ESP catalogue - ESP - 2017

The ESP CCTV range offers the installer a practical range of security and observation solutions reflecting the best features of established and emerging CCTV technology.The range includes cameras with true HD 720P resolution using the latest Sony AHD image processor to deliver superior image quality.

F I R E A N D S E C U R I T Y P R O D U C T S 2 0 1 7 w w w . e s p u k . c o m

720p Bullet Cameras . . . . . . . . . . . . . . . . . . . . . 6720p Dome Cameras . . . . . . . . . . . . . . . . . . . . . 8Pan, Tilt and Zoom Cameras . . . . . . . . . . . . . . 10CCTV Recording . . . . . . . . . . . . . . . . . . . . . . . . . 12CCTV Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16LED CCTV Monitors . . . . . . . . . . . . . . . . . . . . . 18CCTV Combination Unit . . . . . . . . . . . . . . . . . . 20CCTV Accessories . . . . . . . . . . . . . . . . . . . . . . . 21 For more than 20 years ESP has been developing and supplying security related products to the UK electrical industry. As a leading safety and security product specialist, the company offers a comprehensive range of electronic security and fire detection solutions to meet the requirements of installers and contractors. GuardCam WF-M . . . . . . . . . . . . . . . . . . . . . . . 26GuardCam WF-SA . . . . . . . . . . . . . . . . . . . . . . 26GuardCam WF-T . . . . . . . . . . . . . . . . . . . . . . . . 27GuardCam LED . . . . . . . . . . . . . . . . . . . . . . . . . 27CanCam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28CanCam VR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28NightHawk LED . . . . . . . . . . . . . . . . . . . . . . . . 29NH150LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 C C T V External Area Protection 2

Aperta Single Way Video Door Entry . . . . . . . 32Aperta Multi Way Video Door Entry . . . . . . . 35Aperta Audio Door Entry Systems . . . . . . . . . 39Access Control Accessories . . . . . . . . . . . . . . 40 MAGfire Addressable Fire Panels . . . . . . . . . . . . . . 44MAGfire Addressable Detectors . . . . . . . . . . . . . . . 47MAGfire Addressable Accessories . . . . . . . . . . . . . 48MAGfire Addressable Modules . . . . . . . . . . . . . . . . 50MAGfire Conventional Fire Alarm Kits . . . . . . . . . . 51MAGfire Conventional Fire Alarm Panels . . . . . . . . 52MAGfire Conventional 24v Fire Alarm Detectors. . 55MAGfire Conventional 12v Fire Alarm Detectors . . 56MAGfire Conventional Fire Accessories . . . . . . . . . 57 Emergency Bulkheads . . . . . . . . . . . . . . . . . . . 64Emergency Box Sign . . . . . . . . . . . . . . . . . . . . 65Emergency Flush . . . . . . . . . . . . . . . . . . . . . . . 66Emergency Exit Sign . . . . . . . . . . . . . . . . . . . . 66Emergency Twin Spot . . . . . . . . . . . . . . . . . . . 67Emergency Downlight Kit . . . . . . . . . . . . . . . . 67 Access Control Fire Protection Emergency Lighting 3 ESP Fire and Security Products • www.espuk.com

4 C C T V 4 C C T V

5 10 meters 20 meters 30 meters 50 meters 9-22mm Lens 3 meters 10 meters 15 meters 5-50mm Lens 5-50mm Lens N/A 2.8-12mm Lens 9-22mm Lens 9-22mm Lens 5-50mm Lens 2.8-12mm Lens 4-9mm Lens 9-22mm Lens 9-22mm Lens Viewing Capability Distance from Camera C A M E R A S E L E C T I O N G U I D E To select the correct camera consider if the location is internal or external (bear in mind that external cameras are also suitable for internal use). Decide which lens size will achieve the desired image from the guide below. The ESP CCTV range offers the installer a practical range of security and observation solutions reflecting the best features of established and emerging CCTV technology. The range includes cameras with true HD 720P resolution using the latest Sony AHD image processor to deliver superior image quality.

5 to 50mm Varifocal Lens True High Definition 1.3MP Sony AHD sensor Built in 50m Infrared LED Illumination D-WDR incorporating ATR 2D and 3D Noise Reduction Exposure Control High Light Compensation 3-Axis Cable Management Bracket IP66 Weatherproof Bullet Housing H D V C 5 5 0 V F B 5 - 5 0 m m L E N S T R U E H D C A M E R A Pick up Element 1/3” SONY CMOS Effective Pixels NTSC/ PAL:1280(H) x 720(V) Horizontal Resolution 720PMinimum Illumination 0.1 Lux/F1.6 0 Lux (with IR LED ON) Scanning System Progressive Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s IR Distance 50 Meters Video Output 1Vpp, 75Ω Auto Gain Control Auto Power/Current DC12V(+/-10%)/560mA Lens 5-50mm Manual Zoom Lens Dimension 260(L) x 136(H) x 115(D)mm Weight 1200g Storage Temperature -30 ~ +60ºC RH95% Max Operating Temperature -10 ~ +50ºC RH95% Max 6 Day and Night InfraRed Illumination OSD Control Button Varifocal Lens Weatherproof H D V C 6 2 2 V F B 6 - 2 2 m m L E N S T R U E H D C A M E R A 7 2 0 P B U L L E T C A M E R A S 6 to 22mm Varifocal Lens True High Definition 1.3MP Sony AHD sensor Built in 50m Infrared LED Illumination D-WDR incorporating ATR 2D and 3D Noise Reduction Exposure Control High Light Compensation 3-Axis Cable Management Bracket IP66 Weatherproof Bullet Housing Pick up Element 1/3” SONY CMOS Effective Pixels (H×V) NTSC/ PAL:1280(H)x720(V) Horizontal Resolution 720PMinimum Illumination 0.1 Lux/F1.6 0 Lux (with IR LED ON) Scanning System Progressive Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s IR Distance 50 Meters Video Output 1Vpp, 75Ω Auto Gain Control Auto Power/Current DC12V(+/-10%)/560mA Lens 6-22mm Manual Zoom Lens Dimension 260(L) x 136(H) x 115(D)mm Weight 1200g Storage Temperature -30 ~ +60ºC RH95% Max Operating Temperature -10 ~ +50ºC RH95% Max Day and Night InfraRed Illumination OSD Control Button Varifocal Lens Weatherproof

7 H D V C 2 8 1 2 V F B 2 . 8 - 1 2 m m L E N S T R U E H D C A M E R A H D V C 3 6 F B 3 . 6 m m L E N S T R U E H D C A M E R A 2.8 to 12mm Varifocal Lens True High Definition 1.3MP Sony AHD sensor Built in 35m Infrared LED Illumination D-WDR incorporating ATR 2D and 3D Noise Reduction Exposure Control High Light Compensation 3-Axis Cable Management Bracket IP66 Weatherproof Bullet Housing Pick up Element 1/3” SONY CMOS Effective Pixels NTSC/ PAL:1280(H) x 720(V) Horizontal Resolution 720PMinimum Illumination 0.1 Lux/F1.4 0 Lux (with IR LED ON) Scanning System Progressive Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s IR Distance 35 Meters Video Output 1Vpp, 75Ω Auto Gain Control Auto Power/Current DC12V(+/-10%)/360mA Lens 2.8-12mm Manual Zoom Dimension 267(W) x 85(H) x 95(D)mm Weight 1000g Storage Temperature -30 ~ +60ºC RH95% Max Operating Temperature -10 ~ +50ºC RH95% Max Day and Night InfraRed Illumination OSD Control Button Varifocal Lens Weatherproof 3.6mm Fixed Lens True High Definition 1.3MP Sony AHD sensor Built in 20m Infrared LED Illumination D-WDR incorporating ATR 2D and 3D Noise Reduction Exposure Control High Light Compensation 3-Axis Cable Management IP66 Weatherproof Bullet Housing Pick up Element 1/3” SONY CMOS Effective Pixels NTSC/ PAL:1280(H) x 720(V) Horizontal Resolution 720PMinimum Illumination 0.1 Lux/F2.00 0 Lux (with IR LED ON) Scanning System Progressive Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s IR Distance 20 Meters Video Output 1Vpp, 75Ω Auto Gain Control Auto Power/Current DC12V(+/-10%)/240mA Lens 3.6mm Fixed Lens Dimension 153(W) x 70(H) x 57(D)mm Weight 350g Storage Temperature -30 ~ +60ºC RH95% Max Operating Temperature -10 ~ +50ºC RH95% Max Day and Night InfraRed Illumination OSD Control Button Fixed Lens Weatherproof

Vandal resistant 6 to 22mm Varifocal Lens True High Definition 1.3MP Sony AHD sensor 25m Infrared LED Illumination D-WDR incorporating ATR 2D and 3D Noise Reduction Exposure Control High Light Compensation 3-Axis Cable Management Bracket IP66 Weatherproof Dome Housing WB622VFD Wall Mounting Bracket available - see page 22 H D V C 6 2 2 V F D 6 - 2 2 m m L E N S T R U E H D C A M E R A 8 H D V C 2 8 1 2 V F D 2 . 8 - 1 2 m m L E N S T R U E H D C A M E R A 7 2 0 P D O M E C A M E R A S 360º Rotation InfraRed Illumination OSD Control Button Varifocal Lens Weatherproof Pick up Element 1/3” SONY CMOS Effective Pixels NTSC/ PAL:1280(H) x 720(V) Horizontal Resolution 720PMinimum Illumination 0.1 Lux/F1.6 0 Lux (with IR LED ON) Scanning System Progressive Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s IR Distance 25 Meters Video Output 1Vpp, 75Ω Auto Gain Control Auto Power/Current DC12V(+/-10%)/280mA Lens 6-22mm Manual Zoom Lens Dimension 148 x 122(H) mm Weight 900g Storage Temperature -30 ~ +60ºC RH95% Max Operating Temperature -10 ~ +50ºC RH95% Max 2.8 to 12mm Varifocal Lens True High Definition 1.3MP Sony AHD sensor 25m Infrared LED Illumination D-WDR incorporating ATR 2D and 3D Noise Reduction Exposure Control High Light Compensation IP66 Weatherproof Dome Housing DB2812VFD Deep base available - see page 22 360º Rotation InfraRed Illumination OSD Control Button Varifocal Lens Weatherproof Pick up Element 1/3” SONY CMOS Effective Pixels NTSC/ PAL:1280(H) x 720(V) Horizontal Resolution 720PMinimum Illumination 0.1 Lux/F1.4 0 Lux (with IR LED ON) Scanning System Progressive Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s IR Distance 25 Meters Video Output 1Vpp, 75Ω Auto Gain Control Auto Power/Current DC12V(+/-10%)/320mA Lens 2.8-12mm Manual Zoom Dimension 120 x 90(H) mm Weight 800g Storage Temperature -30 ~ +60ºC RH95% Max Operating Temperature -10 ~ +50ºC RH95% Max

