' MINI HUB 1 pcs GW 38 440 SOHO PANEL 10'' CABLE GLANDS 1 pcs GW 38 117 CORD RJ45-RJ45 CAT.5E UTP 1M WHITE 16 pcs 1.8.6  Commands GW 27 003 3-GANG HORIZ. WATERTIGHT CONTAINER 1 pcs GW 20 056 BLANKING MODULE, 1 MODULE SY/WT 2 pcs GW 20 571 ONE-WAY SWITCH 1P 16AX SY/WT 1 pcs GW 70 403 BOX ROTARY SWITCH ISO.4P 16A BLACK HANDLE 2 pcs 1.9  OFFICE 1.9.1  Lighting GW S2 506 ASTRID 60X60 DIFFUSED OPTIC 36W LED 4000K WHITE 4 pcs 1.9.2  Control panel GW 40 225 TB DECORATIVE ENCLOSURE 8M MILK WHITE 1 pcs GW 90 026 COMPACT MCB 1P+N C10 4.5KA 1M 1 pcs Code Description Qty Code Description Qty 88 Metric calculation PB 22359 EN Cata prog Light 0316_EN.indd   88 15/04/16   11:51

GW 90 027 COMPACT MCB 1P+N C16 4.5KA 1M 1 pcs GW 94 328 P ONE-WAY SWITCH MDC+RESTART RMPRO 2P20A 6 0.03-A-4M 1 pcs 1.9.3  Routing and boxes DX 15 120 FK15/20F MEDIUM PLIABLE CONDUIT, BLACK, WITH PROBE 60 m GW 48 005 FLUSH-MOUNTING JUNCTION BOX 160X130X70 1 pcs 1.9.4  Commands GW 16 103 TB ONE PLATE 3P MILK WHITE 1 pcs GW 16 803 SUPPORTS, ITALIAN STD. 3P 1 pcs GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 1 pcs GW 10 195 BLANKING MODULE 1M WHITE 2 pcs GW 10 001 ONE-WAY SWITCH 1M 1P 16AX WHITE 1 pcs 1.9.5  Socket-outlets GW 16 103 TB ONE PLATE 3P MILK WHITE 3 pcs GW 16 803 SUPPORTS, ITALIAN STD. 3P 3 pcs GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 3 pcs GW 10 203 SOCKET-OUTLET 1M 2P+E 16A DUAL AMP.P17-11 ITALIAN STD. WHITE 3 pcs GW 10 204 SOCKET-OUTLET 2M 2P+E 16A DUAL AMP.P30-17 ITAL- IAN/GERMAN STD.B. 3 pcs 1.9.6  Underfloor outlet box GW 24 611 UNDERFLOOR OUTLET BOX 10P STAINLESS STEEL COVER 1 pcs GW 20 271 DATA CONNECTOR RJ45 CAT.5e UTP SY/WT 3 pcs GW 20 251 TELEPHONE CONNECTOR RJ11 SY/WT 2 pcs GW 20 246 SOCKET-OUTLET 2P+E 16A DUAL AMP. ITALIAN/GERMAN STD.  SY/WT 2 pcs GW 20 203 SOCKET-OUTLET 2P+E 16A 230V ITALIAN/GERMAN 1 pcs 1.9.7  Temperature adjustment GW 16 103 TB ONE PLATE 3P MILK WHITE 1 pcs GW 16 803 SUPPORTS, ITALIAN STD. 3P 1 pcs GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 1 pcs GW 10 195 BLANKING MODULE 1M WHITE 1 pcs GW 10 703 FLUSH-MOUNTING TIMED THERMOSTAT 2M 230V AC, WHITE 1 pcs 1.10  REFEREE LOCKER ROOM 1.10.1  Lighting GW S3 136 T SMART [3] - 1200mm - 20W 2 pcs GW S2801 ASTRID 75 - 11.5W LED G2 350mA WHITE 1 pcs 1.10.2  Control panel GW 40 225 TB DECORATIVE ENCLOSURE 8M MILK WHITE 1 pcs GW 90 026 COMPACT MCB 1P+N C10 4.5KA 1M 1 pcs GW 90 027 COMPACT MCB 1P+N C16 4.5KA 1M 1 pcs GW 94 008 RCBO C.1P+N C20 4.5KA AC/0.03 2M 1 pcs 1.10.3  Routing and boxes DX 15 120 FK15/20F MEDIUM PLIABLE CONDUIT, BLACK, WITH  PROBE 60 m GW 48 005 FLUSH-MOUNTING JUNCTION BOX 160X130X70 1 pcs 1.10.4  Commands GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 2 pcs GW 10 195 BLANKING MODULE 1M WHITE 4 pcs GW 10 001 ONE-WAY SWITCH 1M 1P 16AX WHITE 2 pcs GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 2 pcs 1.10.5  Socket-outlets GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 3 pcs GW 10 195 BLANKING MODULE 1M WHITE 3 pcs GW 10 204 SOCKET-OUTLET 2M 2P+E 16A DUAL AMP.P30-17 ITAL- IAN/GERMAN STD.B. 3 pcs GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 3 pcs 1.10.6  Temperature adjustment GW 16 103 TB ONE PLATE 3P MILK WHITE 1 pcs GW 16 803 SUPPORTS, ITALIAN STD. 3P 1 pcs GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 1 pcs GW 10 195 BLANKING MODULE 1M WHITE 1 pcs GW 10 703 FLUSH-MOUNTING TIMED THERMOSTAT 2M 230V AC,  WHITE 1 pcs 1.11  REFEREE LOCKER ROOM 1.11.1  Lighting GW S3 136 T SMART [3] - 1200mm - 20W 2 pcs GW S2 801 ASTRID 75 - 11.5W LED G2 350mA WHITE 1 pcs 1.11.2  Control panel GW 40 225 TB DECORATIVE ENCLOSURE 8M MILK WHITE 1 pcs GW 90 026 COMPACT MCB 1P+N C10 4.5KA 1M 1 pcs GW 90 027 COMPACT MCB 1P+N C16 4.5KA 1M 1 pcs GW 94 008 RCBO C.1P+N C20 4.5KA AC/0.03 2M 1 pcs 1.11.3  Routing and boxes DX 15 120 FK15/20F MEDIUM PLIABLE CONDUIT, BLACK, WITH  PROBE 60 m GW 48 005 FLUSH-MOUNTING JUNCTION BOX 160X130X70 1 pcs 1.11.4  Commands GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 2 pcs GW 10 195 BLANKING MODULE 1M WHITE 4 pcs GW 10 001 ONE-WAY SWITCH 1M 1P 16AX WHITE 2 pcs GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 2 pcs 1.11.5  Socket-outlets GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 3 pcs GW 10 195 BLANKING MODULE 1M WHITE 3 pcs GW 10 204 SOCKET-OUTLET 2M 2P+E 16A DUAL AMP.P30-17 ITAL- IAN/GERMAN STD.B. 3 pcs GW 16 703 TB WATERTIGHT PLATE 3P IP55 WHITE 3 pcs 1.11.6  Temperature adjustment GW 16 103 TB ONE PLATE 3P MILK WHITE 1 pcs GW 16 803 SUPPORTS, ITALIAN STD. 3P 1 pcs GW 24 403 BIGBOX 3-GANG BOX FOR MASONRY WALLS 1 pcs GW 10 195 BLANKING MODULE 1M WHITE 1 pcs GW 10 703 FLUSH-MOUNTING TIMED THERMOSTAT 2M 230V AC, WHITE 1 pcs Code Description Qty Code Description Qty 89 PB 22359 EN Cata prog Light 0316_EN.indd   89 15/04/16   11:51