9 H D V C 3 6 F D L 3 . 6 m m L E N S T R U E H D C A M E R A 3.6mm Fixed Lens True High Definition 1.3MP Sony AHD sensor Built in 20m Infrared LED Illumination D-WDR incorporating ATR 2D and 3D Noise Reduction Exposure Control High Light Compensation IP66 Weatherproof Dome Housing 360º Rotation InfraRed Illumination OSD Control Button Fixed Lens Weatherproof Pick up Element 1/3” SONY CMOS Effective Pixels NTSC/ PAL:1280(H) x 720(V) Horizontal Resolution 720PMinimum Illumination 0.1 Lux/F2.0 0 Lux (with IR LED ON) Scanning System Progressive Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s IR Distance 20 Meters Video Output 1Vpp, 75Ω Auto Gain Control Auto Power/Current DC12V(+/-10%)/240mA Lens 3.6mm Fixed Lens Dimension 93x 65(H)mm Weight 360g Storage Temperature -30 ~ +60ºC RH95% Max Operating Temperature -10 ~ +50ºC RH95% Max HDVC36FD Grey | HDVC36FDW White3 . 6 m m L E N S T R U E H D C A M E R A 3.6mm Fixed Lens True High Definition 1.3MP Sony AHD sensor Built in 10m Infrared LED Illumination D-WDR incorporating ATR 2D and 3D Noise Reduction Exposure Control High Light Compensation IP66 Weatherproof Dome Housing 360º Rotation InfraRed Illumination OSD Control Button Fixed Lens Weatherproof Pick up Element 1/3” SONY CMOS Effective Pixels NTSC/ PAL:1280(H) x 720(V) Horizontal Resolution 720PMinimum Illumination 0.1 Lux/F2.0 0 Lux (with IR LED ON) Scanning System Progressive Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s IR Distance 10 Meters Video Output 1Vpp, 75Ω Auto Gain Control Auto Power/Current DC12V(+/-10%)/130mA Lens 3.6mm Fixed Lens Dimension 60 x 56(H) mm Weight 250g Storage Temperature -30 ~ +60ºC RH95% Max Operating Temperature -10 ~ +50ºC RH95% Max

True High Definition 1.3MP AHD sensor 4.7-84.6mm varifocal lens Full pan, tilt and zoom operation Full 360° rotation pan function 18 x optical zoom Up to 50m IR night illumination Complete with 2 amp power supply IP66 weatherproof rating H D V C 1 8 P T Z E X T E R N A L T R U E H D P T Z C A M E R A Rated Voltage 1 2V DC Max current 1 .25A IR effective distance 50MProtection IP66Pan rotation 360° Endless rotation Speed Pan 0.6-200°/s Tilt 3.5-30°/s Working conditions -10°C - +50°CDimensions 150(W) x 235(H) x 205(D)mm Day and Night InfraRed Illumination Varifocal Lens 360º Rotation Pan and Tilt For use with PTZ cameras Keyboard for programming and camera control Integrated LCD display 3D joystick for control of camera pan, tilt and zoom functions P T Z C O N P A N , T I L T & Z O O M C O N T R O L L E R Protocol Pelco-P, Pelco-D, Panasonic, HikVision, Samsung, RULE, Dahua, SAE Baud rate (bps) 1200, 2400, 4800, 9600, 19200 Max camera support 255 Controllers supported 16 in total (15 auxiliary)Power supply DC 12V±10% Power consumption 6W MAX Working temperature 0°C-50°C Dimension 420 x 260 x 170mm 10 7 2 0 P P A N , T I L T & Z O O M C A M E R A

650TVL Sony Effio-E CCD camera 5-50mm varifocal lens Full pan, tilt and zoom operation Full 360° rotation pan function 10 x optical zoom Up to 40m IR night illumination Complete with 2 amp power supply Ceiling mounting P T Z 1 0 I N T C I N T E R N A L P T Z C E I L I N G M O U N T C A M E R AP T Z 1 0 I N T W I N T E R N A L P T Z W A L L M O U N T C A M E R A Rated Voltage 12V DC Max current 1.25A IR effective distance 40M Pan rotation 360° Endless rotation Speed Pan 0.6-200°/s Tilt 3.5-30°/s Working conditions -10°C - +50°C PTZ10INTC Dimensions Ø 142 x 135(H) mm PTZ10INTW Dimensions 127.5(W) x 205(H) x 194(D) mm Day and Night InfraRed Illumination Varifocal Lens 360º Rotation Pan and Tilt 11 P A N , T I L T & Z O O M C A M E R A S 650TVL Sony Effio-E CCD camera 5-50mm varifocal lens Full pan, tilt and zoom operation Full 360° rotation pan function 10 x optical zoom Up to 50m IR night illumination Complete with 2 amp power supply IP66 weatherproof rating P T Z 1 0 E X T E X T E R N A L PTZ C A M E R A Rated Voltage 1 2V DC Max current 1 .25A IR effective distance 50MProtection IP66Pan rotation 360° Endless rotation Speed Pan 0.6-200°/s Tilt 3.5-30°/s Working conditions -10°C - +50°CDimensions 150(W) x 235(H) x 205(D)mm Day and Night InfraRed Illumination Varifocal Lens 360º Rotation Pan and Tilt

H D V 1 6 R X P R O 1 6 C H A N N E L T R U E H D D V R Integral digital hard drive – 4TB, 8TB, 12TB or 16TB Networkable for remote viewing from PC or Smartphone Realtime 720P HD recording and playback HDMI and VGA outputs (HDMI cable included) USB memory stick backup Mouse driven menu (USB mouse included) WIFI connection to network - requires DVRWLA ordered separately 12 C C T V R E C O R D I N G XMeye App S Y S T E M Main Processor Embedded Processor Operating System Embedded LINUX V I D E O & A U D I O Video input 16 channel BNC Audio input 16 channel RCA Audio output 1 channel RCA D I S P L A Y Video output 1 x HDMI, 1 x VGA Display Split 1, 4, 9 and 16 Resolution 1024×768, 1280×720, 1280×1024, 1440×900, 1920×1080 R E C O R D I N G Video/Audio Compression H.264 Mainprofile/G.711AResolution 1280x720PRecord Rate (Main stream) 16ch 720P Realtime Recording mode Manual/Alarm/Motion Detection/Schedule P L A Y B A C K & B A C K U P Sync Playback 8ch 720P Realtime Backup Mode Network/USB2.0 devices N E T W O R K Ethernet RJ45 10M/100M/1000M Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP Network Monitoring Web browsers, CMS, Android & iPhone apps S T O R A G E Internal HDD 4 SATA HDD, up to 4TB per HDD A U X I L I A R Y I N T E R F A C E Alarm input 16 channel Alarm output 4 channel PTZ control RS485 with multi-protocol USB interface 2 G E N E R A L Power Supply DC12V/6A Power Consumption 10W (without hard disk) Operation Condition 0ºC – +55ºC / 10% – 90% Dimensions 430(W) x 350(D) x 70(H) mm

13 H D V 1 6 R 1 6 C H A N N E L T R U E H D D V R Integral digital hard drive – 2TB, 4TB or 8TB Networkable for remote viewing from PC or Smartphone Realtime 720P HD recording and playback HDMI and VGA outputs (HDMI cable included) USB memory stick backup Mouse driven menu (USB mouse included) WIFI connection to network - requires DVRWLA ordered separately XMeye App S Y S T E M Main Processor Embedded Processor Operating System Embedded LINUX V I D E O & A U D I O Video input 16 channel BNC Audio input 6 channel RCA Audio output 1 channel RCA D I S P L A Y Video output 1 x HDMI, 1 x VGA Display Split 1, 4, 9 and 16 Resolution 1024×768, 1280×720, 1280×1024, 1440×900, 1920×1080 R E C O R D I N G Video/Audio Compression H.264 Mainprofile/G.711AResolution 1280x720PRecord Rate (Main stream) 16ch Realtime 720P recordingRecording mode Manual/Alarm/Motion Detection/Schedule P L A Y B A C K & B A C K U P Sync Playback 1ch Realtime 720P + 3ch 12FPS 720P Backup Mode Network/USB2.0 devices N E T W O R K Ethernet RJ45 10M/100M/1000M Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP Network Monitoring Web browsers, CMS, Android & iPhone apps S T O R A G E Internal HDD 2 SATA HDD, up to 4TB per HDD A U X I L I A R Y I N T E R F A C E Alarm input 4 channel Alarm output 1 channel PTZ control RS485 with multi-protocol USB interface 2 G E N E R A L Power Supply DC12V/4A Power Consumption 10W (without hard disk) Operation Condition 0ºC – +55ºC / 10% – 90% Dimensions 326(W) x 243(D) x 52(H) mm

14 C C T V R E C O R D I N G H D V 8 R X P R O 8 C H A N N E L T R U E H D D V R Integral digital hard drive – 2TB, 4TB or 8TB Networkable for remote viewing from PC or Smartphone Realtime 720P HD recording and playback HDMI and VGA outputs (HDMI cable included) USB memory stick backup Mouse driven menu (USB mouse included) WIFI connection to network - requires DVRWLA ordered separately S Y S T E M Main Processor Embedded Processor Operating System Embedded LINUX V I D E O & A U D I O Video input 8 channel BNC Audio input 6 channel RCA Audio output 1 channel RCA D I S P L A Y Video output 1 x HDMI, 1 x VGA Display Split 1, 4 and 9 Resolution 1024×768, 1280×720, 1280×1024, 1440×900, 1920×1080 R E C O R D I N G Video/Audio Compression H.264 Mainprofile/G.711AResolution 1280x720PRecord Rate (Main stream) 8ch Realtime 720P recordingRecording mode Manual/Alarm/Motion Detection/Schedule P L A Y B A C K & B A C K U P Sync Playback 8ch Realtime 720P playback Backup Mode Network/USB2.0 devices N E T W O R K Ethernet RJ45 10M/100M Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP Network Monitoring Web browsers, CMS, Android & iPhone apps S T O R A G E Internal HDD 2 SATA HDD, up to 4TB per HDD A U X I L I A R Y I N T E R F A C E Alarm input 4 channel Alarm output 1 channel PTZ control RS485 with multi-protocol USB interface 2 G E N E R A L Power Supply DC12V/4A Power Consumption 10W (without hard disk) Operation Condition 0ºC – +55ºC / 10% – 90% Dimensions 326(W) x 243(D) x 52(H) mm XMeye App

15 H D V 8 R 8 C H A N N E L T R U E H D D V RH D V 4 R 4 C H A N N E L T R U E H D D V R Hard drive options: HDV4R – 1TB, 2TB or 4TB HDV8R – 1TB, 2TB or 4TB Networkable for remote viewing from PC or Smartphone Realtime 720P HD recording and playback HDMI and VGA outputs (HDMI cable included) USB memory stick backup Mouse driven menu (USB mouse included) WIFI connection to network - requires DVRWLA ordered separately S Y S T E M Main Processor Embedded Processor Operating System Embedded LINUX V I D E O & A U D I O Video input HDV4R - 4 channel BNC HDV8R - 8 channel BNC Audio input HDV4R - 4 channel RCA HDV8R - 2 channel RCA Audio output 1 channel RCA D I S P L A Y Video output 1 x HDMI, 1 x VGA Display Split HDV4R - 1 and 4 HDV8R - 1, 4 and 9 Resolution 1024×768, 1280×720, 1280×1024, 1440×900, 1920×1080 R E C O R D I N G Video/Audio Compression H.264 Mainprofile/G.711AResolution 1280x720PRecord Rate (Main stream) HDV4R - 4ch Realtime 720P recording HDV8R - 8ch Realtime 720P recording Recording mode Manual/Alarm/Motion Detection/Schedule P L A Y B A C K & B A C K U P Sync Playback HDV4R - 4ch Realtime 720P playback HDV8R - 8ch Realtime 720P playback Backup Mode Network/USB2.0 devices N E T W O R K Ethernet RJ45 10M/100M Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP Network Monitoring Web browsers, CMS, Android & iPhone apps S T O R A G E Internal HDD 1 SATA HDD, up to 4TB per HDD A U X I L I A R Y I N T E R F A C E Alarm input NO Alarm output NO PTZ control RS485 with multi-protocol USB interface 2 G E N E R A L Power Supply DC12V/2A Power Consumption 10W (without hard disk) Operation Condition 0ºC – +55ºC / 10% – 90% Dimensions 250(W) x 210(D) x 45(H) mm XMeye App

16 C C T V K I T S 4 x 1.3MP HD day/night dome cameras - see HDVC36FD page 9 Hard drive options: HDV4KD – 1TB, 2TB or 4TB HDV8KD – 1TB, 2TB or 4TB Remote monitoring via wired or Wi-Fi connection - requires DVRWLA ordered separately Mobile monitoring with Android or iPhone APP Triplex operation – Playback / Record / Remote view simultaneously VGA or HDMI output (HDMI lead supplied) Four recording options – Continuous / Scheduled / Motion USB back up of recordings for easy evidence transfer Mouse driven comprehensive user interface Silent fanless operation HDV4KD 4 CHANNEL TRUE HD CCTV SYSTEMHDV8KD 8 CHANNEL TRUE HD CCTV SYSTEM XMeye App S Y S T E M Main Processor Embedded Processor Operating System Embedded LINUX V I D E O & A U D I O Video input HDV4KD - 4 channel BNC HDV8KD - 8 channel BNC Audio input HDV4KD - 4 channel RCA HDV8KD - 2 channel RCA Audio output 1 channel RCA D I S P L A Y Video output 1 x HDMI, 1 x VGA Display Split HDV4KD - 1 and 4 HDV8KD - 1, 4 and 9 Resolution 1024×768, 1280×720, 1280×1024, 1440×900, 1920×1080 R E C O R D I N G Video/Audio Compression H.264 Mainprofile/G.711AResolution 1280x720PRecord Rate (Main stream) HDV4KD - 4ch Realtime 720P recording HDV8KD - 8ch Realtime 720P recording Recording mode Manual/Alarm/Motion Detection/ Schedule P L A Y B A C K & B A C K U P Sync Playback HDV4KD - 4ch Realtime 720P playback HDV8KD - 8ch Realtime 720P playback Backup Mode Network/USB2.0 devices N E T W O R K Ethernet RJ45 10M/100M Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP Network Monitoring Web browsers, CMS, Android & iPhone appsS T O R A G E Internal HDD 1 SATA HDD, up to 4TB per HDD A U X I L I A R Y I N T E R F A C E Alarm input NO Alarm output NO PTZ control RS485 with multi-protocol USB interface 2 G E N E R A L Power Supply DC12V/2A Power Consumption 10W (without hard disk) Operation Condition 0ºC – +55ºC / 10% – 90%Dimensions 250(W) x 210(D) x 45(H) mm

17 4 x 1.3MP HD day/night bullet cameras - see HDVC36FB page 7 Hard drive options: HDV4KB – 1TB, 2TB or 4TB HDV8KB – 1TB, 2TB or 4TB Remote monitoring via wired or Wi-Fi connection - requires DVRWLA ordered separately Mobile monitoring with Android or iPhone APP Triplex operation – Playback / Record / Remote view simultaneously VGA or HDMI output (HDMI lead supplied) Four recording options – Continuous / Scheduled / Motion USB back up of recordings for easy evidence transfer Mouse driven comprehensive user interface Silent fanless operation HDV4KB 4 CHANNEL TRUE HD CCTV SYSTEMHDV8KB 8 CHANNEL TRUE HD CCTV SYSTEM XMeye App S Y S T E M Main Processor Embedded Processor Operating System Embedded LINUX V I D E O & A U D I O Video input HDV4KB - 4 channel BNC HDV8KB - 8 channel BNC Audio input HDV4KB - 4 channel RCA HDV8KB - 2 channel RCA Audio output 1 channel RCA D I S P L A Y Video output 1 x HDMI, 1 x VGA Display Split HDV4KB - 1 and 4 HDV8KB - 1, 4 and 9 Resolution 1024×768, 1280×720, 1280×1024, 1440×900, 1920×1080 R E C O R D I N G Video/Audio Compression H.264 Mainprofile/G.711AResolution 1280x720PRecord Rate (Main stream) HDV4KB - 4ch Realtime 720P recording HDV8KB - 8ch Realtime 720P recording Recording mode Manual/Alarm/Motion Detection/ Schedule P L A Y B A C K & B A C K U P Sync Playback HDV4KB - 4ch Realtime 720P playback HDV8KB - 8ch Realtime 720P playback Backup Mode Network/USB2.0 devices N E T W O R K Ethernet RJ45 10M/100M Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP Network Monitoring Web browsers, CMS, Android & iPhone appsS T O R A G E Internal HDD 1 SATA HDD, up to 4TB per HDD A U X I L I A R Y I N T E R F A C E Alarm input NO Alarm output NO PTZ control RS485 with multi-protocol USB interface 2 G E N E R A L Power Supply DC12V/2A Power Consumption 10W (without hard disk) Operation Condition 0ºC – +55ºC / 10% – 90%Dimensions 250(W) x 210(D) x 45(H) mm

Energy efficient wide screen LED panel Sleek black design Full composite BNC video input Video loop out via BNC Additional HDMI, VGA and S-VIDEO video inputs M O N 2 3 2 3 . 6 ” L E D C C T V M O N I T O R Size 23.6” LED Aspect Ratio 16:9 Resolution (H x V) 1920 x 1080 Colours 16.7M Viewing Angle H: 170º V: 160º Contrast Ratio 10000:1 (DCR) Response Time 2ms Speakers 2 each (2 watts) Inputs BNC, HDMI, VGA, Audio Outputs BNC, Audio VESA Wall Hanging 100 x 100mm Power Supply AC100-240V~50/60 Hz 1.1A Energy efficient wide screen LED panel Sleek black design Full composite BNC video input Video loop out via BNC Additional HDMI, VGA and S-VIDEO video inputs M O N 2 1 2 1 . 5 ” L E D C C T V M O N I T O R Size 21.5” LED Aspect Ratio 16:9 Resolution (H x V) 1920 x 1080 Colours 16.7M Viewing Angle H: 170º V: 160º Contrast Ratio 10000:1 (DCR) Response Time 2ms Speakers 2 each (2 watts) Inputs BNC, HDMI, VGA, Audio Outputs BNC, Audio VESA Wall Hanging 100 x 100mm Power Supply AC100-240V~50/60 Hz 1.1A 18 L E D C C T V M O N I T O R S

19 Energy efficient wide screen LED panel Sleek black design Full composite BNC video input Video loop out via BNC Additional HDMI, VGA and S-VIDEO video inputs M O N 1 8 1 8 . 5 ” L E D C C T V M O N I T O R Size 18.5” LED Aspect Ratio 16:9 Resolution (H x V) 1360 x 768 Colours 16.7M Viewing Angle H: 170º V: 160º Contrast Ratio 10000:1 (DCR) Response Time 2ms Speakers 2 each (2 watts) Inputs BNC, HDMI, VGA, Audio Outputs BNC, Audio VESA Wall Hanging 100 x 100mm Power Supply AC100-240V~50/60 Hz 1.1A Energy efficient wide screen LED panel Sleek black design Full composite BNC video input Video loop out via BNC Additional HDMI, VGA and S-VIDEO video inputs M O N 1 5 1 5 . 6 ” L E D C C T V M O N I T O R Size 15.6” LED Aspect Ratio 16:9 Resolution (H x V) 1360 x 768 Colours 16.7M Viewing Angle H: 170º V: 160º Contrast Ratio 10000:1 (DCR) Response Time 2ms Speakers 2 each (2 watts) Inputs BNC, HDMI, VGA, Audio Outputs BNC, Audio VESA Wall Hanging 100 x 100mm Power Supply AC100-240V~50/60 Hz 1.1A

The BDeye is a combined CCTV and video door entry solution in one small high design package ideally suited for the executive home or modern office. At the centre of the system is an 8” TFT monitor with a built in full feature DVR. The monitor feeds power to, and accepts video signals from, up to 4 internal or external CCTV cameras. 8” TFT monitor with built in slimline DVR 500GB hard drive LAN connection for remote viewing Touch panel controls High gloss white or black finish Desk or wall mounted Plug and play DIN cables 4 channel quad display Remote viewing via iPhone & Android App USB memory stick for data backup Up to two optional video entry call points Simple set up and operation Contents of BDeye 1 x BDeye 8” TFT monitor1 x BDeye camera with IR illumination1 x BDeye remote control1 x USB mouse and USB memory stick1 x 15m cable1 x Power supply unit BDEYE C O M B I N A T I O N C C T V A C C E S S C O N T R O L S Y S T E M 20 C C T V C O M B I N A T I O N U N I T BDEYE VDE Additional video door entry call point for BDeye c/w 15m cable Remote viewing with MEyePro APP

21 CCTV ACCESSORIES D U A L F U N C T I O N , P O W E R & B N C C A B L E S CAB10 - 10m Power and BNC video cable CAB20 - 20m Power and BNC video cable CAB40 - 40m Power and BNC video cable CAB80 - 80m Power and BNC video cable CAB-BNC CABLE CONNECTOR Connector for use with Power and BNC video cables P S I L 1 CAMERA POWER SUPPLY For use with CCTV cameras 12 volt 1 amp C P S 4 4 W A Y 4 A M P B O X E D P O W E R S U P P L YC P S 9 9 W A Y 9 A M P B O X E D P O W E R S U P P L YC P S 1 6 1 6 W A Y 1 6 A M P B O X E D P O W E R S U P P L Y 12VDC power limited output Protected outputs 100VAC-240VAC (50/60Hz) universal input Filtered and electronically regulated output Short circuit and thermal overload protection AC input and DC output LED indicators CPS4 dimensions 182(W) x 260(H) x 66(D)mm CPS9 dimensions 322(W) x 322(H) x 86(D)mm CPS16 dimensions 322(W) x 322(H) x 86(D)mm

22 CCTV ACCESSORIES DB2812VFD DEEP BASE FOR DOME CAMERA Optional Deep Base for conduit access and cable management For HDVC2812VFD Dome Camera TMPROHD AHD CCTV TEST MONITOR Compatible with both AHD and analogue CCTV cameras Durable design with quality carry case 3.5” LCD low reflection screen 12vDC 1A power output for camera Lithium battery rechargeable (4 hrs working time) Integral CAT5 cable checker PTZ camera control and testing TFT-BRA2 TILT, PIVOT, ROTATE MONITOR BRACKET 27º tilt 180º swivel Close to wall fit To fit screens 12-23” (30-58cm) Supports 20kg (44lbs) TFT-BRA1 FIXED MONITOR BRACKET Close to wall fit Picture style finish To fit screens 12-23” (30-58cm) Supports 20kg (44lbs) W B 6 2 2 V F D W A L L M O U N T B R A C K E T Optional Wall Mount Bracket for Horizontal Mounting For HDVC622VFD Dome Camera

23 H D B A L U N V S I N G L E C H A N N E L H D P A S S I V E B A L U N AHD camera transmission over CAT5 cable Single Channel HD Passive Balun Transmitter and Receiver pack Compatible with AHD and analogue CCTV cameras H D B A L U N V P S I N G L E C H A N N E L H D V I D E O & P O W E R B A L U N AHD camera transmission and power over CAT5 cable Single Channel HD Video & Power Balun Transmitter and Receiver pack Compatible with AHD and analogue CCTV cameras H D B A L U N V P C T S I N G L E C H A N N E L H D V I D E O & P O W E R T R A N S M I T T E R B A L U N AHD camera transmission and power over CAT5 cable Single Channel HD Video & Power Transmitter Balun Compatible with AHD and analogue CCTV cameras WARN1 EXTERNAL WARNING SIGN External durable use - 420mm x 300mm Space available to add scheme ownership details C A M 2 0 0 1 E X T E R N A L D U M M Y C A M E R A Medium external dummy camera Optional red LED Dimensions (mm) 245L x 100W x 185H Battery housed in junction box

24 E X T E R N A L A R E A P R O T E C T I O N

The External Area Protection range is the ideal solution for securing driveways, gardens, forecourts and yards of both domestic and commercial properties. 25

E X T E R N A L A R E A P R O T E C T I O N Surveillance and protection of external areas around homes, offices or industrial and agricultural units. 7” TFT screen with simple user interface Wire free transmission of images Accepts up to four GuardCam WF-T units SD card video recording in receiver unit Stable clear images at up to 150m wire free Built in motion detection with area masking facility Time date stamping of recordings Warning alert of motion detection CE FCC approved G U A R D C A M W F - M A R E A P R O T E C T I O N S Y S T E M W I T H M O N I T O R Detection Method Passive Infrared Sensor Range 12m x 140° Camera Resolution 640 X 480 LED Floodlight output 8 x 1W Nichia High Power LEDLumen output 1100 Time adjustment 5 seconds ~ 10 minutes Lux adjustment Dark - daylight Transmitter signal 2.4GHz FHSS Technology Transmitter output 16bBm Transmission Range 150m open fieldVoltage 100-240V 50Hz/60Hz Current drain 225±20mA IP rating IP55 Operating Temp. -10°C ~ 40°C Surveillance and protection of external areas around homes, offices or industrial and agricultural units. Wire free transmission of images Accepts up to four GuardCam WF-T units Direct AV connection to TV Simple user interface SD card video recording in receiver unit Stable clear images at up to 150m wire free Built in motion detection with area masking facilityTime date stamping of recordings Warning alert of motion detection CE FCC approved G U A R D C A M W F - S A A R E A P R O T E C T I O N S Y S T E M W I T H R E C E I V E R Detection Method Passive Infrared Sensor Range 12m x 140° Camera Resolution 640 X 480 LED Floodlight output 8 x 1W Nichia High Power LEDLumen output 1100 Time adjustment 5 seconds ~ 10 minutes Lux adjustment Dark - daylight Transmitter signal 2.4GHz FHSS Technology Transmitter output 16bBm Transmission Range 150m open fieldVoltage 100-240V 50Hz/60Hz Current drain 225±20mA IP rating IP55 Operating Temp. -10°C ~ 40°C 26

27 Additional transmitter for GuardCam WF systems. For use with GuardCam WF system 12m 140 degree PIR 8W 1100 lumen LED floodlight Up to four units per system Easy pairing to GuardCam monitor (GuardCam WF-MR) or GuardCam receiver (GuardCam WF-SAR) High quality stable images G U A R D C A M W F - T E X T E R N A L A R E A P R O T E C T I O N C A M E R A Detection Method Passive Infrared Sensor Range 12m x 140° Camera Resolution 640 X 480 LED Floodlight output 8 x 1W Nichia High Power LEDLumen output 1100 Time adjustment 5 seconds ~ 10 minutes Lux adjustment Dark - daylight Transmitter signal 2.4GHz FHSS Technology Transmitter output 16bBm Transmission Range 150m open fieldVoltage 100-240V 50Hz/60Hz Current drain 225±20mA IP rating IP55 Operating Temp. -10°C ~ 40°C Dimensions 160 x 176 x 260MM Weight 1400g GuardCam LED is a complete all-in-one PIR floodlight, camera, speaker and DVR system. Simply connect to mains power, fix to wall, set the time and date and switch on! Detect the intruder Floodlight the area Initiate a high resolution 1080 x 720P video recording Deliver an audible warning Ability to record users own warning message Captures 60,000 still images or 750 twenty second video clips with 4GB card supplied Maximum card size allowable now 32GB G U A R D C A M L E D C O M B I N E D S E C U R I T Y L E D F L O O D L I G H T Supply Voltage 100-240VAC Current drain (activated) 0.4ampCurrent drain (quiescent) 0.005ampLED output 1100 Lumens PIR detection angle 160 deg PIR detection range 12 metres Camera exposure control AutomaticCamera white balance Automatic Camera sharpness Automatic SD card format FAT Maximum 32GB Image Format JPEG / AVI IP rating IP44 Dimensions (mm) 180 x 190 x 315mm Weight 1.206KG

28 E X T E R N A L A R E A P R O T E C T I O N CAMERALens High precision multi layer coated Focal length 6mm (approx. 50º field of view) Focal capability 1.5m – infinite White balance Automatic Exposure control Automatic RECORDERMedia SD maximum 32GB Video resolution HD720P or VGA 640x480 Still image resolution 3MP or 5MP or 8MPAudio with video only IMAGE CAPTURE Still image 1 – 9 burst selectable Video 5 - 300 secs Stamping Time and date Control Via on board data screen PIRRange 10-12 m Angle of detection 48 degrees Finish Black (Covert) INFRA REDEffective range 15m Angle of illumination 55 degreesType Black covert CONNECTIVITY AND POWERTV output AV composite video/audio PC Output Mini 5P - Btype USB Power 6vDC plug in power supply Battery 4 x C cell DIMENSIONS Ø 75mm x 140mm CanCam is a battery powered high resolution surveillance camera with integral PIR detector, SD card recording and black infrared illumination. CanCam VR has all the features of CanCam but with the added benefit of a steel vandal resistant case for installation in vulnerable applications such as a shed, rear of van, portable cabin, garage or out house. For internal or external use Battery or 6vdc powered PIR or time lapse controlled Black covert infra red illumination Internal SD card recording Up to 8MP still image resolution Up to HD720P video resolution High quality fixed 6mm lens Up to 1000 still images or 100 video clips with full card overwrite Weather proof IP55 C A N C A M STAND ALONE EXTERNAL SURVEILLANCE SYSTEM C A N C A M V R V A N D A L R E S I S T A N T S U R V E I L L A N C E S Y S T E M

29 LED floodlight – 1100 lumen output 50,000 hours LED life Low energy 12.7w max. power consump. 160 degree PIR detector Wide spread illumination up to 120º Adjustable on time of 5 secs to 5 mins Adjustable lux – dusk to dark Adjustable floodlight and PIR direction – Horizontal and vertical axis Additional switching capability – 50W LED – 500W halogen Ideal for use with up to four NH150LED floodlightsWeather proof, suitable for external use N I G H T H A W K L O W E N E R G Y L E D S E C U R I T Y L I G H T Power source 220 - 240VAC/50Hz Power consumption 12.7w (operational) Detection method Passive Infrared Sensor Detector range 10M x 160 degrees Light output 1100 Lumens Illumination angle 120 degrees Colour 5600K cool white Time adjustment 5 seconds to 5 minutes Maximum additional load LED 50W - Halogen 500W IP rating IP55 LED floodlight – 1100 lumen output Wide spread illumination up to 120º Low energy 12.1w maximum power consumption Adjustable floodlight direction – Horizontal and vertical axis Ideal for use with the NightHawk security light with the capability to switch up to 4 extra NH150LED units Weather proof, suitable for external use N H 1 5 0 L O W E N E R G Y L E D F L O O D L I G H T Power source 220 - 240VAC/50Hz Power consumption 12.7w (operational) Light output 1100 Lumens Illumination angle 120 degrees LED light output colour 5600K cool whiteTime adjustment 5 seconds to 5 minutes Maximum additional load LED 50W - Halogen 500W IP rating IP55

30 Introducing the next generation of Access Control products from ESP. The new Aperta range not only includes proximity reader systems and accessories such as magnetic door locks but also a completely new simplified and easy to install video door entry systems for both single house and multi way apartment applications. C O M P L E T E A C C E S S C O N T R O L S O L U T I O N

31 Master Bedroom Bedroom Kitchen Lounge AC240V A flexible range of superb quality hands-free colour video door entry products specifically for installation in single dwellings. Simplicity of installation is the key to Aperta single way systems, requiring only 2 wires throughout and all outdoor stations and monitors powered by a single power supply. The range includes 2 quick and easy to select base kits with options for combined keypad entry or a stylish but simple bell push outdoor station. Alternatively you can build your own system from 2 outdoor station and 4 monitor options. You really need look no further to find the ideal single way video door entry solution. APDSSW | APDSSWKPDoor stations APPOWSWCombined Power Supply & BUS Separator (Connect up to 5 devices) APMONW | APMONB APMONWG | APMONBGColour monitors S I N G L E W A Y S Y S T E M E X A M P L E C O M P O N E N T S S I N G L E W A Y V I D E O D O O R E N T R Y PSU

32 Simple 2 core cable installation Single power supply (included) supports all monitors and outdoor stations in a flexible combination of upto 5 devices Clear high resolution colour picture on 7” hands free TFT monitor APKIT COLOUR VIDEO DOOR ENTRY SYSTEM S T A T I O NImage sensor 1/3” Colour CCD Min. Illumination 0.1 LUXIllumination 6 LEDs Lens 3.6mmPower 24VDCOperating Temp. -20°C ~ + 40°CDimensions 85mm(W)x 165mm(H)x 53mm(D) Weight 390gM O N I T O RPower 24VDCInstallation Surface Mounted Operational Temp. 0°C~ + 40°CConsumption 300mADimensions 215mm(W)x152mm(H)x18mm(D)Weight 450g Simple 2 core cable installation Single power supply (included) supports all monitors and outdoor stations in a flexible combination of upto 5 devices Clear high resolution colour picture on 7” hands free TFT monitor Outdoor station with built in keypad for code door unlocking APKITKP COLOUR VIDEO DOOR ENTRY KEYPAD SYSTEM S T A T I O NImage sensor 1/3” Colour CCD Min. Illumination 0.1 LUXIllumination 6 LEDs Lens 3.6mm Power 24VDCOperating Temp. -20°C ~ + 40°CDimensions 87mm(W)x 200mm(H)x 53mm(D) Weight 640gM O N I T O RPower 24VDCInstallation Surface Mounted Operational Temp. 0°C~ + 40°CConsumption 300mADimensions 215mm(W)x152mm(H)x18mm(D)Weight 450g S I N G L E W A Y V I D E O D O O R E N T R Y

33 Waterproof IP55 metal outdoor station High resolution colour camera Built in keypad for door code unlocking Simple 2 core cable installation APDSSWKP SINGLEWAY VIDEO D O O R S T A T I O N W I T H K E Y P A D Single way system component 24VDC/800mAh power output Dimensions 75mm(W)x60mm(H)x125mm(L) Only 1 power supply per system required APPOWSW C O M B I N E D P O W E R & B U S S E P A R A T O R U N I T F O R S I N G L E W A Y S Y S T E M Waterproof IP55 outdoor station High resolution colour camera Simple 2 core cable installation APDSSW SINGLEWAY VIDEO D O O R S T A T I O N Image sensor 1/3” Colour CCD Min. Illumination 0.1 LUX Illumination 6 LEDs Lens 3.6mmViewing Angle 70° Power 24VDCOperating Temp. -20°C ~ + 40°C Dimensions 85mm(W)x 165mm(H)x 53mm(D) Weight 390g Image sensor 1/3” Colour CCD Min. Illumination 0.1 LUX Illumination 6 LEDs Lens 3.6mm Viewing Angle 70° Power 24VDCOperating Temp. -20°C ~ + 40°C Dimensions 87mm(W)x 200mm(H)x 53mm(D) Weight 640g

34 7” TFT screen with clear high resolution colour picture Simple 2 core cable installation On screen menu for simple system set up & customisation Optional still or video recording and playback of callers (4GB SD card included) Durable white or black casing APMONWG White | A P M O N B G BlackC O L O U R V I D E O D O O R E N T R Y M O N I T O R W I T H R E C O R D F A C I L I T Y Simple 2 core cable installation 7” TFT screen with clear high resolution colour picture Durable white or black casing APMONW White | A P M O N B BlackC O L O U R V I D E O D O O R E N T R Y M O N I T O R Power 24VDCInstallation Surface Mounted Operational Temp. 0°C~ + 40°CConsumption 300mADimensions 215mm(W)x152mm(H)x18mm(D)Weight 450g Power 24VDCInstallation Surface Mounted Operational Temp. 0°C~ + 40°CConsumption 350mADimensions 183mm(W)x185mm(H)x20mm(D)Weight 550g S I N G L E W A Y V I D E O D O O R E N T R Y

35 M U L T I W A Y V I D E O D O O R E N T R Y PSU AC240V Apartment 1 Apartment 2 Apartment 3 Apartment 4 Apartment 5 Apartment 6 Apartment 7 Apartment 8 Apartment 9 Apartment 10 Apartment 11 Apartment 12 APDSMWMultiway door station APBC4MWBranch Controller (A maximum of 4 monitors to 1 Branch controller) APMONW | APMONB | APMONWG | APMONBGColour monitors M U L T I W A Y S Y S T E M E X A M P L E C O M P O N E N T S APSEPMWPower BUS Separator (Connects to the System Power Supply and 1st Branch controller) APPOWMWSystem Power Supply A flexible range of superb quality hands-free colour video door entry products specifically for installation in multiple apartments. Simplicity of installation is the key to Aperta multi way systems, supporting up to 32 apartments in one system and requiring only 2 wires throughout with all outdoor stations and monitors powered by a single power supply. The keypad multi way door station allows both apartment calling plus door unlocking by passcode, no need for 2 separate keypads. The keypad apartment calling also means that no additional buttons or panels are required, keeping the installation simple, neat and compact. You really need look no further to find the ideal multi way door entry solution. SEP BC BC BC

36 Waterproof IP55 metal multiway outdoor station High resolution colour camera Built in keypad for door calling and code unlocking Simple 2 core cable installation APDSMW M U L T I W A Y V I D E O D O O R S T A T I O N Image sensor 1/3” Colour CCD Min. Illumination 0.1 LUX Illumination 6 LEDs Lens 3.6mm Viewing Angle 70° Power 24VDCOperating Temp. -20°C ~ + 40°C Dimensions 87mm(W)x 200mm(H)x 53mm(D) Weight 640g Multi way system component 24VDC/4.2A power output Dimensions 100mm(W)x200mm(L)x40mm(D) Only 1 power supply per system required APPOWMW P O W E R S U P P L Y U N I T F O R M U L T I W A Y S Y S T E M Multi way system component For use with APPOWMW power supply Multi way system component 1 unit supports wiring to 4 apartments or 4 outdoor stations (APDSMW) APSEPMW P O W E R B U S S E P A R A T O R U N I TF O R M U L T I W A Y S Y S T E M APBC4MW 4 B R A N C H C O N T R O L L E RF O R M U L T I W A Y S Y S T E M M U L T I W A Y V I D E O D O O R E N T R Y

37 7” TFT screen with clear high resolution colour picture Simple 2 core cable installation On screen menu for simple system set up & customisation Optional still or video recording and playback of callers (4GB SD card included) Durable white or black casing APMONWG White | A P M O N B G BlackC O L O U R V I D E O D O O R E N T R Y M O N I T O R W I T H R E C O R D F A C I L I T Y Simple 2 core cable installation 7” TFT screen with clear high resolution colour picture Durable white or black casing APMONW White | A P M O N B BlackC O L O U R V I D E O D O O R E N T R Y M O N I T O R Power 24VDCInstallation Surface Mounted Operational Temp. 0°C~ + 40°CConsumption 300mADimensions 215mm(W)x152mm(H)x18mm(D)Weight 450g Power 24VDCInstallation Surface Mounted Operational Temp. 0°C~ + 40°CConsumption 350mADimensions 183mm(W)x185mm(H)x20mm(D)Weight 550g

38 Easy install, simple self-contained programming Up to 1,010 key tag holders or Pin numbers 2 separate user groups 2 relay outputs Anti tamper option Weather/dust proof robust construction Complete with 10 tags EZT3ST10 Additional Proximity Tags (10 Pack) EZTAG3 PROXIMITY & KEYPAD DOOR ENTRY Working temp. -10 ~ +55ºC Voltage DC: 12V-24V AC: 12V~24V Working current 120mAStandby current 90mACard mode ID / IC card Reader frequency 125KHzEffective distance 5CMCapacity 1010 Cards or Fobs Complete entry system in one box comprising of: EZTAG3 complete with 10 Tags EV-ML-250 Electronic lock EV-EXIT Exit release button EV-EBG Emergency break glass EVBPSBB Boxed power supply EZTAG3 PRO PROXIMITY & KEYPAD DOOR ENTRY KIT S I N G L E D O O R E N T R Y

39 Two-wire connection Durable/Weatherproof door station Clear 2 way audio Lock release option Wiring distance up to 100 meters Easy DIY installation Two-wire connection Durable/Weatherproof door station Clear 2 way audio Lock release option Wiring distance up to 100 meters Easy DIY installation A P K I T A O A U D I O D O O R E N T R Y S Y S T E M HANDSETInput range DC12V Output power =0.6W Working current =50mA Dimension 215mm x 85mm x 60mm CALL POINTInput range DC12V Output power =0.6W Working current =50mA IP rating 55 Dimension 150mm x 65mm x 50mm HANDSETInput range DC12V Output power =0.6W Working current =50mA Dimension 215mm x 85mm x 60mm A P K I T A O H A D D I T I O N A L A P K I T A O A U D I O H A N D S E T A U D I O D O O R E N T R Y S Y S T E M S

40 A C C E S S C O N T R O L A C C E S S O R I E S Holding force 250kg/550lbs max Z & L mounting bracket included Dual voltage 12 & 24 VDC Fail safe Dimensions excl. bracket - 250 x 26 x 41mm NB. Requires EVBPSBB power supply E V - M L - 2 5 0 E L E C T R O M A G N E T I C L O C K IP67 rated weather resistant external lock Holding force 500kg/1200lbs max Z & L mounting bracket included Dual voltage 12 & 24 VDC Fail safe Dimensions excl. bracket - 220 x 42 x 62mm NB. Requires EVBPSBB power supply E V - M L - 5 0 0 X T E L E C T R O M A G N E T I C L O C K Holding force 295kg/650lbs 160ma 12vdc input For use with Yale type rim locks Surface mounting version available Fail secure Dimensions - 28.5 x 31 x 160mm NB. Requires EVBPSBB power supply E N T E R D E L E C T R I C L O C K Holding force 295kg/650lbs 160ma 12vdc input For use with Yale type surface locks Flush mounting version available Fail secure NB. Requires EVBPSBB power supply E N T E R D - Y L R S U R F A C E E L E C T R I C L O C K

41 Stainless steel fascia Flush mounting Push to make contacts E V - E X I T P U S H T O E X I T L O C K R E L E A S E B U T T O N Back up battery output 100-240vAC, 50/60Hz input 1.5A /12vDC fail safe output 1A 12vDC fail secure output Size: 129 x 73 x 50mm LWD E V B P S B B B O X E D P O W E R S U P P L Y Surface mounted Emergency break glass to release door E V - E B G E M E R G E N C Y B R E A K G L A S S B A T 7 1 2 V 7 . 0 A H S L A B A T T E R Y Back up battery for EVBPSBB

42 F I R E P R O T E C T I O N

The MAGfire systems have been created to balance performance, reliability and aesthetics whilst being fully CPR compliant and certified to EN54 standards. The range includes everything required to complete high quality, durable, conventional and addressable fire alarm installations. 43

44 A D D R E S S A B L E F I R E P A N E L S 16 zone addressable fire alarm panel supplied with 1 loop. Expandable to 2 loops using MAGPRO16-L250. A maximum of 250 devices can be connected to each loop. 16 Zones Maximum 250 devices per loop Memory Log: 10,000 events Networkable up to 32 Panels Class change function 4 x 40 character LCD display Free programing software Micro USB port for PC connection Loop & battery calculator software included Certified to EN54–2/4 M A G P R O 1 6 A D D R E S S A B L E 1 6 Z O N E F I R E P A N E L Made in E U EN54 INPUTS Loops 1 expandable to 2 Devices Per Loop 250 Protocol MAGPROPOWER Mains Fail Consumption 125mA DC – 1 LOOP 213mA DC – 2 LOOP Mains Supply 230V AC + - 10% Max Loop Current 500mA DC Backup 1x12V 17Ah OUTPUTS 2 Sounders 24v DC @ 500mA 4 Programable Relays 24v DC @ 100mA 3 Monitored Outputs 24v DC @ 100mA 3 Monitored Inputs Volt free contacts ENVIRONMENT Working Temperature -5C TO +40C Storage -10C TO 60C Humidity 0 - 95% Weight 3.6KG Dimensions 320 x 220 x 80mm MAGPRO16-L250 Single Loop Expander 250 Devices

45 96 zone addressable fire alarm panel supplied with 1 loop. Expandable to 4 loops using additional MAGPRO96-L250’s. A maximum of 250 devices can be connected to each loop. 96 Zones Maximum 250 devices per loop Memory Log: 10,000 events Networkable up to 32 Panels 320 x 240 pixel touch screen display Free programing software Micro USB port for PC connection Loop & battery calculator software included Certified to EN54–2/4 M A G P R O 9 6 A D D R E S S A B L E 9 6 Z O N E F I R E P A N E L INPUTS Loops 1 expandable to 4 Devices Per Loop 250 Protocol MAGPROPOWER Mains Fail Consumption 285mA DC - 1 LOOP 360mA DC - 2 LOOP 435mA DC - 3 LOOP 510mA DC - 4 LOOP Mains Supply 230V AC + - 10% Max Loop Current 500mA DC Backup 1x12V 17Ah OUTPUTS 1 Sounder 24v DC @ 300mA 4 Programable Relays 110v ac @ 1A 2 Monitored Outputs 24v DC @ 300mA 1 Auxillary Output 24v DC @ 300mA 1 Fault Output 24v DC @ 300mA ENVIRONMENT Working Temperature -5C TO +40C Storage -10C TO 60C Humidity 0 - 95% Weight 4.2KG Dimensions 456 x 350 x 125mm MAGPRO96-L250Single Loop Expander 250 Devices Made in E U EN54

46 A D D R E S S A B L E F I R E P A N E L S Slimline flush mount design Compatible with MAGPRO16 Ver2.8 and higher Compatible with MAGPRO96 Requires 24V DC Max consumption of 0.11A (110mA) Each panel in network will require a MAGPRO-NIC Maximum of 32 panels in the network 1000m distance from MAGPRO-REP to MAGPRO-NIC Dimensions 200 x 330 x 48mm Ring type network 10,000 event log within the repeater M A G P R O - R E P A D D R E S S A B L E R E P E A T E R P A N E L M A G P R O - N I C N E T W O R K I N T E R F A C E C A R D POWER From a MAGPRO Panel AUX / GND External 24=/-4 VDC Consumption 110mA INPUT Comunication RS485 Max length between panels 1000m OUTPUT Comunication RS485 max length between panels 1000m TECHNICAL SPEC Memory LOG 10,000 events Network type Ring MAGPRO16 Firmware Compatability Ver 2.8 or higher MAGPRO96 Firmware compatability Ver 4.2 or higher Max number of panels 32 Connection to MAGRO Panel Via MAGPRO-NIC ENVIRONMENT Working Temperature (-5 +50) Humidity 95% Weight 770g Dimension 200 x 330 x 48mm Recommend a Boxed Power Supply with battery backup Made in E U EN54 Networks between MAGPRO16/96 & REP Panels MAGPRO16 Firmware REV 2.8 or higher Required MAGPRO96 Firmware REV 4.2 or higher Required RS-485 Communication protocol On-board LED indication Power supply from the panel Programing from the panel 1000m transmission distance between modules

47 Sensitivity level selectable from the control panel - High/Normal/Middle/Low Protected area - 120m 2 Installation height - up to 16m Day/Night mode Low profile design LED indication with 360° visibility Certified to EN54–7 Base ordered separately see below M A G P R O - S D 1 A D D R E S S A B L E S M O K E D E T E C T O R Can work as a fixed temperature or rate of rise detector Class A1R, A2S, BS selectable from the control panel Day/Night mode Protected area - up to 35m 2 Installation height - up to 3.5m Low profile design LED indication with 360° visibility Certified to EN54–5 Base ordered separately see below M A G P R O - H D 1 A D D R E S S A B L E H E A T D E T E C T O R Sensitivity selectable from the control panel - High/Normal/Middle/Low Class A1R temperature sensor (according to EN54-5) Protected area - up to 120m 2 Installation height - up to 16m Day/Night mode Low profile design LED indication with 360° visibility Certified to EN54–5/7 Base ordered separately see below M A G P R O - H S D 1 COMBINED SMOKE & HEAT DETECTOR A D D R E S S A B L E D E T E C T O R S MAGPRO-DB Detector Base MAGPRO-DBS Sounder Base MAGPRO-DBSS Sounder Strobe Base MAGPRO-DBSC Detector base cover blank plate

48 A D D R E S S A B L E A C C E S S O R I E S M A G P R O - W S S 2 3 S O U N D E R S T R O B E Certified to EN54-23 Piezo sounder Adjustable sound level - 92dB/100 dB 32 sound types selectable from the panel Loop synchronization & powered Base MAGPRO-DB ordered separately M A G P R O - W S S S O U N D E R S T R O B E Certified to EN54–3 Piezo sounder Adjustable sound level - 92dB/100 dB 32 sound types selectable from the panel Loop synchronization & powered Base MAGPRO-DB ordered separately M A G P R O - W S S O U N D E R Certified to EN54–3 Piezo sounder Adjustable sound level - 92dB/100 dB 32 sound types selectable from the panel Loop synchronization & powered Base MAGPRO-DB ordered separately M A G P R O - P R O G P R O G R A M M I N G T O O L For reading/writing addresses and setting of parameters within detectors and modules. Built in MAGPRO-DB standard base Mains or battery powered (4 x 1.5V not included) Programming cable included MAGPRO-CP MANUAL CALL POINT Resettable call point Certified to EN54–11–A Built in isolator IP40 Rated Optional protective plastic cover

49 M A G P R O - I M L O O P I S O L A T O R M O D U L E Protection against short circuit Auto reset after short circuit 4 x cable entry points A maximum of 30 devices between two isolators Certified to EN54–17 Z R L 2 L E D I N D I C A T O R P L A T E Flash rate - permanent Current - 28 mA Max Operating Voltage Range - 5-28V DC M A G P R O - M I N I 1 I N P U T M O D U L E Single volt free contact Compact size – 58mm x 25mm x 12mm Example applications - Integration of third party control devices Compliant to EN54–18 B A T 1 8 B A C K U P B A T T E R Y 12V 17ah SLA back up battery 2 4 V B O X E D P O W E R S U P P L I E S BPS-1 24V 1 amp Boxed power supplyBPS-2 24V 2 amp Boxed power supplyBPS-5 24V 5 amp Boxed power supplyNb Boxed power supplies require 2 x 12V batteries (not supplied) D O O R H O L D E R S DR916-24 24V DC Door HolderDR916-240 240V AC Door HolderDR916-FMB Floor Mounting BracketDR916-KP Spare Keep Plate

50 M A G P R O - 0 i 4 O 4 O U T P U T M O D U L E W I T H I S O L A T O R 4 Relay outputs Loop powered Built in isolator Certified to EN54–18 Example applications - Shutdown of ventilation equipment and door override M A G P R O - 4 i 0 O 4 I N P U T M O D U L E W I T H I S O L A T O R 4 Monitored Inputs Loop powered Built in isolator Certified to EN54–18 Example applications - Input from external equipment, extinguishing/sprinkler panel M A G P R O - R MAINS RELAY OUTPUT MODULE WITH ISOLATOR Suitable for control of 240VAC voltage circuits up to 5A Loop powered Built in isolator Compliant to EN54–18 Example application - AC 240V door magnet override M A G P R O - 2 i 2 O 2 I N P U T 2 OUTPUT MODULE WITH ISOLATOR 2 Monitored Inputs 2 Outputs Loop powered Built in isolator Certified to EN54–18 Example application - Link to monitoring station signalling devices M A G P R O - 1 O S i CONVENTIONAL SOUNDER MODULE WITH ISOLATOR Integrate conventional sounders into an addressable system Loop powered Built in isolator Requires 24V PSU Compliant to EN54–18 M A G P R O - C Z M C O N V E N T I O N A L Z O N E M O D U L E W I T H I S O L A T O R Integrate conventional detectors into an addressable system Max number of detectors in one zone - 32 Loop powered Built in isolator Certified to EN54–18 Example applications - Integrate conventional equipment i.e. beam detectors A D D R E S S A B L E M O D U L E S

51 C O N V E N T I O N A L F I R E K I T S FLK2P kit contains: MAG2P 2 zone fire panel 6 x PSD-2 Optical smoke detectors complete with bases 2 x SCP-2R Resettable call points 2 x BA-2R Banshee sounders 1 x BAT7 12v 7.0ah SLA battery F L K 2 P 2 Z O N E C O N V E N T I O N A L F I R E A L A R M K I T Made in E U EN54 FLK4PH kit contains: MAG4P 4 zone fire panel 5 x PSD-2 Optical smoke detectors complete with bases 1 x FHD-2 Fixed temperature heat detector complete with base 2 x SCP-2R Resettable call points 2 x BA-2R Banshee sounders 1 x BAT7 12v 7.0ah SLA battery F L K 4 P H 4 Z O N E C O N V E N T I O N A L F I R E A L A R M K I T Made in E U EN54

52 2 programmable zones Active end of line monitoring and head removal 30 fire detectors per zone Unlimited number of call points per zone Integral evacuate alarm button ‘Class change’ facility Enable/disable security key One man walk test facility Volt free fire change over relay Volt free fault change over relay Individual sounder circuit fault ID Individual zone/sounder isolate Certified to EN54–2/4 Requires only 1x12v battery MAG2P - ABS casing M A G 2 P 2 Z O N E F I R E P A N E L INPUTS Max detectors per zone 30 Thresholds for 0 - 2 mA (Fault condition) zone conditions 2 - 6 mA (Normal condition) 6 - 110 mA (Fire condition) 110 mA - Short (Fault condition) POWER Mains fail consumption 50mA Mains supply 230 VAC ± 10% Standby supply 1 x 7ah 12V S.L.A. Battery Power availability 0.7 amps OUTPUTS Sounder 1 24V (max 300mA fused) Sounder 2 24V (max 300mA fused) Fault/fire relay Volt free 500mA @ 24V (max load) Auxiliary output 24VDC (300mA fused) ENVIRONMENT Working Temperature 0 to 40ºC Storage Temperature -20 to 60ºC Humidity 0 - 95% Dimensions MAG2P 340 x 290 x 100mm Dimensions MAG2 200 x 290 x 80mm Weight MAG2P - 2.1Kg MAG2 - 2.7Kg Made in E U EN54 C O N V E N T I O N A L F I R E P A N E L S MAG2 2 Zone Fire Panel Metal Casing

53 4 programmable zones Active end of line monitoring and head removal 30 fire detectors per zone Unlimited number of call points per zone Integral evacuate alarm button ‘Class change’ facility Enable/disable security key One man walk test facility Volt free fire change over relay Volt free fault change over relay Individual sounder circuit fault ID Individual zone/sounder isolate Certified to EN54–2/4 Requires only 1x12v battery MAG4P - ABS casing M A G 4 P 4 Z O N E F I R E P A N E L INPUTS Max detectors per zone 30 Thresholds for 0 - 2 mA (Fault condition) zone conditions 2 - 6 mA (Normal condition) 6 - 110 mA (Fire condition) 110 mA - Short (Fault condition) POWER Mains fail consumption 50mA Mains supply 230 VAC ± 10% Standby supply 1 x 7ah 12V S.L.A. Battery Power availability 0.7 amps OUTPUTS Sounder 1 24V (max 300mA fused) Sounder 2 24V (max 300mA fused) Fault/fire relay Volt free 500mA @ 24V (max load) Auxiliary output 24VDC (300mA fused) ENVIRONMENT Working Temperature 0 to 40ºC Storage Temperature -20 to 60ºC Humidity 0 - 95% Dimensions MAG4P 340 x 290 x 100mm Dimensions MAG4 320 x 220 x 80mm Weight MAG4P - 2.5Kg MAG4 - 3.5Kg Made in E U EN54 MAG4 4 Zone Fire Panel Metal Casing

C O N V E N T I O N A L F I R E P A N E L S 54 Up to 16 programmable zones Up to 16 sounder circuits Active end of line monitoring and head removal Up to 32 fire detectors per zone Unlimited number of call points per zone Integral evacuate alarm button Repeater facility and ‘Class change’ facility Enable/disable security key One man walk test facility Volt free fire/fault change over relay Individual sounder circuit fault ID Individual zone/sounder isolate Alarm delay options Certified to EN54–2/4 Requires 1 x 12V batteries ABS casing M A G 8 1 6 8 Z O N E F I R E P A N E L E X P A N D A B L E T O 1 6 Z O N E S M A G F M K F L U S H K I T F O R M A G 8 1 6 P A N E L INPUTS Max. detectors per zone 32 Thresholds for 0 - 2 mA (Fault condition) zone conditions 2 - 10 mA (Normal condition) 10 - 110 mA (Fire condition) 110mA - + Short (Fault condition) POWER Mains fail consumption 130mA (1 zone expander) 260mA (4 zone expanders) Mains supply 230 VAC ± 10% Standby supply 1 x 18ah 12V S.L.A. Batteries Power availability 0.7 amps OUTPUTS On board sounder circuits (4) 300mA @ 24V fuse resettable (PTC) Sounder expander cards (4) 150mA @ 24V fuse resettable (PTC) Fault/fire relay Volt free 500mA @ 24V (max load) Auxiliary output 24VDC (300mA fused) ENVIRONMENT Working Temperature 0 to 40ºC Storage Temperature -20 to 60ºC Humidity 0 to 93% Dimensions (mm) 456 x 350 x 125mm Weight 4.2 KG Made in E U EN54 FIRE ZONE / SOUNDER OUTPUT MATRIX Number of zone cards fitted 2 3 4 2 3 1 2 1 Number of sounder cards fitted 0 0 0 1 1 2 2 3 Number of zones 8 12 16 8 12 4 8 4 Number of sounder outputs 4 4 4 8 8 12 12 16 NB The MAG816 features 4 sounder circuits. Space is provided for up to 4 extra expansion cards of any combination. Sounder cards carry 4 sounder circuits, Zone cards carry 4 fire zones. The MAG816 is supplied as standard with 8 fire zones and 4 sounder circuits. MAGZC816 4 Zone Expander Card MAGSC816 4 Zone Sounder Expander Card

C O N V E N T I O N A L D E T E C T O R S 55 MODEL CSD-2 PSD-2 FHD-2 RHD-2 Description Combined smoke/heat Optical smoke Fixed temp heat Rate of rise heat Type Conventional Conventional Conventional Conventional Approval EN54-7, EN54-5 EN54-7 EN54-5 EN54-5 Class A1R N/A A2S A1R Operating Voltage 9 - 30VDC 9 - 30VDC 9 - 30VDC 9 - 30VDC Standby Current @ 24v 60μA 60μA 60μA 60μA Alarm Current @ 24v 49mA 49mA 49mA 49mA Wire Gauge 0.4mm - 2.0mm TWIN 0.4mm - 2.0mm TWIN 0.4mm - 2.0mm TWIN 0.4mm - 2.0mm TWIN Operating Temperature -10°C to 60°C -10°C to 60°C -10°C to 60°C -10°C to 60°C Test Facility Simulated Smoke/ Heat Simulated Smoke Heat Source Heat Source These MAGfire detectors have been developed to provide a perfect compliment to the MAGfire MAG panels. All detectors are supplied with a diode base. Fully compliant with CPR and approved to EN54 standards. C S D - 2 C O M B I N E D O P T I C A L S M O K E & F I X E D H E A T D E T E C T O R P S D - 2 O P T I C A L S M O K E D E T E C T O RF H D - 2 F I X E D T E M P E R A T U R E H E A T D E T E C T O RR H D - 2 R A T E O F R I S E H E A T D E T E C T O R

56 1 2 V F I R E A L A R M D E T E C T O R S MODEL CSD-212 PSD-212 FHD-212 RHD-212 Description Combined smoke/heat Optical smoke Fixed temp heat Rate of rise heat Type Conventional Conventional Conventional Conventional Approval EN54-7, EN54-5 EN54-7 EN54-5 EN54-5 Class A1R N/A A2S A1R Operating Voltage 9 - 30VDC 9 - 30VDC 9 - 30VDC 9 - 30VDC Standby Current @ 12v 50μA 50μA 50μA 50μA Alarm Current @ 12v 29mA 29mA 29mA 29mA Wire Gauge 0.4mm - 2.0mm TWIN 0.4mm - 2.0mm TWIN 0.4mm - 2.0mm TWIN 0.4mm - 2.0mm TWIN Operating Temperature -10°C to 60°C -10°C to 60°C -10°C to 60°C -10°C to 60°C Test Facility Simulated Smoke/ Heat Simulated Smoke Heat Source Heat Source The new range of MAGfire detectors have been developed to provide a perfect compliment to 12V hardwire intruder alarm systems. All detectors are supplied with a relay base. Fully compliant with CPR and approved to EN54 standards. C S D - 2 1 2 C O M B I N E D O P T I C A L S M O K E & F I X E D H E A T D E T E C T O R P S D - 2 1 2 O P T I C A L S M O K E D E T E C T O RF H D - 2 1 2 F I X E D T E M P E R A T U R E H E A T D E T E C T O RR H D - 2 1 2 R A T E O F R I S E H E A T D E T E C T O R

57 C O N V E N T I O N A L A C C E S S O R I E S B D 5 0 0 0 - 1 0 0 F I R E R A Y 5 0 0 0 M O T O R I S E D R E F L E C T I V E B E A M 100m operational Distance Integral laser alignment Auto Align Fast automatic beam alignment Low level system Controller 24v DC 37mA max current draw EN 54:12 & UL268 approved B D 5 0 0 0 - 5 0 F I R E R A Y 5 0 0 0 M O T O R I S E D R E F L E C T I V E B E A M 50m operational Distance Integral laser alignment Auto Align Fast automatic beam alignment Low level system Controller 24v DC 37mA max current draw EN 54:12 & UL268 approved

58 C O N V E N T I O N A L C A L L P O I N T A N D S O U N D E R S Sound Output @ 1m 89 - 110 dBA Current - 3-39 mA IP Rating - IP45 B A - 2 R R E D B A N S H E E S O U N D E R Sound Output @ 1m 89 - 110 dBA Current - 3-39 mA IP Rating - IP45 B A - 2 W W H I T E B A N S H E E S O U N D E R S C P 2 - R R E S E T T A B L E C A L L P O I N T Surface or flush mounting Complete with surface back box Spare keys available - SCP2RK Z R L 2 R E M O T E L E D I N D I C A T O R P L A T E Flash rate - permanent Current - 28 mA Max Operating Voltage Range - 5-28V DC

59 Flash rate - 60/minute 12V & 24V (80mA & 30mA) IP Rating - IP65 F S - 1 L L E D S T R O B E Sound Output - 89-110 dBA Flash rate - 60/minute Current - 40 mA plus sounder IP Rating – IP66 CB-1RIP66 WATERPROOF SOUNDER AND STROBE C O N V E N T I O N A L S O U N D E R S A N D S T R O B E S Sound Output @ 1m - 90 dBA Current - 7 mA B S - 1 R Red | B S - 1 W White B E D R O O M S O U N D E R Sound Output - 89-110 dBA Flash rate - 60/minute Current - 40 mA plus sounder IP Rating - IP45 CB-1R BANSHEE SOUNDER AND STROBE

60 C O N V E N T I O N A L F I R E A C C E S S O R I E S I F B - 1 I N T E R N A L F I R E B E L L Sound Output - 95 dBA Current - 11 mA 6” diameter IP Rating - IP21C W F B - 1 WEATHERPROOF FIRE BELL Sound Output - 95 dBA Current - 25 mA 8” diameter IP Rating - IP55 S D - D B D E T E C T O R D E E P B A S E Deepbase for PSD2, CSD2, PSD212 & CSD212 D B S 1 D E T E C T O R B A S E S O U N D E R Sound Output @ 1m - 93 dBA Current - 18 mA B A T 1 8 1 2 V 1 7 A H S L A B A T T E R Y Back up battery for MAG16 B A T 7 1 2 V 7 . 0 A H S L A B A T T E R Y Back up battery for MAG2P, MAG2, MAG4P and MAG4

61 2 4 V B O X E D P O W E R S U P P L I E S BPS-1 24V 1 amp Boxed power supplyBPS-2 24V 2 amp Boxed power supplyBPS-5 24V 5 amp Boxed power supplyNb Boxed power supplies require 2 x 12V batteries (not supplied) M A G R 8 Z O N E R E L A Y M O D U L E F O R M A G 8 1 6 Expander module providing 8 relay switches for zone activation Separate zone (max. 8) activation in fire condition N.O & N.C options D O O R H O L D E R S DR916-24 24V DC Door HolderDR916-240 240V AC Door Holder D R 9 1 6 - F M B F L O O R M O U N T I N G B R A C K E T For use with DR916-24 and DR916-240 M A G I S O R P F I R E S Y S T E M I S O L A T I O N S W I T C H Complies with BS5839 Part1 Isolates the mains voltage supply to the fire system Enables safety for maintenance and offers protection against tamper Both the live and neutral supply is switched D R 9 1 6 - K P S P A R E K E E P E R P L A T E For use with DR916-24 and DR916-240

E M E R G E N C Y L I G H T I N G 62

63 The new emergency lighting collection provides contractors and installers with a comprehensive, contemporary product range that has been independently tested to comply with the latest industry standards and regulations.

E M 8 W M B U L K 8 W T 5 I P 6 5 M A I N T A I N E D B U L K H E A D 64 E M E R G E N C Y L I G H T I N G 6000K colour temperature 8W T5 Fluorescent Lamp Polycarbonate housing Ceiling or wall mounted Charge and discharge protection Green LED Indicator 3 Hours Emergency Duration 2.4V 4500mAH NI-CAD Battery BS EN 60598-2-22 Standards Mains light output - 113 Lumens Emergency light output - 97 Lumens Dimensions - 352 x 118 x 73mm Weight - 1.1Kg Photometric spacing data 1 Lux (centre to centre in metres on emergency escape routes) Mounting Axial/ Axial/ Transverse/ Transverse/ Transverse/ Height Wall Axial Axial Transverse Wall 2.0m 1.9 4.7 5.3 5.9 2.32.5m 1.9 4.7 5.2 5.8 2.23.0m 1.7 4.9 5.1 5.3 2.0 Illuminance values based on a maintenance factor of 0.85 EMBULKLGD Emergency Legend EMBULKFLUSH Optional Flush Mounting Kit

65 E M L E D 3 W M B U L K 2 3 W L E D I P 6 5 M A I N T A I N E D B U L K H E A D E M L E D 3 W M E X B O X 3 W L E D M A I N T A I N E D S I G N 6000K colour temperature SMD 2835 LED Lamp Polycarbonate housing Ceiling or wall mounted Charge and discharge protection Green LED Indicator 3 Hours Emergency Duration Luminous Efficacy - 34 lm/w 3.6V 1500mAH NI-CAD Battery BS EN 60598-2-22 Standards Mains light output - 121 Lumens Emergency light output - 119 Lumens Dimensions - 345 x 110 x 60mm Weight - 0.6Kg 6500K colour temperature Viewing distance – 32m SMT 5050 LED Lamp Steel housing Wall mounted Charge and discharge protection Green LED Indicator 3 Hours Emergency Duration 3.6V 1800mAH NI-CAD Battery BS EN 60598-2-22 Standards Dimensions - 390 x 190 x 60mm Weight - 1.3Kg Photometric spacing data 1 Lux (centre to centre in metres on emergency escape routes) Mounting Axial/ Axial/ Transverse/ Transverse/ Transverse/ Height Wall Axial Axial Transverse Wall 2.0m 3.1 7.4 6.5 5.6 2.42.5m 3.3 8.3 7.3 6.3 2.63.0m 3.4 9.0 8.0 6.9 2.7 Illuminance values based on a maintenance factor of 0.85 EMBULKLGD Emergency Legend EMLED3WMEXBOXU3W LED Maintained Emergency Sign UP EMLED3WMEXBOXD3W LED Maintained Emergency Sign DOWN EMLED3WMEXBOXL3W LED Maintained Emergency Sign LEFT EMLED3WMEXBOXR3W LED Maintained Emergency Sign RIGHT

E M L E D 5 W M F L U S H 5 W L E D M A I N T A I N E D E M E R G E N C Y F L U S H 66 E M E R G E N C Y L I G H T I N G E M 2 W M E X S I G N L E D 2 W M A I N T A I N E D E X I T S I G N 6000K colour temperature Viewing distance – 24m SMD 3528 Lamp Polycarbonate frame with legend Ceiling or wall mounted Charge and discharge protection Green LED Indicator 3 Hours Emergency Duration 4.8V 600mAH Battery BS EN 60598-2-22 Standards Dimensions - 305 x 160 x 225mm Weight - 0.8Kg 6500K colour temperature LED Lamp Steel housing Recessed mounting Charge and discharge protection Green LED Indicator 3 Hours Emergency Duration Luminous Efficacy - 32.97 lm/w 3.6V 1500mAH NI-CAD Battery BS EN 60598-2-22 Standards Mains light output - 163 Lumens Emergency light output - 148 Lumens Dimensions - 410 x 145 x 90mm Weight - 1.5Kg EM2WMEXSIGNULED 2W Maintained Exit Sign Legend UP EM2WMEXSIGNDLED 2W Maintained Exit Sign Legend DOWN EM2WMEXSIGNLLED 2W Maintained Exit Sign Legend LEFT EM2WMEXSIGNRLED 2W Maintained Exit Sign Legend RIGHT Photometric spacing data 1 Lux (centre to centre in metres on emergency escape routes) Mounting Axial/ Axial/ Transverse/ Transverse/ Transverse/ Height Wall Axial Axial Transverse Wall 2.0m 2.3 5.5 5.5 5.5 2.3 2.5m 2.5 6.0 6.0 6.1 2.5 3.0m 2.7 6.5 6.5 6.6 2.7 Illuminance values based on a maintenance factor of 0.85

67 E M 3 W N M D L K 3 W L E D N O N M A I N T A I N E D D O W N L I G H T K I T E M 9 W N M S P O T 2 L E D I P 6 5 N O N M A I N T A I N E D E M E R G E N C Y T W I N S P O T 2 x 15 SMD 2835 LED Lamps Polycarbonate housing & heads Wall mounted Charge and discharge protection Green LED Indicator 3 Hours Emergency Duration 9.6V 2200mAH NI-CAD Battery BS EN 60598-2-22 Standards Emergency light output - 535 Lumens Dimensions - 305 x 306 x 70mm Weight - 1.85Kg Mounting Transverse to Transverse to Height Wall Transverse 2.5m 5.8 13.84.0m 7.2 17.46.0m 8.4 20.7 Calculated with lamp heads fixed at 30º below horizontal Photometric spacing data 1 Lux 3W LED Lamp Aluminium housing Recessed mounting Charge and discharge protection Green LED Indicator 3 Hours Emergency Duration Luminous Efficacy - 53.44 lm/w 4.8V 1800mAH NI-CAD Battery BS EN 60598-2-22 Standards Emergency light output - 138 Lumens Photometric spacing data 1 Lux (centre to centre in metres on emergency escape routes) Mounting Axial/ Axial/ Transverse/ Transverse/ Transverse/ Height Wall Axial Axial Transverse Wall 2.0m 2.9 7.2 7.1 7.2 2.8 2.5m 3.1 7.7 7.6 7.7 2.9 3.0m 3.1 8.1 8.0 8.0 3.0 Illuminance values based on a maintenance factor of 0.85 Cut out – 35mm

E&OE - Errors and omissions excepted. ESPCAT01/17 Elite Security Products Unit 7, Target Park, Shawbank Road, Lakeside, Redditch B98 8YN Tel: +44 (0) 1527 51 51 50 Fax: +44 (0) 1527 51 51 43 www.espuk.com • [email protected] Elite Security Products Ireland 18 Corrig Road, Sandyford Ind. Estate, Dublin D18 WV79, Ireland Tel: +353 (1) 281 11 22 Fax: +353 (1) 281 12 24 www.espuk.com • [email protected] Held in the new purpose built showroom at our Redditch offices the training days are aimed at electrical contractors and wholesalers who would like to add fire and security equipment to their product portfolio but feel they do not have the core knowledge to do this with confidence. Most aspects of security will be covered including CCTV, Access Control and External Area Protection with a separate training day dedicated entirely to Fire Protection products. P R O D U C T A W A R E N E S S T R A I N I N G D A Y S

Published: 12 January 2017 Category: Product Catalogues & Brochures
